BCZ3200DL
BCZ3200DW
OWNER'S MANUAL
BRUSHCUTTERS
BCZ3200DL / BCZ3200DW
848JCG93A1 (704)
GB-1
G
G
B
B

Advertisement

Table of Contents
loading

Related Manuals for Zenoah BCZ3200DL

Summary of Contents for Zenoah BCZ3200DL

  • Page 1 BCZ3200DL BCZ3200DW BCZ3200DL / BCZ3200DW 848JCG93A1 (704) OWNER’S MANUAL BRUSHCUTTERS GB-1...
  • Page 2 BCZ3200DL / BCZ3200DW EXPLANATION OF SYMBOLS AND SAFETY WARNINGS BCZ3200DL BCZ3200DW MODEL BCZ3200DL 29.5 cm BCZ3200DW 29.5 cm APPROVAL NUMBER OF CE EXHAUST EMISSION REGULATION GB-2 DIRECTIVE 89/336/EEC, 98/37/EC BCZ3200DL BCZ3200DW 41200101 and up 1st April 2007 WARNING!!! RISK OF DAMAGING HEARING Wear head, eye and ear protection.

  • Page 3: Table Of Contents

    5. For safe operation ... 5 6. Set up ... 8 7. Fuel ... 9 8. Operation ... 10 9. Maintenance ... 13 10. Storage ... 15 11. Disposal ... 15 12. Troubleshooting guide ... 16 BCZ3200DL BCZ3200DL / BCZ3200DW BCZ3200DW GB-3...

  • Page 4: Specifications

    According to these indications, please be careful not to make a mistake. GB-4 (when using ZENOAH genuine oil) Never modify your machine. We won’t warrant the machine, if you use the remodeled brushcutter or if you don’t observe the proper usage written in the manual.

  • Page 5: For Safe Operation

    2. Never use the product, a. when the ground is slippery or when you can’t maintain a steady posture. BCZ3200DL / BCZ3200DW b. At night, at times of heavy fog, or at any other times when your field of vision might be...
  • Page 6 BCZ3200DL / BCZ3200DW 5. For safe operation BEFORE STARTING THE ENGINE 1. The area within a perimeter of 15 m (50 ft) of the person using the product should be considered a hazardous area into which no one should enter. If necessary,...
  • Page 7 BCZ3200DL / BCZ3200DW HANDLING FUEL 1. The engine of the ZENOAH prod- uct is designed to run on a mixed fuel, which contains highly flam- mable gasoline. Never store cans...

  • Page 8: Set Up

    2. Put the handle assembly into the bracket and put the upper cap over it. Tighten the cap securely. CONNECTING THROTTLE WIRE (BCZ3200DL/DW) 1. Remove the air cleaner cover. 2. Connect the end of the throttle wire to the joint on the top of the carburetor.

  • Page 9: Fuel

    • The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added quality oil expressly labeled for air-cooled 2-cycle engine use (JASO FC GRADE OIL or ISO EGC GRADE).

  • Page 10: Operation

    4. Move the choke lever to the closed position. [BCZ3200DL] [BCZ3200DW] (3) Stop switch 5. [BCZ3200DL] Set the stop switch to the “I” posi- tion. Set the throttle trigger to the start position (1 → 2 → 3). Place the unit on a flat, firm place.

  • Page 11: Blade

    • Replace by a suitable recommended cutting attach- ment according to the object to be cut. • When replacing blade always be sure to use products which have been certified by ZENOAH. WARNING • When sharpening, removing, or reattaching the blade, be sure to wear thick, sturdy gloves and use only proper tools and equipment to prevent injury.
  • Page 12 BCZ3200DL / BCZ3200DW 8. Operation CUTTING METHOD (a) Use the front left side cutting. (b) Guide the blade from your right to left with it tilted slightly to your left. (c) When mowing a wide area, start working from your left end to avoid interference of cut grass.

  • Page 13: Angle Transmission

    3. Do not use water when using a grinder. • It is recommended that filing should be done by pro- fessionals. • Especially regarding filing the saw blade, Leave it to the professionals. BCZ3200DL / BCZ3200DW Note after after replace, if necessary...
  • Page 14 BCZ3200DL / BCZ3200DW 9. Maintenance REFILLING TRIMMING LINE 1. For replacement line, use a diameter of 2.4mm(.095in). The spool is capable for a line upto 6m(20ft) on the 10cm(4”) head. Avoid using a larger line as it may cut down the trimming performance.

  • Page 15: Storage

    Store the unit indoor taking necessary measures for rust prevention. 11. Disposal When disposing your machine, fuel or oil for the machine, be sure to allow your local regulations. BCZ3200DL / BCZ3200DW GB-15...

  • Page 16: Troubleshooting Guide

    (exhaust port) → carbon is built-up air cleaner cylinder fin, fan cover When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
