Summary of Contents for Zenoah BCZ2602DL
- Page 1 BCZ2602DL 848JA193A3 (708) OWNER’S MANUAL BRUSHCUTTERS BCZ2602DL GB-1...
- Page 2 BCZ2602DL ZENOAH CO., LTD. 1st April 2007 Masahiko GOUDA EXPLANATION OF SYMBOLS AND SAFETY WARNINGS WARNING!!! RISK OF DAMAGING HEARING Wear head, eye and ear protection. SOUND LEVEL VIBRATION LEVEL MODEL EN27917 ISO 7916 ISO 10884 idling racing measured guaranteed 86 dB(A) 106.47 dB(A)
-
Page 3: Table Of Contents
4. Symbols on the machine ... 4 5. For safe operation ... 5 6. Set up ... 8 7. Fuel ... 9 8. Operation ... 10 9. Maintenance ... 14 10. Storage ... 15 11. Disposal ... 15 12. Troubleshooting guide ... 16 BCZ2602DL GB-3... -
Page 4: Specifications
GB-4 (when using ZENOAH genuine oil) 4. Symbols on the machine For safe operation and maintenance, symbols are carved in relief on the machine. According to these indications, please be careful not to make a mistake. -
Page 5: For Safe Operation
2. Never use the product, a. when the ground is slippery or when you can’t maintain a steady posture. BCZ2602DL b. At night, at times of heavy fog, or at any other times when your field of vision might be... - Page 6 If it continues to rotate even after the throttle has been moved fully back, turn off the engine and take the unit to your authorized ZENOAH servic- ing dealer for repair. USING THE PRODUCT IMPORTANT Cut only materials recommended by the manufacturer.
- Page 7 BCZ2602DL HANDLING FUEL 1. The engine of the ZENOAH prod- uct is designed to run on a mixed fuel, which contains highly flam- mable gasoline. Never store cans of fuel or refill the tank of the unit...
-
Page 8: Set Up
6. Set up INSTALLING HANDLE • Mount the handle to the shaft tube and clamp it at a location that is comfortable to you. INSTALLING DEBRIS GUARD FOR LINE HEAD ･ Attach the debris guard (RED) with the bolts provided. INSTALLING LINE HEAD 1. -
Page 9: Fuel
• The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added quality oil expressly labeled for air-cooled 2-cycle engine use (JASO FC GRADE OIL or ISO EGC GRADE). -
Page 10: Operation
8. Operation STARTING ENGINE WARNING The cutting head will start rotating upon the engine starts. 1. Feed fuel into the fuel tank and tighten the cap se- curely. 2. Rest the unit on a flat, firm place. Keep the cutting head off the ground and clear of surrounding objects, as it will start rotating upon starting of the engine. - Page 11 • Replace by a suitable recommended cutting attach- ment according to the object to be cut. • When replacing blade always be sure to use products which have been certified by ZENOAH. WARNING • When sharpening, removing, or reattaching the blade, be sure to wear thick, sturdy gloves and use only proper tools and equipment to prevent injury.
- Page 12 8. Operation CUTTING METHOD (a) Use the front left side cutting. (b) Guide the blade from your right to left with it tilted slightly to your left. (c) When mowing a wide area, start working from your left end to avoid interference of cut grass. (d) The blade may be seized by weeds if the engine speed is too low, or the blade cuts too deep into weeds.
- Page 13 • Each time the head is bumped, the line advances about 25 mm. For better effect, tap the head on bear ground or hard soil. Avoid bumping in thick, tall grass as the engine may stall by overload. BCZ2602DL GB-13...
-
Page 14: Maintenance
• Starting failure and misfiring are often caused by a fouled spark plug. Clean the spark plug and check that the plug gap is in the correct range. For a re- placement plug, use the correct type specified by ZENOAH. • REPLACEMENT PLUG IS A NGK CMR7A. Note after... -
Page 15: Storage
Store the unit indoor taking necessary measures for rust prevention. 11. Disposal When disposing your machine, fuel or oil for the machine, be sure to allow your local regulations. BCZ2602DL GB-15... -
Page 16: Troubleshooting Guide
(exhaust port) → carbon is built-up air cleaner cylinder fin, fan cover When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
