WASHING MACHINE ZWF 1651W JETSYSTEM TIMELINE Quick Installation Guide: visit our WEB SITE to view an install video www.video.uk.electrolux.com INSTRUCTION BOOKLET 132985250... -
Page 2: Important Safety Information
Important Safety Information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings. -
Page 3: Table Of Contents
Contents For the User Important Safety Information Your New Washing Machine Description of the Appliance Detergent dispenser drawer Child safety feature The Control Panel Programme information Operating Sequence Washing 6 kg of white cotton at 90°C Load the laundry Measure out the detergent and the fabric softener Switch the machine on Switching the machine on for the first time Select the desired programme/fabric... -
Page 4: Your New Washing Machine
Your New Washing Machine Your new washing machine, which is fitted with the New Jet System, meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. ● The special Handwash and Silk programme with their new delicate wash system treats your delicate items with extreme care. -
Page 5: Description Of The Appliance
Description of the Appliance 01 Detergent dispenser drawer 02 Control panel 03 Door opening handle 04 Drain pump 05 Adjustable feet Detergent dispenser drawer Prewash Main wash Fabric softener Child safety feature This machine incorporates a special child safety feature to prevent small children from being trapped inside the machine. -
Page 6: The Control Panel
The Control Panel JETSYSTEM TI M EL I NE 1 Detergent dispenser drawer 2 Programme selector dial The selector dial is divided into the following sections: • Cottons (blue colour , Synthetics (green colour Delicates (gray colour • Handwash, Wool, Silk and Minipr. 30 (gray colour •... - Page 7 By depressing Temperature Temp. button, the relevant message will appear on the second row of the display (instead of «cycle end at»). In the corner of the third row appears the indication of the selected temperature. 5 Spin speed button “Spin” Press this button repeatedly to change the spin speed, if you want your laundry to be spun at a speed different from the one proposed by the washing machine.
- Page 8 Exit button allows you to return to the previous selection. Depending on the programme, different functions can be combined. These must be selected after choosing the desired programme and before depressing the Start/Pause button. By depressing the Options button, all the symbol icons, allowed for the selected programme will appear in the display.
- Page 9 cycle temperature and the fabric type. EASY IRON: selecting this button the laundry is gently washed and spun to avoid any creasing. In this way ironing is easier. Furthermore the machine will perform 6 rinses instead of 3 for cotton and 4 rinses instead of 3 for synthetics.
- Page 10 SOUND The sound setting permits you to modify the function. You can choose between different levels: low, no sound and normal. Example: 1. Enter the Menu option and select the sound setting. 2. Use the Change button to select the desired level. RINSE + The washing machine is set such that its water consumption is extremely economical.
- Page 11 CONTRAST The Contrast setting allows you to modify the optical characteristic of the display. Example: 1. Enter the Menu option and select the Contrast setting. 2. Use the Change button to set up the desired contrast level. BRIGHTNESS The Brightness setting allows you to modify the backlight intensity of the display.
-
Page 12: Programme Information
PROGRAMME INFORMATION Wool Washing programme for machine washable wool well as for hand washable woollens and delicate fabrics with the “hand washing” care symbol. Rinse With this programme it is possible to rinse and spin garments which have been washed by hand. The machine performs 3 rinses, followed by a final spin at maximum speed. -
Page 13: Operating Sequence
Operating Sequence Before the first wash, we recommend that you run a cotton cycle at 90°C, without any laundry in the machine, to remove any manufacturing residue from the drum and tub. Pour 1/2 a measure of detergent into the dispenser drawer and start the machine. -
Page 14: Select The Desired Programme/Fabric
2.Press the Exit button to confirm the selection. All indicators in the display will appear in this language from now on. Note: If the undesired language has been set, press simultaneously Spin + Options buttons for about 3 seconds in order to change the language. Follow the instructions as before. -
Page 15: Select The Delay Time
9. Select the DELAY TIME Before you start the programme, if you wish the starting to be delayed, choose the DELAY option. The selected delay time value (up to 20 hours) will appear on the display while selecting. The end cycle will be updated and shown on the relative position of the display. -
Page 16: End Of Programme
14. End of programme At the end of the programme, the washing machine stops automatically, gives an audible signal (if option no sound has not been selected), and displays the relevant message. If you had selected the option, the Start/Pause button light is off and the “Cycle ended/ Door locked”... -
Page 17: Washing Hints
Washing Hints Do NOT overload the machine. Weigh the laundry the first few times you use the appliance. The average weights of the most common items are listed below as a guide: 1000g = 1 kg Sheet Pillow case Tablecloth Serviette Tea towel Linen hand towel... -
Page 18: Which Detergent
Which detergent?... To ensure you obtain the best wash results from your appliance, it is important to use the right detergent in your everyday wash, and only detergents recommended for use in automatic machines. To maintain the appearance of your clothes and household textiles and to make them last longer you should use different types of detergent for different washes, whether for whites, colours or delicates. -
Page 19: Wash Care Symbols
Wash Care Symbols Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine. -
Page 20: Washing Programmes
Washing Programmes Wash programme/ Type of laundry Washing symbol White and coloured Cottons cotton: e.g. sheets, tablecloths, household linen White and coloured cotton Economy: e.g. shirts, Cottons blouses, underwear, towels, Economy house-hold linen Synthetic fabrics: e.g. Synthetics shirts, blouses, underwear Delicate fabrics: e.g. -
Page 21: Washing Programmes
Washing Programmes Special programmes Programme dial Wash programme position Separate rinse cycle for Rinse hand washed items of cotton fabric For emptying out the water of the last rinses Drain of programmes with option Cycle Separate spin for Spin cottons Special short programme Delicate for lightly soiled synthetic... -
Page 22: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine. -
Page 23: Cleaning The Water Inlet Filter
cover and remove it. Always keep a rag nearby to dry up spillage of water when removing the cover. Remove any objects from the pump impeller by • rotating it. • Put the cap back on the emergency emptying hose and place the latter back in its seat. -
Page 24: Something Not Working
Something Not Working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Force Centre, please carry out the checks listed below. During machine operation it is possible that one of the following messages appear on the display and at the same time an acoustic signal will sound: •... -
Page 25: Service And Spare Parts
For the address of your local Service Force Centre and further information about Service Force, please visit the website at www.serviceforce.co.uk. For Customer Service in Ireland please contact us at the address below: Zanussi Electrolux Electrolux Group (Irl) Ltd Long Mile Road Dublin 12 Republic of Ireland Tel: +353 (0)1 4090751 Email: service.eid@electrolux.ie... -
Page 26: Guarantee Conditions
Guarantee Conditions Standard guarantee conditions We, Zanussi Electrolux, undertake that if, within 12 months of the date of the purchase, this ZANUSSI ELECTROLUX appliance or any part thereof is proved to be defective by reason only of faulty workmanship or... -
Page 27: Installation Instructions
Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. -
Page 28: Unpacking
Unpacking All transit bolts and packing must be removed before using the appliance. You are advised to keep all the packaging for re-use in case the machine is to be transported again. Using a spanner unscrew and remove the two rear bottom screws. -
Page 29: Water Inlet
Installation on a Suspended Floor Suspended wooden floors are particularly susceptible to vibration. To help prevent vibration we recommend you place a waterproof wood panel, at least 15 mm thick under the appliance, secured to at least 2 floor beams with screws. -
Page 30: Levelling
If your drain hose looks like this (see below) you do not require the “U” piece”. Just push the hose firmly into the standpipe. 2. Onto a sink outlet spigot. If the outlet spigot has not been used before, remove any blanking plug that may be in place. -
Page 31: Electrical Connection
If you require any further advice please contact your local water authority. Electrical connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. WARNING: THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this safety measure not be observed. - Page 32 From the Electrolux Group. The world’s No. 1 choice The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
