- Page 1 O W N E R ’ S M A N U A L...
-
Page 2: Important Safety Instructions
(i.e., insurance claims, tech support, return authorization, make dad proud, etc.) Like us Purchased at: Follow us Watch our dang videos Date of purchase: Part No. SW1191 Rev. A 12/16 ©2016 LOUD Technologies Inc. All Rights Reserved. Big Knob Passive Monitor Controller... -
Page 3: Table Of Contents
The passive audio path ensures pristine sonic integrity INTRODUCTION ................3 is maintained throughout your signal chain. More than just a level control solution, Big Knob Passive features QUICK START ...................3 the ability to choose between two sources and two HOOKUP DIAGRAM .................4 monitor pairs. -
Page 4: Hookup Diagram
Hookup Diagram Big Knob Passive is the perfect monitoring tool as a level control for a home / project studio or integrated as part of a larger studio. There are many great things about the Big Knob Passive, but one of the features is no need for power...it can be placed anywhere to your heart’s content! After you’ve decided on a spot, it’s time to make connections. -
Page 5: Rear Panel Description
MP3 player, or other signal The rear panel is where to connect various sources source. feeding IN to the Big Knob Passive. These signals are then routed through the Big Knob Passive and released The Source Input B 1/4" and 1/8" line- through the monitor OUT jacks. -
Page 6: Front Panel Description
The left and right input signals are summed and the mono signal is output at both the left and right outputs. This allows you to check for phase problems in the stereo signal when played over a monophonic system. Big Knob Passive Monitor Controller... -
Page 7: Appendix A: Service Info
Appendix A: Service Information Noise/Hum/Buzz If you think your Big Knob Passive has a problem, • Check the signal cable between the source(s) and the please check out the following troubleshooting tips and Big Knob Passive. Make sure all connections are secure. -
Page 8: Appendix B: Technical Information
<–100 dB Disclaimer LOUD Technologies is always striving to improve our products by incorporating new and improved materials, components and manufacturing methods. Therefore, we reserve the right to change these specifications at any time without notice. Big Knob Passive Monitor Controller... -
Page 9: Big Knob Passive Dimensions
Big Knob Passive Dimensions 5.4" / 137 mm 5.6" / 142 mm 3.1" / 79 mm WEIGHT 2.2 lb / 1.0 kg WEIG 2.2 lb 1.0 k 3.1" / 79 mm Owner’s Manual... -
Page 10: Big Knob Passive Block Diagram
Big Knob Passive Block Diagram Big Knob Passive Monitor Controller... -
Page 11: Big Knob Passive Limited Warranty
