Thank you very much for purchasing
Panasonic Washing Machine.
TWIN-TUB ELECTRIC WASHING MACHINE (household use)
NA-W1350T
NA-W1250N
OPERATING INSTRUCTIONS
Please read these instructions and the warranty carefully
before use. Thereafter, keep them in a safe place and refer
to them as necessary.
CONTENTS
SAFETY PRECAUTIONS ................................................ 2
NAMES OF PARTS ......................................................... 4
HOW TO USE THE OPERATION PANELS .................... 5
HOW TO INSTALL .......................................................... 7
HOW TO WASH .............................................................. 9
HOW TO SOAK ............................................................. 16
HOW TO SPIN ............................................................... 17
CARE AND MAINTENANCE ......................................... 19
TROUBLESHOOTING .................................................. 20
REQUESTS AND THINGS TO ABIDE BY ..................... 22
Advertisement
Table of Contents
Related Manuals for Panasonic NA-W1350T
Summary of Contents for Panasonic NA-W1350T
-
Page 1: Table Of Contents
Thank you very much for purchasing Panasonic Washing Machine. TWIN-TUB ELECTRIC WASHING MACHINE (household use) NA-W1350T NA-W1250N OPERATING INSTRUCTIONS CONTENTS SAFETY PRECAUTIONS ..........2 NAMES OF PARTS ............4 HOW TO USE THE OPERATION PANELS ....5 HOW TO INSTALL ............7 HOW TO WASH .............. -
Page 4: Names Of Parts
NAMES OF PARTS 1. Control Panel of Washing Tub, Spinner Tub. 2. Inlet Hose Connector 3. Water Supply Selector 4. Wash Tub Lid 5. Wash Tub 6. Lint Filter 7. Pulsator 8. Drain Hose 9. Spinner Lid 10. Inner Lid 11. -
Page 5: How To Use The Operation Panels
HOW TO USE THE OPERATION PANELS WASH TIMER: Use this timer to set washing/rinsing time up to 15 minutes SOAK FUNCTION: Soak/Wash mode timing at 15-45 minutes Stop Work Stop Work Stop Work (7 min.) (2 min. Soak) (7 min.) (2 min. - Page 6 HOW TO USE THE OPERATION PANELS SOAK IF WATER DROPS HERE ADJUST WATER TAP Water Supply Selector When the water spills out of the hole under the label, it means too - WASH TUB (LEFT) much water has supplied. Close the water tap and adjust the level. - SPIN TUB (RIGHT) WATER INLET This selector is to turn to your desired length of time for spin-dry...
-
Page 7: How To Install
HOW TO INSTALL Installing this Washer should be settled in a Insert the power plug firmly into well-ventilated, safe place and where can the power outlet. connect the drain hose and the power supply. It is recommended to place the washer on a level floor and avoid a place where the washer can be exposed to direct sunlight. - Page 8 HOW TO INSTALL Fixation of Drain Hose Drain Hose connector Connect the included drain hose to the drain hose connector on the side of the washing machine. Drain Hose Fix the drain hose and drain hose connector on the side of the washing machine by using of Hose band.
-
Page 9: How To Wash
HOW TO WASH 1. Set the Cycle Selector to “WASH” 2. Fill the tub with water up to half of the water level line. 3. Put the clothes in the tub. Do not put an excessive amount of laundry, which specified in table 1 and 2, in the tub. (See attached table 3 and 4 for NA-W1250N) 4. - Page 10 CAUTION When using “Pre Wash” Detergent Please use “Pre Wash” Detergent inside the Washing Machine as shown in Figure 1 & not outside of the Washing Machine as shown in Figure 2. Using some type of “Pre Wash” Detergent outside the Washing Machine sometimes may cause damage on the plastic part.
- Page 11 HOW TO WASH Table 1: The amount of laundry (For NA-W1350T Only) NA-W1350T NA-W1350T 82 10 90 13...
- Page 12 HOW TO WASH Table 2: The amount of the laundry and setting control panel (For NA-W1350T Only) NA-W1350T NA-W1350T Clothes Amount of laundry Synthetic fiber Cotton Heavy Stained Clothes System Washing time 2 minutes 2-5 minutes 7-10 minutes Less than 1.2 g...
- Page 13 HOW TO WASH Table 3: The amount of laundry (For NA-W1250N Only) NA-W1250N NA-W1250N 82 10 88 12...
- Page 14 HOW TO WASH Table 4: The amount of the laundry and setting control panel (For NA-W1250N Only) NA-W1250N NA-W1250N Clothes Amount of laundry Synthetic fiber Cotton Heavy Stained Clothes System Washing time 2 minutes 2-5 minutes 7-10 minutes Less than 1.2 g Wash Selector GENTLE REGULAR...
- Page 15 HOW TO WASH Table 5: The amount of water & detergent (For NA-W1350T Only) NA-W1350T NA-W1350T Water Level Detergent Quantity High (90 Liter) Detergent Quantity used Medium (82 Liter) according to the amount Low (74 Liter) specified on the Minimum (61 Liter) detergent package.
-
Page 16: How To Soak
HOW TO SOAK How the Soak Function operates SOAK FUNCTION Soak Function enhances the efficiency of the regular function, which helps to wash the clothes cleaner. Soak function will be operated after the WASH TIMER switch is set to 45 min. position, then the washer will operate with soak function. Soak function will run and stop alternately for 3 times until the 15th minute then the operation will reverse to regular function. -
Page 17: How To Spin
HOW TO SPIN Spinning • Put the laundry into the spinner tub by putting the small-sized laundry in the bottom area to keep the balance of the tub. • Place the SPINNER CAP in the tub as shown in the below figures. •... - Page 18 HOW TO SPIN Table 7: Setting time for Spinning upon laundry Capacity : 9.0 Type of Laundry Spinning time Working clothes 5 min. Delicate clothes 1 min. (Thin synthetic fiber, waving cloth) Sweater (Synthetic fiber) 1-2 min. Underwear (Knitting clothes) 3-5 min.
-
Page 19: Care And Maintenance
CARE AND MAINTENANCE Be sure to remove the power plug from the power outlet before cleaning the machine and filter. How to clean the Lint Filter Pull out the lint filter from the lock. By using fingers to press and pull out at the upper part of the lint filter's side. -
Page 20: Troubleshooting
TROUBLESHOOTING If any abnormality is found, check the following before calling for service: 1. Is the power plug inserted firmly or power cord disconnected? 2. Is the fuse blown? 3. Is the timing switch turned to “OFF” position? 4. Is the spinner lid closed properly? 5. -
Page 22: Requests And Things To Abide By
REQUESTS AND THINGS TO ABIDE BY If the spinner tub does not stop after 15 seconds from the Do not use sprays on the cover or on the machine parts. time you lifted the cover, immediately stop use of the Bug poison, hair spray, air freshener, etc. - Page 23 MEMO...
- Page 24 W9901-0FR40 T0804-4074...
