ADTRAN NETVANTA 2000 Series System Manual
Hide thumbs Also See for NETVANTA 2000 Series:

Advertisement

Quick Links

61200361L1-1E
May 2002
NETVANTA 2000 SERIES
System Manual
1200362L1
NetVanta 2050 System
1200361L1
NetVanta 2100 System
1200366L1
NetVanta 2300 System
1200367L1
NetVanta 2400 System

Advertisement

Table of Contents
loading

Summary of Contents for ADTRAN NETVANTA 2000 Series

  • Page 1 NETVANTA 2000 SERIES System Manual 1200362L1 NetVanta 2050 System 1200361L1 NetVanta 2100 System 1200366L1 NetVanta 2300 System 1200367L1 NetVanta 2400 System 61200361L1-1E May 2002...
  • Page 2 To the Holder of the Manual The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change the contents without prior notice. In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
  • Page 3 About this Manual This manual provides a complete description of the NetVanta 2000 series system and system software. The purpose of this manual is to provide the technician, system administrator, and manager with general and specific information related to the planning, installation, operation, and maintenance of the NetVanta 2000 series.
  • Page 4 4. Use only the power cord, power supply, and/or batteries indicated in the manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for special disposal instructions. Save These Important Safety Instructions NetVanta 2000 Series System Manual © 2001 ADTRAN, Inc.
  • Page 5 Cet appareil numérique respecte les limites de bruits radioelectriques applicables aux appareils numériques de Class A prescrites dans la norme sur le materiel brouilleur: “Appareils Numériques,” NMB-003 edictee par le ministre des Communications. © 2001 ADTRAN, Inc. NetVanta 2000 Series System Manual...
  • Page 6 The termination on a loop may consist of any combination of devices subject only to the requirement that the total of the Load Numbers of all devices does not exceed 100. NetVanta 2000 Series System Manual © 2001 ADTRAN, Inc.
  • Page 7 Warranty and Customer Service ADTRAN will repair and return this product within five years from the date of shipment if it does not meet its published specifications or fails while in service. For detailed warranty, repair, and return information refer to the ADTRAN Equipment Warranty and Repair and Return Policy Procedure.
  • Page 8 Customer Service, Product Support Information, and Training ADTRAN will repair and return this product if within five years from the date of shipment the product does not meet its published specification or the product fails while in service. A return material authorization (RMA) is required prior to returning equipment to ADTRAN. For service, RMA requests, training, or more information, use the contact information given below.
  • Page 9 Your reseller should serve as the first point of contact for support. If additional support is needed, the ADTRAN Support web site provides a variety of support services such as a searchable knowledge base, updated firmware releases, latest product documentation, service request ticket generation and trouble-shooting tools.
  • Page 10 NetVanta 2000 Series System Manual © 2001 ADTRAN, Inc.
  • Page 11 Routing ..............14 61200361L1-1E © 2002 ADTRAN, Inc.
  • Page 12 IP spoofing, ICMP redirect, land attacks, ping-of-death, and IP reassembly problems. For encryption, the NetVanta 2000 series encrypt the data being sent out onto the network, using either the Data Encryption Standard (DES) or 3DES encryption algorithms. Data integrity is ensured using MD5 or SHA1 as it is transported across the public infrastructure.
  • Page 13 Section 1, System Description FEATURES AND BENEFITS The NetVanta 2000 series provide granular control over network access that includes maximum security, data authenticity and privacy, and significant ease of use. The major features of the NetVanta 2000 series are described below. Physical Interfaces •...
  • Page 14 Section 1, System Description NetVanta 2000 Series System Manual DHCP • Server (to manage IP addresses on local network) • Client (to acquire the WAN-side IP address from service provider) PPPoE • Client (to acquire the WAN-side IP address from service provider) Routing •...
  • Page 15: Table Of Contents

    Table 1. NetVanta 2000 series Front Panel Description ....... . 17 Table 2.
  • Page 16: Equipment Dimensions

    The NetVanta 2300 units are17.25" W, 7.75" D, and 1.26" H and come equipped for rackmount use. POWER REQUIREMENTS NetVanta 2050 and 2100 The NetVanta 2000 series has a maximum power consumption of 9W and a maximum current draw of 800mA. NetVanta 2300 and 2400 The NetVanta 2300 has a maximum power consumption of 11W and a maximum current draw of 0.2A.
  • Page 17 NetVanta 2000 Series System Manual Section 2, Engineering Guidelines NetVanta 2100 The NetVanta 2100 front panel monitors operation by providing status LEDs for both the LAN and WAN interfaces, as well as VPN tunnels and traffic. The front panel is shown in Figure 2.
  • Page 18: Front Panel Leds

    NetVanta 2000 Series System Manual Front Panel LEDs With the NetVanta 2000 series powered-up, the front panel LEDs provide visual information about the status of the system. Table 1 provides a brief description of the front panel features, and Table 2 provides detailed information about the LEDs.
  • Page 19: Reviewing The Rear Panel Design

    NetVanta 2000 Series System Manual Section 2, Engineering Guidelines Table 2. NetVanta 2000 series LEDs (Continued) For these LEDs... This color light... Indicates that... VPN TD Green (blink) Flashes with VPN data transmitted by the NetVanta 2000 series. VPN RD...
  • Page 20: Lan Interface

    Figure 7. NetVanta 2400 Rear Panel Layout LAN Interface The NetVanta 2000 series provides a standard 10/100BaseT Ethernet interface for connection to the local corporate network. Connect the LAN interface to a hub located on your local corporate network. A DHCP Server is enabled on the LAN interface by default.
