- Page 1 FREE STANDING ELECTRIC COOKER WITH GAS HOB ZCM 1000X INSTRUCTION BOOKLET...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using the appliance. Your safety is of paramount importance. If you are unsure about any of the information in this book contact the Customer Care Department. -
Page 3: Table Of Contents
CONTENTS FOR THE USER Important Safety Information Description of the Appliance Rating Plates Before Using the Appliance Location The Gas Hob Uses of the Hob To Light the Hob Burners Things to Note Hints & Tips The Timber Surround Accessories – Chopping board Helpful Hints When Buying and Preparing Food Care and Cleaning Cleaning Materials... -
Page 4: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE SLOT IN ELECTRIC COOKER WITH GAS HOB The appliance contains a multifunction oven which comprises a number of different cooking functions and a full width grill. The gas hob with five burners is fitted with automatic ignition. RATING PLATES The Hob: This is situated on the underside of the right hand side of the hob, above the towel rail. -
Page 5: Before Using The Appliance
BEFORE USING THE APPLIANCE IMPORTANT Please read both accompanying ZBM 799 Instruction Book before installing or using this appliance and retain for future reference. Should the appliance be sold or transferred, always ensure that the book is left with the appliance in order that the new owners can get to know the functions of the new appliance and the relevant warnings. -
Page 6: The Gas Hob
THE GAS HOB USES OF THE HOB The gas hob has four different burner sizes to suit different types of cooking: To ensure maximum burner efficiency only use pots and pans with flat bases appropriate to the burner size used. Burner Minimum Pan Size... -
Page 7: Things To Note
THINGS TO NOTE · If you are having any difficulty lighting a hob burner turn all the hob controls off and make sure the burner parts have been replaced correctly. See page 11 for more information. HINTS AND TIPS · Keep flames under the base of pans. -
Page 8: Helpful Hints When Buying And Preparing Food
HELPFUL HINTS WHEN BUYING AND PREPARING FOOD Care must be taken when handling foods in the home. Always follow the basic rules of food hygiene to prevent bacterial and microbial growth and cross contamination when preparing, reheating, cooking, cooling, defrosting and freezing foods. 1. -
Page 9: Care And Cleaning
CARE AND CLEANING For hygiene and safety reasons you must keep this cooker clean. A build up of fat or other foodstuff could cause a fire. Before cleaning the cooker always ensure the cooker is cool before switching off the supply. -
Page 10: Cleaning The Hob Burner Parts And Pan Support
CLEANING THE HOB BURNER PARTS AND PAN SUPPORT Take care not to damage the spark electrodes. If damaged they will not light. Please note that due to the nature of stainless steel the pan support will tarnish through use over a period of time. -
Page 11: Replacing The Pan Support
REPLACING THE HOB BURNER PARTS 1. Crown to burner body Do not force the crown on to the burner body. Make sure the hole in the crown is over the electrode. Check that the location pegs sit in the slots in the body. Check that the crown can be moved slightly from side to side. -
Page 12: Something Not Working
SOMETHING NOT WORKING? Please carry out the following checks on your appliance before calling a Service Engineer. It may be that the problem is a simple one which you can solve yourself without the expense of a service call. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the appliance is under guarantee. -
Page 13: Service And Spare Parts
Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. CUSTOMER CARE DEPARTMENT For general enquires concerning your Zanussi appliance, or for further information on Zanussi products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.zanussi.co.uk... -
Page 14: Guarantee Conditions
STANDARD GUARANTEE CONDITIONS We, Zanussi, undertake that if within 12 months of the date of the purchase this Zanussi appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ·... -
Page 15: Technical Details
TECHNICAL DETAILS TECHNICAL DETAILS Loading info : Gas hotplate L.H.F. – Simmer - Injector marking L.H.R. / R.H.R. – Normal- Injector marking R.H.F. – Rapid - Injector marking Centre. – Ultra Rapid - Injector marking Physical Characteristics – Height: 940 mm Width: 1050 mm Depth:... -
Page 16: Warnings
INSTALLATION INSTRUCTIONS For Instructions relating to the oven please refer to the ZBM 799 Instruction Book WARNINGS · This appliance must be installed by a qualified electrician/competent person (CORGI Registered). Safety may be impaired if installation is not carried out in accordance with these instructions. ·... -
Page 17: Moving The Appliance
INSTALLATION INSTRUCTIONS MOVING THE APPLIANCE You may damage some soft or badly fitted floor coverings when you move the appliance. The floor coverings under the appliance should be securely fixed so it does not ruck up when you move the appliance across it. -
Page 18: Location Of Appliance
INSTALLATION INSTRUCTIONS LOCATION OF APPLIANCE This appliance is not for commercial use and must only be installed in domestic premises. This appliance must not be installed in a bed-sitting room of volume less than 20m or in a bathroom, shower or garage. -
Page 19: Connecting To The Electricity Supply
INSTALLATION INSTRUCTIONS CONNECTING TO THE ELECTRICITY SUPPLY WARNING: THIS APPLIANCE MUST BE EARTHED. DO NOT EARTH THIS APPLIANCE TO THE GAS SUPPLY PIPING. This appliance must be connected to 230V-240V A.C. 50Hz supply. It is supplied with 2 metres of 5 amp 3 core cable incorporating a moulded 13 amp plug, fitted with a 3 amp fuse, which can be plugged directly into the nearest suitable socket. -
Page 20: Connecting To Gas
INSTALLATION INSTRUCTIONS CONNECTING TO GAS This appliance is designed to be installed with an appliance flexible connection only. Supply piping should not be less than R /8. Connection is made to the Rc ½ (½” B>S>P>) female threaded entry pipe located just below the hotplate level on the rear left hand side of the appliance. -
Page 21: Fitting The Stability Chain
INSTALLATION INSTRUCTIONS FITTING THE STABILITY CHAIN It is recommended that if the appliance is to be installed with a flexible supply pipe that a stability chain is fitted and is available from your supplier (see Important Safety Requirements, Page 20). These instructions should be read in conjunction with the leaflet packed with the stability chain. -
Page 22: Pressure Testing
INSTALLATION INSTRUCTIONS PRESSURE TESTING 1. The rapid injector is used as a pressure test point. 2. Connect the pressure gauge to the Rapid injector. 3. Check the supply pressure by turning the Rapid burner on and one other hotplate burner full on and light the appropriate burner. -
Page 23: Notes
NOTES... - Page 24 In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed. ZANUSSI 55 – 77 HIGH STREET, SLOUGH, BERKSHIRE,...
