Zanussi ZCG ID Operating And Installation Instructions

Zanussi gas cooker operating and installation instructions zcg id
Hide thumbs Also See for ZCG ID:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading

Related Manuals for Zanussi ZCG ID

Summary of Contents for Zanussi ZCG ID

  • Page 2: For Your Safety

    t i o Introduction This gas oven has been designed and manufactured to all the necessary British Standards. It also carries the C.E. mark. The cooker complies with European Council Directive 90/396/EEC. It is important that you understand how to use and care for the oven properly before you use it for the first time.

  • Page 3: Table Of Contents

    Z C G I D Contents Lighting the cooker The grill The hotplate The ovens Oven cooking chart - main oven - second oven The electronic timer Slow cooking Care and cleaning Installing the cooker General information What is wrong and why? Servicing and spare parts Guarantee conditions Technical Data...

  • Page 4: Lighting The Cooker

    Lighting the cooker The system works by means of an electric spark system. Details about the plug are given on page 36. Hotplate To light 1. Lift up the lid. You cannot use the hotplate when the lid is down. 2.
  • Page 5 Grill/second oven The grill and the second oven are operated by the same control so you cannot use them both at the same time. Grill To light: 1 Open the door. 2 Push in the control knob and turn it to the right to the large flame symbol (highest setting), and press the ignition button immediately.

  • Page 6: Main Oven

    Main oven To light: 1 Open the oven door. 2 Push in the control knob and turn it to gas mark 9. The oven will light automatically. 3 Now turn the control knob back to the gas mark you want. 4 Close the oven door.

  • Page 7: The Grill

    The grill The grill is a high-speed grill. The instructions below tell you how to vary the heat setting and how to change the height of the grid to suit the food you are cooking. You should remember to turn the food regularly. You should not use the grill to keep food warm as it will continue to cook the food.
  • Page 8 General The shelf in the grill/second oven is different from the shelves in the main oven. It is important that you do not swap them over. Only use the shelf with the solid metal plate underneath it in the grill/second oven. When you are not using the grill you should remove the handle and store the pan on the shelf in the grill.

  • Page 9: The Grill Pan And Handle

    To remove the handle, slide the handle to the right and lift the handle away from the cut out on the grill pan. Note If you require an additional handle for your grill pan, this can be ordered from your local Zanussi Service Force Centre by quoting part number 311479800\6.

  • Page 10: The Hotplate

    Z C G I D The hotplate You can only use the hotplate when the lid is open. If you have any trouble lighting a hotplate burner turn all hotplate control knobs off and make sure the hotplate burner parts have been replaced correctly. See page 29 for more information.
  • Page 11 Z C G I D For your safety Take care to avoid burns and scalds when you are reaching across the hotplate. Use pans with flat bases. They are more stable than pans which are warped. Do not use pans with very heavy handles which cause the pan to tip.

  • Page 12: Helpful Hints

    Helpful hints Keep flames under the base of pans. If the flames lick round the sides of the pans you are wasting gas. Only heat the amount of liquid you need. Do not overfill pans. Cover pans with a lid whenever possible.

  • Page 13: The Ovens

    The ovens Before you use the ovens you should wipe them out with a damp cloth to remove any dust. Heat zones Main oven - There are zones of heat within the oven. The temperature in the middle is the gas mark you have chosen.

  • Page 14: Baking Trays And Dishes

    Most second oven cooking should be carried out using the shelf provided in shelf position 2. However when cooking a small joint or a deep cake you can use the shelf on the base of the second oven to allow enough air to circulate around the food.
  • Page 15 Z C G I D Condensation Condensation may form on the cooker. This is quite normal and nothing to worry about. The condensation forms when heat and moisture are present, for example during cooking. Whenever possible try to make sure that food which contains a lot of moisture, for example casseroles, are covered.

  • Page 16: Oven Cooking Chart - Main Oven

    Z C G I D...
  • Page 17 Z C G I D...
  • Page 18 Z C G I D...

  • Page 19: Second Oven

    Z C G I D...
  • Page 20 Z C G I D...
  • Page 21 Z C G I D...

  • Page 22: The Electronic Timer

    The electronic timer Please note that this is a 24 hour clock, for example 2.00 pm is shown as 14.00 In the following pages we explain how to set the controls. Read through them a few times until you are familiar with the procedure.

  • Page 23: Automatic Control

    When you are using the 'Countdown you can make the clock show the time of day by turning the selector knob to 'manual'. The bell symbol will stay on to remind you that the minute minder is set. At the end of the timed period an alarm will sound and the bell symbol will go out.
  • Page 24 3 How long will Turn the selector knob to the food take 'Cook Time'. Then turn the to cook? setting knob until the length of time you want the food to cook shows in the display. The maximum cooking time is 10 hours.

  • Page 25: Hints And Tips For Automatic Cooking

    Hints and tips for automatic cooking 1 Check the instructions for setting the automatic controls until you are familiar with the timer operation. 2 If the oven has been used, allow it to cool completely before using for automatic cooking. 3 You should leave food in the oven for as short a time as possible before automatic cooking starts.

  • Page 26: Slow Cooking

    Slow cooking Please note: There is no slow cook on the second oven. The slow cook setting gives a very low heat in the oven. It is particularly useful when you are cooking soups, stews and casseroles because the long slow cooking will make cheaper, tougher cuts of meat more tender. You need to cook food at gas mark 6 for 30 minutes before you turn the oven down to the slow cook setting.
  • Page 27 Soups, casseroles and stews Do not cook casseroles over 3kg (6lb). Bring to the boil on the hotplate then cook on slow cook. Cook in the middle of the oven or above. Vegetables Cut into small pieces. Dried beans must be pre-soaked then boiled in an open pan for 15 minutes before adding to any dish.

  • Page 28: Care And Cleaning

    Care and cleaning For your safety For hygiene and safety reasons you must keep this gas cooker clean. A build up of fat or other foodstuff could cause a fire. Try to mop up spills and splashes as soon as they happen. But be careful as parts of the cooker will be hot.

  • Page 29: When Replacing Hotplate Burner Parts

    Clean the burner crowns by soaking them in very hot soapy water. You can remove any stubborn stains by scouring with a soap filled pad such as 'Brillo'. If you look after the burner crowns in this way they will stay reasonably clean.

  • Page 30: The Main Oven

    The main oven The sides and back of your ovens are coated in a special material which helps to keep itself clean. Follow these simple rules to maintain the appearance of the special finish. Do not overfill dishes or they will boil over. Do not put dishes too high in the oven.
  • Page 31 Main oven cleaning cycle You need to follow the cycle to keep the inside of the oven in good condition. The type of cooking you do will affect how often you need to follow the cycle. If you do a lot of roasting and very little other baking you should follow the cleaning cycle once a week.
  • Page 32 Top oven cleaning cycle You need to follow the cycle to keep the inside of the oven in good condition. The type of cooking you do will affect how often you need to follow the cycle. If you do a lot of roasting and very little other baking you should follow the cleaning cycle once a week.

  • Page 33: Cleaning Between The Outer And Inner Door Glass

    Cleaning between the outer and inner door glass. You can remove the glass from the oven and grill doors if you need to. Note: For top oven door it is important not to open the door when the glass is removed because the door is lighter and it will spring shut. To remove the outer glass 1 Open the door so you can get at the two cross head screws on the top of the door.

  • Page 34: Installing The Cooker

    Cleaning The Door Glass To prevent damaging or weakening the door glass panels avoid the use of the following: Household detergents and bleaches Impregnated pads unsuitable for non-stick saucepans Brillo/Ajax pads or steel wool pads Chemical oven pads or aerosols Rust removers Bath/Sink stain removers If the door glass panel becomes chipped or has deep scratches...
  • Page 35 Positioning The diagram shows how close to the cooker cupboards, shelves, curtains and so on can be fitted. Look at the diagram and carefully read the instructions to make sure your cooker is fitted safely. If you are in doubt your installer will give you advice. Do not fit any materials which may catch fire, for example wood or curtains behind the cooker.

  • Page 36: General Information

    General information For your safety Do not block any of the cooker vents. Never line any part of the cooker with aluminium foil. Don't let items which can catch fire or electric mains leads such as kettle flexes trail over any part of the cooker. Moving your cooker You may damage some soft or badly fitted floor coverings when you move the cooker.

  • Page 37: Replacing The Oven Light Bulb

    If the ignition system doesn't work there may be a fault with the electrical supply. First, check the socket by trying out another piece of electrical equipment in it, if that works correctly renew the fuse in the plug. If the fuse keeps failing there is a fault in the cooker which must be put right.

  • Page 38: What Is Wrong And Why

    What is wrong and why? We strongly recommend that you carry out the following checks on your cooker before calling a Service Engineer. Problem The oven, grill or hotplate will not light. Check If only the hotplate burners will not light make sure that the burner parts have been replaced correctly.
  • Page 39 Problem Having difficulty cleaning any part of the cooker. Check Check that the instructions for care and cleaning, beginning on page 28 are being followed. Problem The oven light will not work. Check If the light does not work you probably need to replace the bulb. To do this see instructions on page 37.

  • Page 40: Service And Spare Parts

    Service and spare parts In the event of your appliance requiring service or if you wish to purchase spare parts please contact your local Zanussi Service Force Centre by telephoning 0 8 7 0 5 9 2 9 9 2 9 Your call will be routed to the Service Force Centre covering your postcode area.
  • Page 41 Customer Care Department For general enquiries concerning your Zanussi cooker or further information on products, you are invited to contact our Customer Care Department by letter or telephone to the address below or visit our website http://www.Zanussi.co.uk...

  • Page 42: Guarantee Conditions

    Guarantee Conditions Standard guarantee conditions We, Zanussi, undertake that if within 12 months of the date of the purchase this Zanussi appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour,...

  • Page 43: Technical Data

    TECHNICAL DATA DIMENSIONS Height to hotplate Space for fixing at hotplate level Space for fixing above hotplate level Minimum space above hotplate Weight of appliance Minimum distance from rear wall CONNECTIONS Electric IGNITION Spark generator GRILL Heat Input Injector Marking HOTPLATE Heat Input Injector Marking...

  • Page 44: Safety Requirements/Ventilation

    MAIN OVEN Heat Input Injector Marking Flame Supervision Device Thermostat Thermostat By-Pass Marking SECOND OVEN Heat Input Injector Marking Flame Supervision Device Dual Control Dual Control By-pass GENERAL Ignition Spark Gap IMPORTANT - SAFETY REQUIREMENTS This appliance must be installed in accordance with the Gas Safety (Installation and Use) Regulations Current Editions and the I.E.E.

  • Page 45: Location Of Appliance

    LOCATION OF APPLIANCE This appliance must not be installed in a bed-sitting room of volume less than 20m³ or in a bathroom or shower room. It is essential that the appliance is positioned as stated below (see Fig. 1a) i.e. shelves, wall cabinets and cooker hoods must be fitted a minimum of 787mm directly above the top of hotplate and 400mm above the hotplate when fitted in line with the outside of the appliance.

  • Page 46: Location Of Storage Board

    LOCATION OF STORAGE BOARD Storage board kits are available from your retailer. Fix the Storage Board by drilling 2 holes of 6 mm in diameter in the position shown. See fig 1c. Use screws and wall plugs provided in the pack. To enable the Storage Board to be fitted, a 2 mm gap between the screw head and wall is required.

  • Page 47: Installation

    INSTALLATION 1. PARTS REQUIRED The loose hotplate parts are packed in the polystyrene fitment on top of the hotplate. 2. LEVELLING THE APPLIANCE If the appliance requires levelling or its height adjusting (from the hotplate to any working surface), the procedure below must be followed: Adjustment to suit floor conditions or height is obtained by rotating clockwise or anticlockwise the feet, at the front and rear of the appliance.
  • Page 48 4. CONNECTING TO GAS This appliance is designed to be installed with an appliance flexible connection only. Supply piping should not be less that R³/8. Connection is made to the Rc ½ (½" B.S.P.) female threaded entry pipe located just below the hotplate level on the rear left hand side of the appliance.

  • Page 49: Testing

    If the wiring is extended or a completely new cable fitted a 3-pin 13 amp plug should be fitted. (See Fig.4a). Connect the wires as follows: BROWN to the Live Terminal. BLUE to the Neutral Terminal. GREEN and YELLOW to the Earth Terminal. As the colours of the wires in the mains lead which you fit may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:...

  • Page 50: Checking The Main Oven

    10. CHECKING THE MAIN OVEN CONTROLS TO SET THE TIME OF DAY (see Fig.5) Turn on the electricity supply and ensure that the thermostat is in the off position. Before setting timer read important note below. Rotate the left hand clock knob to Manual and back to the 'Time Setting' position.

  • Page 51: Checking The Second Oven

    13. CHECKING THE SECOND OVEN Turn the second oven thermostat control knob anticlockwise to Mk8 and press the ignition button. As soon as the burner is alight the button can be released. When the oven burner lights up there should be a low gas rate at first to the oven burner which is the F.S.D.
  • Page 52 N O T E S...
  • Page 53 N O T E S...
  • Page 54 N O T E S ZCG ID 311513700...
  • Page 56 © Electrolux Household Appliances Limited 2000 311513700 PART NO:...
