- Page 1 LCD MONITOR LCD FARBMONITOR MONITEUR LCD MONITOR LCD MONITOR LCD LL-T1811W OPERATION MANUAL BEDIENUNGSANLEITUNG MODE D’EMPLOI MANUALE D’USO MANUAL DE FUNCIONAMIENTO Downloaded from: http://www.usersmanualguide.com/...
-
Page 2: Table Of Contents
Table of Contents Notice for Users in the USA ..........................4 TCO'99 ................................5 Notice for Users in Europe ..........................7 Notice for Users in the UK ..........................8 Notice for Users in Australia ..........................8 Tips and safety precautions ..........................9 Product description ............................ -
Page 3: Notice For Users In The Usa
Sharp Plaza, Mahwah, New Jersey 07430 TEL :1-800-BE-SHARP * As an ENERGY STAR Partner, SHARP has determined that this product meets the ENERGY STAR guidelines for energy efficiency. This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury. Disposal of these materials may be regulated due to environmental considerations. -
Page 4: Tco'99
Congratulations! You have just purchased a TCO'99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. Why do we have environmentally labelled computers? In many countries, environmental labelling has become an established method for encouraging the adapta- tion of goods and services to the environment. - Page 5 TCO Development SE-114 94 Stockholm, Sweden Fax: +46 8 782 92 07 Email (Internet): development@tco.se Current information regarding TCO'99 approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/ Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire.
-
Page 6: Notice For Users In Europe
Notice for Users in Europe This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC. Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG. Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE. -
Page 7: Notice For Users In The Uk
"WARNING :THIS APPARATUS MUST BE EARTHED" Notice for Users in Australia Service Inquiries Please contact your dealer for service if required or contact Sharp Corporation of Australia on 1 300 13 50 22 for referral to your nearest Sharp authorized Service Center. Downloaded from:... -
Page 8: Tips And Safety Precautions
Sharp Corporation holds authorship rights to the during use, except where indemnity liability is Utility Disk program. Do not reproduce it without recognized under law. -
Page 9: Product Description
Product description Front view Control Panel 1. INPUT button To switch between the signal’s input terminals. (Analogue signal input terminal ↔ DVI-I input terminal) 2. MENU button This button is used to pop-up, select and close the OSD Menu. 3. SELECT button This button is used to select menu options when the OSD Menu is displayed. - Page 10 Product description Rear view 7. Analog signal input terminal Remove the cover to see the analog signal input terminal. At the time of leaving the factory the analog signal cable is connected. 8. Power terminal Remove the cover to see the power terminal. The AC adapter is con- nected here.
-
Page 11: Connecting The Monitor And Turning The Monitor On And Off
Connecting the monitor and turning the monitor on and off 5. Connect power cord to AC adapter. Connecting the monitor to a power source Use only the AC adapter supplied. Notes: Do not overly bend the cable or add extension Power cord cords as this could lead to malfunction. -
Page 12: Connecting The Monitor To A Computer (Pc Etc.)
Connecting the monitor and turning the monitor on and off Connect using a display cable (to be purchased Connecting the monitor to a computer separately) (PC etc.) Using a display cable (to be purchased separately), it can be connected to the Connect using this device’s analogue signal computer’s (PC etc.) digital RGB output terminal cable... -
Page 13: Connecting A Usb Device
Connecting the monitor and turning the monitor on and off Connecting a USB device Turning the power on This monitor can be used with hubs which use the 1. Press the monitor's power button. USB standard (Rev. 1.1). 2. Turn on the computer. The power LED will be lit green, and the screen Downstream (2 ports) will display an image. - Page 14 Connecting the monitor and turning the monitor on and off Installing set-up information and the ICC profile For Windows98 (Windows) Installing monitor set-up information into Win- Depending on the computer or OS, it may be neces- dows98, and setting the monitor's ICC profile as a sary to use the computer to operate the installation predetermined value.
- Page 15 Connecting the monitor and turning the monitor on and off For Windows2000 5. Select the monitor details from the list, then click [Next], [Next], and [Finish]. If the "Add new Installing monitor set-up information into Win- Hardware Wizard" appears, repeat the installa- dows2000, and setting the monitor's ICC profile as a tion commands beginning from 2 above.
-
Page 16: Turning The Power Off
Connecting the monitor and turning the monitor on and off Information about the ColorSync profile (MacOS) Turning the power off 1. Turn the computer off. About the ColorSync profile ColorSync is the Apple Corporation's color 2. Press the monitor's power button. management system and is a function that The Power LED will disappear. -
Page 17: Adjusting The Screen Display
Adjusting the screen display Note: For analog signal While ALL RESET is displayed, the control 1. First perform an automatic adjustment. (p. 19) buttons are disabled. 2. Perform manual adjustment where necessary. It is not possible to reset values when the (p. -
Page 18: Adjusting The Screen Display (When Using An Analog Signal)
Adjusting the screen display (when using an analog signal) Opening the Adjustment Pattern (for Windows) Automatic screen adjustment If you are using Windows, you can use the Adjust- Options in the ADJUSTMENT Menu can be adjusted ment Pattern (for Windows) on the accompanying automatically (CLOCK, PHASE, H-POS V-POS). -
Page 19: Manual Screen Adjustment
Adjusting the screen display (when using an analog signal) CLOCK Manual screen adjustment The figure below demonstrates how to adjust so that Adjustments can be made using On Screen Display vertical flicker noise is not emitted. ( buttons) (OSD) Menu provided. 1. - Page 20 Adjusting the screen display (when using an analog signal) GAIN CONTROL Menu WHITE BALANCE Menu MANUAL: Individual menu options are manually adjusted. Notes: AUTO: Every menu option is automatically On settings other than [STD] not all graduations adjusted using the Auto Gain Control* can be displayed.
- Page 21 Adjusting the screen display (when using an analog signal) SCALING (Level of scaling) MODE SELECT Menu If [EXPAND] is set on [ON1] or [ON2], the sharpness of the image can be adjusted. ( buttons) Note: If [EXPAND] is set on [OFF], [SCALING] cannot be adjusted.
-
Page 22: Adjusting The Screen Display (When Using A Digital Signal)
Adjusting the screen display (when using a digital signal) WHITE BALANCE Menu Manual screen adjustment Adjustments can be made using the On Screen Display (OSD) Menu provided. 1. Display an image that makes the entire screen very bright. If using Windows, you can open and use the Adjustment Pattern on the accompanying Utility Disk. - Page 23 Adjusting the screen display (when using a digital signal) MODE SELECT Menu COLOR MODE If this is set on [STD], the original color scheme of the LCD monitor will be displayed. If this is set on [sRGB], the colors of will be corrected according to the computer image.
-
Page 24: Monitor Care And Repair
LCD panel. (A soft cloth such inquire at the shop where you purchased the as gauze or that used for lens cleaning is suitable.) monitor or your nearest Sharp authorized Service Center. (Never attempt this CAUTION! replacement on your own.) -
Page 25: Specifications
90° from left through right Power supply Approx. 2.0 m AC100-240V, 50/60Hz (Use special AC adapter, type NL-A03E of Sharp Corporation.) Temperature of operating environment Approx. H 120 mm x D 60 mm x H 35 mm 5 - 35°C... - Page 26 Specifications Relevant signal timings (analog) Relevant signal timings (digital) Hsync Vsync Dot fre- Hsync Vsync Dot fre- Display mode Display mode (kHz) (Hz) quency (MHz) (kHz) (Hz) quency (MHz) VESA 640x480 31.5kHz 60Hz 25.175MHz VESA 640x480 31.5kHz 60Hz 25.175MHz 37.9kHz 72Hz 31.5MHz 37.9kHz...
- Page 27 Specifications The DVI-I input connector pin DDC (Plug & Play) This monitor supports the VESA DDC (Display Data Channel) standard. DDC is a signal standard for carrying out Plug & Play functions on the monitor or PC. It transfers information such as degree of resolution between (DVI-I connector with 29 pins) the monitor and PC.
-
Page 28: Instructions For Attaching A Vesa Compliant Arm
Instructions for attaching a VESA compliant arm An arm or stand based on the VESA standard 4. Remove the two screws, and remove the cover. (purchased separately) can be attached to the Cover monitor. Procurement of the arm or stand is at the custom- er's discretion. - Page 29 SHARP CORPORATION © 2001 SHARP CORPORATION DSN2 TINSE1024MPZZ (2) Downloaded from: http://www.usersmanualguide.com/...
