INSTALLATION INSTRUCTION
GENERAL
This completely assembled blower unit is manufactured under
ISO 9002 Quality System Certification and includes a well-
insulated cabinet, a DX cooling coil with copper tubes and alu-
minum fins, an expansion valve, a distributor, throwaway fil-
ters, a centrifugal blower, a blower motor, a blower motor
contactor, an adjustable belt drive and a small holding charge
of Refrigerant-22.
The unit is shipped in the vertical position with a vertical air dis-
charge. The blower section can be repositioned as shown in Fig-
ure1 for horizontal applications.
REFERENCE
This instruction covers the installation of the evaporator blower
unit. For information on the installation and operation of the
matching condensing unit refer to Form 035-17263-000.
Additional information for the accessories on this equipment is
available in the following instructions:
Electric Heater - 550.13-N10.1V
Supply Air Plenum - 550.13-N10.2V
Return Air Grille - 550.13-N10.3V
Base - 550.13-N10.4V
Hot Water & Steam Coil - 550.13-N10.7V
Suspension Mounting - 550.13-N7.1
Renewal Parts:
Refer to Parts Manual for complete listing of replacement
parts on this equipment.
All forms may be ordered from:
Standard Register
2101 West Tecumseh Road
Norman, OK 73069
Installer should pay particular attention to the words: NOTE, CAU-
TION and WARNING. Notes are intended to clarify or make the installation easier. Cautions are given to prevent equipment dam-
age. Warnings are given to alert installer that personal injury and/or equipment damage may result if installation procedure is not
®
Supersedes: 550.39-N5YI (894)
MODEL K3EU180A50
(WORLD 50 HZ)
SUNLINE™ SPLIT-SYSTEM
EVAPORATOR BLOWER
(AIR COOLED)
INSPECTION
As soon as a unit is received, it should be inspected for possible
damage during transit. If damage is evident, the extent of the
damage should be noted on the carrier's delivery receipt. A
separate request for inspection by the carrier's agent should
be made in writing. See Local Distributor for additional infor-
mation.
NOMENCLATURE
Product Category
K = Split-System Evaporator Blower
Product Generation
1,2,3 = Design Level
Product Identifier
EU = Evaporator Blower Unit
Nominal Cooling Capacity
180 = 180Mbh (52.7kW)
Refrigerant Line Connections
A = Cooling Only
Voltage Code
50 = 380/415-3-50
CAUTION
THIS PRODUCT M UST BE INSTALLED IN STRICT COMPLIANCE W ITH
THE ENCLOSED INSTALLATION INSTRUCTIONS AND ANY APPLICABLE
LOCAL, STATE, AND NATIONAL CODES INCLUDING, BUT NOT LIMITED
TO, BUILDING, ELECTRICAL, AND MECHANICAL CODES.
WARNING
INCORRECT INSTALLATION MAY CREATE A CONDITION WHERE THE
OPERATION OF THE PRODUCT COULD CAUSE PERSONAL INJURY
O R P R O P E R T Y D A M A G E .
035-12124-000 Rev. A (0501)
3 EU
K
180 A 50
