York FAN COIL YVC Installation & Operation Manual

INSTALLATION, OPERATION, & MAINTENANCE
YVC
YVF/YVS
YWC
Notes:
1. 2-Pipe units have one water coil. 4-Pipe units have two water coils.
2. Changeover is used to select heating or cooling mode.
3. YORK International does not recommend "fan cycle" applications for cooling on unit mounted thermostats.
4. For proper operation, control valve must be normally closed.
5. Aquastats provided where required.
***** WARNING TO INSTALLER, SERVICE PERSONNEL AND OWNER *****
Altering the product or replacing parts with non authorized factory parts voids all warranty or
implied warranty and may result in adverse operational performance and/or a possible hazardous
safety condition to service personnel and occupants. Company employees and/or contractors are
not authorized to waive this warning.
L23953Y 1006
Supersedes: Form 115.20-NOM3 (105) Form 115.20-NOM3 (1006)
MODEL YVC -Vertical Concealed Model
The YVC model fan coil is designed to be furred into the
wall where the supply and return or both are connected
to short runs of ductwork. These units are often used
for perimeter heating and cooling of offices, corridors,
hospitals, apartments, hotels, and other multi-room
buildings.
00563VIPa
MODEL YVS I YVF -Vertical Cabinet Models YVS
(Slant Top), YVF (Flat Top)
The YVS I YVF model fan coils have the addition of an
attractive, painted cabinet to blend with any decor. These
units will have heavy-duty stamped face louvered grilles
(Style A), plastic discharge grilles (Style A), or metal
grilles (Style B). These units are typically installed in
plain sight, under windows or against walls in schools,
hospitals, office buildings, and other institutions.
00803VIPa
MODEL YWC -Vertical Recessed Wall Model
The YWC model fan coil is designed to be recessed
into the wall. These units are engineered to be quiet and
designed to be easy to install and service. These units
are ideal for perimeter heating and cooling in hotels,
apartments, hospitals, public office buildings, offices,
corridors, and other multi-room buildings. This unit
comes standard with a decorative wall panel for front
supply and return air.
00771VIPa
