  • Page 1 RX-V3900 AV Receiver OWNER’S MANUAL...

  • Page 2: Important Safety Instructions

    This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product. 2 IMPORTANT: When connecting this product to accessories and/or another product use only high quality shielded cables.
  • Page 3 12 Only voltage specified on this unit must be used. Using this unit with a higher voltage than specified is dangerous and may cause fire, damage to this unit, and/or personal injury. Yamaha will not be held responsible for any damage resulting from use of this unit with a voltage other than specified.
  • Page 4 Interface” are trademarks, or registered trademarks of HDMI Licensing LLC. x.v.Color™ “x.v.Color” is a trademark of Sony Corporation. “SILENT CINEMA” is a trademark of Yamaha Corporation. The XM name and related logos are registered trademarks of XM Satellite Radio Inc. Caution-iii This product is manufactured under license from Neural Audio Corporation and THX Ltd.

  • Page 5: Table Of Contents

    USB and network menu tree... 68 Navigating USB and network menus ... 69 Using a USB storage device or a USB portable audio player ... 69 Using a PC server or Yamaha MCX-2000... 70 Using the Internet Radio... 71 Using the Rhapsody® service (U.S.A.
  • Page 6 What you can do with the GUI menu By configuring the parameters in the GUI menu of this unit, you can adjust a variety of system settings suited for your listening environment. The following is a brief description of some of the useful menus you can configure in the GUI menu.

  • Page 7: Features

    720p/1080i/1080p, 480p(576p) → 720p/1080i/1080p, 720p → 1080i/1080p, 1080i → 720p/1080p DOCK terminal ◆ DOCK terminal to connect a Yamaha iPod universal dock (such as YDS-11, sold separately) or Bluetooth wireless audio receiver (such as YBA-10, sold separately) USB and network features ◆...

  • Page 8: Getting Started

    GETTING STARTED About this manual • y indicates a tip for your operation. • Some operations can be performed by using either the buttons on the front panel or the ones on the remote control. In case the button names differ between the front panel and the remote control, the button name on the remote control is given in parentheses.

  • Page 9: Quick Start Guide

    The following steps describe the easiest way to enjoy DVD movie playback in your home theater. Front right speaker Video monitor Subwoofer Front left speaker Center speaker DVD player Surround back left Surround left speaker Step 1: Set up your speakers Step 2: Connect your DVD player and other components Step 3: Turn on the power and...
  • Page 10 Quick start guide Step 1: Set up your speakers Place your speakers in the room and connect them to this unit. HDMI COMPONENT VIDEO VIDEO MONITOR OUT BD/HD DVD CBL/SAT BD/HD DVD CBL/SAT MONITOR OUT S VIDEO VIDEO CBL/ (PLAY) OUT (REC) SURROUND BACK/BI-AMP MD/CD-R...

  • Page 11: Connect Dvd Player And Other Components

    • TV monitor or projector AV receiver • Other components • External amplifier • Multi-format player or external decoder • Yamaha iPod universal dock or Bluetooth wireless audio receiver • FM/AM antennas DVD DIGITAL INPUT COAXIAL jack • XM Mini-Tuner Home Dock •...
  • Page 12 Quick start guide Step 3: Turn on the power and start playback Check the type of the connected speakers. If the speakers are 6-ohm speakers, set “SPEAKER IMP.” to “6Ω MIN” before using this unit (page 26). You can also use 4-ohm speakers as the front speakers (page 121).

  • Page 13: Connections

    Rear panel HDMI COMPONENT VIDEO BD/HD DVD CBL/SAT MONITOR OUT CBL/ (PLAY) OUT (REC) MD/CD-R REMOTE CENTER FRONT(6CH) SURROUND PHONO HD DVD SUR.BACK WOOFER (8CH) AUDIO MULTI CH INPUT DOCK DIGITAL INPUT COAXIAL SIRIUS TRIGGER OUT Name HDMI jacks COMPONENT VIDEO jacks Audio component jacks REMOTE IN/OUT jacks Video component jacks...

  • Page 14: Placing Speakers

    Connections Placing speakers The speaker layout below shows the speaker setting we recommend. • 7.1-channel speaker layout is highly recommended for playback of the high definition digital audio sources (Dolby TrueHD, DTS-HD Master Audio, etc.) with sound field programs. • We recommend that you add the presence speakers for the effect sounds of the CINEMA DSP sound field program. 7.1-channel speaker layout 30˚...

  • Page 15: Speaker Types

    (page 88). Subwoofer (SW) The use of a subwoofer with a built-in amplifier, such as the Yamaha Active Servo Processing Subwoofer System, is effective not only for reinforcing bass frequencies from any or all channels, but also for reproducing the high fidelity sound of the LFE (low-frequency effect) channel included in bitstreams and multi-channel PCM sources.

  • Page 16: Connecting Speakers

    Connections Connecting speakers Be sure to connect the left channel (L), right channel (R), “+” (red) and “–” (black) properly. If the connections are faulty, this unit cannot reproduce the input sources accurately. Caution • Before connecting the speakers, make sure that this unit is turned off (page 26). •...
  • Page 17 ■ 6.1-channel speaker connection Surround back speaker Subwoofer WOOFER Right Front speakers ■ 5.1-channel speaker connection Subwoofer Front speakers for the bi-amplification connections (page 14) WOOFER Right Front speakers Presence speakers (page 11) or Zone 2/Zone 3 speakers (page 117) SPEAKERS PRESENCE/ZONE 2/ZONE 3 CENTER...

  • Page 18: Connecting The Speaker Cable

    Connections ■ Connecting the speaker cable Remove approximately 10 mm (0.4 in) of insulation from the end of each speaker cable and then twist the exposed wires of the cable together to prevent short circuits. 10 mm (0.4 in) Loosen the knob, insert one bare wire into the hole and then tighten the knob.

  • Page 19: Information On Jacks And Cable Plugs

    Information on jacks and cable plugs This unit has three types of audio jacks, three types of video jacks and HDMI jacks. You can choose the connection method depending on the component to be connected. ■ Audio jacks DIGITAL AUDIO COAXIAL (White) (Red)

  • Page 20: Information On Hdmi

    Connections Information on HDMI™ This unit has four HDMI input jacks and two HDMI output jacks for digital audio and video signal input/output. ■ HDMI jack and cable plug HDMI • We recommend that you use a commercially available HDMI cable shorter than 5 meters (16 feet) with the HDMI logo printed on it.

  • Page 21: Audio And Video Signal Flow

    Audio and video signal flow ■ Audio signal flow Input HDMI DIGITAL AUDIO (COAXIAL) DIGITAL AUDIO (OPTICAL) AUDIO Digital Note Only the HDMI input jacks support DSD, Dolby TrueHD, Dolby Digital Plus, DTS-HD Master Audio and DTS-HD High Resolution Audio signal inputs. ■...

  • Page 22: Connecting A Tv Monitor Or Projector

    Connections Connecting a TV monitor or projector Make sure that this unit and other components are unplugged from the AC wall outlets. Note If you turn off the video monitor connected to the HDMI OUT jacks via a DVI connection, the connection may fail. In this case, the HDMI indicator flashes irregularly.

  • Page 23: Connecting Audio And Video Components

    Connecting other components ■ Connecting audio and video components This unit has three types of audio jacks, three types of video jacks and HDMI jacks. You can choose the connection method depending on the component to be connected. HDMI can transmit both digital audio and video over a single HDMI cable. COMPONENT VIDEO Video jacks HDMI...

  • Page 24: Jacks Used For Audio/Video Connections

    Connections Jacks used for audio and video connections Recommended connections are indicated by boldface. When connecting a recording component, you need to make additional connections for recording (signal transmission from this unit to the recording component). Make sure that this unit and other components are unplugged from the AC wall outlets.

  • Page 25: Connecting An External Amplifier

    Component Signal type Audio Video Audio recording Video recording CD player Audio MD or CD recorder Audio Audio recording Turntable Audio Notes • Be sure to make the same type of video connections as those made for your TV if the video conversion is disabled. For example, if you connected your TV to the VIDEO MONITOR OUT jack of this unit, connect other components to the VIDEO jacks.
  • Page 26 Bluetooth wireless audio receiver This unit is equipped with the DOCK terminal on the rear panel that allows you to connect a Yamaha iPod universal dock (such as YDS-11, sold separately) or Bluetooth wireless audio receiver (such as YBA-10, sold separately).

  • Page 27: Connecting To The Network

    (Dynamic Host Configuration Protocol) server function. The following diagram shows a connection example where this unit is connected to one of the LAN ports on a 4-port router. To enjoy music files saved on your PC and Yamaha MCX- 2000, access the Internet Radio, or control this unit by using your PC, each device must be connected properly in the network.
  • Page 28 • The AM loop antenna should always be connected, even if an outdoor AM antenna is connected to this unit. VOLUME • If you experience poor reception quality, install an outdoor INFO BAND antenna. Consult the nearest authorized Yamaha dealer or service center about outdoor antennas. Indoor FM antenna (supplied) OPTICAL...

  • Page 29: Connecting The Power Cable

    (U.S.A. model) Connecting the wire of the AM loop antenna Insert Press and hold The wire of the AM loop antenna does not have any polarity and you can connect either end of the wire to AM or GND terminal. Connecting the power cable ■...

  • Page 30: Setting The Speaker Impedance

    Connections Setting the speaker impedance and GUI language Caution If you are to use 6 ohm speakers, set “SPEAKER IMP.” to “6Ω MIN” as follows BEFORE using this unit. You can also use 4 ohm speakers as the front speakers (page 121). Make sure this unit is turned off.

  • Page 31: Front Panel Display

    Front panel display DOCK V-AUX neural SILENT YPAO PRESET CINEMA OUT 1 OUT 2 VIRTUAL ADAPTIVE DRC ENHANCER DISCRETE MATRIX DIGITAL PLUS PL x TRUE HD MASTER AUDIO SILENT YPAO PRESET CINEMA OUT 1 OUT 2 VIRTUAL ADAPTIVE DRC ENHANCER DISCRETE DIGITAL PLUS PL x...

  • Page 32: Using The Remote Control

    Connections n Tuner indicators Light up when this unit is in the FM, AM, XM Satellite Radio, or SIRIUS Satellite Radio tuning mode. Note The HD and TAG indicators are only applicable to the U.S.A. model and used when this unit is tuned into the HD Radio reception band.
  • Page 33 Operation mode selector (F) The function of some buttons depends on the operation mode selector position. Operates the amplifier function of this unit. SOURCE Operates the component selected with an input selector button (page 107). Operates the TV (page 106). Notes •...

  • Page 34: Optimizing The Speaker Setting For Your Listening Room

    Optimizing the speaker setting for your listening room This unit employs the YPAO (Yamaha Parametric room Acoustic Optimizer) technology which lets you avoid troublesome listening-based speaker setup and achieves highly accurate sound adjustments automatically. The supplied optimizer microphone collects and this unit analyzes the sound your speakers produce in your actual listening environment.

  • Page 35: Basic Automatic Setup

    Optimizer microphone It is recommended that you use a tripod (etc.) to affix the optimizer microphone at the same height as your ears would be when you are seated in your listening position. You can use the attached screw of a tripod (etc.) to fix the optimizer microphone to the tripod (etc.).
  • Page 36 Optimizing the speaker setting for your listening room Parameter Descriptions Distance This unit checks and adjusts the distance of each speaker from the listening position and (Speaker distance) adjusts the timing of each channel. Size This unit checks and adjusts the frequency response of each speaker and sets the (Speaker size) appropriate low-frequency crossover for...

  • Page 37: Advanced Automatic Setup

    Advanced automatic setup Use this feature to optimize the setup of this unit for multiple listening positions. You can also select the parameters to be optimized by the automatic setup. Turn on the video monitor and then connect the optimizer microphone to the OPTIMIZER MIC jack on the front panel.
  • Page 38 Optimizing the speaker setting for your listening room Note If an error or warning message appears, see “Error and warning messages” (page 32). Move the optimizer microphone to the second listening position and then press 9ENTER to start the measurement. To skip the measurements at the remaining listening positions, press 9n.
  • Page 39 Parameter Descriptions Multi Measure Displays the number of listening position actually measured. (Multiple point measurement) Wiring Displays the polarity of each connected speaker. (Speaker wiring) – “NRM” appears when the polarity of the connected speaker is normal. – “REV” appears when the polarity of the connected speaker is reversed.

  • Page 40: Playback

    Caution Extreme caution should be exercised when you play back CDs encoded in DTS. If you play back a CD encoded in DTS on a DTS-incompatible CD player, you will only hear some unwanted noise that may damage your speakers. Check whether your CD player supports CDs encoded in DTS.

  • Page 41: Selecting Audio Input Jacks (Audio Select)

    Selecting audio input jacks (AUDIO SELECT) Use this feature (audio input jack select) to switch the input jack assigned to an input source when more than one jacks are assigned to an input source. Rotate the C INPUT selector (or press one of the input selector buttons (3)) to select the desired input source.

  • Page 42: Using Your Headphones

    Playback Using your headphones Connect a pair of headphones with a stereo analog audio cable plug to the PHONES jack on the front panel. AUDIO SELECT/ TONE SEARCH STEREO/ REC OUT MENU CONTROL ENTER PRESET/TUNING/CH MEMORY MODE MONO CATEGORY BAND INPUT STRAIGHT ZONE ON/OFF...

  • Page 43: Using The Sleep Timer

    ■ Video information HDMI signal Type of the source video signals and the video signals output at the HDMI OUT jacks of this unit. HDMI Resolution Resolution of the input signal (analog or HDMI) and the output signal (HDMI). Analog Resolution Resolution of the source video signals and the analog video signals output at the COMPONENT MONITOR OUT...

  • Page 44: Sound Field Programs

    This unit is equipped with a variety of precise digital decoders that allow you to enjoy multi-channel playback from almost any stereo or multi-channel sound source. This unit is also equipped with a Yamaha digital sound field processing (DSP) chip containing several sound field programs which you can use to enhance your playback experience.

  • Page 45: For Audio Music Sources

    Descriptions of the characteristics of the sound field programs Following indexes indicates the characteristics and trends of each sound field program. Note The characteristics of the sound field programs may differ depending on the settings of the listening room, etc. Size of sound field space (Size) Small Indicates the size of the sound field to be generated.
  • Page 46 Sound field programs Hall in Amsterdam The large, shoe box shaped hall seats about 2200 around the circle stage. Reflections are rich and pleasing while the sound travels freely. Church in Freiburg Located in the south of Germany, this grand, stone-built church has a pointed tower at 120 meters in height.

  • Page 47: For Various Sources

    ■ For various sources ENTERTAIN ENTERTAIN Sports This program allows the listeners to enjoy stereo sport broadcasts and studio variety programs with enriched live feeling. In sports broadcasts, the voices of the commentator and sportscaster are positioned clearly on the center while the atmosphere of the stadium expands in an optimum space to offer the listeners with a feeling of presence in the stadium.

  • Page 48: For Movie Sources

    Sound field programs ■ For movie sources You can select the desired decoder (page 74) used with following sound field program (except “Mono Movie”). MOVIE MOVIE Standard This program create a sound field emphasizing the surrounding feeling without disturbing the original acoustic positioning of multi-channel audio such as Dolby Digital and DTS.

  • Page 49: Stereo Playback

    ■ Stereo playback STEREO STEREO 2ch Stereo Use this program to mix down multi-channel sources to 2 channels. 7ch Stereo Use this program to output sound from all speakers. When you play back multi-channel sources, this unit downmixes the source to 2 channels, and then output the sound from all speakers.

  • Page 50: Using Cinema Dsp 3D Mode

    Sound field programs Before performing the following operation, set the operation mode selector on the remote control to F AMP. Using CINEMA DSP 3D mode CINEMA DSP 3D mode creates the intensive and accurate stereoscopic sound field in the listening room. You can activate and deactivate the CINEMA DSP 3D mode.

  • Page 51: Using Audio Features

    Before performing the following operation, set the operation mode selector on the remote control to F AMP. Enjoying pure hi-fi sound Use the PURE DIRECT mode to enjoy the pure fidelity sound of the selected source. When the PURE DIRECT mode is activated, this unit plays back the selected source with the least circuitry.

  • Page 52: Fm/Am Tuning

    Overview You can use two tuning modes to tune into the desired FM/AM station: Frequency tuning mode You can search or specify the frequency of the desired FM/AM station automatically or manually (see “FM/AM tuning operations” on this page). Preset tuning mode You can preset the desired FM/AM station in advance, and then recall the station by specifying the preset group and number (see “Recalling a preset station”...

  • Page 53: Preset Fm/Am Stations

    Before performing the following operations, set the operation mode selector on the remote control to FSOURCE and then press 3TUNER. Preset FM/AM stations Use this feature to store up to 40 stations FM/AM stations (A1 to E8: 8 preset station numbers in each of the 5 preset station groups).
  • Page 54 FM/AM tuning • You can also select a preset number (1 to 8) by pressing the numeric buttons (B). • If you select a preset number being used (“*” appears next to the preset number), the current preset station will be overwritten.

  • Page 55: Using Hd Radio™ Features (U.s.a. Model Only)

    Using HD Radio™ features (U.S.A. model only) HD Radio technology is a new technology that enables FM and AM radio stations to broadcast programs digitally. Digital broadcasting provides listeners with radically improved audio quality and reception as well as new data services. Furthermore, supplemental program services allow listeners to select from up to 8 HD Radio programs multicast on a single FM HD Radio channel.

  • Page 56: Displaying Hd Radio™ Information

    • This unit transmits the iTunes Tagging information to the iPod if an iPod that supports iTunes Tagging feature is stationed in the Yamaha iPod universal dock (YDS-11, sold separately) connected to the DOCK terminal of this unit. Otherwise, this unit stores the information in the internal memory and will transmit it next time your iPod is stationed.

  • Page 57: Xm ® Satellite Radio Tuning

    XM Satellite Radio offers an extraordinary variety of commercial-free music, plus the best in sports, news, talk and entertainment. XM is broadcast in superior digital audio from coast to coast. From rock to reggae, from classical to hip hop, XM has something for every music fan. XM Satellite Radio online information For U.S.

  • Page 58: Activating Xm Satellite Radio

    XM® Satellite Radio tuning Activating XM Satellite Radio Once you have installed the XM Mini-Tuner Home Dock, inserted the XM Mini-Tuner, connected the XM Mini- Tuner Home Dock to your XM Ready system, and installed the antenna, you are ready to subscribe and begin receiving XM programming.

  • Page 59: Setting The Xm Satellite Radio Preset Channels

    ■ Preset Search mode Prior to selecting a preset channel in the Preset Search mode, you must preset XM Satellite Radio channels. For details, see “Setting the XM Satellite Radio preset channels” (page 55). Press HSEARCH MODE (or ISRCH MODE) repeatedly to select “PRESET SEARCH”.

  • Page 60: Displaying The Xm Satellite Radio Information

    XM® Satellite Radio tuning • You can also select a preset number (1 to 8) by pressing the numeric buttons (B). • If you select a preset number being used (“*” appears next to the preset number), the current preset channel will be overwritten.
  • Page 61 Back to “CATEGORY INFO” • If the XM Satellite Radio information contains a character that cannot be recognized by this unit, the character will be displayed with a space. • When the antenna of the XM Mini-Tuner Home Dock cannot receive the signals, “NO SIGNAL”...

  • Page 62: Sirius Satellite Radio™ Tuning

    SIRIUS Satellite Radio™ tuning SIRIUS Satellite Radio provides over 130 channels of exclusive entertainment and 100% commercial-free music. Only SIRIUS has more than 65 original music channels, from today’s hits to R&B, oldies, and classical masterpieces. From authentic country and real bluegrass to cool jazz, hot latin, reggae, rock and many more. Best of all, it’s all 100% commercial-free.

  • Page 63: Activating Sirius Satellite Radio™ Subscription

    Activating SIRIUS Satellite Radio™ subscription Before using the SIRIUS Satellite Radio feature, you need to activate your SIRIUS Satellite Radio subscription. To activate the subscription you need the Sirius ID which is uniquely assigned to the SiriusConnect tuner. Sirius ID is 12-digit number and it appears on the package of the SiriusConnect tuner, on the label of the SiriusConnect tuner, and when you tune into the SIRIUS Satellite Radio...

  • Page 64: All Channel Search Mode

    SIRIUS Satellite Radio™ tuning ■ All Channel Search mode Press HSEARCH MODE (or ISRCH MODE) repeatedly to select “ALL CH SEARCH”. Press FPRESET/TUNING/CH l / h (or 9PRESET/CH k / n) repeatedly to search for a channel within all channels. •...

  • Page 65: Setting The Sirius Satellite Radio™ Preset Channels

    Before performing the following operations, set the operation mode selector on the remote control to FSOURCE and then press 3SIRIUS. Setting the SIRIUS Satellite Radio™ preset channels You can use this feature to store up to 40 SIRIUS Satellite Radio channels (A1 to E8: 8 preset channel numbers in each of the 5 preset channel groups).

  • Page 66: Setting The Parental Lock

    SIRIUS Satellite Radio™ tuning Setting the Parental Lock You can use the Parental Lock feature to limit the access to the desired SIRIUS Satellite channels. This unit automatically skips the locked channels when this unit is in the All Channel Search mode or Category Search mode and you search a channel by pressing FPRESET/ TUNING/CH l / h (or 9PRESET/CH k / n).

  • Page 67: Displaying The Sirius Satellite Radio™ Information

    Channel number 0 1 8 L O C K E D P I N : _ _ _ _ Note If the entered code number is incorrect, “Wrong” appears in the front panel display and this unit is tuned into the previously selected channel.

  • Page 68: Using Bluetooth™ Components

    Using Bluetooth™ components You can connect a Yamaha Bluetooth wireless audio receiver (such as YBA-10, sold separately) to the DOCK terminal of this unit and enjoy the music contents stored in your Bluetooth component (such as a portable music player) without wiring between this unit and the Bluetooth component.

  • Page 69: Music Content Menu

    In “Music Content” menu of the GUI menu, you can browse the music contents of iPod, USB component, PC/ MusicCAST, Internet radio, and Rhapsody configure the playback style setting for the selected sub input source. Music Content menu operations Set the operation mode selector to FAMP on the remote control and then press IMENU to display the GUI menu.

  • Page 70: Using Ipod

    • Some features may not be compatible depending on the model or the software version of your iPod. • Some features may not be compatible depending on the model of your Yamaha iPod universal dock. The following description is based on using YDS-11.

  • Page 71: Controlling Ipod

    Controlling iPod™ You control your iPod with the following remote control buttons. ■ GUI menu operation To navigate the iPod menu using the GUI screen, set the operation mode selector to FAMP. Button Function 9 ENTER Subsequent menu/Play Menu up Menu down Previous menu Subsequent menu...

  • Page 72: Using Usb And Network Features

    This unit is equipped with USB and network features that allow you to enjoy WAV (PCM format only), MP3, MPEG-4 AAC, and WMA files saved on your USB storage device, USB portable audio player, PC and Yamaha MCX-2000 or access the Internet Radio. You can also access the Rhapsody...

  • Page 73: Navigating Usb And Network Menus

    Navigating USB and network menus You can navigate the USB and network menus with the following remote control buttons. ■ GUI menu operation To navigate the USB and network menus using the GUI screen, set the operation mode selector to FAMP. Button Function 9 ENTER...

  • Page 74: Using A Pc Server Or Yamaha Mcx-2000

    ■ Registering this unit on the Yamaha MCX-2000 You must register this unit on your Yamaha MCX-2000 so that this unit can be recognized by your Yamaha MCX- 2000. For details, refer to the operation manual supplied with your Yamaha MCX-2000.

  • Page 75: Using The Internet Radio

    Using the Internet Radio Use this feature to listen to Internet Radio stations. This unit uses the vTuner Internet Radio station database service particularly customized for this unit, providing over 2000 radio station database. Further, you can store your favorite stations with bookmarks. Notes •...

  • Page 76: Using Shortcut Buttons

    Using USB and network features Use 9k / n / l / h and 9ENTER to input your password (up to 64 characters), select “OK” and then press 9ENTER. “Please wait...” appears and then top “Rhapsody” menu screen appears. Note If registration failed, the error message appears.
  • Page 77 • To store the selected content under an empty preset number automatically, press and hold GMEMORY (or 0MEMORY) for more than 2 seconds instead of step 2. In this case, the following steps are unnecessary. • To cancel the preset, press GMEMORY (or 0MEMORY) again.

  • Page 78: Advanced Sound Configurations

    Advanced sound configurations Selecting decoders ■ Selecting decoders for 2-channel sources (surround decode mode) Use this feature to play back sources with selected decoders. You can play back 2-channel sources on multi- channels. Set the operation mode selector to F AMP and then press S SUR.
  • Page 79 ■ Selecting decoders for multi-channel sources If you connected surround back speakers, use this feature to enjoy 6.1/7.1-channel playback for multi-channel sources using the Dolby Pro Logic IIx, Dolby Digital EX, DTS-ES, or Neural-THX decoders. Set the operation mode selector to FAMP and then press MEXTD SUR.

  • Page 80: Graphical User Interface (Gui) Menu

    Graphical user interface (GUI) menu ■ GUI menu tree Stereo/Surround (page 80) Input Select SIRIUS SATELLITE RADIO (U.S.A. and Canada models only) (page 85) XM (U.S.A. and Canada models only) TUNER MULTI CH PHONO MD/CD-R BD/HD DVD CBL/SAT VIDEO AUX DOCK* PC/MCX NET RADIO...
  • Page 81 Language (page 100) Note * “iPod” appears when an iPod is stationed in a Yamaha iPod universal dock connected to the DOCK terminal. “Bluetooth” appears when a Yamaha Bluetooth receiver is connected to the DOCK terminal. Graphical user interface (GUI) menu...

  • Page 82: Gui Menu Overview

    Graphical user interface (GUI) menu GUI menu overview This unit features a sophisticated graphical user interface (GUI) menu that helps you to control the amplifier function of this unit. With the GUI menu, you can view the information of the signals being input and the status of this unit. •...

  • Page 83: Gui Menu Operations

    GUI menu operations This unit features a sophisticated graphical user interface (GUI) menu that helps you to control the amplifier function of this unit. With the GUI menu, you can view the information of the signals being input and the status of this unit. You can also set up this unit using the GUI menu.
  • Page 84 Graphical user interface (GUI) menu Stereo/Surround You can enjoy good quality sound with the initial factory settings. Although you do not have to change the initial factory settings, you can change some of the parameters to better suit the input source or your listening room. To customize the program parameter settings, press 0SUBMENU to turn on the submenu after you select the desired program.

  • Page 85: Sound Field Parameter Descriptions

    ■ Sound field parameter descriptions You can adjust the values of certain digital sound field parameters so that the sound fields are recreated accurately in your listening room. Not all of the following parameters are found in every program. Sound field parameter Decode Type Decoder type.
  • Page 86 Graphical user interface (GUI) menu Sound field parameter Liveness Liveness. Surround and surround back liveness. Adjusts the reflectivity of the virtual walls in the hall by changing the rate at which the early reflections decay. The early reflections of a sound source decay much Sur.
  • Page 87 Sound field parameter Rev. Delay Reverberation delay. Adjusts the time difference between the beginning of the direct sound and the beginning of the reverberation sound. The larger the value, the later the reverberation sound begins. A later reverberation sound makes you feel as if you are in a larger acoustic environment. Control range: 0 to 250 ms Rev.
  • Page 88 Graphical user interface (GUI) menu ■ Compressed Music Enhancer mode parameter descriptions The Compressed Music Enhancer mode Level Straight enhancer or 7-channel enhancer effect level. Select “High” or “Low” to adjust the effect for the high- frequency. (“Straight Enhancer” and “7ch Enhancer”...

  • Page 89: Input Select

    Input Select Use this menu to adjust the parameters of each input source. To customize the input source settings, press 0SUBMENU to turn on the submenu after you select the input source. Input source Parameter SIRIUS SATELLITE Volume Trim RADIO Parental Lock (U.S.A.

  • Page 90: Parental Lock

    (page 98), the name of the input source appears in the choices of this parameter. ■ Pairing (Bluetooth pairing) Use this feature to start pairing the connected Yamaha Bluetooth wireless audio receiver (such as YBA-10, sold separately) with your Bluetooth component. For details about the pairing, refer to “Pairing the Bluetooth™...

  • Page 91: Music Content

    Bluetooth components, “Not found” appears. ■ Connect (Bluetooth connection) Use this feature to establish a connection between the Yamaha Bluetooth wireless audio receiver (such as YBA- 10, sold separately) and your Bluetooth component. Note Pairing must be performed when using a Bluetooth component with the Bluetooth receiver connected to this unit for the first time of if the pairing data has been deleted.
  • Page 92 Graphical user interface (GUI) menu Surround Back (Surround back left/right speakers) Choice Descriptions Large x1 Select this setting when the single surround back speaker is large. Small x1 Select this setting when the single surround back speaker is small. Small x2 Select this setting when the surround back left and right speakers are small.
  • Page 93 Speaker distances Control range: 0.30 to 24.00 m (1.0 to 80.0 ft) Initial setting: 3.00 m (10.0 ft) Control step: 0.05 m (0.2 ft) Distance Adjusted speaker Front L Front left speaker Front R Front right speaker Center Center speaker Surround L Surround left speaker Surround R...
  • Page 94 Graphical user interface (GUI) menu Max Volume (Maximum volume) Use this feature to set the maximum volume level in the main zone. This feature is useful to avoid the unexpected loud sound by mistake. For example, the original volume range is –80.0 dB to +16.5 dB.
  • Page 95 PEQ Select (Parametric equalizer type select) Use this feature to select the parametric equalizer type that applied to the results of the automatic setup. page 35 for the descriptions of each parametric equalizer type. Choice Descriptions Manual Applies the manually configured parametric equalizer in “Setup”.
  • Page 96 Graphical user interface (GUI) menu Repeat steps 3 and 4 until you are satisfied with the results. If you want to reset all “Parametric EQ” parameter settings for the selected speaker, select “RESET” and press 9ENTER. Select “EXIT” and press 9 ENTER to exit from the settings window.
  • Page 97 ■ Pure Direct (Pure Direct) Use this feature to select whether this unit outputs the video signals when this unit is in the PURE DIRECT mode. Choice Functions Audio Does not output video signals. Audio + Video Outputs video signals. For the better sound quality, this unit only activates the limited video features.
  • Page 98 Graphical user interface (GUI) menu ■ HDMI HDMI (HDMI-to-HDMI video signal processing) Use this feature to select whether this unit processes the HDMI-to-HDMI video signals (input at HDMI input jacks and output at HDMI OUT jacks). Choice Functions Through Select this setting when you do not want this unit to process the HDMI-to-HDMI video signals.
  • Page 99 Input (HDMI IN jack select) Use this feature to select an HDMI IN jack that accepts HDMI signals when this unit is in the standby mode. Note This setting is available only when “Mode” is set to “Fix”. Choice HDMI IN jack HDMI IN1 (BD/HD DVD) jack HDMI IN2 (DVD) jack HDMI IN3 (CBL/SAT) jack...
  • Page 100 Graphical user interface (GUI) menu DNS Server (P) (Primary DNS server) DNS Server (S) (Secondary DNS server) Use this parameter to specify the IP address of the primary and secondary DNS (Domain Name System) servers. Note If you have only one DNS address, enter the DNS address in “DNS Server (P)”.
  • Page 101 Note When “Zone2 Volume” or “Zone3 Volume” is set to “Fixed”, you cannot select the following parameters: – Zone2 Max Vol./Zone3 Max Vol. – Zone2 Initial Vol./Zone3 Initial Vol. Zone2 Max Vol./Zone3 Max Vol. (Zone 2/Zone 3 Maximum volume setting) Use this feature to set the maximum volume level in the Zone 2 or Zone 3.
  • Page 102 Graphical user interface (GUI) menu ■ I/O Assignment (Input/output assignment) Use this feature to assign the input/output jacks according to the component to be used if the initial settings of this unit do not correspond to your needs. Change the parameter to reassign the respective jacks and effectively connect more components.
  • Page 103 Position (GUI screen position) Use this feature to adjust the vertical and horizontal position of the GUI screen. Control range: –5 (downward/left) to +5 (upward/right) Button Moving direction of the GUI display Down Right Left Wall Paper (Wall paper) Use this feature to display the wall paper or gray background in your video monitor when there is no video signal being input.
  • Page 104 Graphical user interface (GUI) menu ■ Trigger Output (Trigger output) Use this feature to select the functions of each TRIGGER OUT jack of this unit. Choice Function Trigger1 Sets the functions for the TRIGGER OUT 1 jack. Trigger2 Sets the functions for the TRIGGER OUT 2 jack.

  • Page 105: Saving And Recalling The System Settings (System Memory)

    Saving and recalling the system settings (System Memory) Use this feature to save and recall up to six of your favorite setting for the main zone. You can also save up to four of your favorite settings for Zone 2 or Zone 3. Saving the system settings ■...

  • Page 106: Renaming The Stored Settings

    Saving and recalling the system settings (System Memory) ■ Renaming the stored settings Follow steps 1 to 4 in “Saving by the GUI menu operation” (page 101). Press 9k / n repeatedly to select “xxx Rename” and then press 9h. “xxx”...

  • Page 107: Loading The System Settings

    Loading the system settings Note If you load the system settings, the settings currently configured are overwritten. If you do not want to erase the current settings, save the settings using the System Memory feature in advance. ■ Loading by the 7 SYSTEM MEMORY buttons You can recall the system settings stored in “Memory1”...
  • Page 108 Saving and recalling the system settings (System Memory) ■ Example 2: Switching the settings for different room environments The tonal characteristics of the listening room may vary depending on the situations of the room (for example, whether the curtains are open or closed), and the settings of this unit should be arranged for each situation of the room.

  • Page 109: Controlling This Unit By Using The Web Browser (Web Control Center)

    Controlling this unit by using the Web browser (Web Control Center) You can operate this unit by using a Web browser. You can select the input source and sound field program, browse the iPod or USB/network contents, select the preset items, and adjust the parameters of this unit by using the graphical user interface (Web Control Center) that appears in the Web browser.

  • Page 110: Remote Control Features

    In addition to controlling this unit, the remote control can also operate other audiovisual components made by Yamaha and other manufacturers. To control your TV or other components, you must set up the appropriate remote control code for each input source (page 109).

  • Page 111: Controlling Other Components

    ■ Controlling other components Set the operation mode selector to FSOURCE to control other components selected with the input selector buttons (3). You must set the appropriate remote control code for each input source in advance (page 109). The following table shows the function of each control button used to control other components assigned to each input selector button (3).

  • Page 112: Customizing The Remote Control

    Remote control features ■ Selecting a component to be controlled You can select a component to be controlled independently of the input source selected with the input selector buttons (3). Press 5 SELECT l / h repeatedly to select the desired component.

  • Page 113: Setting The Backlight Mode Of The Remote Control

    SOURCE Yamaha Note You may not be able to operate your Yamaha component even if a Yamaha remote control code is preset as listed above. In this case, try setting another Yamaha remote control code. Check the remote control code for your component in advance.
  • Page 114 • The supplied remote control does not contain all possible codes for commercially available audio and video components (including Yamaha components). If operation is not possible with any of the remote control codes, program the new remote control function using the learning feature (page 111) or use the remote control supplied with the component.

  • Page 115: Programming Codes From Other Remote Controls

    Programming codes from other remote controls You can program remote control codes from other remote controls. Use the learning feature if you want to program functions not included in the basic operations covered by the remote control codes, or an appropriate remote control code is not available.

  • Page 116: Changing Source Names In The Display Window

    Remote control features Press G SETUP again to exit from the setup menu. Notes • “ERROR” appears in the display window (4) on the remote control if you press a button not indicated in the respective step, or when you press more than one button simultaneously. •...

  • Page 117: Macro Programming Features

    Macro programming features The macro programming feature makes it possible to perform a series of operations with the press of a single button. For example, when you want to play a CD, normally you would turn on the components, select the CD input, and press the play button to start playback.
  • Page 118 Remote control features ■ Programming macro operations You can program your own macro to transmit several remote control commands in sequence at the press of a button. Be sure to set up remote control codes or perform learning operations before programming the macro. Notes •...

  • Page 119: Clearing Configurations

    Clearing configurations You can clear all changes made in each function set, such as learned functions, macros, renamed control area names and setup remote control ID. ■ Clearing function sets Press GSETUP using a ballpoint pen or similar object. “SETUP” appears in the display window (4). Press 9k / n repeatedly to select “CLEAR”...

  • Page 120: Simplified Remote Control

    Remote control features Simplified remote control Use the supplied simplified remote control to make basic controls of this unit. STANDBY Sets the selected zone to the standby mode. ☞ P. 26, 119 SYSTEM MEMORY Save or recall the system settings. ☞...

  • Page 121: Using Multi-Zone Configuration

    Yamaha dealer or service center about the Zone 2 and Zone 3 connections that best meet your requirements. • Some Yamaha models are able to connect directly to the REMOTE jacks of this unit. If you own these products, you may not need to use an infrared signal emitter.
  • Page 122 Using multi-zone configuration ■ Using the internal amplifiers of this unit Important safety notice The speaker terminals of this Receiver should not be connected to a Passive Loudspeaker Selector Box or more than one loudspeaker per channel. Connection to a Passive Loudspeaker Selector Box or multiple speakers per channel could create an abnormally low impedance load resulting in amplifier damage.

  • Page 123: Controlling Zone 2 Or Zone 3

    ■ Using TRIGGER OUT jacks for Zone 2 and Zone 3 This unit is equipped with two TRIGGER OUT jacks. You can turn on and off the component corresponding to the selection of the input source of the desired zone or turning on and off the desired zone by configuring the “Trigger Output”...

  • Page 124: Using The Zone Osd

    Using multi-zone configuration ■ Selecting the input source of Zone 2 or Zone 3 Rotate the CINPUT selector (or set the operation mode selector to FAMP and then press one of the input selector buttons (3)). • Select “TUNER” as the input source to use the FM/AM tuning features (page 48) in the selected zone.

  • Page 125: Advanced Setup

    Choice Setting remote control ID Use this feature to set the remote control ID. This feature is useful when you control multiple Yamaha AV receiver or amplifier with using the remote control. REMOTE SENSOR Descriptions Select this setting if you want to activate the signal-receiving capability of the remote control sensor.
  • Page 126 Advanced setup Press GID repeatedly using a ballpoint pen or similar object on the remote control to select the desired remote control ID. Each time you press GID, the remote control ID indicator changes as shown below. To set the remote control ID of the simplified remote control, see page 116 for details.
  • Page 127 ■ TV format TV FORMAT Use this feature to set the color encoding format of your television. Choices: NTSC, PAL Initial setting: [U.S.A., Canada, General and Korea models]: NTSC [Other models]: PAL This setting is applied to the video monitor in the main zone, Zone 2 and Zone 3.

  • Page 128: Troubleshooting

    Refer to the table below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, turn off this unit, disconnect the power cable, and contact the nearest authorized Yamaha dealer or service center. ■ General...
  • Page 129 Problem No picture. Your video monitor is connected to one of the analog video output jacks of this unit and the picture is input at different types of video jacks. 1080p-resolution analog video signals are only output at the COMPONENT VIDEO MONITOR OUT jacks.
  • Page 130 Troubleshooting Problem No sound is heard “Bass Out” in “Configuration” is set to from the subwoofer. “Front” when a Dolby Digital or DTS signal is being played. “Bass Out” in “Configuration” is set to “SWFR” or “Front” when a 2-channel source is being played.
  • Page 131 Problem An audio source The audio source component is not cannot be recorded by connected to the DIGITAL INPUT jacks. the digital recording Some components cannot records Dolby component connected Digital or DTS sources. to the DIGITAL OUTPUT jacks. You are trying to record an audio source input at the DOCK terminal by the digital recording component connected to the DIGITAL OUTPUT jacks.
  • Page 132 Troubleshooting ■ HDMI Problem No picture or sound. The number of the connected HDMI components is over the limit. HDCP authentication failed. ■ Tuner (FM/AM) Problem FM stereo reception is The characteristics of FM stereo noisy. broadcasts may cause this problem when the transmitter is too far away or the antenna input is poor.
  • Page 133 Cause The HD Radio station currently selected does not support the iTunes Tagging feature. Station your iPod in a Yamaha iPod universal dock connected to the DOCK terminal of this unit. Delete unnecessary data from your iPod to make room and try again.

  • Page 134: Xm Satellite Radio

    Troubleshooting ■ XM Satellite Radio If an operation takes longer than usual or an error occurs, one of the following messages may appear in the front panel display. In this case, read the cause and follow the corresponding remedies. Status message CHECK XM TUNER The XM Mini-Tuner is not installed in the XM Mini-Tuner Home Dock or the...
  • Page 135 ■ SIRIUS Satellite Radio If an operation takes longer than usual or an error occurs, one of the following messages may appear in the front panel display. In this case, read the cause and follow the corresponding remedies. Status message ANTENNA ERROR The antenna is not connected to the SiriusConnect tuner properly.
  • Page 136 Troubleshooting ■ Remote control Problem The remote control Wrong distance or angle. does not work or function properly. Direct sunlight or lighting (from an inverter type of fluorescent lamp, etc.) is striking the remote control sensor of this unit. The batteries are weak. The batteries do not last long and get quickly exhausted.
  • Page 137 Play music recorded in a format that this unit is compatible with. Use MCX-2000 or the PC server. Set your Yamaha MCX-2000 to the “Auto Config” mode. Check the firewall setting of the network device. Check the configuration of the network device, and then contact the network connection provider.
  • Page 138 Troubleshooting Status message Please wait This unit is in the middle of waking up (Starting Server) MCX-2000 that has been set to the standby mode. Connect error There is a problem with the signal path from your network to this unit. Disconnected Your USB storage device or USB portable audio player has been disconnected from...
  • Page 139 Yamaha Bluetooth wireless audio receiver (such as YBA-10, sold separately). Cause Turn off this unit and reconnect the Yamaha iPod universal dock to the DOCK terminal of this unit. Try resetting your iPod. This unit supports iPod touch, iPod (Click Wheel, including iPod classic), iPod nano and iPod mini.
  • Page 140 Check the microphone setting. Check the speaker connections and placement. The optimizer microphone or OPTIMIZER MIC jack may be defective. Contact the nearest Yamaha dealer or service center. Perform the automatic setup again. Perform the automatic setup again. Remedy page —...
  • Page 141 • If warning message “W2” or “W3” appears, the adjustments are made, however the adjustment may not be optimal. • Depending on the speakers, warning message “W1” may appears even if the speaker connections are correct. • If error message “E10” occurs repeatedly, contact a qualified Yamaha service center. Cause Check the speaker connections for proper polarity (+ or –).

  • Page 142: Resetting The System

    RESETTING THE SYSTEM Use this feature to reset all the parameters of this unit to the initial factory settings. Notes • This procedure completely resets all the parameters of this unit including the “GUI menu” parameters. • The initial factory settings are activated next time you turn on this unit. To cancel the initialization procedure at any time without making any changes, press A MASTER ON/OFF on the front panel to release it outward to the OFF position.

  • Page 143: Operation Modes Of Front Panel Controls

    * In the BT pairing mode, this unit searches for Bluetooth components to be paired. This mode is available only when “DOCK” is selected as an input source and a Yamaha Bluetooth wireless audio receiver (such as YBA-10, sold separately) is connected to the DOCK terminal of this unit.

  • Page 144: Glossary

    GLOSSARY ■ Audio and video synchronization (lip sync) Lip sync, an abbreviation for lip synchronization, is a technical term that involves both a problem and a capability of maintaining audio and video signals synchronized during post-production and transmission. Whereas the audio and video latency requires complex end-user adjustments, HDMI version 1.3 incorporates an automatic audio and video syncing capability that allows devices to perform this synchronization automatically and accurately...

  • Page 145: Dolby Surround

    ■ Dolby Surround Dolby Surround uses a 4-channel analog recording system to reproduce realistic and dynamic sound effects: 2 front left and right channels (stereo), a center channel for dialog (monaural), and a surround channel for special sound effects (monaural). The surround channel reproduces sound within a narrow frequency range.
  • Page 146 Glossary ■ LFE 0.1 channel This channel reproduces low-frequency signals. The frequency range of this channel is from 20 Hz to 120 Hz. This channel is counted as 0.1 because it only enforces a low-frequency range compared to the full-range reproduced by the other 5/6 channels in Dolby Digital or DTS 5.1/6.1-channel systems.

  • Page 147: Sound Field Program Information

    The acoustics in your room could be changed to those of a concert hall, a dance floor, or a room with virtually any size at all. This ability to create sound fields at will is exactly what Yamaha has done with the digital sound field processor. ■ CINEMA DSP...

  • Page 148: Parametric Equalizer Information

    PARAMETRIC EQUALIZER INFORMATION Parametric equalizer information This unit employs Yamaha Parametric room Acoustic Optimizer (YPAO) technology to optimize the frequency characteristics of its parametric equalizer to match your listening environment. YPAO uses a combination of the following three parameters (Frequency, Gain and Q factor) to provide highly precise adjustment of the frequency characteristics.

  • Page 149: Specifications

    AUDIO SECTION • Minimum RMS Output Power for Front, Center, Surround, Surround back 20 Hz to 20 kHz, 0.04% THD, 8 Ω ... 140 W • Dynamic Power (IHF) [U.S.A., Canada, General, Asia, China, Korea, and Australia models] Front L/R 8/6/4/2 Ω ... 170/205/265/345 W •...
  • Page 150 We Want You Listening For A Lifetime Yamaha and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion –...

  • Page 151: Index

    ■ Numerics 2ch Stereo, sound field program ... 45 3D indicator ... 27 5.1-channel speaker connection ... 13 5.1-channel speaker layout ... 10 6.1-channel speaker connection ... 13 6.1-channel speaker layout ... 10 7.1-channel speaker connection ... 12 7.1-channel speaker layout ... 10 7ch Enhancer, sound field program ...
  • Page 152 Index Direct number access mode, XM Radio ... 55 Direct, sound field parameter ... 83 Display information, Sirius Satellite Radio ... 63 Display language setting ... 26 Display Set, GUI menu ... 98 Display settings, GUI menu ... 98 Display window, remote control ... 28 Displaying information, HD Radio ...
  • Page 153 Multiple point measurement, automatic setup ... 31 Multi-zone configuration ... 117 Music Content menu ... 65 Music Content, GUI menu ... 87 Music Video, sound field program ... 43 Muting audio output ... 38 Muting Type, GUI menu ... 90 ■...
  • Page 154 Index SOURCE, operation mode selector ... 29 Speaker cable connection ... 14 Speaker configurations, GUI menu ... 87 Speaker connection ... 12 Speaker distance, automatic setup ... 32 Speaker distance, GUI menu ... 88 Speaker equalizing, automatic setup ... 32 SPEAKER IMP., advanced setup ...

  • Page 155: (At The End Of This Manual) Front Panel

    ■ Front panel AUDIO SELECT/ REC OUT INPUT MAIN ZONE ON/OFF MASTER AUDIO SELECT/ TONE REC OUT MENU CONTROL ENTER STRAIGHT EFFECT YPAO PROGRAM OPTIMIZER TONE SEARCH STEREO/ MENU CONTROL ENTER PRESET/TUNING/CH MEMORY MODE MONO ZONE ON/OFF ZONE CONTROLS STRAIGHT MULTI ZONE EFFECT ZONE 2...

  • Page 156: Remote Control

    ■ Remote control POWER POWER MULTI V-AUX HD DVD TUNER SELECT SYSTEM MEMORY STATUS PRESET/CH TITLE BAND ENTER SUBMENU RETURN MEMORY CLASSICAL LIVE/CLUB STEREO ENHANCER HDMI OUT INFO LEVEL TV VOL TV CH STANDBY POWER PHONO DOCK CD-R SIRIUS SOURCE MACRO SETUP MODE...

  • Page 157: Sound Output In Each Sound Field Program

    Sound output in each sound field program Front left speaker Center speaker Front right speaker Speaker from which sound is being output Speaker settings 7-channel : OFF PL x neural : ON or discrete 6.1/7.1-channel audio signals are input. PL x neural Program CLASSICAL...
  • Page 158 Program ENTERTAINMENT Sports Action Game Roleplaying Game Music Video Recital/Opera MOVIE Standard Spectacle Sci-Fi Adventure Drama MOVIE Mono Movie STEREO –– 2ch Stereo STEREO –– 7ch Stereo MUSIC ENHANCER 7ch Enhancer SUR.DECODE –– Surround Decoder (Pro Logic) (PLII Movie) (PLII Game) SUR.DECODE ––...

  • Page 159: List Of Remote Control Codes

    List of remote control codes CENTURION 00401 ACURA 00101 CHANGHONG 09701 ADDISON 01201, 01601, CHING TAI 08401 CHUN YUN ADMIRAL 01301, 02201, 05801 CHUNG HSIN 00701, 01601, ADVENT 09601 06801 CIMLINE AIKO 01201 CINERAL AKAI 00101, 00301, CITIZEN 02901, 04601, 06801, 08901, CLARION 10501...
  • Page 160 MEDION 08501, 10301, PENNEY 11401 MEGATRON 01801, 02601 MEMOREX 00101, 01901, 02001, 02601, PERDIO 03401, 05801, PHILCO 11401 METZ 05501 00301, 01901, 02601 MICROMAXX 10301 PHILIPS MICROSTAR 10301 MIDLAND 00201, 00501, 00601 MINERVA 06301 MINOKA 05101 MITSUBISHI 00301, 01301, PHONOLA 01601, 01901, PILOT 02001, 02601,...
  • Page 161 YAMAHA 00301, 01801, DE GRAAF 08301, 10001, DECCA 11001, 13501, DENON 13601, 13701, DUAL 13801, 14001, DUMONT 14101, 14201 YAPSHE 03401 DYNATECH YOKO 00401, 03701 ELCATECH ZENITH 00201, 01201, ELECTROHOME 02601, 05801 ELECTROPHONIC EMEREX ADMIRAL 01102 EMERSON ADVENTURA 00002 AIKO...
  • Page 162 00702, 01002, 01102, 01202, SATELLITE TUNER 01402, 01502, 02002 @SAT WHITE WESTINGHOUSE ABSAT 01402 ALBA XR-1000 00002, 00302, ALPHASTAR 02504 01402 AMSTRAD YAMAHA 00602 ASTON YAMISHI 01402 ASTRO YOKAN 01402 ATSAT YOKO 02002 AVALON ZENITH 00002, 00202, BLAUPUNKT 00604 00502, 04402...
  • Page 163 00710 VENTURER 03810 VICTOR 00110 WARDS 00410 YAMAHA 00510, 01410, 03110, 04810, 05510, 05610, 05710, 05810, 05910, 06010 YAMAHA (iPOD) 05310 YAMAHA (NET) 05410 YAMAHA (TUNER ID1) 04910 YAMAHA (TUNER ID2) 05010 YAMAHA (XM ID1) 05110 YAMAHA (XM ID2) 05210...

  • Page 164: Tape Deck

    00111 SONY 00211 THORENS 00111 WARDS 00011 YAMAHA 00311, 00411 Information about software This product uses the following software. For information (copyright, etc) about each software, read the original sentences stated below. ■ About The Independent JPEG Group's JPEG software...
  • Page 165 The emphasis in designing this software has been on achieving portability and flexibility, while also making it fast enough to be useful. In particular, the software is not intended to be read as a tutorial on JPEG. (See the REFERENCES section for introductory material.) Rather, it is intended to be reliable, portable, industrial-strength code.
  • Page 166 send usenet/news.answers/jpeg-faq/part1 send usenet/news.answers/jpeg-faq/part2 RELATED SOFTWARE Numerous viewing and image manipulation programs now support JPEG. (Quite a few of them use this library to do so.) The JPEG FAQ described above lists some of the more popular free and shareware viewers, and tells where to obtain them on Internet. If you are on a Unix machine, we highly recommend Jef Poskanzer's free PBMPLUS software, which provides many useful operations on PPM-format image files.
  • Page 167 Printed in Malaysia WP55260 © 2008 Yamaha Corporation All rights reserved.
  • Page 168 MENU CONTROL ENTER PRESET/TUNING/CH MEMORY MODE STRAIGHT ZONE ON/OFF MULTI ZONE EFFECT ZONE 2 YPAO SILENT CINEMA S VIDEO VIDEO AUDIO PROGRAM OPTIMIZER PHONES VIDEO AUX PURE DIRECT VOLUME STEREO/ MONO CATEGORY INFO BAND ZONE CONTROLS ZONE 3 OPTICAL RX-V3900...
  • Page 169 ■ Remote control / Boîtier de télécommande POWER POWER STANDBY POWER MULTI V-AUX PHONO DOCK HD DVD CD-R TUNER SIRIUS SOURCE SELECT MACRO SETUP MODE ZONE SYSTEM MEMORY STATUS VOLUME PRESET/CH TITLE MENU BAND SRCH MODE CAT. ENTER SUBMENU PLAY INFO RETURN DISPLAY MEMORY...

This manual is also suitable for:

Rx v3900 - av network receiverRx-v3900bl - network home theater receiver

Table of Contents
