Yamaha RX-V396 Owner's Manual
Natural sound av receiver
Hide thumbs
Also See for RX-V396:
- Service manual (77 pages) ,
- Owner's manual (368 pages) ,
- Service manual (76 pages)
Related Manuals for Yamaha RX-V396
Summary of Contents for Yamaha RX-V396
- Page 1 U C A RX-V396 Natural Sound AV Receiver Ampli-tuner audio-vidéo OWNER’S MANUAL MODE D’EMPLOI...
-
Page 2: Safety Instructions
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. • Explanation of Graphical Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert you to the presence of uninsulated “dangerous voltage”... - Page 3 This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product. 2. IMPORTANT : When connecting this product to accessories and/or another product use only high quality shielded cables.
- Page 4 Using this unit with a higher voltage than specified is dangerous and may result in fire or other accidents. YAMAHA will not be held responsible for any damage resulting from the use of this unit with a voltage other than that specified.
-
Page 5: Table Of Contents
Digital Sound Field Processor (DSP) Dolby Digital Decoder Dolby Pro Logic Decoder CINEMA DSP: Theater-like Sound Experience by the Combination of YAMAHA DSP Technology and Dolby Digital or Dolby Pro Logic Automatic Input Balance Control for Dolby Pro Logic decoding... -
Page 6: Getting Started
Checking the Package Contents Check that the following items are included in your package. Remote control Battery Installation in the Remote Control Turn the remote control over and slide the battery compartment cover in the direction of the arrow. Insert the batteries (AAA, R03 or UM-4 type) according the polarity markings on the inside of the battery compartment. - Page 7 Using the Remote Control Remote control sensor Within approximately 6 m (20 feet) The remote control transmits a directional infrared beam. Be sure to aim the remote control directly at the infrared sensor during operation. When the sensor is covered or there is a large object between the remote control and the sensor, the sensor cannot receive signals.
-
Page 8: Controls And Functions
Front Panel – STANDBY/ON Press this switch to turn on the power of this unit or to set this unit in the standby mode. Before turning the power on, set VOLUME to the “m” position. Standby mode In this mode, this unit consumes a very small quantity of power to receive infrared-signals from the remote control. -
Page 9: Controls And Functions
Tone controls These controls are only effective for the sound from the main speakers. a) BASS Turn this control clockwise to increase or counterclockwise to decrease the low-frequency response. The “0” position produces a flat response. b) TREBLE Turn this control clockwise to increase or counterclockwise to decrease the high-frequency response. - Page 10 CONTROLS AND FUNCTIONS Display g and o indicators “ g ” lights up when the built-in Dolby Digital decoder is on and the signals of the selected source are encoded with Dolby Digital. “ o ” lights up when the built-in Dolby Pro Logic decoder is on. DSP program indicators The name of the selected DSP program lights up.
-
Page 11: Remote Control
Remote Control This section describes basic operation of this unit with the remote control. First, press AMP(TUNER) on the component selector. Refer to “PRESET REMOTE CONTROL” on page 38 for full details. Indicator This flashes in red when pressing a button on the remote control. -
Page 12: Preparation
LFE (low frequency effect) channel with high fidelity when playing back a source encoded with Dolby Digital. The YAMAHA Active Servo Processing Subwoofer System is ideal for natural and lively bass reproduction. -
Page 13: Connections
When you connect other YAMAHA audio components (such as a tape deck, MD recorder and CD player or changer), connect it to the terminals with the same number labels as !, #, $ etc. YAMAHA applies this labeling system to all its products. -
Page 14: Indoor/Outdoor Fm Antenna
CONNECTIONS Connecting the Antennas Both AM and FM indoor antennas are included with this unit. In general, these antennas should provide sufficient signal strength. However, a properly installed outdoor antenna provides clearer reception than an indoor one. If you experience poor reception quality, an outdoor antenna may improve the quality. -
Page 15: Connecting The Am Loop Antenna
AM loop antenna (included) AM loop antenna Connecting the AM loop antenna Antenna stand Outdoor AM antenna Vinyl covered wire (5 m to 10 m) Ground (GND terminal) The AM loop antenna can be removed from the stand and attached to a wall, etc. However, note that the reception sensitivity may deteriorate if the antenna is attached to a metal or steel reinforced wall. -
Page 16: Connecting To An External Decoder
CONNECTIONS Connecting an Audio Component OUTPUT LINE OUT Tape deck or CD player MD recorder Connecting to an External Decoder External decoder MAIN SURROUND CENTER Be sure to connect the right channel (R), left channel (L), input (IN) and output (OUT) properly. (U.S.A. - Page 17 Connecting a Video Component DVD/LD player ANALOG VIDEO COAXIAL AUDIO OUT DIGITAL OUT AUDIO Audio signal terminals Be sure to connect the right channel (R), left channel (L), input (IN) and output (OUT) properly. Video signal terminals Be sure to connect the input (IN) and output (OUT) properly.
-
Page 18: Connecting Speakers
Connecting Speakers Right Subwoofer connection If you have a subwoofer with built- in amplifier, including the YAMAHA Active Servo Processing Subwoofer System, connect the input terminal of the subwoofer system to the SUBWOOFER OUTPUT terminal of this unit. Be sure to connect the right channel (R), left channel (L), “+”... - Page 19 Speaker cables 10 mm (3/8”) Connecting to the MAIN SPEAKERS terminals Red: positive (+) Black: negative (–) Connecting to the REAR and CENTER SPEAKERS terminals Red: positive (+) Black: negative (–) Remove approx. 10 mm (3/8”) of insulation from each of the speaker cable. Twist the exposed wires of the cable together to prevent short circuits.
-
Page 20: Impedance Selector Switch
CONNECTIONS IMPEDANCE SELECTOR Switch WARNING Do not change the IMPEDANCE SELECTOR switch setting while the power to this unit is on, otherwise the unit may be damaged. If this unit fails to turn on when STANDBY/ON is pressed, the IMPEDANCE SELECTOR switch may not be fully slide to either position. -
Page 21: Adjusting The Speaker Balance
ADJUSTING THE SPEAKER BALANCE This procedure lets you adjust the sound output level balance between the main, center and rear speakers by using the built-in test tone generator. When this adjustment is performed, the sound output level heard at the listening position will be the same from each speaker. - Page 22 ADJUSTING THE SPEAKER BALANCE Adjust BALANCE on the front panel so that the sound output level of the right main speaker and the left main speaker is the same. Press TIME/LEVEL repeatedly to select the speaker to be adjusted. “CENTER”, “R SUR.” or “L SUR.”...
-
Page 23: Basic Operation
BASIC OPERATION When using the remote control, press AMP(TUNER) on the component selector. – – Set VOLUME to the “m” position. Turn the power on. Front panel Press SPEAKERS A or B to select the main speakers to be used. If you use two main speaker systems, press both A and B. -
Page 24: Playing A Source
PLAYING A SOURCE Play the source. Refer to the instructions for the source component (and page 26 for details about tuning). Note • When controlling an audio/video component (tape deck, MD recorder, CD player, DVD/LD player, etc.) with the remote control, press one of the component selector buttons, (TAPE/MD, CD, DVD/LD, etc.), which corresponds to the component you want to control. - Page 25 Input Mode (for the DVD/LD and TV/ digital TV and satellite tuner sources) This unit allows you to switch the input mode for sources that send both digital and analog signals to this unit. The AUTO and ANALOG input modes are provided. When you turn on the power of this unit, the input mode for the DVD/LD source is always set to AUTO and for TV/ digital TV or satellite tuner source is set according to “SAT...
-
Page 26: Digital Sound Field Processor (Dsp) Effect
DIGITAL SOUND FIELD PROCESSOR (DSP) EFFECT Selecting a DSP Program You can enhance your listening experience by selecting a DSP program. Refer to pages 23 to 25 for details about each program. – – On the front panel Make sure that the effect speakers (center, rear, and subwoofer) are turned on. -
Page 27: Sound Field Program
This unit incorporates a sophisticated, multi-program digital sound field processor (DSP). This processor allows you to electronically expand and change the shape of the audio sound field from both audio and video sources, creating a theater- like experience in your listening room. You can create outstanding audio sound by selecting a suitable DSP program (this will, of course, depend on what you are listening to). - Page 28 SOUND FIELD PROGRAM PROGRAM MOVIE [1] 70 mm SPECTACLE THEATER 1 ( o x ) • Input source: • Output channel: • DSP: [2] DGTL SPECTACLE ( g x ) • Input source: • Output channel: • DSP: [3] 70 mm SCI-FI ( o x ) •...
- Page 29 PROGRAM MONO MOVIE • Input source: Monaural • Output channel: 1 channel • DSP: TV SPORTS • Input source: Audio/Video • Output channel: 2 to 5.1 channels • DSP: 2 to 3 (presence & surround) For Hi-Fi audio sources PROGRAM DISCO •...
-
Page 30: Tuning
Automatic tuning is effective when station signals are strong and there is no interference. However, if the signal from the station you want to select is weak, you must tune in to it manually (manual tuning). – – Automatic Tuning Use INPUT to select the tuner as the input source. - Page 31 Automatic Preset Tuning (for FM stations only) You can make use of the automatic preset tuning function for FM stations only. This function enables the unit to automatically tune in with strong signals and to sequentially store up to 40 FM stations (5 groups x 8 stations). –...
-
Page 32: Manual Preset Tuning
TUNING Manual Preset Tuning You can also store up to 40 stations (5 groups x 8 stations) manually. – – Tune in to the desired station. Refer to page 26 for the tuning procedure. Press MEMORY. The “MEMORY” indicator flashes for about five seconds. -
Page 33: Exchanging Preset Stations
Exchanging Preset Stations You can exchange the assignment of two preset stations with each other. Example: If you want to exchange preset station “E1” with “A5”. – – Recall preset station “E1”. Refer to the procedure in the section “To Recall a Preset Station”... -
Page 34: Recording A Source On Tape, Md Or Video Cassette
RECORDING A SOURCE ON TAPE, MD OR VIDEO CASSETTE Recording adjustments and other operations are performed from the tape deck, MD recorder or VCR. Refer to the instructions for these components. – – Set VOLUME to the “m” position. Select the source you want to record. Front panel Begin recording by the tape deck, MD recorder or VCR connected to this unit. -
Page 35: Advanced Operation
ADVANCED OPERATION This unit provides you with the following items in the SET MENU to maximize the performance of your system and expand your enjoyment for audio listening and video watching. 1. CENTER SP 2. REAR SP 3. MAIN SP 4. -
Page 36: Set Menu
SET MENU Description of Each Item 1. CENTER SP Choices: LRG (Large)/SML (Small)/NONE Preset position: LRG (Large) LRG (Large) Select this position if your center speaker is approximately the same size as the main speakers. In this position, full- range signals on the center channel are directed to the center speaker. - Page 37 5. MAIN LVL Choices: NORM (Normal)/–10 dB Preset position: NORM (Normal) NORM (Normal) Normally select this position. –10 dB Select this position if the sound output from the main speakers is too loud and cannot be balanced with the sound output from the center and rear speakers.
- Page 38 SET MENU 8. CNTR DELAY (Adjusting the delay of the center sound) Control range: 0 ms to 5 ms (in 1 ms steps) Preset value: 0 ms Note • This adjustment is only effective when Dolby Digital is being decoded and the selected source encoded with Dolby Digital contains center channel signals.
-
Page 39: Delay Time And Speaker Output Levels
DELAY TIME AND SPEAKER OUTPUT LEVELS When using the digital sound field processor with the Dolby Pro Logic decoder or Dolby Digital decoder, you can adjust the delay time between the main sound and sound effect, and each speaker’s output level as you wish. Delay Time You can adjust the time difference between the beginning of the sound from the main speakers and the beginning of the... -
Page 40: Delay Time And Speaker Output Levels
DELAY TIME AND SPEAKER OUTPUT LEVELS Adjusting Method Adjustments should be performed with the remote control while watching the information on the display. Press AMP(TUNER) on the component selector. Press TIME/LEVEL repeatedly to select the item you want to adjust. Each time you press TIME/LEVEL, the selected item changes and appears on the display as below. -
Page 41: Sleep Timer
The SLEEP timer can be used to automatically set this unit in the standby mode. This timer is useful when you are going to sleep while enjoying a broadcast or other desired input source. The SLEEP timer can only be set with the remote control. -
Page 42: Preset Remote Control
The provided remote control is factory set to control not only this unit but also most YAMAHA audio components connected to it. There are eight component selector buttons. Press one of these buttons which corresponds to the component you want to control with the remote control. -
Page 43: Preset Remote Control
POWER (TAPE) This button turns this unit on if you have set the code for a YAMAHA tape deck. This button turns on the tape deck that has a remote control with a power button if you have set the code for another manufacturer. - Page 44 POWER This button turns this unit on if you have set the code for a YAMAHA CD player. This button turns on the CD player that has a remote control with a power button if you have set the code for another manufacturer.
- Page 45 Press DVD/LD. POWER (DVD) This button turns this unit on if you have set the code for a YAMAHA DVD player. This button turns on the DVD player that has a remote control with a power button if you have set the code for another manufacturer.
-
Page 46: Vcr Mode
PRESET REMOTE CONTROL VCR MODE Note • TV VOLUME, TV INPUT and TV SLEEP function if you have set the code for your TV. VCR POWER VCR CHANNEL +/– VOLUME MUTE TV SLEEP VCR REC Press this button twice to start recording. -
Page 47: Setup Codes
Advanced Information Setup codes You can set the code for the manufacturer of your component after pressing the component selector buttons other than AMP(TUNER). Turn on your component to be used. Press one of the component selector buttons which corresponds to the component to be controlled. - Page 48 0101 CBL/SAT Satellite tuner 0006 0002 DVD/LD DVD player 0008 (YAMAHA DVD player) CD player 0005 (YAMAHA CD player) TAPE/MD Tape deck 0004 (YAMAHA Tape deck) We recommend that you write all the code numbers you have set on the “Quick Reference Card”.
-
Page 49: Appendix
If the unit fails to operate normally, check the following points to determine whether the fault can be corrected by the simple measures suggested. If it cannot be corrected, or if the fault is not listed in the SYMPTOM column, disconnect the power cord and contact your authorized YAMAHA dealer or service center. General... - Page 50 TROUBLESHOOTING SYMPTOM No sound from the “BASS OUT” in the SET MENU is set to the subwoofer. SW or MAIN position when playing a 2-channel source. The source does not contain low bass signals (below 90 Hz). A “humming” sound can Incorrect cable connections.
- Page 51 Remote control SYMPTOM The remote control does Direct sunlight or lighting (from an inverter not work. type of fluorescent lamp, etc.) is striking the remote control sensor of this unit. The batteries are weak. The unit or other The component to be controlled has not been component cannot be selected.
-
Page 52: Specifications
AUDIO SECTION • Minimum RMS Output Power 20 Hz to 20 kHz, 0.06% THD, 8 ohms Main L/R, Center, Rear L/R ... 60 W 1 kHz, 0.09% THD, 8 ohms Main L/R, Center, Rear L/R ... 70 W*/65 W • Maximum Output Power (EIAJ) 1 kHz, 10% THD, 8 ohms ... -
Page 53: Glossary
Dolby Surround or Dolby Digital. The YAMAHA “CINEMA DSP” logo indicates those programs that are created by the combination of YAMAHA DSP technology and Dolby Surround or Dolby Digital. LFE 0.1 Channel This channel is for reproduction of low bass signals. The frequency range for this channel is 20 Hz to 120 Hz. -
Page 54: Index
Accessories ... 2 AC outlet ... 16 Antennas ... 10, 11 BALANCE ... 20 BGV (background video) function ... 20 Canceling sound effect ... 22 CINEMA DSP ... 25, 49 Connections Antennas ... 10, 11 Audio components (tape deck/MD recorder and CD player) ... - Page 55 LIST OF MANUFACTURER’S CODES LISTES DES CODES FABRICANT Elin Elta A-Mark 1161 Emerson A Tandy 0941 Abex 1151 Admira 1141 Adventura 1131 Aiko 1121 Akai 0331, 1101, 1111 Alba 0431 Alleron 1091 Envision Ambassador 1081 Erres Amstrad 0481, 1081 Etron Anam 0251, 1041, 1051, Ferguson...
- Page 56 0971, 0991, 1031, Spectavision 1091, 1111, 1771 Standard Components 0186 Watson 1001 Starcom V Xogego 1611, 1621, 1661, Stargate 1741, 1761 Sylvania/Texscan Yamaha 0221, 0361, 0571, Teknika 1031, 1111, 1141, Teleservice 1381 Teleview Yoko 1001 Texscan Zenith 0011, 0041, 0891,...
- Page 57 0242, 0612, 0842, Realistic 0902, 0922 Sharp 0002, 0282 Sony Schneider 0852 Victor Scott 0342, 0712, 0762, Yamaha 0872, 0882, 0892 Sears 0302, 0592, 0602, CD PLAYER 0612, 0682, 0692, 0842, 0902, 0912, Acoustic Research 0932 Sharp 0402, 0472 Adcom...
- Page 58 YAMAHA ELECTRONIQUE FRANCE S.A. RUE AMBROISE CROIZAT BP70 CROISSY-BEAUBOURG 77312 MARNE-LA-VALLEE CEDEX02, FRANCE YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD1 7JS, ENGLAND YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN Printed in Malaysia ID V502730-2 YAMAHA MUSIC AUSTRALIA PTY, LTD.
-
Page 59: Quick Reference Card
Quick Reference Card AMP(TUNER) POWER POWER Input selector buttons A/B/C/D/E EFFECT TEST PRESET+/– VOLUME VOLUME TV VOLUME MUTE MUTE SLEEP SLEEP TV INPUT REC/PAUSE +/– PLAY PRG+, DIR A (TAPE) PRG– SKIP– (MD) TIME LEVEL REWIND (TAPE) SEARCH (MD) MENU TAPE/MD POWER Input selector... - Page 60 Quick Reference Card DVD MENU POWER Numeric buttons CLEAR CHANNEL+/– DISC SKIP+/– VOLUME VOLUME TV VOLUME MUTE RETURN TV SLEEP INDEX TV INPUT VCR REC MENU UP MENU SELECT VCR PLAY MENU LEFT MENU RIGHT TITLE MENU REWIND MENU DOWN Press this button twice to start recording.
- Page 61 Connection Guide (when listening to a digital 5.1-channel source) DVD player AUDIO OUT VIDEO OUT DIGITAL OUT COAXIAL VIDEO COAXIAL DIGITAL OUT ANALOG AUDIO OUT VIDEO IN TV Monitor LD player DOLBY DOLBY DIGITAL DIGITAL OPTICAL RF OUT RF OUT OPTICAL DOLBY DIGITAL DIGITAL OUT...
