Page 1 ___________________ Introduction ___________________ Safety Information ___________________ System overview of SIMATIC Ident SIMATIC RF600 ___________________ RF600 system planning RFID systems SIMATIC RF600 ___________________ Readers ___________________ Antennas System Manual ___________________ Transponder ___________________ Integration into networks ___________________ System diagnostics ___________________ Accessories ___________________ Appendix 11/2018 J31069-D0171-U001-A21-7618...
Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
Page 3: Table Of Contents
Table of contents Introduction ............................13 Preface ............................ 13 Abbreviations and naming conventions .................. 14 Safety Information ..........................15 General safety instructions ..................... 15 Safety instructions for third-party antennas as well as for modifications to the RF600 system ............................. 19 Safety distance to transmitter antenna ...................
Page 4 Table of contents 4.3.9.4 Types of antenna ........................53 4.3.9.5 Antenna cables ........................53 Environmental conditions for transponders ................55 The response of electromagnetic waves in the UHF band ............ 55 4.5.1 The effect of reflections and interference ................55 4.5.2 Influence of metals .........................
Page 5 Table of contents 5.2.1.6 Pin assignment of the Industrial Ethernet interface (X1 P1) ..........104 5.2.2 Planning operation ........................ 104 5.2.2.1 Internal antenna ........................104 5.2.2.2 Interpretation of directional radiation patterns ..............109 5.2.3 Installing/mounting ........................ 110 5.2.4 Configuration/integration ....................... 111 5.2.5 Technical specifications ......................
Page 6 Table of contents SIMATIC RF685R ........................ 169 5.5.1 Description ........................... 169 5.5.1.1 Overview ..........................169 5.5.1.2 Ordering data ........................170 5.5.1.3 Pin assignment of the DI/DQ interface (X10 DI/DQ) ............171 5.5.1.4 Switching scheme for the DI/DQ interface ................172 5.5.1.5 Pin assignment of the RS422 interface (X80 DC24V) ............
Page 7 Table of contents 6.3.8 Dimension drawing ....................... 242 6.3.9 Approvals & certificates ......................243 SIMATIC RF640A ......................... 244 6.4.1 Characteristics ........................244 6.4.2 Ordering data ........................245 6.4.3 Installation ..........................245 6.4.4 Connecting the antenna ......................246 6.4.5 Antenna parameter assignment .................... 247 6.4.5.1 Setting RF640A parameters for RF650R................
Page 8 Table of contents 6.7.5 Antenna parameter assignment ................... 302 6.7.6 Antenna patterns ........................304 6.7.7 Technical data ........................307 6.7.8 Dimension drawing ......................309 6.7.9 Approvals & certificates ....................... 310 SIMATIC RF680A ........................ 311 6.8.1 Characteristics ........................311 6.8.2 Ordering data ........................312 6.8.3 Installation ..........................
Page 9 Table of contents SIMATIC RF690L Smartlabel ....................364 7.5.1 Characteristics ........................364 7.5.2 Ordering data ........................364 7.5.3 Memory organization ......................365 7.5.4 Technical specifications ......................365 7.5.5 Dimension drawing ....................... 367 7.5.6 Certificates and approvals ....................368 SIMATIC RF610T ......................... 369 7.6.1 Features ..........................
Page 10 Table of contents 7.11 SIMATIC RF630T......................... 399 7.11.1 Characteristics ........................399 7.11.2 Ordering data ........................400 7.11.3 Planning application ......................400 7.11.3.1 Optimum antenna/transponder positioning ................400 7.11.3.2 Range when mounted on flat metallic carrier plates ............402 7.11.4 Technical specifications ....................... 403 7.11.5 Dimension drawing ......................
Page 11 Table of contents 7.15.3.3 Range when mounted on flat metallic carrier plates ............. 442 7.15.4 Technical specifications ......................443 7.15.5 Dimension drawing ....................... 445 7.15.6 Certificates and approvals ....................446 Integration into networks ........................447 Overview of parameterization of RF600 reader ..............447 Integration in IT networks via the user application ...............
Page 12 Table of contents SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 13: Introduction
Do not dispose of the products at public disposal sites. For environmentally compliant recycling and disposal of your electronic waste, please contact a company certified for the disposal of electronic waste or your Siemens representative. Note the different country-specific regulations.
Page 14: Abbreviations And Naming Conventions
Introduction 1.2 Abbreviations and naming conventions History Currently released versions of the SIMATIC RF600 system manual: Edition Comment 11/2005 First edition 10/2014 15th revised and extended edition: New readers RF650R, RF680R and RF685R 07/2015 16th revised and extended edition 10/2015 17th revised and extended edition: Approval for the readers RF650R, RF680R, and RF685R 12/2015...
Page 15: Safety Information
Safety Information General safety instructions Note Heed the safety notices Please observe the safety instructions on the back cover of this documentation. SIMATIC RFID products comply with the salient safety specifications to VDE/DIN, IEC, EN, UL and CSA. If you have questions about the admissibility of the installation in the designated environment, please contact your service representative.
Page 16 Safety Information 2.1 General safety instructions Operating temperature CAUTION Increased temperatures on the lower casing Note that the lower casing of the readers is made of metal. This means that temperatures can occur on the lower casing that are higher than the maximum permitted operating temperature.
Page 17 Safety Information 2.1 General safety instructions Lightning protection CAUTION Installation only in protected areas Antennas and readers can be installed in the protected part of a building. When implementing your lightning protection concept, make sure you adhere to the VDE 0182 or IEC 62305 standards.
Page 18 Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customers’...
Page 19: Safety Instructions For Third-Party Antennas As Well As For Modifications To The Rf600 System
Safety Information 2.2 Safety instructions for third-party antennas as well as for modifications to the RF600 system Safety instructions for third-party antennas as well as for modifications to the RF600 system Always observe the following general safety instructions before selecting a component from a different vendor: The manufacturer accepts no responsibility for functional suitability or legal implications for the installation of third-party components.
Page 20: Safety Distance To Transmitter Antenna
Safety Information 2.3 Safety distance to transmitter antenna Note User responsibility for modified product As a user of the modified product, you accept responsibility for use of the complete RFID product comprising both SIMATIC RF600 components and third-party RFID components. This particularly applies to modification or replacement of: •...
Page 21: Minimum Distance To Antenna In Accordance With Etsi
Safety Information 2.3 Safety distance to transmitter antenna 2.3.2 Minimum distance to antenna in accordance with ETSI Minimum distance to antenna in accordance with ETSI (EU, EFTA, Turkey) At a transmission frequency of 900 MHz, the wavelength of the electromagnetic wave λ is approximately 0.34 m.
Page 22: Minimum Distance To Antenna In Accordance With Fcc (Usa)
The SIMATIC RF685R (ETSI) reader has a maximum radiated power of 2 W ERP. The safety clearance is therefore at least 0.24 m. When using Siemens products and with suitable configuration via the WBM, the high limits cannot be exceeded.
Page 23 The SIMATIC RF685R (CC) reader has a maximum transmit power of 2 W. This means that the safety distance is at least 0.12 m. When using Siemens products and with suitable configuration via the WBM, the high limits cannot be exceeded.
Page 24 Safety Information 2.3 Safety distance to transmitter antenna SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 25: System Overview Of Simatic Rf600
System overview of SIMATIC RF600 SIMATIC RF600 is an identification system that operates in the UHF range. UHF technology supports large write/read distances with passive transponders. The general automation and IT structure of a company is shown in the following figure. This comprises several different levels that are described in detail below.
Page 26: Application Areas Of Rf600
System overview of SIMATIC RF600 3.1 Application areas of RF600 ● Acquisition level This level contains the RFID readers that read the appropriate transponder data and transfer it to the next higher level. ● Control level At the control level, the RFID data is collected, preprocessed and made available to the production control and business administration control levels for further processing.
Page 27: System Components
System overview of SIMATIC RF600 3.2 System components System components Table 3- 1 System components of the RF600 product series Product photo Description SIMATIC RF615R RF615R reader is suitable for applications in production logistics and distribution. It is charac- terized by a very compact size - with reduced transmit power - as well as an internal antenna. It is integrated for distribution via Ethernet with the XML protocol or OPC UA.
Page 28 System overview of SIMATIC RF600 3.2 System components Product photo Description SIMATIC RF650M The RF650M mobile reader expands the identification system RF600 with a powerful handheld terminal for applications in the areas of logistics, production and service. In addi- tion, it is an indispensable aid for commissioning and testing. SIMATIC RF615A and RF620A SIMATIC RF615A and RF620A are linear antennas with a very compact design suitable for industry.
Page 29 System overview of SIMATIC RF600 3.2 System components Product photo Description SIMATIC RF660A SIMATIC RF660A is a powerful circular antenna for production and logistics applications. SIMATIC RF680A SIMATIC RF680A is an antenna whose polarization can be changed (circular, linear horizon- tal or linear vertical) of medium size for universal use in industrial applications in production and logistics.
Page 30: Features
PROFIBUS external antennas Depends on the connected antenna and the transponder being used Certificates RF600 readers support the following certificates and approvals: ● RF615R certificates (https://support.industry.siemens.com/cs/ww/en/ps/25391/cert) ● RF650R certificates (https://support.industry.siemens.com/cs/ww/en/ps/15085/cert) ● RF680R/RF685R certificates (https://support.industry.siemens.com/cs/ww/en/ps/15088/cert) SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 31 System overview of SIMATIC RF600 3.3 Features Table 3- 4 Characteristics of the RF650M mobile reader Transmission frequency ETSI: 865 to 868 MHz • FCC: 902 to 928 MHz • CMIIT: 920 to 925 MHz • Read/write distance Standards ISO 18000-63 Table 3- 5 Characteristics of the transponders Version...
Page 32 System overview of SIMATIC RF600 3.3 Features SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 33: Rf600 System Planning
RF600 system planning Overview You should observe the following criteria for implementation planning: ● Possible system configurations ● Antenna configurations ● Environmental conditions for transponders ● The response of electromagnetic waves in the UHF band ● Regulations applicable to frequency bands ●...
Page 34: Intralogistics Scenario
RF600 system planning 4.2 Possible system configurations 4.2.1 Intralogistics scenario This scenario describes the transport of material via conveyor systems that are made up of large numbers of standard elements. They are characterized by long distances, frequent branches (separators, infeed and outfeed), standardized transport containers and high movement speeds.
Page 35 RF600 system planning 4.2 Possible system configurations Intralogistics (separator) ① ④ Power supply using Power over Ethernet Separator setting by means of DQ ② ⑤ Distributed small gate Individual read point ③ ⑥ Trigger by light barrier on DI Mobile data acquisition Figure 4-2 Scenario: Intralogistics (separator) In this example scenario, items must be distributed to the correct storage location in a...
Page 36: Scenario For Workpiece Identification
RF600 system planning 4.2 Possible system configurations 4.2.2 Scenario for workpiece identification A typical characteristic of modern manufacturing scenarios is their multitude of variations. The individual data and production steps are stored in the transponder of a tool holder or product.
Page 37: Goods Tracking Scenario
RF600 system planning 4.2 Possible system configurations identification quality of the wanted transponders while reducing the identification of unwanted transponders. 4.2.3 Goods tracking scenario In this scenario, a gate consisting of a SIMATIC RF650R reader and four antennas checks the goods passing through the gate. All stored goods are equipped with transponders. A traffic light indicates whether the goods may leave the warehouse.
Page 38: Scenario Incoming Goods, Distribution Of Goods And Outgoing Goods
RF600 system planning 4.2 Possible system configurations 4.2.4 Scenario incoming goods, distribution of goods and outgoing goods The scenario consists of an RFID system with three readers. The SIMATIC RF650R reader with its four antennas identifies the incoming/outgoing products at the incoming/outgoing goods gates of a factory building hall through which pallets are delivered.
Page 39: Antenna Configurations
RF600 system planning 4.3 Antenna configurations After the sorter, the goods are loaded onto pallets - each pallet is fitted with a transponder. These transponders also contain user data that provides information about the sender and receiver of the goods. Based on the data read by the SIMATIC RF650R reader, there is a check to make sure that the correct pallets for the specific receiver are available at the outgoing goods gate.
Page 40: Antenna Configuration Example
RF600 system planning 4.3 Antenna configurations 4.3.1 Antenna configuration example The following figure shows an example of an application with an antenna configuration of the RF650R. The antennas are positioned at the height at which the transponders to be identified are expected. The maximum width of the portal recommended for reliable operation is 4 m.
Page 41: Possibilities And Application Areas For Antenna Configurations
RF600 system planning 4.3 Antenna configurations 4.3.2 Possibilities and application areas for antenna configurations Some basic antenna configurations and possible fields of application are shown below. With the various configurations, please note that up to four external antennas can be connected to the RF650R and F680R readers, while one external antenna can be connected to the RF615 and RF685R readers.
Page 42 RF600 system planning 4.3 Antenna configurations Antenna configuration 2 Description/ application areas This arrangement of antennas is appro- priate when the transponders to be read are only located on one side of the items to be identified, e.g. when pallets are to be identified and it is known on which side the transponders to be read are located.
Page 43 RF600 system planning 4.3 Antenna configurations Antenna configuration 4 Description/ application areas Preferred for the identification of goods at loading gates: Similar to configuration 2, but with additional reading reliability when the transponder is at an angle to the vertical. ①...
Page 44 RF600 system planning 4.3 Antenna configurations Antenna configuration 6 Description/ application areas Preferred for the identification of goods at loading gates: Similar to configuration 4, but the reliability of transponder identi- fication is improved as a result of the four antennas at separate locations, so the transponder position is not critical.
Page 45: Transponder Orientation In Space
RF600 system planning 4.3 Antenna configurations 4.3.3 Transponder orientation in space The alignment of the transponder antenna to the antenna of the reader influences the reading range. For maximum performance and to achieve the maximum read range, the transponder antenna should therefore be aligned parallel to the reader antenna: Parallel transponder alignment Large reading range The probability of identification of the tran-...
Page 46: Specified Minimum And Maximum Spacing Of Antennas
RF600 system planning 4.3 Antenna configurations 4.3.4 Specified minimum and maximum spacing of antennas Specified minimum spacing of antennas The following diagram shows the specified minimum and maximum spacings for mounting antennas: Between the antenna and liquids or metals, a minimum distance of 50 cm should be kept to. The distance between the antenna and the floor should also be at least 50 cm.
Page 47: Reciprocal Influence Of Read Points
RF600 system planning 4.3 Antenna configurations 4.3.5 Reciprocal influence of read points Antenna alignment and resulting antenna spacing The minimum distance required between antennas that use the same frequency and that are connected to different readers depends on the maximum transmit power set and the antenna alignment.
Page 48: Read And Write Range
RF600 system planning 4.3 Antenna configurations Antenna spacing with portal configuration In the portal configuration, multiple antennas are connected to one reader. In this case, the antennas must not exceed the maximum distance to one another. Table 4- 2 Maximum antenna spacing of the external antennas with a portal configuration Antenna Antenna alignment Maximum distance (D)
Page 49: Static/Dynamic Mode
RF600 system planning 4.3 Antenna configurations Factors Description Reflection characteristics of the envi- In a multiple-reflection environment (e.g., in rooms with ronment reflecting surfaces, machinery, or concrete walls), the read- ing range can be significantly higher than in a low-reflection environment.
Page 50: Operation Of Several Readers Within Restricted Space
RF600 system planning 4.3 Antenna configurations 4.3.8 Operation of several readers within restricted space 4.3.8.1 Using more than one reader When mounting the readers make sure that there is a minimum clearance of 0.5 m between the readers to avoid them influencing each other. Avoiding problems When several RFID readers are used, there is a danger that RFID transponders can also be read out by other readers.
Page 51: Frequency Hopping
RF600 system planning 4.3 Antenna configurations 4.3.8.3 Frequency hopping This technique is intended to prevent mutual interference between readers. The reader changes its transmission channel in a random or programmed sequence (FHSS). Procedure for FCC Frequency hopping is always active in the FCC country profile. With 50 available channels the probability is low that two readers will be operating on the same frequency.
Page 52: General Application Planning
RF600 system planning 4.3 Antenna configurations Purpose of this chapter This section will help you to select the suitable antenna or the suitable cable taking into account all important criteria and to make the relevant settings in the configuration software/WBM of the SIMATIC RF600 system. Correct and safe integration into the SIMATIC RF600 system is only possible following adaptation of all required parameters.
Page 53: Types Of Antenna
With the readers, the parameters for the transmit/radiated power, antenna gain and cable loss (user-defined) are set using the WBM. In the WBM, you can select the Siemens products being used from a drop-down list quickly and easily, and the values and their effect on the transmit/radiated power are calculated directly.
Page 54 RF600 system planning 4.3 Antenna configurations Antenna cable loss In order to be able to transmit the available UHF power from the RF600 reader to the antenna or antennas, the antenna cable loss should not exceed a value of approx. 5 dB. Dependency of the cable loss The cable loss depends on two important factors: ●...
Page 55: Environmental Conditions For Transponders
RF600 system planning 4.4 Environmental conditions for transponders Environmental conditions for transponders Basic rules The transponder must not be placed directly on metal surfaces or on containers of liquid. The on-metal transponders designed specifically for use in metallic environments are an exception to this.
Page 56: Influence Of Metals
RF600 system planning 4.5 The response of electromagnetic waves in the UHF band Reducing the effect of reflections/interference on transponder identification ● Reducing the transmit power: To minimize interference, we recommend that the transmit power of the reader is reduced until it is sufficient for an identification rate of 100%.
Page 57: Influence Of Liquids And Non-Metallic Substances
RF600 system planning 4.5 The response of electromagnetic waves in the UHF band This effect depends very much on the transmitted power, the components being used (cable, antenna) and the distance from the metallic surface to the antenna. In this case, repositioning/realigning the antenna or reducing the radiated power can remedy the situation.
Page 58: Planning And Installation Of Uhf Read Points
RF600 system planning 4.6 Planning and installation of UHF read points Planning and installation of UHF read points Due to their comparatively large effective range, RFID UHF systems (frequency band 865 - 928 MHz) have different requirements in terms of planning, commissioning and operation compared with the HF systems commonly used up to now in automation (frequency band 13.56 MHz).
Page 59 RF600 system planning 4.6 Planning and installation of UHF read points ● distance between antenna and transponder, ● reflections, ● noise level in the channel used and in neighboring channels The RSSI value is important for the automatic evaluation of the read point and for filtering. A simple comparison of the RSSI values of two transponders is nevertheless not possible because the values are influenced by the transponder tolerances and the non-homogeneous antenna field.
Page 60: Implementation Of Uhf Rfid Installations
RF600 system planning 4.6 Planning and installation of UHF read points Properties of the transmitting antenna Depending on their design, UHF RFID antennas provide different properties. They differ in the polarization and antenna gain. The direction of the electrical field component of an electromagnetic wave and the alignment of the antenna decide the polarization of the radiation.
Page 61: Preparation Phase
RF600 system planning 4.6 Planning and installation of UHF read points 4.6.2.1 Preparation phase Device selection When selecting the suitable RFID hardware, remember the following minimum criteria: ● Integration in a control/IT environment ● Degree of protection ● Size of the identification range ●...
Page 62: Test Phase
The read point setup described in this section is performed using the Web Based Management (WBM) and applies to the RF600 readers. You can find a detailed description of the WBM in the configuration manual "SIMATIC RF600 (https://support.industry.siemens.com/cs/ww/en/ps/15081/man)". SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 63 RF600 system planning 4.6 Planning and installation of UHF read points Adjust antennas Follow the steps below to optimize the antenna alignment: 1. Position the object fitted with a transponder and to be identified at the required read point. 2. Align the reader or the antenna so that its front points in the direction of the object (transponder) to be identified.
Page 64 RF600 system planning 4.6 Planning and installation of UHF read points 4. In the "RSSI display" area, you can see the current (light blue) and maximum reached (dark blue) RSSI values. Note Transponder is not identified If no transponder is identified, first increase the radiated power as described in the following section.
Page 65 RF600 system planning 4.6 Planning and installation of UHF read points Detect activation power Follow the steps below to detect the activation power: 1. In the "Settings - Activation power" menu item, select the connected antenna and click the "Start measurement" button. 2.
Page 66: Dealing With Field Disturbances
RF600 system planning 4.6 Planning and installation of UHF read points 4.6.3 Dealing with field disturbances 4.6.3.1 Types and approaches to solutions The superposition of radio waves and reflection by conductive materials (in particular metal) can lead to weakening or strengthening of the antenna field at certain points in space. These effects can lead to disruptions when identifying RFID transponders that can be distinguished as follows: ●...
Page 67: Measures For Eliminating Field Disturbances
RF600 system planning 4.6 Planning and installation of UHF read points ● Reader ↔ reader influence: Several readers influence or disturb each other during transponder identification. Approaches to solutions: – "Interconnect" neighboring readers so that they do not send at the same time –...
Page 68 RF600 system planning 4.6 Planning and installation of UHF read points Channel management To operate the readers, depending on the country profile, you have between four and fifty send channels available. Ideally, you should make the channel assignments manually in STEP 7 Basic / Professional (TIA Portal) or in the WBM.
Page 69: Chemical Resistance Of The Readers And Transponders
Aluminum Fiber-optic cable Makrolon®2405 Decorative membrane Autotex V200 Socket Brass (copper alloy) CuZn40Pb2 Non-relevant component for resistance of complete housing In case of questions please contact Siemens Support (section "Service & support (Page 490)"). SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 70: Pocan Cf2200
RF600 system planning 4.7 Chemical resistance of the readers and transponders 4.7.1.2 Pocan CF2200 The following table provides an overview of the chemical resistance of the Pocan CF2200. Table 4- 5 Resistance to chemicals - Pocan CF2200 Substance Test conditions Evaluation Concentration [%] Temperature [°C]...
Page 71 RF600 system planning 4.7 Chemical resistance of the readers and transponders Substance Test conditions Evaluation Concentration [%] Temperature [°C] Cleaning products Curd soap ++++ Detergent ++++ Cleaning products ++++ Salt solutions Sodium hypochloride ￮ Sea water ++++ Acids Hydrochloric acid 20 % Nitric acid ++++...
Page 72: Transponder
RF600 system planning 4.7 Chemical resistance of the readers and transponders 4.7.2 Transponder 4.7.2.1 Overview of the transponders and their housing materials The following sections describe the resistance to chemicals of the various transponders. Resistance to chemicals depends on the housing materials used to manufacture the transponders.
Page 73: Acrylonitrile/Butadiene/Styrene (Abs)
RF600 system planning 4.7 Chemical resistance of the readers and transponders 4.7.2.2 Acrylonitrile/butadiene/styrene (ABS) The following table provides an overview of the chemical resistance of the transponder made of acrylonitrile/butadiene/styrene (ABS). Table 4- 7 Resistance to chemicals - ABS Substance Test conditions Evaluation Concentration [%]...
Page 74: Polyamide 12 (Pa12)
RF600 system planning 4.7 Chemical resistance of the readers and transponders 4.7.2.3 Polyamide 12 (PA12) The following table provides an overview of the chemical resistance of the transponder made of polyamide 12. The resistance of the plastic housing to chemicals used in the automobile sector (e.g.: oils, greases, diesel fuel, gasoline, etc,) is not listed extra.
Page 75 RF600 system planning 4.7 Chemical resistance of the readers and transponders Substance Test conditions Evaluation Concentration [%] Temperature [°C] Lactic acid, w. 50 % 20 ℃ 10 % 20 ℃ 10 % 60 ℃ Sodium carbonate, w. (soda) c. s. 60 ℃...
Page 76: Polyamide 6.6 (Pa 6.6)
RF600 system planning 4.7 Chemical resistance of the readers and transponders 4.7.2.4 Polyamide 6.6 (PA 6.6) The following table provides an overview of the chemical resistance of the transponder made of polyamide 6.6 (PA 6.6). It must be emphasized that the plastic housing is extremely resistant to chemicals in automobiles (e.g.: oil, grease, diesel fuel, gasoline, ...) which are not listed separately.
Page 77: Polyamide 6.6 Gf (Pa 6.6 Gf)
RF600 system planning 4.7 Chemical resistance of the readers and transponders 4.7.2.5 Polyamide 6.6 GF (PA 6.6 GF) The following table provides an overview of the chemical resistance of the transponder made of polyamide 6.6 GF. Different values may apply to the stainless steel bolt head. It must be emphasized that the plastic housing is extremely resistant to chemicals in automobiles (e.g.: oil, grease, diesel fuel, gasoline, ...) which are not listed separately.
Page 78: Polyethylene Terephthalate (Pet)
RF600 system planning 4.7 Chemical resistance of the readers and transponders Substance Test conditions Evaluation Concentration [%] Temperature [°C] Sulfuric acid 25 % 20 ℃ ￮ 10 % 20 ℃ ￮ Hydrogen sulfide 20 ℃ ++++ 60 ℃ ￮ Carbon tetrachloride 1 ...
Page 79 RF600 system planning 4.7 Chemical resistance of the readers and transponders Substance Test conditions Evaluation Concentration [%] Temperature [°C] Dioxane 100 % 20 ℃ ++++ 100 % 60 ℃ ￮ Acetic acid conc. 20 ℃ ++++ conc. 60 ℃ conc. 80 ℃...
Page 80: Polypropylene (Pp)
RF600 system planning 4.7 Chemical resistance of the readers and transponders Substance Test conditions Evaluation Concentration [%] Temperature [°C] Water 20 ℃ ++++ Hydrogen peroxide 20 ℃ ++++ 20 ℃ ++++ Xylene 10 % 20 ℃ ++++ Zinc chloride 20 ℃ ++++ Explanation of the rating ++++...
Page 81 RF600 system planning 4.7 Chemical resistance of the readers and transponders Substance Test conditions Evaluation Concentration [%] Temperature [°C] Arsenic acid, w. 50 °C ++++ Ascorbic acid, w. 50 °C ++++ Gasoline 20 ℃ ￮ Benzene 20 ℃ ￮ Prussic acid, w. 50 °C ++++ Sodium hypochlorite solution...
Page 82 RF600 system planning 4.7 Chemical resistance of the readers and transponders Substance Test conditions Evaluation Concentration [%] Temperature [°C] Formaldehyde 10 % 50 °C ++++ 40 % 50 °C Formaldehyde solution 30 % 50 °C ++++ Glycerine 50 °C ++++ Glycol 50 °C ++++...
Page 83 RF600 system planning 4.7 Chemical resistance of the readers and transponders Substance Test conditions Evaluation Concentration [%] Temperature [°C] Phosphoric acid, w 20 % 50 °C ++++ Propane liquid 20 ℃ ++++ Propane gaseous 20 ℃ Mercury pure 50 °C ++++ Crude oil 100 %...
Page 84: Polyphenylene Sulfide (Pps)
RF600 system planning 4.7 Chemical resistance of the readers and transponders Explanation of the rating Water solution c. s. Cold saturated 4.7.2.8 Polyphenylene sulfide (PPS) The following table provides an overview of the chemical resistance of the transponder made of polyphenylene sulfide (PPS). The transponder has special chemical resistance to solutions up to a temperature of 200 °C.
Page 85: Polyvinyl Chloride (Pvc)
RF600 system planning 4.7 Chemical resistance of the readers and transponders Substance Test conditions Evaluation Concentration [%] Temperature [°C] 1, 1, 1-Trichloroethane 80 ℃ ++++ Xylene Zinc chloride (saturated) 80 ℃ 75 ℃ ++++ Explanation of the rating ++++ Resistant Practically resistant Conditionally resistant Less resistant...
Page 86: Regulations Applicable To Frequency Bands
Internet page: EPCglobal (http://www.gs1.org/docs/epcglobal/UHF_Regulations.pdf) You will find a list of all the country-specific approvals for SIMATIC RFID systems on the following Internet page: Wireless approvals of SIMATIC RFID systems (http://www.siemens.com/rfid-approvals) Guidelines for electromagnetic compatibility (EMC) 4.9.1 Overview These EMC directives answer the following questions: ●...
Page 87: What Does Emc Mean
RF600 system planning 4.9 Guidelines for electromagnetic compatibility (EMC) 4.9.2 What does EMC mean? The increasing use of electrical and electronic devices is accompanied by: ● Higher component density ● More switched power electronics ● Increasing switching rates ● Lower power consumption of components due to steeper switching edges The higher the degree of automation, the greater the risk of interaction between devices.
Page 88: Basic Rules
RF600 system planning 4.9 Guidelines for electromagnetic compatibility (EMC) 4.9.3 Basic rules It is often sufficient to follow a few elementary rules in order to ensure electromagnetic compatiblity (EMC). The following rules must be observed: Shielding by enclosure ● Protect the device against external interference by installing it in a cabinet or housing. The housing or enclosure must be connected to the chassis ground.
Page 89: Propagation Of Electromagnetic Interference
RF600 system planning 4.9 Guidelines for electromagnetic compatibility (EMC) ● Feed the connected shield through to the module without interruption. ● Use braided shields, not foil shields. Line and signal filter ● Use only line filters with metal housings ● Connect the filter housing to the cabinet chassis using a large-area low-HF-impedance connection.
Page 90 RF600 system planning 4.9 Guidelines for electromagnetic compatibility (EMC) Interference sources In order to achieve a high level of electromagnetic compatibility and thus a very low level of disturbance in a plant, it is necessary to recognize the most frequent interference sources. These must then be eliminated by appropriate measures.
Page 91: Equipotential Bonding
RF600 system planning 4.9 Guidelines for electromagnetic compatibility (EMC) What interference can affect RFID? Table 4- 16 Interference sources: Causes and remedies Interference source Cause Remedy Switched-mode power supply Interference emitted from the Replace the power supply current infeed Interference injected through Cable is inadequately shield- Better cable shielding the cables connected in...
Page 92: Cable Shielding
RF600 system planning 4.9 Guidelines for electromagnetic compatibility (EMC) Figure 4-17 Equipotential bonding (EBS = Equipotential bonding strip) The better the equipotential bonding in a plant, the smaller the chance of interference due to fluctuations in potential. Equipotential bonding should not be confused with protective earthing of a plant. Protective earthing prevents the occurrence of excessive contact voltages in the event of equipment faults whereas equipotential bonding prevents the occurrence of differences in potential.
Page 93 RF600 system planning 4.9 Guidelines for electromagnetic compatibility (EMC) Figure 4-18 Cable shielding The shielding bus should be connected to the control cabinet enclosure in a manner allowing good conductance (large-area contact) and must be situated as close as possible to the cable inlet.
Page 94 RF600 system planning 4.9 Guidelines for electromagnetic compatibility (EMC) Figure 4-20 Interruption of shielded cables If intermediate connectors, which do not have a suitable shield connection are used, the shield must be continued by fixing cable clamps at the point of interruption. This ensures a large-area, HF-conducting contact.
Page 95: Readers
Readers Overview The following table shows the most important features of the stationary RF600 readers at a glance: Table 5- 1 Characteristics of the readers Characteristics SIMATIC RF615R SIMATIC RF650R SIMATIC RF680R SIMATIC RF685R Air interface / ISO 18000-62 standards supported ISO 18000-63 Radio profile variants ETSI, FCC, CMIIT...
Page 96 Readers 5.1 Overview Characteristics SIMATIC RF615R SIMATIC RF650R SIMATIC RF680R SIMATIC RF685R Max. transmit power 23 dBm 30 dBm 33 dBm ETSI and CMIIT 0.2 W Max. transmit power 23 dBm 30 dBm 33 dBm 0.2 W Max. transmit power 24 dBm 30 dBm ARIB...
Page 97: Simatic Rf615R
Readers 5.2 SIMATIC RF615R SIMATIC RF615R 5.2.1 Description 5.2.1.1 Overview SIMATIC RF615R is a stationary reader in the UHF frequency band with an integrated antenna. An external UHF RFID antenna can be connected via an RP-TNC connector. The maximum transmit power is 400 mW at the reader output. A radiated power of up to 1000 mW ERP / 1400 mW EIRP is achieved when the appropriate antennas and antenna cables are used.
Page 98: Ordering Data
Readers 5.2 SIMATIC RF615R 5.2.1.2 Ordering data Table 5- 2 RF615R ordering data Product Article number RF615R (ETSI) 6GT2811-6CC10-0AA0 RF615R (FCC) 6GT2811-6CC10-1AA0 RF615R (CMIIT) 6GT2811-6CC10-2AA0 Table 5- 3 Ordering data accessories Product Article number Holders for securing the reader 6GT2890-0AB00 DIN rail T35 (S7-1200) •...
Page 99: Pin Assignment Of The Di/Dq Interface (X10 Di/Dq)
Readers 5.2 SIMATIC RF615R 5.2.1.3 Pin assignment of the DI/DQ interface (X10 DI/DQ) View of the DI/DQ interface (reader end) Table 5- 4 Pin assignment of the DI/DQ interface M12 socket (reader end) Pin assignment DI Common / Input Common DO Common / Output Common Not connected Note...
Page 100: Switching Scheme For The Di/Dq Interface
Readers 5.2 SIMATIC RF615R 5.2.1.4 Switching scheme for the DI/DQ interface Connection possibilities You can connect the reader in different ways. In general, the outputs and inputs should be connected as follows: Output (DQ) ● The output is rated for 0.5 A current (at < 20 °C; 0.33 A at 55 °C) and electronically protected.
Page 101 Readers 5.2 SIMATIC RF615R Voltage infeed from external source with various voltages Figure 5-2 Circuit example 3: Digital input Voltage infeed from external source Figure 5-3 Circuit example 4: Digital output Voltage infeed from an external source is shown here for 12 V as an example. Other voltages are also permissible.
Page 102: Pin Assignment Of The Rs422 Interface (X80 Dc24V)
Readers 5.2 SIMATIC RF615R 5.2.1.5 Pin assignment of the RS422 interface (X80 DC24V) Table 5- 5 Pin assignment of the RS422 interface (reader end) Interface view Wire colors Assignment Device end 8-pin M12 White + 24 V Brown - Transmit Green Yellow + Transmit...
Page 103 Readers 5.2 SIMATIC RF615R Comment The cables with open cable ends (6GT2891-4EH20, 6GT2891-4EH50) have an 8-pin M12 plug at one end, while the other end of the cable is "open". There are 8 color-coded single wires there for connecting to external devices. The product range includes additional cables of the type 6GT2891-0Fxxx (2 to 50 m) with an M12 connector at both ends.
Page 104: Pin Assignment Of The Industrial Ethernet Interface (X1 P1)
Readers 5.2 SIMATIC RF615R 5.2.1.6 Pin assignment of the Industrial Ethernet interface (X1 P1) Table 5- 6 Pin assignment of the Industrial Ethernet interface Interface view Pin assignment (M12 connector, 4-pole, D coding, wiring side) Data line TxP Data line RxP Data line TxN Data line RxN 5.2.2...
Page 105 Readers 5.2 SIMATIC RF615R Antenna diagram RF615R (ETSI) The following radiation diagrams show the directional characteristics of the internal antenna of the RF615R (ETSI) reader. For the spatial presentation of the directional characteristics, the horizontal plane (azimuth section) as well as the vertical plane (elevation section) must be considered.
Page 106 Readers 5.2 SIMATIC RF615R Radiation diagram (ETSI) Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 5-5 Directional radiation pattern of RF615R in the ETSI frequency band SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 107 Readers 5.2 SIMATIC RF615R Overview of the antenna parameters Table 5- 7 Maximum linear electrical aperture angle at 865 MHz: Polarization (circular) Azimuth section 100° Elevation section 100° Typical antenna gain -1 dBi in the frequency band 865 to 868 MHz Antenna axis ratio 2 dB You will find more information on the antennas in the section "Guidelines for selecting RFID...
Page 108 Readers 5.2 SIMATIC RF615R Radiation diagram (FCC) Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 5-7 Directional radiation pattern of RF615R in the FCC frequency band SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 109: Interpretation Of Directional Radiation Patterns
Readers 5.2 SIMATIC RF615R Overview of the antenna parameters Table 5- 8 Maximum linear electrical aperture angle at 915 MHz: Polarization (circular) Azimuth section 100° Elevation section 100° Typical antenna gain 0 dBi in the frequency band 902 to 928 MHz Antenna axis ratio 2 dB You will find more information on the antennas in the section "Guidelines for selecting RFID...
Page 110: Installing/Mounting
Readers 5.2 SIMATIC RF615R 5.2.3 Installing/mounting Requirement NOTICE Close unused connectors Note that the readers only have the specified degree of protection when all connectors are in use or when unused connectors are closed with the protective caps. CAUTION Emitted radiation The transmitter complies with the requirements of Health Canada and the FCC limit values for subjecting persons to HF radiation, provided that a minimum spacing of 26 cm exists between antenna and person.
Page 111: Configuration/Integration
Readers 5.2 SIMATIC RF615R 5.2.4 Configuration/integration An Ethernet interface is available for integrating the device into system environments/networks. RF615R can be configured via the Ethernet interface and with direct connection to the PC. You can configure and program the reader using the following tools: ●...
Page 112: Technical Specifications
Readers 5.2 SIMATIC RF615R 5.2.5 Technical specifications Table 5- 10 Technical specifications of the RF615R reader 6GT2811-6CC10-xAA0 Product type designation SIMATIC RF615R Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 to 928 MHz • • CMIIT 920 to 925 MHz •...
Page 113 Readers 5.2 SIMATIC RF615R 6GT2811-6CC10-xAA0 Typical transmission time per byte Write access 2 ms • • Read access 0.15 ms • • Supply voltage 24 V DC (20 ... 30 V DC) Maximum permitted current consumption 0.3 A Maximum permitted current consumption via 0.5 A (<...
Page 114 Readers 5.2 SIMATIC RF615R 6GT2811-6CC10-xAA0 Conditions relating to UL approval for indoor use only (dry location) • Mounting height shall be equal or less than • 2 m (MS1 classification according UL/IEC 62368-1). La hauteur de montage doit être égale ou in- férieure à...
Page 115: Dimension Drawing
Readers 5.2 SIMATIC RF615R 5.2.6 Dimension drawing Figure 5-9 Dimension drawing RF615R All dimensions in mm (± 0.5 mm tolerance) SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 116: Certificates And Approvals
Readers 5.2 SIMATIC RF615R 5.2.7 Certificates and approvals 5.2.7.1 CE mark Note Marking on the readers according to specific approval The certificates and approvals listed here apply only if the corresponding mark is found on the readers. Table 5- 11 6GT2811-6CC10-0AA0 Labeling Description...
Page 117: Fcc Information
Readers 5.2 SIMATIC RF615R 5.2.7.3 FCC information Siemens SIMATIC RF615R (FCC): 6GT2811-6CC10-1AA0 FCC ID: NXW-RF615R This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 118: Ic-Fcb Information
Readers 5.2 SIMATIC RF615R 5.2.7.4 IC-FCB information Siemens SIMATIC RF615R (FCC): 6GT2811-6CC10-1AA0 IC: 267X-RF615R This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 119: Simatic Rf650R
Readers 5.3 SIMATIC RF650R SIMATIC RF650R 5.3.1 Description 5.3.1.1 Overview The SIMATIC RF650R is a stationary reader in the UHF frequency band without an integrated antenna. Up to four external UHF RFID antennas can be connected via RP-TNC connectors. The maximum transmit power is 1000 mW at the reader output. A radiated power of up to 2000 mW ERP / 4000 mW EIRP is achieved when the appropriate antennas and antenna cables are used.
Page 120: Ordering Data
Readers 5.3 SIMATIC RF650R 5.3.1.2 Ordering data Table 5- 14 Ordering data RF650R Product Article number RF650R (ETSI) 6GT2811-6AB20-0AA0 RF650R (FCC) 6GT2811-6AB20-1AA0 RF650R (CMIIT) 6GT2811-6AB20-2AA0 RF650R (ARIB) 6GT2811-6AB20-4AA0 Table 5- 15 Ordering data accessories Product Article number Holders for securing the reader 6GT2890-0AB00 DIN rail T35 (S7-1200) •...
Page 121: Pin Assignment Of The Di/Dq Interface (X10 Di/Dq)
LPS (Limited Power Sources) and NEC Class 2. Color scheme of the DI/DQ standard cable with M12 connector The following figure shows the color scheme of the DI/DQ standard cable from Siemens (6GT2891-0CH50). You can use the color scheme to assign the wire colors to the pins.
Page 122: Switching Scheme For The Di/Dq Interface
Readers 5.3 SIMATIC RF650R 5.3.1.4 Switching scheme for the DI/DQ interface Connection possibilities You can connect the reader in different ways. In general, the outputs and inputs should be connected as follows: Output (DO 0 ... 3) ● Each output is rated for 0.5 A current and is electronically protected. ●...
Page 123 Readers 5.3 SIMATIC RF650R Voltage infeed from internal source (no electrical isolation) Figure 5-11 Circuit example 1: Digital inputs Alternative connection possibilities: ● Pin 2 (VCC) to Pin 9 DI Common ● Pin 1 GND to busbar inputs SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 124 Readers 5.3 SIMATIC RF650R Voltage infeed from external source Figure 5-12 Circuit example 2: Digital inputs Voltage infeed from external source with various voltages Figure 5-13 Circuit example 3: Digital inputs SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 125 Readers 5.3 SIMATIC RF650R Voltage infeed from internal source Figure 5-14 Circuit example 4: Digital outputs Alternative connection possibilities: ● Pin 1 GND to Pin 3 DO Common ● Pin 2 (VCC) to busbar outputs SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 126 Readers 5.3 SIMATIC RF650R Voltage infeed from external source Figure 5-15 Circuit example 5: Digital outputs Voltage infeed from an external source is shown here for 12 V as an example. Other voltages are also permissible. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 127: Pin Assignment Of The Rs422 Interface (X80 Dc24V)
Readers 5.3 SIMATIC RF650R Voltage infeed from external source with various voltages Figure 5-16 Circuit example 6: Digital outputs 5.3.1.5 Pin assignment of the RS422 interface (X80 DC24V) Table 5- 17 Pin assignment of the RS422 interface (reader end) Interface view Wire colors Assignment Device end...
Page 128 Readers 5.3 SIMATIC RF650R Note Requirement for external power sources The reader must only be supplied with power by power supply units that meet the requirements of LPS (Limited Power Source) and NEC Class 2. Requirement for external power sources The reader must only be supplied with power by power supply units that meet the requirements of limited power source (LPS) and NEC Class 2.
Page 129: Pin Assignment Of The Industrial Ethernet Interface (X1 P1)
Note Use of Siemens cables We recommend that you only use original Siemens cables and connectors (refer to the section Ordering data (Page 120)) to connect to the Ethernet socket of the reader. If plug-in connectors from other manufacturers are used, it may be difficult or even impossible to remove the plug from the reader.
Page 130: Planning Operation
Readers 5.3 SIMATIC RF650R Ground connection Screw (M4 x 8) Flat washer Cable lug Contact washer 5.3.2 Planning operation 5.3.2.1 Antenna/read point configurations You can connect up to four external antennas to the RF650R reader. The standard setting is that an antenna is connected when the reader is started. When connecting multiple antennas, note the information in the section "Specified minimum and maximum spacing of antennas (Page 46)".
Page 131: Installation/Mounting
Readers 5.3 SIMATIC RF650R 5.3.3 Installation/mounting Requirement NOTICE Close unused connectors Note that the readers only have the specified degree of protection when all connectors are in use or when unused connectors are closed with the protective caps. CAUTION Emitted radiation The transmitter complies with the requirements of Health Canada and the FCC limit values for subjecting persons to HF radiation, provided that a minimum spacing of 26 cm exists between antenna and person.
Page 132 Readers 5.3 SIMATIC RF650R Mounting the reader on a DIN/standard rail Table 5- 19 DIN rail mounting Description 1. Place the spring in the groove. 2. Mount the holder using the supplied Torx screws. When mounting the holder, make sure that the angled tip is positioned above the spring in the groove.
Page 133 Readers 5.3 SIMATIC RF650R Description 3. Fit the lower part of the locking mechanism of the reader into the DIN rail. To be able to mount the reader on or remove it from the DIN rail, pull down the holder mounted in step 2.
Page 134 Readers 5.3 SIMATIC RF650R Table 5- 20 Installation on a standard rail Description 1. Mount the two adapter pieces using the supplied Torx screws. 2. Fit the upper part of the locking mechanism of the reader into the standard rail. 3.
Page 135: Configuration/Integration
Readers 5.3 SIMATIC RF650R 5.3.4 Configuration/integration An Ethernet interface is available for integrating the device into system environments/networks. The RF650R can be configured via the Ethernet interface and with direct connection to the PC. You can configure and program the reader using the following tools: ●...
Page 136: Technical Specifications
Readers 5.3 SIMATIC RF650R 5.3.5 Technical specifications Table 5- 21 Technical specifications of the RF650R reader 6GT2811-6AB20-xAA0 Product type designation SIMATIC RF650R Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 to 928 MHz • • CMIIT 920 to 925 MHz •...
Page 137 Readers 5.3 SIMATIC RF650R 6GT2811-6AB20-xAA0 Channel spacing ETSI 600 kHz • • 500 kHz • • CMIIT 250 kHz • • ARIB (STD-T107) 200 kHz • • Modulation methods ASK: DSB modulation & PR-ASK modulation encoding, Manchester or Pulse Interval (PIE) Multitag capability Typical transmission time per byte Write access...
Page 138 Readers 5.3 SIMATIC RF650R 6GT2811-6AB20-xAA0 Mechanical specifications Material Upper part of housing Pocan (silicone-free) • • Lower part of housing Aluminum • • Color Upper part of housing TI-Grey • • Lower part of housing Silver • • Permitted ambient conditions Ambient temperature During operation -25 ...
Page 139: Dimension Drawing
Readers 5.3 SIMATIC RF650R 6GT2811-6AB20-xAA0 Standards, specifications, approvals Proof of suitability EN 301 489-1 V1.9.2 / EN 301 489-3 V1.6.1 / EN 302 208-1/-3 V1.4.1 FCC CFR 47, Part 15 section 15.247 MTBF 31 years Measured at the output of the antenna socket. All supply and signal voltages must be safety extra low voltage (SELV/PELV according to EN 60950).
Page 140: Certificates And Approvals
Readers 5.3 SIMATIC RF650R 5.3.7 Certificates and approvals Note Marking on the readers according to specific approval The certificates and approvals listed here apply only if the corresponding mark is found on the readers. Table 5- 22 6GT2811-6AB20-0AA0 Labeling Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU South Africa radio approval:...
Page 141 Readers 5.3 SIMATIC RF650R Labeling Description Brazil radio approval Marking on the reader (6GT2811-6AB20-1AA0): Statement about approval: Este equipamento opera em caráter secundário, isto é, não tem direito à proteção contra interferência prejudicial, mesmo de es- tações do mesmo tipo e não pode causar interferência a sistemas operando em caráter primário.
Page 142: Fcc Information
Readers 5.3 SIMATIC RF650R 5.3.7.1 FCC information Siemens SIMATIC RF650R (FCC): 6GT2811-6AB20-1AA0 FCC ID: NXW-RF600R2 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 143: Ic-Fcb Information
Readers 5.3 SIMATIC RF650R 5.3.7.2 IC-FCB information Siemens SIMATIC RF650R (FCC): 6GT2811-6AB20-1AA0 This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 144: Simatic Rf680R
Readers 5.4 SIMATIC RF680R SIMATIC RF680R 5.4.1 Description 5.4.1.1 Overview The SIMATIC RF680R is a stationary reader in the UHF frequency band without an integrated antenna. Up to four external UHF RFID antennas can be connected via RP-TNC connectors. The maximum transmit power is 2000 mW at the reader output. A radiated power of up to 2000 mW ERP / 4000 mW EIRP is achieved when the appropriate antennas and antenna cables are used.
Page 145: Ordering Data
Readers 5.4 SIMATIC RF680R 5.4.1.2 Ordering data Table 5- 25 Ordering data RF680R Product Article number RF680R (ETSI) 6GT2811-6AA10-0AA0 RF680R (FCC) 6GT2811-6AA10-1AA0 RF680R (CMIIT) 6GT2811-6AA10-2AA0 RF680R (ARIB) 6GT2811-6AA10-4AA0 Table 5- 26 Ordering data accessories Product Article number Holder set for securing the reader 6GT2890-0AB00 DIN rail T35 (S7-1200) •...
Page 146: Pin Assignment Of The Di/Dq Interface (X10 Di/Dq)
Readers 5.4 SIMATIC RF680R Product Article number Wide-range power supply unit for SIMATIC RF systems 6GT2898-0AC00 With EU plug • 6GT2898-0AC10 With UK plug • 6GT2898-0AC20 With US plug • 24 V connecting cable reader ↔ wide-range power supply unit 6GT2891-0PH50 with plug, 5 m •...
Page 147: Switching Scheme For The Di/Dq Interface
5.4 SIMATIC RF680R Color scheme of the DI/DQ standard cable with M12 connector The following figure shows the color scheme of the DI/DQ standard cable from Siemens (6GT2891-0CH50). You can use the color scheme to assign the wire colors to the pins.
Page 148 Readers 5.4 SIMATIC RF680R The following diagrams illustrate various connection possibilities. Note Minimum time between changes Note that changes on the I/O interface that are not applied for at least 1.5 seconds are not detected by the reader. Voltage infeed from internal source (no electrical isolation) Figure 5-20 Circuit example 1: Digital inputs Alternative connection possibilities:...
Page 149 Readers 5.4 SIMATIC RF680R Voltage infeed from external source Figure 5-21 Circuit example 2: Digital inputs Voltage infeed from external source with various voltages Figure 5-22 Circuit example 3: Digital inputs SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 150 Readers 5.4 SIMATIC RF680R Voltage infeed from internal source Figure 5-23 Circuit example 4: Digital outputs Alternative connection possibilities: ● Pin 1 GND to Pin 3 DO Common ● Pin 2 (VCC) to busbar outputs SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 151 Readers 5.4 SIMATIC RF680R Voltage infeed from external source Figure 5-24 Circuit example 5: Digital outputs Voltage infeed from an external source is shown here for 12 V as an example. Other voltages are also permissible. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 152: Pin Assignment Of The Rs422 Interface (X80 Dc24V)
Readers 5.4 SIMATIC RF680R Voltage infeed from external source with various voltages Figure 5-25 Circuit example 6: Digital outputs 5.4.1.5 Pin assignment of the RS422 interface (X80 DC24V) Table 5- 28 Pin assignment of the RS422 interface (reader end) Interface view Wire colors Assignment Device end...
Page 153 Readers 5.4 SIMATIC RF680R Note Requirement for external power sources The reader must only be supplied with power by power supply units that meet the requirements of LPS (Limited Power Source) and NEC Class 2. Requirement for external power sources The reader must only be supplied with power by power supply units that meet the requirements of limited power source (LPS) and NEC Class 2.
Page 154: Pin Assignment Of The Industrial Ethernet Interface (X1 P1; X1 P2)
Readers 5.4 SIMATIC RF680R 5.4.1.6 Pin assignment of the Industrial Ethernet interface (X1 P1; X1 P2) Table 5- 29 Pin assignment of the Industrial Ethernet interface Interface view Pin assignment (M12 connector, 4-pin, D coding, wiring end) Data line TxP Data line RxP Data line TxN Data line RxN...
Page 155: Planning Operation
Readers 5.4 SIMATIC RF680R Ground connection Screw (M4 x 8) Flat washer Cable lug Contact washer 5.4.2 Planning operation 5.4.2.1 Antenna/read point configurations You can connect up to four external antennas to the RF680R reader. The standard setting is that an antenna is connected when the reader is started. When connecting multiple antennas, note the information in the section "Specified minimum and maximum spacing of antennas (Page 46)".
Page 156: Installation/Mounting
Readers 5.4 SIMATIC RF680R 5.4.3 Installation/mounting Requirement NOTICE Close unused connectors Note that the readers only have the specified degree of protection when all connectors are in use or when unused connectors are closed with the protective caps. Close any connectors on the reader that you are not using with protective caps. You can order the protective cap set using the article number specified in the section "Ordering data".
Page 157 Readers 5.4 SIMATIC RF680R Mounting the reader on a DIN/standard rail Table 5- 30 DIN rail mounting Description 1. Place the spring in the groove. 2. Mount the holder using the supplied Torx screws. When mounting the holder, make sure that the angled tip is positioned above the spring in the groove.
Page 158 Readers 5.4 SIMATIC RF680R Description 3. Fit the lower part of the locking mechanism of the reader into the DIN rail. To be able to mount the reader on or remove it from the DIN rail, pull down the holder mounted in step 2.
Page 159 Readers 5.4 SIMATIC RF680R Table 5- 31 Installation on a standard rail Description 1. Mount the two adapter pieces using the supplied Torx screws. 2. Fit the upper part of the locking mechanism of the reader into the standard rail. 3.
Page 160: Configuration/Integration
Readers 5.4 SIMATIC RF680R 5.4.4 Configuration/integration An Ethernet interface is available for integrating the device into system environments/networks. The RF680R can be configured via the Ethernet interface and with direct connection to the PC. You can configure and program the reader using the following tools: ●...
Page 161: Technical Specifications
Readers 5.4 SIMATIC RF680R 5.4.5 Technical specifications Table 5- 32 Technical specifications of the RF680R reader 6GT2811-6AA10-xAA0 Product type designation SIMATIC RF680R Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 to 928 MHz • • CMIIT 920 to 925 MHz •...
Page 162 Readers 5.4 SIMATIC RF680R 6GT2811-6AA10-xAA0 Channel spacing ETSI 600 kHz • • 500 kHz • • CMIIT 250 kHz • • ARIB (STD-T106) 1200 kHz • • Modulation methods ASK: DSB modulation & PR-ASK modulation encoding, Manchester or Pulse Interval (PIE) Multitag capability Typical transmission time per byte Write access...
Page 163 Readers 5.4 SIMATIC RF680R 6GT2811-6AA10-xAA0 Mechanical specifications Material Upper part of housing Pocan (silicone-free) • • Lower part of housing Aluminum • • Color Upper part of housing TI-Grey • • Lower part of housing Silver • • Permitted ambient conditions Ambient temperature During operation -25 ...
Page 164: Dimension Drawing
Readers 5.4 SIMATIC RF680R 6GT2811-6AA10-xAA0 Standards, specifications, approvals Proof of suitability EN 301 489-1 V1.9.2 / EN 301 489-3 V1.6.1 / EN 302 208-1/-3 V1.4.1 FCC CFR 47, Part 15 section 15.247 MTBF 28 years Measured at the output of the antenna socket. All supply and signal voltages must be safety extra low voltage (SELV/PELV according to EN 60950).
Page 165: Certificates And Approvals
Readers 5.4 SIMATIC RF680R 5.4.7 Certificates and approvals Note Marking on the readers according to specific approval The certificates and approvals listed here apply only if the corresponding mark is found on the readers. Table 5- 33 6GT2811-6AA10-0AA0 Labeling Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU South Africa radio approval:...
Page 166 Readers 5.4 SIMATIC RF680R Labeling Description Brazil radio approval Marking on the reader (6GT2811-6AA10-1AA0): Statement about approval: Este equipamento opera em caráter secundário, isto é, não tem direito à proteção contra interferência prejudicial, mesmo de es- tações do mesmo tipo e não pode causar interferência a sistemas operando em caráter primário.
Page 167: Fcc Information
Readers 5.4 SIMATIC RF680R 5.4.7.1 FCC information Siemens SIMATIC RF680R (FCC): 6GT2811-6AA10-1AA0 FCC ID: NXW-RF600R2 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 168: Ic-Fcb Information
Readers 5.4 SIMATIC RF680R 5.4.7.2 IC-FCB information Siemens SIMATIC RF680R (FCC): 6GT2811-6AA10-1AA0 This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 169: Simatic Rf685R
Readers 5.5 SIMATIC RF685R SIMATIC RF685R 5.5.1 Description 5.5.1.1 Overview The SIMATIC RF685R is a stationary reader in the UHF frequency band with an integrated antenna. An additional external UHF RFID antenna can be connected via an RP-TNC connector. The maximum transmit power is 2000 mW at the external reader output. A radiated power of up to 2000 mW ERP / 4000 mW EIRP is achieved when the appropriate antennas and antenna cables are used.
Page 170: Ordering Data
Readers 5.5 SIMATIC RF685R 5.5.1.2 Ordering data Table 5- 36 Ordering data RF685R Product Article number RF685R (ETSI) 6GT2811-6CA10-0AA0 RF685R (FCC) 6GT2811-6CA10-1AA0 RF685R (CMIIT) 6GT2811-6CA10-2AA0 RF685R (ARIB) 6GT2811-6CA10-4AA0 Table 5- 37 Ordering data accessories Product Article number Holder set for securing the reader 6GT2890-0AB00 DIN rail T35 (S7-1200) •...
Page 171: Pin Assignment Of The Di/Dq Interface (X10 Di/Dq)
Readers 5.5 SIMATIC RF685R Product Article number Wide-range power supply unit for SIMATIC RF systems 6GT2898-0AC00 With EU plug • 6GT2898-0AC10 With UK plug • 6GT2898-0AC20 With US plug • 24 V connecting cable reader ↔ wide-range power supply unit 6GT2891-0PH50 with plug, 5 m •...
Page 172: Switching Scheme For The Di/Dq Interface
5.5 SIMATIC RF685R Color scheme of the DI/DQ standard cable with M12 connector The following figure shows the color scheme of the DI/DQ standard cable from Siemens (6GT2891-0CH50). You can use the color scheme to assign the wire colors to the pins.
Page 173 Readers 5.5 SIMATIC RF685R The following diagrams illustrate various connection possibilities. Note Minimum time between changes Note that changes on the I/O interface that are not applied for at least 1.5 seconds are not detected by the reader. Voltage infeed from internal source (no electrical isolation) Figure 5-29 Circuit example 1: Digital inputs Alternative connection possibilities:...
Page 174 Readers 5.5 SIMATIC RF685R Voltage infeed from external source Figure 5-30 Circuit example 2: Digital inputs Voltage infeed from external source with various voltages Figure 5-31 Circuit example 3: Digital inputs SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 175 Readers 5.5 SIMATIC RF685R Voltage infeed from internal source Figure 5-32 Circuit example 4: Digital outputs Alternative connection possibilities: ● Pin 1 GND to Pin 3 DO Common ● Pin 2 (VCC) to busbar outputs SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 176 Readers 5.5 SIMATIC RF685R Voltage infeed from external source Figure 5-33 Circuit example 5: Digital outputs Voltage infeed from an external source is shown here for 12 V as an example. Other voltages are also permissible. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 177: Pin Assignment Of The Rs422 Interface (X80 Dc24V)
Readers 5.5 SIMATIC RF685R Voltage infeed from external source with various voltages Figure 5-34 Circuit example 6: Digital outputs 5.5.1.5 Pin assignment of the RS422 interface (X80 DC24V) Table 5- 39 Pin assignment of the RS422 interface (reader end) Interface view Wire colors Assignment Device end...
Page 178 Readers 5.5 SIMATIC RF685R Note Requirement for external power sources The reader must only be supplied with power by power supply units that meet the requirements of LPS (Limited Power Source) and NEC Class 2. Requirement for external power sources The reader must only be supplied with power by power supply units that meet the requirements of limited power source (LPS) and NEC Class 2.
Page 179: Pin Assignment Of The Industrial Ethernet Interface (X1 P1; X1 P2)
Readers 5.5 SIMATIC RF685R 5.5.1.6 Pin assignment of the Industrial Ethernet interface (X1 P1; X1 P2) Table 5- 40 Pin assignment of the Industrial Ethernet interface Interface view Pin assignment (M12 connector, 4-pole, D coding, wiring side) Data line TxP Data line RxP Data line TxN Data line RxN...
Page 180: Planning Operation
Readers 5.5 SIMATIC RF685R Ground connection Screw (M4 x 8) Flat washer Cable lug Contact washer 5.5.2 Planning operation 5.5.2.1 Internal antenna Minimum mounting clearances of two readers The RF685R has an adjustable antenna (linear horizontal or linear vertical). This means that you can set the antenna polarization to be either horizontal, vertical or circular.
Page 181 Readers 5.5 SIMATIC RF685R Antenna diagram for RF685R (ETSI) The following radiation diagrams show the directional characteristics of the internal antenna of the RF685R (ETSI) reader. For the spatial presentation of the directional characteristics, the horizontal plane (azimuth section) as well as the vertical plane (elevation section) must be considered.
Page 182 Readers 5.5 SIMATIC RF685R Radiation diagram (Azimuth section) Figure 5-36 Azimuth section SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 183 Readers 5.5 SIMATIC RF685R Radiation diagram (elevation section) Figure 5-37 Elevation section SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 184 Readers 5.5 SIMATIC RF685R Radiation diagram circular Figure 5-38 Circular section Overview of the antenna parameters Table 5- 41 Maximum linear electrical aperture angle at 865 MHz: Polarization Circular polariza- tion Linear vertical Linear horizontal Azimuth section 64° 61° 65° Elevation section 64°...
Page 185 Readers 5.5 SIMATIC RF685R Antenna diagram for RF685R (FCC) The following radiation diagrams show the directional characteristics of the internal antenna of the RF685R (FCC) reader. For the spatial presentation of the directional characteristics, the horizontal plane (azimuth section) as well as the vertical plane (elevation section) must be considered.
Page 186 Readers 5.5 SIMATIC RF685R Radiation diagram (Azimuth section) Figure 5-40 Azimuth section SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 187 Readers 5.5 SIMATIC RF685R Radiation diagram (elevation section) Figure 5-41 Elevation section SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 188 Readers 5.5 SIMATIC RF685R Radiation diagram (circular) Figure 5-42 Circular section Overview of the antenna parameters Table 5- 42 Maximum linear electrical aperture angle at 915 MHz: Polarization Circular polariza- tion Linear vertical Linear horizontal Azimuth section 74° 64° 73° Elevation section 70°...
Page 189: External Antenna
Readers 5.5 SIMATIC RF685R Interpretation of directional radiation patterns The following overview table will help you with the interpretation of directional radiation patterns. The table shows which dBi values correspond to which read/write ranges (in %): You can read the radiated power depending on the reference angle from the directional radiation patterns, and thus obtain information on the read/write range with this reference angle with regard to a transponder.
Page 190: Installation/Mounting
Readers 5.5 SIMATIC RF685R 5.5.3 Installation/mounting Requirement NOTICE Close unused connectors Note that the readers only have the specified degree of protection when all connectors are in use or when unused connectors are closed with the protective caps. Close any connectors on the reader that you are not using with protective caps. You can order the protective cap set using the article number specified in the section "Ordering data".
Page 191 Readers 5.5 SIMATIC RF685R Mounting the reader on a DIN/standard rail Table 5- 44 DIN rail mounting Description 1. Place the spring in the groove. 2. Mount the holder using the supplied Torx screws. When mounting the holder, make sure that the angled tip is positioned above the spring in the groove.
Page 192 Readers 5.5 SIMATIC RF685R Description 3. Fit the lower part of the locking mechanism of the reader into the DIN rail. To be able to mount the reader on or remove it from the DIN rail, pull down the holder mounted in step 2.
Page 193 Readers 5.5 SIMATIC RF685R Table 5- 45 Installation on a standard rail Description 1. Mount the two adapter pieces using the supplied Torx screws. 2. Fit the upper part of the locking mechanism of the reader into the standard rail. 3.
Page 194: Configuration/Integration
Readers 5.5 SIMATIC RF685R 5.5.4 Configuration/integration An Ethernet interface is available for integrating the device into system environments/networks. The RF685R can be configured via the Ethernet interface and with direct connection to the PC. You can configure and program the reader using the following tools: ●...
Page 195: Technical Specifications
Readers 5.5 SIMATIC RF685R 5.5.5 Technical specifications Table 5- 46 Technical specifications of the RF685R reader 6GT2811-6CA10-xAA0 Product type designation SIMATIC RF685R Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 to 928 MHz • • CMIIT 920 to 925 MHz •...
Page 196 Readers 5.5 SIMATIC RF685R 6GT2811-6CA10-xAA0 Channel spacing ETSI 600 kHz • • 500 kHz • • CMIIT 250 kHz • • ARIB (STD-T106) 1200 kHz • • Modulation methods ASK: DSB modulation & PR-ASK modulation encoding, Manchester or Pulse Interval (PIE) Multitag capability Typical transmission time per byte Write access...
Page 197 Readers 5.5 SIMATIC RF685R 6GT2811-6CA10-xAA0 Mechanical specifications Material Upper part of housing Pocan (silicone-free) • • Lower part of housing Aluminum • • Color Upper part of housing TI-Grey • • Lower part of housing Silver • • Permitted ambient conditions Ambient temperature During operation -25 ...
Page 198: Dimension Drawing
Readers 5.5 SIMATIC RF685R 6GT2811-6CA10-xAA0 Standards, specifications, approvals Proof of suitability EN 301 489-1 V1.9.2 / EN 301 489-3 V1.6.1 / EN 302 208-1/-3 V1.4.1 FCC CFR 47, Part 15 section 15.247 MTBF 29 years Measured at the output of the antenna socket. All supply and signal voltages must be safety extra low voltage (SELV/PELV according to EN 60950).
Page 199: Certificates And Approvals
Readers 5.5 SIMATIC RF685R 5.5.7 Certificates and approvals Note Marking on the readers according to specific approval The certificates and approvals listed here apply only if the corresponding mark is found on the readers. Table 5- 47 6GT2811-6CA10-0AA0 Labeling Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU South Africa radio approval:...
Page 200 Readers 5.5 SIMATIC RF685R Labeling Description Brazil radio approval Marking on the reader (6GT2811-6CA10-1AA0): Statement about approval: Este equipamento opera em caráter secundário, isto é, não tem direito à proteção contra interferência prejudicial, mesmo de es- tações do mesmo tipo e não pode causar interferência a sistemas operando em caráter primário.
Page 201: Fcc Information
Readers 5.5 SIMATIC RF685R 5.5.7.1 FCC information Siemens SIMATIC RF685R (FCC): 6GT2811-6CA10-1AA0 FCC ID: NXW-RF600R2 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 202: Ic-Fcb Information
Readers 5.5 SIMATIC RF685R 5.5.7.2 IC-FCB information Siemens SIMATIC RF685R (FCC): 6GT2811-6CA10-1AA0 This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 203: Simatic Rf650M
Readers 5.6 SIMATIC RF650M SIMATIC RF650M 5.6.1 Description SIMATIC RF650M expands the RF600 identification system with a powerful mobile reader for applications in the areas of logistics, production and service. In addition, it is an indispensable aid for startup and testing. 5.6.2 Field of application and features Device variants for different frequency ranges...
Page 204 ● Easy creation of your own RFID applications with the software "Application Interface" (API) You will find further information on the RF650M handheld terminal in the operating instructions "SIMATIC RF650M mobile handheld terminal (https://support.industry.siemens.com/cs/ww/en/view/109475735)". SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 205: Antennas
Antennas Overview The following table shows the most important features of the RF600 antennas at a glance: Table 6- 1 Characteristics of the RF615A, RF620A and RF660A antennas Characteristics RF615A RF620A RF660A Material PA 6, silicone-free PA 12, silicone-free Frequency range 865-868 902-928 865-868...
Page 206 Antennas 6.1 Overview Table 6- 2 Characteristics of the RF640A and RF642A antennas Characteristics RF640A RF642A Material PA 12, silicone-free Frequency range 865-868 MHz 902-928 MHz 865-868 MHz 902-928 MHz Impedance 50 ohms nominal Antenna gain 4 dBi (7 dBic) 4.3 dBi (7.3 dBic) 6 dBi 7 dBi...
Page 207: Simatic Rf615A
Antennas 6.2 SIMATIC RF615A SIMATIC RF615A 6.2.1 Characteristics SIMATIC RF615A Characteristics Area of application The SIMATIC RF615A is a universal UHF antenna in a compact size for industrial applications, e.g. for instal- lation directly on the robot arm. Frequency range 865 to 868 MHz (RF615A ETSI) •...
Page 208: Ordering Data
Antennas 6.2 SIMATIC RF615A 6.2.2 Ordering data Table 6- 4 RF615A ordering data Product Article number SIMATIC RF615A (ETSI) 6GT2812-0EA00 SIMATIC RF615A (FCC) 6GT2812-0EA01 Table 6- 5 Ordering data accessories Product Article number Connecting cable between 1 m (cable loss 0.5 dB) 6GT2815-0BH10 reader and antenna 3 m (cable loss 1.0 dB)
Page 209: Connecting The Antenna
Requirement Note Use of Siemens antenna cable To ensure optimum functioning of the antenna, it is recommended that a Siemens antenna cable is used in accordance with the list of accessories. Strain relief To protect the antenna connecting cable from strain, you can attach strain relief, e.g. in the form of a strain relief clamp.
Page 210: Antenna Parameter Assignment
Antennas 6.2 SIMATIC RF615A Cable designa- Article number Length [m] Cable loss [dB] Bending radius tion [mm] Antenna cable 6GT2815-0BN20 Antenna cable 6GT2815-0BN40 Permissible minimum bending radius with multiple bending. With cables capable of being used in drag chains, 100,000 bending cycles at a bending radius of 100 mm and a bend of ±...
Page 211 Antennas 6.2 SIMATIC RF615A Make the following settings to ensure that the maximum permitted radiated power of the antenna is not exceeded: ● Conducted power P (dBm) of the RF600 reader: < 30 dBm ● Antenna gain G (dBi) in the FCC frequency band: ≤ -5 dBi ●...
Page 212: Antenna Patterns
Antennas 6.2 SIMATIC RF615A 6.2.6 Antenna patterns 6.2.6.1 Alignment of transponders to the antenna Polarization axis Since the RF615A antenna has linear polarization, it is necessary to consider the alignment of the transponders with regard to the polarization axis of the antenna. The polarization axes of antenna and transponder must always be parallel.
Page 213 Antennas 6.2 SIMATIC RF615A Alignment The following diagram shows the optimum alignment of the RF600 transponders to the RF615A antenna. Figure 6-3 Optimum alignment of transponders to the antenna SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 214 Antennas 6.2 SIMATIC RF615A Angle deviation diagram for alignment The following diagram shows the dependence of the following factors: ● Alignment angle of transponder to antenna ● Maximum range of antenna Figure 6-4 Effect on the read/write range depending on the antenna alignment SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 215: Antenna Pattern Etsi
Antennas 6.2 SIMATIC RF615A 6.2.6.2 Antenna pattern ETSI Directional radiation pattern ETSI The directional radiation pattern is shown for nominal alignment and a center frequency of 866.3 MHz. The nominal antenna alignment is given when the antenna elevation is provided as shown in the following figure.
Page 216 Antennas 6.2 SIMATIC RF615A Directional radiation pattern ETSI on metallic mounting surface (15 cm x 15 cm) Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-6 Directional radiation pattern RF615A ETSI on metallic mounting surface SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 217 Antennas 6.2 SIMATIC RF615A Directional radiation pattern ETSI on non-metallic mounting surface Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-7 Directional radiation pattern RF615A ETSI on non-metallic mounting surface SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 218: Antenna Pattern Fcc
Antennas 6.2 SIMATIC RF615A 6.2.6.3 Antenna pattern FCC Directional radiation pattern FCC The directional radiation pattern is shown for nominal alignment and a center frequency of 915 MHz. Figure 6-8 Reference system The half-power beam width of the antenna is defined by the angle between the two -3 dB points (corresponding to half the power in relation to the maximum power).
Page 219 Antennas 6.2 SIMATIC RF615A Directional radiation pattern of the RF615A (FCC) on metallic mounting surface (15 cm x 15 cm) Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-9 Directional radiation pattern of the RF615A (FCC) on metallic mounting surface SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 220 Antennas 6.2 SIMATIC RF615A Directional radiation pattern of the RF615A (FCC) on non-metallic mounting surface Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-10 Directional radiation pattern of the RF615A (FCC) on non-metallic mounting surface SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 221: Interpretation Of Directional Radiation Patterns
Antennas 6.2 SIMATIC RF615A 6.2.6.4 Interpretation of directional radiation patterns The following overview table will help you with the interpretation of directional radiation patterns. The table shows which dBi values correspond to which read/write ranges (in %): You can read the radiated power depending on the reference angle from the directional radiation patterns, and thus obtain information on the read/write range with this reference angle with regard to a transponder.
Page 222: Technical Data
Antennas 6.2 SIMATIC RF615A 6.2.7 Technical data Table 6- 7 Technical specifications for the RF615A antenna 6GT2812-0EA0x Product type designation SIMATIC RF615A Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 to 928 MHz • • Maximum radiated power ETSI ≤...
Page 223 Antennas 6.2 SIMATIC RF615A 6GT2812-0EA0x Power ETSI ≤ 2 W • • ≤ 1 W • • Interfaces Plug connection 30 cm coaxial cable with RP-TNC coupling (for connection of the antenna cable) Mechanical specifications Material PA6 V0, silicone-free Color Black Tightening torque (at room temperature) ≤...
Page 224: Dimension Drawing
Antennas 6.2 SIMATIC RF615A 6.2.8 Dimension drawing Figure 6-11 Dimension drawing RF615A All dimensions in mm 6.2.9 Certificates & approvals Table 6- 8 6GT2812-0EA00 Labeling Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Table 6- 9 6GT2812-0EA01 Labeling Description...
Page 225: Simatic Rf620A
Antennas 6.3 SIMATIC RF620A SIMATIC RF620A 6.3.1 Characteristics SIMATIC RF620A Characteristics Area of application The SIMATIC RF620A is a universal UHF antenna in a compact size for industrial applications in limited in- stallation spaces. Frequency range 865 to 868 MHz (RF620A ETSI) •...
Page 226: Ordering Data
Antennas 6.3 SIMATIC RF620A 6.3.2 Ordering data Table 6- 10 Ordering data RF620A Product Article number SIMATIC RF620A (ETSI) 6GT2812-1EA00 SIMATIC RF620A (FCC) 6GT2812-1EA01 Table 6- 11 Ordering data accessories Product Article number Connecting cable between 1 m (cable loss 0.5 dB) 6GT2815-0BH10 reader and antenna 3 m (cable loss 1.0 dB)
Page 227: Connecting The Antenna
Requirement Note Use of Siemens antenna cable To ensure optimum functioning of the antenna, it is recommended that a Siemens antenna cable is used in accordance with the list of accessories. Strain relief To protect the antenna connecting cable from strain, you can attach strain relief, e.g. in the form of a strain relief clamp.
Page 228: Antenna Parameter Assignment
Antennas 6.3 SIMATIC RF620A Cable designa- Article number Length [m] Cable loss [dB] Bending radius tion [mm] Antenna cable 6GT2815-0BN20 Antenna cable 6GT2815-0BN40 Permissible minimum bending radius with multiple bending. With cables capable of being used in drag chains, 100,000 bending cycles at a bending radius of 100 mm and a bend of ±...
Page 229 Antennas 6.3 SIMATIC RF620A Make the following settings to ensure that the maximum permitted radiated power of the antenna is not exceeded: ● Conducted power P (dBm) of the RF600 reader: < 30 dBm ● Antenna gain G (dBi) in the FCC frequency band: ≤ -5 dBi ●...
Page 230: Antenna Patterns
Antennas 6.3 SIMATIC RF620A 6.3.6 Antenna patterns 6.3.6.1 Alignment of transponders to the antenna Polarization axis Since the RF620A antenna has linear polarization, it is necessary to consider the alignment of the transponders with regard to the polarization axis of the antenna. The polarization axes of antenna and transponder must always be parallel.
Page 231 Antennas 6.3 SIMATIC RF620A Alignment The following diagram shows the optimum alignment of the RF600 transponders to the RF620A antenna. Figure 6-14 Antenna/transponder alignment SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 232 Antennas 6.3 SIMATIC RF620A Angle deviation diagram for alignment The following diagram shows the dependence of the following factors: ● Alignment angle of transponder to antenna ● Maximum range of antenna Figure 6-15 Angle deviation diagram for alignment SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 233: Antenna Pattern Etsi
Antennas 6.3 SIMATIC RF620A 6.3.6.2 Antenna pattern ETSI Directional radiation pattern ETSI The directional radiation pattern is shown for nominal alignment and a center frequency of 866.3 MHz. The nominal antenna alignment is given when the antenna elevation is provided as shown in the following figure.
Page 234 Antennas 6.3 SIMATIC RF620A Directional radiation pattern ETSI on metallic mounting surface (15 cm x 15 cm) Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-17 Directional radiation pattern RF620A ETSI on metallic mounting surface SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 235 Antennas 6.3 SIMATIC RF620A Directional radiation pattern ETSI on non-metallic mounting surface Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-18 Directional radiation pattern RF620A ETSI on non-metallic mounting surface SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 236: Antenna Pattern Fcc
Antennas 6.3 SIMATIC RF620A 6.3.6.3 Antenna pattern FCC Directional radiation pattern FCC The directional radiation pattern is shown for nominal alignment and a center frequency of 915 MHz. Figure 6-19 Reference system The half-power beam width of the antenna is defined by the angle between the two -3 dB points (corresponding to half the power in relation to the maximum power).
Page 237 Antennas 6.3 SIMATIC RF620A Directional radiation pattern of the RF620A (FCC) on metallic mounting surface (15 cm x 15 cm) Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-20 Directional radiation pattern of the RF620A (FCC) on metallic mounting surface SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 238 Antennas 6.3 SIMATIC RF620A Directional radiation pattern of the RF620A (FCC) on non-metallic mounting surface Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-21 Directional radiation pattern of the RF620A (FCC) on non-metallic mounting surface SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 239: Interpretation Of Directional Radiation Patterns
Antennas 6.3 SIMATIC RF620A 6.3.6.4 Interpretation of directional radiation patterns The following overview table will help you with the interpretation of directional radiation patterns. The table shows which dBi values correspond to which read/write ranges (in %): You can read the radiated power depending on the reference angle from the directional radiation patterns, and thus obtain information on the read/write range with this reference angle with regard to a transponder.
Page 240: Technical Data
Antennas 6.3 SIMATIC RF620A 6.3.7 Technical data Table 6- 13 Technical specifications for the RF620A antenna 6GT2812-1EA0x Product type designation SIMATIC RF620A Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 to 928 MHz • • Maximum radiated power ETSI ≤...
Page 241 Antennas 6.3 SIMATIC RF620A 6GT2812-1EA0x Electrical data Range See section "Maximum read/write ranges of transponders (Page 341)" Impedance 50 Ω Polarization Linear VSWR (standing wave ratio) ≤ 2:1 Power ETSI ≤ 2 W • • ≤ 1 W • • Interfaces Plug connection 30 cm coaxial cable with RP-TNC coupling...
Page 242: Dimension Drawing
Antennas 6.3 SIMATIC RF620A 6.3.8 Dimension drawing Figure 6-22 Dimension drawing RF620A All dimensions in mm SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 243: Approvals & Certificates
Antennas 6.3 SIMATIC RF620A 6.3.9 Approvals & certificates Table 6- 14 6GT2812-1EA00 Labeling Designation Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Table 6- 15 6GT2812-1EA01 Labeling Description FCC CFR 47, Part 15 sections 15.247 Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits Federal Communications for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 244: Simatic Rf640A
Antennas 6.4 SIMATIC RF640A SIMATIC RF640A 6.4.1 Characteristics SIMATIC RF640A Characteristics Area of application The SIMATIC RF640A is a universal UHF antenna in a medium size with medium range for industrial applica- tions in production and logistics. Frequency range 865 to 928 MHz Read range Max.
Page 245: Ordering Data
To achieve optimum wave propagation, the antenna should not be surrounded by conducting objects. The area between antenna and transponder should also allow wave propagation without interference. Antenna holders The Siemens antenna holders allow for fine adjustment of the antenna field by setting the solid angle. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 246: Connecting The Antenna
Requirement Note Use of Siemens antenna cable To ensure optimum functioning of the antenna, it is recommended that a Siemens antenna cable is used in accordance with the list of accessories. Strain relief To protect the antenna connecting cable from strain, you can attach strain relief, e.g. in the form of a strain relief clamp.
Page 247: Antenna Parameter Assignment
Antennas 6.4 SIMATIC RF640A Table 6- 18 Bending radii and bending cycles of the antenna cable Cable designa- Article number Length [m] Cable loss [dB] Bending radius tion [mm] Antenna cable 6GT2815-0BH10 Antenna cable 6GT2815-0BH30 Antenna cable 6GT2815-2BH50 (suitable for drag chains) Antenna cable 6GT2815-1BN10...
Page 248 Antennas 6.4 SIMATIC RF640A Make the following settings to ensure that the maximum permitted radiated power of the antenna is not exceeded: ● Antenna gain: 4 dBi (or 7 dBiC) ● Radiated power: ≤ 1360 mW ERP (or 31.35 dBm ERP) Converted into EIRP: ≤...
Page 249: Setting Rf640A Parameters For Rf680R/Rf685R
Antennas 6.4 SIMATIC RF640A Limitations in Japan Note Limitation of the radiated power (ARIB STD-T107) RF600 systems that are put into operation in Japan must not exceed the following radiated power with an RF640A antenna: • 500 mW EIRP (or 27 dBm EIRP) 6.4.5.2 Setting RF640A parameters for RF680R/RF685R Depending on the country or region in which the antenna is being operated, it is subject to...
Page 250 Antennas 6.4 SIMATIC RF640A Limitations in the USA and Canada Note Limitation of the radiated power (FCC) RF600 systems that are put into operation in the USA and Canada must not exceed the following radiated power with an RF640A antenna: •...
Page 251: Antenna Patterns
Antennas 6.4 SIMATIC RF640A 6.4.6 Antenna patterns 6.4.6.1 Antenna radiation patterns in the ETSI frequency band Directional radiation pattern Europe (ETSI) The directional radiation pattern is shown for nominal alignment and a center frequency of 866.3 MHz. The nominal antenna alignment is given when the antenna elevation is provided as shown in the following figure.
Page 252 Antennas 6.4 SIMATIC RF640A Directional radiation patterns in the ETSI frequency band Polarization axis and axis of symmetry are parallel In a configuration based on the following directional radiation pattern of the antenna, the axis of symmetry of the antenna and the polarization axis of the transponder are parallel. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 253 Antennas 6.4 SIMATIC RF640A Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-25 The RF640A directional radiation pattern in the ETSI frequency band, polarization axis of the transponder, and axis of symmetry of the antenna are parallel to each other. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 254 Antennas 6.4 SIMATIC RF640A Polarization axis and axis of symmetry are orthogonal to each other In a configuration based on the following directional radiation pattern of the antenna, the axis of symmetry of the antenna and the polarization axis of the transponder are orthogonal to each other.
Page 255 Antennas 6.4 SIMATIC RF640A Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-26 The RF640A directional radiation pattern in the ETSI frequency band, axis of symmetry of the antenna, and polarization axis of the transponder are orthogonal to each other SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 256: Antenna Radiation Patterns In The Fcc Frequency Band
Antennas 6.4 SIMATIC RF640A 6.4.6.2 Antenna radiation patterns in the FCC frequency band Directional radiation pattern USA (FCC) The directional radiation pattern is shown for nominal alignment and a center frequency of 915 MHz. Figure 6-27 Reference system The half-power beam width of the antenna is defined by the angle between the two -3 dB points (corresponding to half the power referred to the maximum power).
Page 257 Antennas 6.4 SIMATIC RF640A Directional radiation pattern in the FCC frequency band Polarization axis and axis of symmetry are parallel In the following directional radiation pattern of the antenna, the axis of symmetry of the antenna and the polarization axis of the transponder are parallel. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 258 Antennas 6.4 SIMATIC RF640A Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-28 The RF640A directional radiation pattern in the FCC frequency band, polarization axis of the transponder, and axis of symmetry of the antenna are parallel to each other SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 259 Antennas 6.4 SIMATIC RF640A Polarization axis and axis of symmetry are orthogonal to each other In the following directional radiation pattern of the antenna, the axis of symmetry of the antenna and the polarization axis of the transponder are orthogonal to each other. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 260 Antennas 6.4 SIMATIC RF640A Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-29 The RF640A directional radiation pattern in the FCC frequency band, axis of symmetry of the antenna, and polarization axis of the transponder are orthogonal to each other SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 261: Interpretation Of Directional Radiation Patterns
Antennas 6.4 SIMATIC RF640A 6.4.6.3 Interpretation of directional radiation patterns The following overview table will help you with the interpretation of directional radiation patterns. The table shows which dBi values correspond to which read/write ranges (in %): You can read the radiated power depending on the reference angle from the directional radiation patterns, and thus obtain information on the read/write range with this reference angle with regard to a transponder.
Page 262: Technical Data
Antennas 6.4 SIMATIC RF640A 6.4.7 Technical data Table 6- 19 Technical specifications for the RF640A antenna 6GT2812-0GA08 Product type designation SIMATIC RF640A Radio frequencies Operating frequency 865 to 928 MHz Maximum radiated power ETSI RF650R: ≤ 1360 mW ERP • •...
Page 263 Antennas 6.4 SIMATIC RF640A 6GT2812-0GA08 Electrical data Range See section "Maximum read/write ranges of transponders (Page 341)" Impedance 50 Ω Polarization Circular VSWR (standing wave ratio) ETSI ≤ 1.25 • • ≤ 1.6 • • Power Interfaces Plug connection 30 cm coaxial cable with RP-TNC coupling (for connection of the antenna cable) Mechanical specifications Material...
Page 264: Dimension Drawing
Antennas 6.4 SIMATIC RF640A 6.4.8 Dimension drawing Figure 6-30 Dimension drawing RF640A All dimensions in mm SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 265: Approvals & Certificates
Antennas 6.4 SIMATIC RF640A 6.4.9 Approvals & certificates Table 6- 20 6GT2812-0GA08 Labeling Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Table 6- 21 6GT2812-0GA08 Labeling Description FCC CFR 47, Part 15 sections 15.247 Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits Federal Communications for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 266: Simatic Rf642A
Antennas 6.5 SIMATIC RF642A SIMATIC RF642A 6.5.1 Characteristics SIMATIC RF642A Characteristics Area of application The SIMATIC RF642A is a universal UHF antenna in a medium size with high range for industrial applications in production and logistics. Frequency range 865 to 928 MHz Read range Max.
Page 267: Ordering Data
To achieve optimum wave propagation, the antenna should not be surrounded by conducting objects. The area between antenna and transponder should also allow wave propagation without interference. Antenna holders The Siemens antenna holders allow for fine adjustment of the antenna field by setting the solid angle. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 268: Connecting The Antenna
Requirement Note Use of Siemens antenna cable To ensure optimum functioning of the antenna, it is recommended that a Siemens antenna cable is used in accordance with the list of accessories. Strain relief To protect the antenna connecting cable from strain, you can attach strain relief, e.g. in the form of a strain relief clamp.
Page 269 Antennas 6.5 SIMATIC RF642A Table 6- 24 Bending radii and bending cycles of the antenna cable Cable designa- Article number Length [m] Cable loss [dB] Bending radius tion [mm] Antenna cable 6GT2815-0BH10 Antenna cable 6GT2815-0BH30 Antenna cable 6GT2815-2BH50 (suitable for drag chains) Antenna cable 6GT2815-1BN10...
Page 270: Antenna Parameter Assignment
Antennas 6.5 SIMATIC RF642A 6.5.5 Antenna parameter assignment 6.5.5.1 Alignment of transponders to the antenna Polarization axis Since the RF642A antenna has linear polarization, it is necessary to consider the alignment of the transponders with regard to the polarization axis of the antenna. The polarization axes of antenna and transponder must always be parallel.
Page 271 Antennas 6.5 SIMATIC RF642A Alignment The following diagram shows the optimum alignment of the RF600 transponders to the RF642A antenna. Figure 6-33 Antenna/transponder alignment SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 272 Antennas 6.5 SIMATIC RF642A Angle deviation diagram for alignment The following diagram shows the dependence of the following factors. ● Alignment angle of transponder to antenna ● Maximum range of antenna Figure 6-34 Angle deviation diagram for alignment SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 273: Rf642A Parameter Assignment
Antennas 6.5 SIMATIC RF642A 6.5.5.2 RF642A parameter assignment Depending on the country or region in which the antenna is being operated, it is subject to regional limitations with respect to the radiated power. Limitations in the EU, EFTA, or Turkey Note Limitation of the radiated power according to EN 302 208 V1.4.1 (ETSI) RF600 systems that are put into operation in the EU, EFTA or Turkey must not exceed the...
Page 274 Antennas 6.5 SIMATIC RF642A Limitations in China Note Limitation of the radiated power (CMIIT) RF600 systems that are put into operation in China must not exceed the following radiated power with an RF642A antenna: • 2000 mW ERP (or 33 dBm ERP) Converted into EIRP: 3250 mW EIRP (or 35 dBm EIRP) Make the following settings to ensure that the maximum permitted radiated power of the antenna is not exceeded:...
Page 275: Antenna Patterns
Antennas 6.5 SIMATIC RF642A 6.5.6 Antenna patterns 6.5.6.1 Antenna radiation patterns in the ETSI frequency band Directional radiation pattern Europe (ETSI) The directional radiation pattern is shown for nominal alignment and a center frequency of 866.3 MHz. The nominal antenna alignment is given when the antenna elevation is provided as shown in the following figure.
Page 276 Antennas 6.5 SIMATIC RF642A Directional radiation pattern in the ETSI frequency band Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-36 Directional radiation pattern of RF642A in the ETSI frequency band SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 277: Antenna Radiation Patterns In The Fcc Frequency Band
Antennas 6.5 SIMATIC RF642A 6.5.6.2 Antenna radiation patterns in the FCC frequency band Directional radiation pattern USA (FCC) The directional radiation pattern is shown for nominal alignment and a center frequency of 915 MHz. Figure 6-37 Reference system The half-power beam width of the antenna is defined by the angle between the two -3 dB points (corresponding to half the power referred to the maximum power).
Page 278 Antennas 6.5 SIMATIC RF642A Directional radiation pattern of the RF642A in the FCC frequency band Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-38 Directional radiation pattern of the RF642A in the FCC frequency band SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 279: Interpretation Of Directional Radiation Patterns
Antennas 6.5 SIMATIC RF642A 6.5.6.3 Interpretation of directional radiation patterns The following overview table will help you with the interpretation of directional radiation patterns. The table shows which dBi values correspond to which read/write ranges (in %): You can read the radiated power depending on the reference angle from the directional radiation patterns, and thus obtain information on the read/write range with this reference angle with regard to a transponder.
Page 280: Technical Data
Antennas 6.5 SIMATIC RF642A 6.5.7 Technical data Table 6- 25 Technical specifications for the RF642A antenna 6GT2812-1GA08 Product type designation SIMATIC RF642A Radio frequencies Operating frequency 865 to 928 MHz Maximum radiated power ETSI RF650R: ≤ 2000 mW ERP • •...
Page 281 Antennas 6.5 SIMATIC RF642A 6GT2812-1GA08 Interfaces Plug connection 30 cm coaxial cable with RP-TNC coupling (for connection of the antenna cable) Mechanical specifications Material PA 12 Color Pastel turquoise Tightening torque (at room temperature) ≤ 2 Nm Permitted ambient conditions Ambient temperature During operation -25 ...
Page 282: Dimension Drawing
Antennas 6.5 SIMATIC RF642A 6.5.8 Dimension drawing Figure 6-39 Dimensional drawing of RF642A All dimensions in mm SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 283: Approvals & Certificates
Antennas 6.5 SIMATIC RF642A 6.5.9 Approvals & certificates Table 6- 26 6GT2812-1GA08 Labeling Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Table 6- 27 6GT2812-1GA08 Labeling Description FCC CFR 47, Part 15 sections 15.247 Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits Federal Communications for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 284: Simatic Rf650A
Antennas 6.6 SIMATIC RF650A SIMATIC RF650A 6.6.1 Characteristics SIMATIC RF650A Characteristics Area of application The SIMATIC RF650A is a universal UHF antenna in a medium size with medium range for industrial applica- tions in production and logistics Frequency range 865 to 928 MHz Read range Max.
Page 285: Ordering Data
To achieve optimum wave propagation, the antenna should not be surrounded by conducting objects. The area between antenna and transponder should also allow wave propagation without interference. Antenna holders The Siemens antenna holders allow for fine adjustment of the antenna field by setting the solid angle. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 286: Connecting The Antenna
Requirement Note Use of Siemens antenna cables To ensure optimum functioning of the antenna, it is recommended that a Siemens antenna cable be used in accordance with the list of accessories. Strain relief To protect the antenna from strain, you can attach strain relief, e.g. in the form of a strain relief clamp.
Page 287: Antenna Parameter Assignment
Antennas 6.6 SIMATIC RF650A Table 6- 30 Bending radii and bending cycles of the antenna cable Cable designa- Article number Length [m] Cable loss [dB] Bending radius tion [mm] Antenna cable 6GT2815-0BH10 Antenna cable 6GT2815-0BH30 Antenna cable 6GT2815-2BH50 (suitable for drag chains) Antenna cable 6GT2815-1BN10...
Page 288 Antennas 6.6 SIMATIC RF650A Limitations in the USA and Canada Note Limitation of the radiated power (FCC) RF600 systems that are put into operation in the USA and Canada must not exceed the following radiated power with an RF650A antenna: •...
Page 289: Antenna Patterns
Antennas 6.6 SIMATIC RF650A 6.6.6 Antenna patterns Transponder alignment The RF650A antenna has a circular antenna. With a circular antenna the alignment of the antenna axis of symmetry changes between horizontal and vertical each time it transmits. For this reason the alignment of the transponder polarization axis (horizontal/vertical) is unimportant.
Page 290: Antenna Patterns In The Etsi Frequency Band
Antennas 6.6 SIMATIC RF650A 6.6.6.1 Antenna patterns in the ETSI frequency band Directional radiation pattern Directional radiation pattern ETSI The directional radiation pattern is shown for nominal alignment and a center frequency of 866.3 MHz. The nominal antenna alignment is given when the antenna elevation is provided as shown in the following figure.
Page 291 Antennas 6.6 SIMATIC RF650A Directional radiation patterns in the ETSI frequency band Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-43 Directional radiation pattern of RF650A in the ETSI frequency band SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 292: Antenna Patterns In The Fcc Frequency Band
Antennas 6.6 SIMATIC RF650A 6.6.6.2 Antenna patterns in the FCC frequency band Directional radiation pattern FCC The directional radiation pattern is shown for nominal alignment and a center frequency of 915 MHz. Figure 6-44 Reference system The half-power beam width of the antenna is defined by the angle between the two -3 dB points (corresponding to half the power in relation to the maximum power).
Page 293 Antennas 6.6 SIMATIC RF650A Directional radiation pattern in the FCC frequency band Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-45 Directional radiation pattern of the RF650A in the FCC frequency band SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 294: Interpretation Of Directional Radiation Patterns
Antennas 6.6 SIMATIC RF650A 6.6.6.3 Interpretation of directional radiation patterns The following overview table will help you with the interpretation of directional radiation patterns. The table shows which dBi values correspond to which read/write ranges (in %): You can read the radiated power depending on the reference angle from the directional radiation patterns, and thus obtain information on the read/write range with this reference angle with regard to a transponder.
Page 295: Technical Data
Antennas 6.6 SIMATIC RF650A 6.6.7 Technical data Table 6- 32 Technical specifications for the RF650A antenna 6GT2812-0GB08 Product type designation SIMATIC RF650A Radio frequencies Operating frequency 865 to 928 MHz Maximum radiated power ETSI RF650R: ≤ 1365 mW ERP • •...
Page 296 Antennas 6.6 SIMATIC RF650A 6GT2812-0GB08 Electrical data Range See section "Maximum read/write ranges of transponders (Page 341)" Impedance 50 Ω Polarization Circular VSWR (standing wave ratio) ≤ 1.45 Power ≤ 2 W Interfaces Plug connection RP-TNC coupling (for connection of the an- tenna cable) Mechanical specifications Material...
Page 297: Dimension Drawing
Antennas 6.6 SIMATIC RF650A 6.6.8 Dimension drawing Figure 6-46 Dimension drawing RF650A All dimensions in mm SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 298: Approvals & Certificates
Antennas 6.6 SIMATIC RF650A 6.6.9 Approvals & certificates Table 6- 33 6GT2812-0GB08 Labeling Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Table 6- 34 6GT2812-0GB08 Labeling Description FCC CFR 47, Part 15 sections 15.247 Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits Federal Communications for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 299: Simatic Rf660A
Antennas 6.7 SIMATIC RF660A SIMATIC RF660A 6.7.1 Characteristics SIMATIC RF660A Characteristics Area of application The SIMATIC RF660A is a universal UHF antenna with high range for industrial applications in production and logistics. Frequency ranges 865 to 868 MHz (RF660A FCC) •...
Page 300: Ordering Data
To achieve optimum wave propagation, the antenna should not be surrounded by conducting objects. The area between antenna and transponder should also allow wave propagation without interference. Antenna holders The Siemens antenna holders allow for fine adjustment of the antenna field by setting the solid angle. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 301: Connecting The Antenna
6GT2815-0BH10 (length 1m), since this cable has the lowest cable loss. Requirement Note Use of Siemens antenna cable To ensure optimum functioning of the antenna, it is recommended that a Siemens antenna cable is used in accordance with the list of accessories. Figure 6-47 Rear of antenna with RTNC connection...
Page 302: Antenna Parameter Assignment
Antennas 6.7 SIMATIC RF660A Cable designa- Article number Length [m] Cable loss [dB] Bending radius tion [mm] Antenna cable 6GT2815-2BN15 (suitable for drag chains) Antenna cable 6GT2815-0BN20 Antenna cable 6GT2815-0BN40 Permissible minimum bending radius with multiple bending. With cables capable of being used in drag chains, 100,000 bending cycles at a bending radius of 100 mm and a bend of ±...
Page 303 Antennas 6.7 SIMATIC RF660A Limitations in the USA and Canada Note Limitation of the radiated power (FCC) RF600 systems that are put into operation in the USA and Canada must not exceed the following radiated power with an RF660A antenna: •...
Page 304: Antenna Patterns
Antennas 6.7 SIMATIC RF660A 6.7.6 Antenna patterns Spatial directional radiation pattern The following schematic diagram shows the main and auxiliary fields of the RF660A antenna in free space in the absence of reflecting/absorbing materials. Please note that the diagram is not to scale. The recommended working range lies within the main field that is shown in green.
Page 305 Antennas 6.7 SIMATIC RF660A Radiation diagram (horizontal) Europe (ETSI) The radiation diagram is shown for horizontal alignment and for a center frequency of 865 MHz. Horizontal antenna alignment is provided when the TNC connection on the antenna points vertically up or down. The radiating/receiving angle of the antenna is defined by the angle between the two -3 dB points (corresponding to half the power referred to the maximum performance at a 0°...
Page 306 Antennas 6.7 SIMATIC RF660A USA (FCC) The radiation diagram is shown for horizontal alignment and for a center frequency of 915 MHz. The radiating/receiving angle of the antenna is defined by the angle between the two -3 dB points (corresponding to half the power referred to the maximum performance at a 0° angle). The optimum radiating/receiving angle is therefore approximately ±35 degrees.
Page 307: Technical Data
Antennas 6.7 SIMATIC RF660A 6.7.7 Technical data Table 6- 38 Technical specifications for the RF660A antenna 6GT2812-0AA0x Product type designation SIMATIC RF660A Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 to 928 MHz • • Maximum radiated power ETSI RF650R: ≤...
Page 308 Antennas 6.7 SIMATIC RF660A 6GT2812-0AA0x Electrical data Range See section "Maximum read/write ranges of transponders (Page 341)" Impedance 50 Ω Polarization Circular VSWR (standing wave ratio) ≤ 2 Power ≤ 2 W Interfaces Plug connection RP-TNC coupling (for connection of the an- tenna cable) Mechanical specifications Material...
Page 309: Dimension Drawing
Antennas 6.7 SIMATIC RF660A 6.7.8 Dimension drawing Figure 6-51 Dimension drawing RF660A All dimensions in mm (± 0.5 mm tolerance) SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 310: Approvals & Certificates
Antennas 6.7 SIMATIC RF660A 6.7.9 Approvals & certificates Table 6- 39 6GT2812-0AA00 Labeling Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Table 6- 40 6GT2812-0AA01 Labeling Description FCC CFR 47, Part 15 sections 15.247 Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits Federal Communications for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 311: Simatic Rf680A
Antennas 6.8 SIMATIC RF680A SIMATIC RF680A NOTICE Note on release The use of the adaptive antenna SIMATIC RF680A with the readers RF650R, RF680R and RF685R as of version V2.2.0 (supplied as of 03/2016) is possible. You will find the version on the type plate of the device. 6.8.1 Characteristics SIMATIC RF680A...
Page 312: Ordering Data
Antennas 6.8 SIMATIC RF680A LED status display The operating statuses of the antenna are displayed by an LED status display. The LED can adopt the colors green, red or yellow and the statuses off , on , flashing : Table 6- 41 Display of operating statuses of the antenna Meaning LED static for 1 second when the reader starts up:...
Page 313: Installation
To achieve optimum wave propagation, the antenna should not be surrounded by conducting objects. The area between antenna and transponder should also allow wave propagation without interference. Antenna holders The Siemens antenna holders allow for fine adjustment of the antenna field by setting the solid angle. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 314: Connecting The Antenna
6GT2815-0BH10 (length 1 m), since this cable has the lowest cable loss. Requirement Note Use of Siemens antenna cables To ensure optimum functioning of the antenna, it is recommended that a Siemens antenna cable be used in accordance with the list of accessories. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 315 Antennas 6.8 SIMATIC RF680A Strain relief To protect the antenna from strain, you can attach strain relief, e.g. in the form of a strain relief clamp. The following graphic shows the optimum mounting point for attaching strain relief. ① RF600 antenna cable ②...
Page 316: Antenna Parameter Assignment
Antennas 6.8 SIMATIC RF680A 6.8.5 Antenna parameter assignment Depending on the country or region in which the antenna is being operated, it is subject to regional limitations with respect to the radiated power. Limitations in the EU, EFTA, or Turkey Note Limitation of the radiated power according to EN 302 208 V1.4.1 (ETSI) RF600 systems that are put into operation in the EU, EFTA or Turkey must not exceed the...
Page 317 Antennas 6.8 SIMATIC RF680A Limitations in China Note Limitation of the radiated power (CMIIT) RF600 systems that are put into operation in China must not exceed the following radiated power with an RF680A antenna: • 2000 mW ERP (or 33 dBm ERP) Converted into EIRP: 3250 mW EIRP (or 35 dBm EIRP) Make the following settings to ensure that the maximum permitted radiated power of the antenna is not exceeded:...
Page 318: Antenna Patterns
Antennas 6.8 SIMATIC RF680A 6.8.6 Antenna patterns Transponder alignment The antenna RF680A has an adjustable antenna (circular or linear horizontal or linear vertical). With a circular antenna the alignment of the antenna axis of symmetry changes between horizontal and vertical each time it transmits. For this reason, with a circular antenna the alignment of the transponder polarization axis (horizontal/vertical) is unimportant.
Page 319: Antenna Patterns In The Etsi Frequency Band
Antennas 6.8 SIMATIC RF680A 6.8.6.1 Antenna patterns in the ETSI frequency band Directional radiation pattern ETSI The directional radiation pattern is shown for nominal alignment and a center frequency of 866.3 MHz. The nominal antenna alignment is given when the antenna elevation is provided as shown in the following figure.
Page 320 Antennas 6.8 SIMATIC RF680A Radiation diagram circular in the ETSI frequency band Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-56 Directional radiation pattern of RF680A in the ETSI frequency band SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 321 Antennas 6.8 SIMATIC RF680A Radiation diagram (linear horizontal) in the ETSI frequency band Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-57 The RF680A directional radiation pattern in the ETSI frequency band, axis of symmetry of the antenna, and polarization axis of the transponder are aligned horizontally SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 322 Antennas 6.8 SIMATIC RF680A Radiation diagram (linear vertical) in the ETSI frequency band Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-58 The RF680A directional radiation pattern in the ETSI frequency band, axis of symmetry of the antenna, and polarization axis of the transponder are aligned vertically SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 323: Antenna Patterns In The Fcc Frequency Band
Antennas 6.8 SIMATIC RF680A 6.8.6.2 Antenna patterns in the FCC frequency band Directional radiation pattern FCC The directional radiation pattern is shown for nominal alignment and a center frequency of 915 MHz. Figure 6-59 Reference system The half-power beam width of the antenna is defined by the angle between the two -3 dB points (corresponding to half the power in relation to the maximum power).
Page 324 Antennas 6.8 SIMATIC RF680A Radiation diagram circular in the FCC frequency band Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-60 Directional radiation pattern of the RF680A in the FCC frequency band SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 325 Antennas 6.8 SIMATIC RF680A Radiation diagram (linear horizontal) in the FCC frequency band Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-61 The RF680A directional radiation pattern in the FCC frequency band, axis of symmetry of the antenna, and polarization axis of the transponder are aligned horizontally SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 326 Antennas 6.8 SIMATIC RF680A Radiation diagram (linear vertical) in the FCC frequency band Pattern of the vertical plane of the antenna Pattern of the horizontal plane of the antenna Figure 6-62 The RF680A directional radiation pattern in the FCC frequency band, axis of symmetry of the antenna, and polarization axis of the transponder are aligned vertically SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 327: Interpretation Of Directional Radiation Patterns
Antennas 6.8 SIMATIC RF680A 6.8.6.3 Interpretation of directional radiation patterns The following overview table will help you with the interpretation of directional radiation patterns. The table shows which dBi values correspond to which read/write ranges (in %): You can read the radiated power depending on the reference angle from the directional radiation patterns, and thus obtain information on the read/write range with this reference angle with regard to a transponder.
Page 328: Technical Data
Antennas 6.8 SIMATIC RF680A 6.8.7 Technical data Table 6- 46 Technical specifications for the RF680A antenna 6GT2812-2GB08 Product type designation SIMATIC RF680A Radio frequencies Operating frequency 865 to 928 MHz Maximum radiated power ETSI RF650R: ≤ 1220 mW ERP • •...
Page 329 Antennas 6.8 SIMATIC RF680A 6GT2812-2GB08 Electrical data Range See section "Maximum read/write ranges of transponders (Page 341)" Impedance 50 Ω Polarization Linear, circular (can be switched over) VSWR (standing wave ratio) ≤ 1.45 Power ≤ 2 W Interfaces Plug connection RP-TNC coupling (for connection of the an- tenna cable) Mechanical specifications...
Page 330: Dimension Drawing
Antennas 6.8 SIMATIC RF680A 6.8.8 Dimension drawing Figure 6-63 Dimension drawing RF680A All dimensions in mm 6.8.9 Approvals & certificates Table 6- 47 6GT2812-2GB08 Labeling Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 331 Antennas 6.8 SIMATIC RF680A Table 6- 48 6GT2812-2GB08 Labeling Description FCC CFR 47, Part 15 sections 15.247 Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits Federal Communications for a Class B digital device, pursuant to Part 15 of the FCC Rules. Commission The FCC approval is granted in association with the FCC approval of the following RF600 readers:...
Page 332 Antennas 6.8 SIMATIC RF680A SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 333: Transponder
Transponder Overview 7.1.1 Mode of operation of transponders The transponder mainly comprises a microchip with an integrated memory and a dipole antenna. The principle of operation of a passive RFID transponder is as follows: ● Diversion of some of the high-frequency energy emitted by the reader to supply power to the integrated chip ●...
Page 334: Transponder Classes And Generations
● Object class: Corresponds to the article number ● Serial Number: consecutive number of the article The Siemens UHF transponders are all suitable for working with EPC and other number schemes. Before a transponder can work with a number scheme, the relevant numbers must first be written to the transponder.
Page 335 Transponder 7.1 Overview Presetting of the EPC memory of industrial Siemens transponders RF6xxT The first 12 bytes of the EPC memory ("0x00 - 0x0B") are preset. As of byte 13 ("0x0C") the EPC memory is not preset. Table 7- 1...
Page 336: Simatic Memory Configuration Of The Rf600 Transponders And Labels
Transponder 7.1 Overview 7.1.4 SIMATIC memory configuration of the RF600 transponders and labels Special memory configuration of the RF600 transponders and smartlabels Address spaces of the transponder versions With the RF600 readers, the user data, TID, EPC and passwords are read out via the relevant memory banks.
Page 337: Minimum Distances And Maximum Ranges
Transponder 7.1 Overview 7.1.5 Minimum distances and maximum ranges The following section describes the configuration of the antenna and transponder relative to each other. The aim of the section is to help you achieve the maximum ranges listed here in a typical electromagnetic environment.
Page 338 Transponder 7.1 Overview With the antenna types with linear polarization (RF620A and RF642A), the polarization axes of the antenna and of the transponder must be aligned parallel to each other to achieve a maximum range. NOTICE Reduction of the maximum read/write range when using linear antennas If the alignment of the polarization axes of linear antennas (RF620A or RF642A) and transponders is not parallel, this reduces the read/write range.
Page 339 Transponder 7.1 Overview Linear antennas To achieve the maximum range with linear antennas, make sure that the polarization axes of the antenna and transponder are parallel to each other. Changing the transponder angle within the x-y plane leads to a reduction of the range. ①...
Page 340 Transponder 7.1 Overview Suboptimal transponder alignment for all antenna types If the angle is changed within the y-z plane, this causes a reduction in range for all antenna types. ① Antenna RF615A, RF620A, RF640A, RF642A, RF650A or RF680A ② Transponder Figure 7-5 Suboptimal transponder alignment Note...
Page 341: Effects Of The Materials Of The Mounting Surfaces On The Range
Transponder 7.1 Overview 7.1.5.2 Effects of the materials of the mounting surfaces on the range Effects due to antenna mounting For the RF640A, RF642A, RF650A, RF660A and RF680A antennas, the antenna gain and therefore the maximum read/write range does not depend on the selected material of the mounting surface.
Page 342 Transponder 7.1 Overview Table 7- 3 Read range of the transponders I (all ranges in meters [m]) SIMATIC RF630L SIMATIC RF630L SIMATIC RF630L SIMATIC RF640L 6GT2810-2AB00 6GT2810-2AB02- 6GT2810-2AB03 0AX0 SIMATIC RF615R with internal antenna with RF615A with RF620A with RF640A with RF642A with RF650A with RF660A...
Page 343 Transponder 7.1 Overview Table 7- 4 Read range of the transponders II (all ranges in meters [m]) SIMATIC RF642L SIMATIC RF690L SIMATIC RF610T SIMATIC RF620T SIMATIC RF615R with internal antenna with RF615A with RF620A with RF640A with RF642A with RF650A with RF660A with RF680A SIMATIC RF650R...
Page 344 Transponder 7.1 Overview Table 7- 5 Read range of the transponders III (all ranges in meters [m]) SIMATIC RF622T SIMATIC RF625T SIMATIC RF630T SIMATIC RF640T 1) 2) SIMATIC RF615R with internal antenna with RF615A with RF620A with RF640A with RF642A with RF650A with RF660A with RF680A...
Page 345 Transponder 7.1 Overview Table 7- 6 Read range of the transponders IV (all ranges in meters [m]) SIMATIC RF645T SIMATIC RF680T SIMATIC RF682T SIMATIC RF615R with internal antenna with RF615A with RF620A with RF640A with RF642A with RF650A with RF660A with RF680A SIMATIC RF650R with RF615A...
Page 346: Minimum Distances Between Antennas And Transponders
Transponder 7.1 Overview 7.1.5.4 Minimum distances between antennas and transponders The antennas listed here are all far field antennas. For this reason, a minimum distance between antennas and transponders must be maintained to ensure reliable transponder data access: Table 7- 7 Minimum distances to be maintained between antennas and transponders RF600 antenna Minimum distances to be maintained...
Page 347: Storage And Transportation Roll Goods
Transponder 7.1 Overview 7.1.7 Storage and transportation roll goods NOTICE Notes on storage and transportation of rolls Note the following information on the storage and transportation of rolls: • Protect the transponders from direct sunlight and heat (e.g. heating appliances). •...
Page 348: Simatic Rf630L Smartlabel
Transponder 7.2 SIMATIC RF630L Smartlabel SIMATIC RF630L Smartlabel 7.2.1 Features SIMATIC RF630L smart labels are passive, maintenance-free data carriers based on UHF Class 1 Gen2 technology that are used to store the "Electronic Product Code" (EPC). Smart labels offer numerous possible uses for a wide range of applications and support efficient logistics throughout the process chain.
Page 349: Ordering Data
Transponder 7.2 SIMATIC RF630L Smartlabel 7.2.2 Ordering data Table 7- 8 Ordering data RF630L Product Article number SIMATIC RF630L 6GT2810-2AB00 Smart label 101.6 mm x 152.4 mm (4" x 6") SIMATIC RF630L 6GT2810-2AB02-0AX0 Smart label 97 mm x 27 mm SIMATIC RF630L 6GT2810-2AB03 Smart label 54 mm x 34 mm...
Page 350: Technical Data
Transponder 7.2 SIMATIC RF630L Smartlabel 7.2.3 Technical data Table 7- 9 Technical specifications of the transponder SIMATIC RF630L 6GT2810-2AB00 Product type designation SIMATIC RF630L Radio frequencies Operating frequency 860 to 960 MHz Memory Chip (manufacturer/type) IMPINJ / MONZA 2 Memory type EEPROM Memory configuration 12 bytes / 96 bits...
Page 351 Transponder 7.2 SIMATIC RF630L Smartlabel 6GT2810-2AB00 Permitted ambient conditions Ambient temperature In operation, during write/read access -40 ... +65 °C • • In operation, outside write/read access -40 ... +80 °C • • During transportation and storage +15 ... +25 °C •...
Page 352 Transponder 7.2 SIMATIC RF630L Smartlabel Table 7- 10 Technical specifications of the transponder SIMATIC RF630L 6GT2810-2AB02-0AX0 6GT2810-2AB03 Product type designation SIMATIC RF630L Radio frequencies Operating frequency 860 to 960 MHz Memory Chip (manufacturer/type) IMPINJ / MONZA 4QT NXP / G2XM Memory type EEPROM Memory configuration...
Page 353 Transponder 7.2 SIMATIC RF630L Smartlabel 6GT2810-2AB02-0AX0 6GT2810-2AB03 Permitted ambient conditions Ambient temperature In operation, during write/read access -40 ... +65 °C • • In operation, outside write/read access -40 ... +80 °C • • During transportation and storage +15 ... +25 °C •...
Page 354: Dimension Drawings
Transponder 7.2 SIMATIC RF630L Smartlabel 7.2.4 Dimension drawings Figure 7-7 SIMATIC RF630L 6GT2810-2AB00 dimension drawing Figure 7-8 Dimension drawing SIMATIC RF630L 6GT2810-2AB02-0AX0 Figure 7-9 SIMATIC RF630L 6GT2810-2AB03 dimension drawing SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 355: Certificates And Approvals
Transponder 7.3 SIMATIC RF640L Smartlabel 7.2.5 Certificates and approvals Certificate Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Passive labels and transponders comply with the valid regulations; certification is not required. Federal Communications Commission SIMATIC RF640L Smartlabel 7.3.1 Features The SIMATIC RF640L Smartlabel is a passive and maintenance-free data carrier.
Page 356: Ordering Data
Transponder 7.3 SIMATIC RF640L Smartlabel 7.3.2 Ordering data Table 7- 11 Ordering data RF640L Product Article number SIMATIC RF640L (ETSI) 6GT2810-2AC00 SIMATIC RF640L (FCC) 6GT2810-2AC10 Delivery format SIMATIC RF640L smart label is supplied in the following form: ● 500 smart labels per packaging unit: 500 labels on one roll Minimum order quantity: 1 packaging unit (500 units) 7.3.3 Memory organization...
Page 357: Technical Specifications
Transponder 7.3 SIMATIC RF640L Smartlabel 7.3.4 Technical specifications Table 7- 13 Technical specifications of the transponder SIMATIC RF640L 6GT2810-2ACx0 Product type designation SIMATIC RF640L Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 to 928 MHz • •...
Page 358 Transponder 7.3 SIMATIC RF640L Smartlabel 6GT2810-2ACx0 Permitted ambient conditions Ambient temperature In operation, during write/read access -20 ... +85 °C • • In operation, outside write/read access -25 ... +85 °C • • During transportation and storage +13 ... +23 °C •...
Page 359: Dimension Drawing
Transponder 7.3 SIMATIC RF640L Smartlabel 7.3.5 Dimension drawing ① Printable area ② Polarization axis ③ Conveyor direction Figure 7-10 RF640L dimension drawing All dimensions in mm 7.3.6 Certificates and approvals Certificate Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Passive labels and transponders comply with the valid regulations;...
Page 360: Simatic Rf642L Smartlabel
Transponder 7.4 SIMATIC RF642L Smartlabel SIMATIC RF642L Smartlabel 7.4.1 Features The SIMATIC RF642L-Smartlabel is a passive and maintenance-free data carrier. The Smartlabel operates based on UHF Class 1 Gen 2 technology and is used to save the "Electronic Product Code" (EPC) up to 448 bits. The transponder also has 2048 bits of user memory.
Page 361: Technical Specifications
Transponder 7.4 SIMATIC RF642L Smartlabel 7.4.3 Technical specifications Table 7- 15 Technical specifications of the SIMATIC RF642L transponder 6GT2810-3ACx0 Product type designation SIMATIC RF642L Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 to 928 MHz • •...
Page 362 Transponder 7.4 SIMATIC RF642L Smartlabel 6GT2810-3ACx0 Permitted ambient conditions Ambient temperature In operation, during write/read access -20 to +85 °C • • In operation, outside write/read access -25 to +85 °C • • During transportation and storage +13 ... +23 °C •...
Page 363: Dimension Drawing
Transponder 7.4 SIMATIC RF642L Smartlabel 7.4.4 Dimension drawing ① Printable area ② Polarization axis ③ Conveyor direction Figure 7-11 Dimension drawing RF642L All dimensions in mm SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 364: Simatic Rf690L Smartlabel
Transponder 7.5 SIMATIC RF690L Smartlabel SIMATIC RF690L Smartlabel 7.5.1 Characteristics The SIMATIC RF690L High Temp Smartlabel is a passive and maintenance-free data carrier. It operates based on the UHF Class 1 Gen 2 technology and is used to store the "Electronic Product Code"...
Page 365: Memory Organization
Transponder 7.5 SIMATIC RF690L Smartlabel 7.5.3 Memory organization Transponders with an "Alien Higgs 3" chip have an EPC memory with a standard size of 96 Bits (12 bytes). When necessary, the EPC memory size can be expanded to 480 bits (60 bytes) in steps of 16 bits at the cost of the user memory.
Page 366 Transponder 7.5 SIMATIC RF690L Smartlabel 6GT2810-2AGx0 Number of write cycles (< 40 °C) > 500 Number of read cycles (< 40 °C) > 10 Data retention time (< 40 °C) 50 years Electrical data Range Writing ??? m • • Reading ≤...
Page 367: Dimension Drawing
Transponder 7.5 SIMATIC RF690L Smartlabel 6GT2810-2AGx0 Design, dimensions and weight Dimensions (L x W x D) ETSI 88 × 25 × 1.6 mm • • 75 × 25 × 1.6 mm • • Weight The EPC memory has a default size of 96 bits. When necessary, the EPC memory size can be expanded to 480 bits in steps of 16 bits at the cost of the user memory.
Page 368: Certificates And Approvals
Transponder 7.5 SIMATIC RF690L Smartlabel Figure 7-13 Dimension drawing RF690L (FCC, article number: 6GT2810-2AG10) All dimensions in mm 7.5.6 Certificates and approvals Certificate Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Passive labels and transponders comply with the valid regulations; certification is not required.
Page 369: Simatic Rf610T
Transponder 7.6 SIMATIC RF610T SIMATIC RF610T 7.6.1 Features The SIMATIC RF610T is passive and maintenance-free. It operates based on the UHF Class 1 Gen 2 technology and is used for saving the electronic product code (EPC) of 96 bits / 240 bits. The label also has a 512 bit user memory. The SIMATIC RF610T offers a host of possible uses for a wide range of applications and supports efficient logistics throughout the entire process chain.
Page 370: Technical Specifications
Transponder 7.6 SIMATIC RF610T Delivery format SIMATIC RF610T is supplied in the following form: ● 500 transponders per packaging unit Minimum order quantity: 1 packaging unit (500 units) 7.6.3 Technical specifications Table 7- 20 Technical specifications of the transponder SIMATIC RF610T 6GT2810-2BB80 Product type designation SIMATIC RF610T...
Page 371 Transponder 7.6 SIMATIC RF610T 6GT2810-2BB80 Mechanical specifications Material Silicone-free Color White Antenna material Aluminum Type of antenna Shortened dipole Printing Can be printed using heat transfer technique Permitted ambient conditions Ambient temperature In operation, during write/read access -25 ... +85 °C •...
Page 372: Dimension Drawing
Transponder 7.6 SIMATIC RF610T 7.6.4 Dimension drawing Figure 7-14 Dimensional drawing of SIMATIC RF610T All dimensions in mm 7.6.5 Certificates and approvals Certificate Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Passive labels and transponders comply with the valid regulations; certification is not required.
Page 373: Simatic Rf610T Atex
Transponder 7.7 SIMATIC RF610T ATEX SIMATIC RF610T ATEX 7.7.1 Features The SIMATIC RF610T special variant ATEX is passive and maintenance-free. It operates based on the UHF Class 1 Gen 2 technology and is used for saving the electronic product code (EPC) of 96 bits / 240 bits. The label also has a 512 bit user memory. The SIMATIC RF610T special variant ATEX provides numerous possible uses for a wide range of applications and allows efficient logistics throughout the entire process chain.
Page 374: Use Of The Transponder In Hazardous Areas
This device/system may only be used for the applications described in the catalog and the technical documentation "System manual SIMATIC RF600 (https://support.industry.siemens.com/cs/ww/en/ps/15069/man)" and only in combination with third-party devices and components recommended and/or approved by Siemens. 7.7.3 Use of the transponder in hazardous areas In a conformity declaration, TÜV NORD CERT GmbH has confirmed compliance with the...
Page 375 II 3 D Ex ic IIIB T 120°C Dc, II 3 G Ex ic IIB T6/T5/T4 Gc -25 °C < Ta < +85 °C Warning WARNING WARNING POTENTIAL ELECTROSTATIC CHARGIMG HAZARD-SEE INSTRUCTIONS Manufacturer's address - distributor Siemens AG DE-76181 Karlsruhe SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 376: Use Of The Transponder In Hazardous Areas For Gases
Transponder 7.7 SIMATIC RF610T ATEX 7.7.3.1 Use of the transponder in hazardous areas for gases Temperature class grading for gases with up to 2000 mW ERP The temperature class of the transponder for hazardous areas depends on the ambient temperature range. If the radiated power of an antenna radiating into the hazardous area or located in the hazardous area and operating in the 865 - 868 MHz frequency band cannot exceed the value 2000 mW, the temperature class grading is as follows:...
Page 377: Use Of The Transponder In Hazardous Areas For Dusts
Transponder 7.7 SIMATIC RF610T ATEX 7.7.3.2 Use of the transponder in hazardous areas for dusts The equipment is suitable for dusts whose ignition temperatures for a dust layer of 5 mm are higher than 210 °C (smoldering temperature). The ignition temperature specified here according to EN 60079-0: 2012 + A11: 2013 for ignition protection type ic in this case references the smoldering temperature of a layer of combustible flyings (ic IIIA) or alternatively non-conductive dusts (ic IIIB).
Page 378: Technical Specifications
Transponder 7.7 SIMATIC RF610T ATEX 7.7.4 Technical specifications Table 7- 24 Technical specifications of the transponder SIMATIC RF610T special variant ATEX 6GT2810-2BB80-0AX1 Product type designation SIMATIC RF610T special variant ATEX Radio frequencies Operating frequency ETSI 865 to 868 MHz • •...
Page 379 Transponder 7.7 SIMATIC RF610T ATEX 6GT2810-2BB80-0AX1 Permitted ambient conditions Ambient temperature In operation, during write/read access -25 ... +85 °C • • In operation, outside write/read access -40 ... +85 °C • • During transportation and storage -40 … +85 °C •...
Page 380: Dimension Drawing
Transponder 7.7 SIMATIC RF610T ATEX 7.7.5 Dimension drawing Figure 7-16 Dimension drawing SIMATIC RF610T (special variant ATEX) All dimensions in mm 7.7.6 Certificates and approvals Certificate Description Conformity with the ATEX directive 2014/34/EU based on: Conformity statement no. TÜV 11 ATEX 081778 X Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Passive labels and transponders comply with the valid regulations;...
Page 381: Simatic Rf620T
Transponder 7.8 SIMATIC RF620T SIMATIC RF620T 7.8.1 Characteristics The SIMATIC RF620T Transponder is passive and maintenance-free, based on the UHF Class 1 Gen2 technology for storing the 96-bit/128-bit "electronic product code" (EPC). The transponder also has a 64-byte user memory. The container tag for industrial applications is rugged and highly resistant to detergents.
Page 382: Ordering Data
Transponder 7.8 SIMATIC RF620T 7.8.2 Ordering data Table 7- 25 Ordering data RF620T Product Article number SIMATIC RF620T 6GT2810-2HC81 Spacer for SIMATIC RF620T 6GT2898-2AA00 Delivery format SIMATIC RF620T is supplied in the following form: ● 20 transponders per packaging unit Minimum order quantity: 1 packaging unit (20 units) 7.8.3 Planning the use...
Page 383: Range When Mounted On Non-Metallic Carrier Materials
Transponder 7.8 SIMATIC RF620T Table 7- 26 Range with metallic, flat carriers without spacers Carrier material Range Metal plate at least 300 x 300 mm typically 40% Table 7- 27 Range with flat metallic carriers with spacers Carrier material Range Metal plate at least 300 x 300 mm typically 100% The use of spacers on metallic surfaces is recommended.
Page 384: Technical Specifications
Transponder 7.8 SIMATIC RF620T 7.8.4 Technical specifications Table 7- 29 Technical specifications of the transponder SIMATIC RF620T 6GT2810-2HC81 Product type designation SIMATIC RF620T Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 to 928 MHz • • Memory Chip (manufacturer/type) IMPINJ / MONZA 4QT...
Page 385 Transponder 7.8 SIMATIC RF620T 6GT2810-2HC81 Permitted ambient conditions Ambient temperature In operation, during write/read access -25 ... +85 °C • • In operation, outside write/read access -40 ... +85 °C • • During transportation and storage -40 … +80 °C •...
Page 386: Dimension Drawing
Transponder 7.8 SIMATIC RF620T 7.8.5 Dimension drawing Figure 7-18 SIMATIC RF620T UHF container tag Units of measurement: All dimensions in mm Tolerances, unless indicated otherwise, are +-0.5 mm. ① Labeling area, see Section Characteristics (Page 381) SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 387: Certificates And Approvals
Transponder 7.8 SIMATIC RF620T 7.8.6 Certificates and approvals Table 7- 30 6GT2810-2HC00 - RF620T Certificate Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Table 7- 31 6GT2810-2HC80 - RF620T Certificate Description Passive labels or transponders comply with the valid regulations; certification is not required.
Page 388: Simatic Rf622T
Transponder 7.9 SIMATIC RF622T SIMATIC RF622T 7.9.1 Features The SIMATIC RF622T is a passive and maintenance-free data carrier. It operates on the basis of the UHF Class 1 Gen 2 technology and has a fast FRAM user memory of 3,424 bytes.
Page 389: Technical Specifications
Transponder 7.9 SIMATIC RF622T Delivery format SIMATIC RF622T is supplied in the following form: ● 10 transponders per packaging unit Minimum order quantity: 1 packaging unit (10 units) 7.9.3 Technical specifications Table 7- 33 Technical specifications of the transponder SIMATIC RF622T 6GT2810-4HC80 Product type designation SIMATIC RF622T...
Page 390 Transponder 7.9 SIMATIC RF622T 6GT2810-4HC80 Mechanical specifications Material PA12 Silicone-free Color Anthracite Antenna material Aluminum Type of antenna Shortened dipole Printing Can be printed using heat transfer technique Permitted ambient conditions Ambient temperature In operation, during write/read access -25 ... +85 °C •...
Page 391: Dimension Drawing
Transponder 7.9 SIMATIC RF622T 7.9.4 Dimension drawing Figure 7-19 Dimension drawing RF622T Figure 7-20 Dimension drawing spacer RF622T Figure 7-21 Dimension drawing RF622T mounted All dimensions in mm; tolerances unless indicated otherwise ±0.5 mm. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 392: Certificates And Approvals
Transponder 7.10 SIMATIC RF625T 7.9.5 Certificates and approvals Certificate Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Passive labels and transponders comply with the valid regulations; certification is not required. Federal Communications Commission 7.10 SIMATIC RF625T 7.10.1 Characteristics The SIMATIC RF625T transponder is a passive, maintenance-free data carrier with a round...
Page 393: Ordering Data
Transponder 7.10 SIMATIC RF625T 7.10.2 Ordering data Table 7- 34 Ordering data RF625T Product Article number SIMATIC RF625T (ETSI) 6GT2810-2EE00 SIMATIC RF625T (FCC) 6GT2810-2EE01 Delivery format SIMATIC RF625T is supplied in the following form: ● 10 transponders per packaging unit Minimum order quantity: 1 packaging unit (10 units) 7.10.3 Planning the use...
Page 394: Range When Mounted On Flat Metallic Carrier Plates
Transponder 7.10 SIMATIC RF625T 7.10.3.2 Range when mounted on flat metallic carrier plates The transponder generally has linear polarization. The polarization axis runs as shown in the diagram below. When using a circular antenna and when the transponder is centrally mounted on a plane metal plate, which may either be almost square or circular, it can be aligned in any direction.
Page 395: Range When Mounted On Non-Metallic Carrier Materials
Transponder 7.10 SIMATIC RF625T 7.10.3.3 Range when mounted on non-metallic carrier materials The transponder is generally designed for mounting on metallic objects which provide the conditions for the maximum reading ranges Table 7- 36 Range with non-metallic carriers Carrier material Range Transponder on wooden carrier approx.
Page 396: Technical Specifications
Transponder 7.10 SIMATIC RF625T 7.10.4 Technical specifications Table 7- 37 Technical specifications of the transponder SIMATIC RF625T 6GT2810-2EE0x Product type designation SIMATIC RF625T Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 ... 928 MHz • • Memory Chip (manufacturer/type) IMPINJ / MONZA 4QT...
Page 397 Transponder 7.10 SIMATIC RF625T 6GT2810-2EE0x Permitted ambient conditions Ambient temperature In operation, during write/read access -25 ... +85 °C • • In operation, outside write/read access -40 ... +125 °C • • During transportation and storage -40 … +125 °C •...
Page 398: Dimension Drawing
Transponder 7.10 SIMATIC RF625T 7.10.5 Dimension drawing Figure 7-25 SIMATIC RF625T UHF Disk Tag Units of measurement: All dimensions in mm 7.10.6 Certificates and approvals Table 7- 38 6GT2810-2EE00 - RF625T Certificate Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Table 7- 39 6GT2810-2EE01 - RF625T Certificate...
Page 399: Simatic Rf630T
Transponder 7.11 SIMATIC RF630T 7.11 SIMATIC RF630T 7.11.1 Characteristics The SIMATIC RF630T transponder is a passive (i.e. battery-free) and maintenance-free, cylindrical data carrier. It operates based on UHF Class 1 Gen 2 technology and is used to save the "Electronic Product Code" (EPC) of 96 bits/240 bits. The transponder also has a 512-bit user memory.
Page 400: Ordering Data
Transponder 7.11 SIMATIC RF630T 7.11.2 Ordering data Table 7- 40 Ordering data RF630T Product Article number SIMATIC RF630T (ETSI) 6GT2810-2EC00 SIMATIC RF630T (FCC) 6GT2810-2EC10 Delivery format SIMATIC RF630T is supplied in the following form: ● 10 transponders per packaging unit Minimum order quantity: 1 packaging unit (10 units) 7.11.3 Planning application...
Page 401 Transponder 7.11 SIMATIC RF630T Application example ① Antenna ② Object made of metal (e.g. motor block) ③ Transponder ④ Conveyor belt Figure 7-26 RF630T application example SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 402: Range When Mounted On Flat Metallic Carrier Plates
Transponder 7.11 SIMATIC RF630T 7.11.3.2 Range when mounted on flat metallic carrier plates The transponder generally has linear polarization. The polarization axis runs as shown in the diagram below. If the tag is mounted in the center of a flat metal plate, which is either approximately square or circular, it can be aligned in any direction since the transmitting and receiving RF660A antennas operate with circular polarization.
Page 403: Technical Specifications
Transponder 7.11 SIMATIC RF630T 7.11.4 Technical specifications Table 7- 42 Technical specifications of the transponder SIMATIC RF630T 6GT2810-2EC0x Product type designation SIMATIC RF630T Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 ... 928 MHz • • Memory Chip (manufacturer/type) NXP / G2XM...
Page 404 Transponder 7.11 SIMATIC RF630T 6GT2810-2EC0x Permitted ambient conditions Ambient temperature In operation, during write/read access -25 ... +85 °C • • In operation, outside write/read access -40 ... +125 °C • • During transportation and storage -40 … +125 °C •...
Page 405: Dimension Drawing
Transponder 7.11 SIMATIC RF630T 7.11.5 Dimension drawing Figure 7-28 SIMATIC RF630T Units of measurement: All dimensions in mm General tolerances in accordance with DIN ISO 2768f. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 406: Certificates And Approvals
Transponder 7.11 SIMATIC RF630T 7.11.6 Certificates and approvals Table 7- 43 6GT2810-2EC00 - RF630T Certificate Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Table 7- 44 6GT2810-2EC10 - RF630T Standard Passive labels and transponders comply with the valid regulations; certification is not required.
Page 407: Simatic Rf640T
Transponder 7.12 SIMATIC RF640T 7.12 SIMATIC RF640T 7.12.1 Characteristics SIMATIC RF640T transponder is a passive (i.e. battery-free) and maintenance-free, round- shaped data carrier. It operates based on UHF Class 1 Gen 2 technology and is used to save the "Electronic Product Code" (EPC) of 96 bits/240 bits. The transponder also has a 512-bit user memory.
Page 408: Planning The Use
Transponder 7.12 SIMATIC RF640T Delivery format SIMATIC RF640T is supplied in the following form: ● 10 transponders per packaging unit Minimum order quantity: 1 packaging unit (10 units) 7.12.3 Planning the use 7.12.3.1 Optimum antenna/transponder positioning with plane mounting of the transponder on metal Example of optimum antenna/transponder positioning Figure 7-29...
Page 409: Range When Mounted On Flat Metallic Carrier Plates
Transponder 7.12 SIMATIC RF640T 7.12.3.2 Range when mounted on flat metallic carrier plates The transponder generally has linear polarization. The polarization axis runs as shown in the diagram below. If the tag is mounted in the center of a flat metal plate, which is either approximately square or circular, it can be aligned in any direction since the transmitting and receiving RF660A antennas operate with circular polarization.
Page 410: Range When Mounted On Non-Metallic Carrier Materials
Transponder 7.12 SIMATIC RF640T 7.12.3.3 Range when mounted on non-metallic carrier materials The transponder is generally designed for mounting on metallic objects which provide the conditions for the maximum reading ranges Table 7- 47 Range with non-metallic carriers Carrier material Range Transponder on wooden carrier approx.
Page 411: Use Of The Transponder In Hazardous Areas For Gases
Transponder 7.12 SIMATIC RF640T 7.12.3.5 Use of the transponder in hazardous areas for gases Note Transponder labeling The labeling of the front of the transponder shown above is an example and can vary between batches produced at different times. This does not affect the hazardous area marking. Temperature class grading for gases The temperature class of the transponder for hazardous atmospheres (gases) depends on the ambient temperature and the radiated power of an antenna in the 865 - 868 MHz...
Page 412 Transponder 7.12 SIMATIC RF640T Temperature class assignment for gases and a radiated power less than 100 mW ERP If the radiated power of an antenna radiating into the hazardous area or located in the hazardous area and operating in the 865 - 868 MHz frequency band cannot exceed the value 100 mW, the temperature class assignment is as follows: Ambient temperature range Temperature class...
Page 413: Use Of The Transponder In Hazardous Areas For Dusts
Transponder 7.12 SIMATIC RF640T Figure 7-31 Maximum permitted ambient temperature depending on the radiated power 7.12.3.6 Use of the transponder in hazardous areas for dusts The equipment is suitable for dusts whose ignition temperatures for a dust layer of 5 mm are higher than 210 °C (smoldering temperature).
Page 414 Transponder 7.12 SIMATIC RF640T Temperature class assignment for dusts and a radiated power less than 500 mW ERP If the radiated power of an antenna radiating into the hazardous area or located in the hazardous area and operating in the 865 - 868 MHz frequency band cannot exceed the value 500 mW, the temperature class assignment is as follows: Ambient temperature range Temperature value...
Page 415 Transponder 7.12 SIMATIC RF640T WARNING Ignitions of dust-air mixtures Using the RF640T transponder with radiant power greater than 1280 mW ERP requires compliance with the reduced maximum ambient temperature (see diagram) for maintaining the maximum temperature value of 135 °C. Non-compliance with the permitted temperature ranges while using the transponder can lead to ignitions of dust-air mixtures.
Page 416: Technical Specifications
Transponder 7.12 SIMATIC RF640T 7.12.4 Technical specifications Table 7- 48 Technical specifications of the transponder SIMATIC RF640T 6GT2810-2DC0x Product type designation SIMATIC RF640T Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 ... 928 MHz • • Memory Chip (manufacturer/type) NXP / G2XM...
Page 417 Transponder 7.12 SIMATIC RF640T 6GT2810-2DC0x Permitted ambient conditions Ambient temperature In operation, during write/read access -25 ... +85 °C • • In operation, outside write/read access -40 ... +125 °C • • During transportation and storage -40 … +125 °C •...
Page 418 Transponder 7.12 SIMATIC RF640T WARNING Ignitions of gas-air or dust-air mixtures When using the RF640T transponder, check to ensure that the temperature values are observed in respect of the requirements of the hazardous area of application. Non-compliance with the permitted temperature ranges while using the transponder can lead to ignitions of gas-air or dust-air mixtures.
Page 419: Dimension Drawing
Transponder 7.12 SIMATIC RF640T 7.12.5 Dimension drawing Figure 7-33 SIMATIC RF640T Units of measure: All dimensions in mm SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 420: Certificates And Approvals
The producing factory of the RF640T has an ATEX quality assurance system recognized by the DEKRA EXAM GmbH with notice number BVS 11 ATEX ZQS/E111. Manufacturer's address - distributor Manufacturer's address - factory Siemens Aktiengesellschaft (PD PA CI) Siemens Aktiengesellschaft (DF FA CE) Process Industries and Drives Division Digital Factory...
Page 421: Simatic Rf645T
Transponder 7.13 SIMATIC RF645T 7.13 SIMATIC RF645T 7.13.1 Characteristics SIMATIC RF645T is a passive and maintenance-free on-metal data storage medium. It is specially designed for mounting directly on metal surfaces. It operates based on UHF Class 1 Gen 2 technology and is used to save the "Electronic Product Code" (EPC) up to 448 bits. The transponder also has 2048 bits of user memory.
Page 422: Technical Specifications
Transponder 7.13 SIMATIC RF645T Delivery format The SIMATIC RF645T is supplied in the following form: ● 20 transponders per packaging unit Minimum order quantity: 1 packaging unit (20 units) The mounting cover for SIMATIC RF645T is supplied in the following form: ●...
Page 423 Transponder 7.13 SIMATIC RF645T 6GT2810-2HC05 Mechanical specifications Material Plastic (ABS) Silicone-free Color Black Antenna material Aluminum Printing Permitted ambient conditions Ambient temperature In operation, during write/read access -40 ... +85 °C • • In operation, outside write/read access -40 ... +85 °C •...
Page 424: Dimension Drawing
Transponder 7.13 SIMATIC RF645T 7.13.4 Dimension drawing All dimensions in mm SIMATIC RF645T Figure 7-34 Dimension drawing of SIMATIC RF645T SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 425 Transponder 7.13 SIMATIC RF645T Retaining bracket for SIMATIC RF645T Figure 7-35 Dimension drawing mounting cover (6GT2898-5AA00) for SIMATIC RF645T SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 426: Certificates And Approvals
Transponder 7.13 SIMATIC RF645T Figure 7-36 Dimension drawing (6GT2898-5AB00) for SIMATIC RF645T 7.13.5 Certificates and approvals Table 7- 53 Certificates and approvals Labeling Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Passive labels and transponders comply with the valid regulations; certification is not required.
Page 427: Simatic Rf680T
Transponder 7.14 SIMATIC RF680T 7.14 SIMATIC RF680T 7.14.1 Characteristics The heat-resistant SIMATIC RF680T transponder is a passive, maintenance-free data carrier. It operates based on UHF Class 1 Gen 2 technology and is used to save the "Electronic Product Code" (EPC) of 96 bits/240 bits. The transponder also has a 512-bit user memory.
Page 428: Ordering Data
Transponder 7.14 SIMATIC RF680T 7.14.2 Ordering data Table 7- 54 Ordering data RF680T Product Article number SIMATIC RF680T 6GT2810-2HG80 Delivery format SIMATIC RF680T is supplied in the following form: ● 10 transponders per packaging unit Minimum order quantity: 1 packaging unit (10 units) 7.14.3 Planning the use 7.14.3.1...
Page 429: Range When Mounted On Flat Metallic Carrier Plates
Transponder 7.14 SIMATIC RF680T 7.14.3.2 Range when mounted on flat metallic carrier plates The transponder generally has linear polarization. The polarization axis runs as shown in the diagram below. If the transponder is centrally mounted on a plane metal plate, which may either be almost square or circular, it can be aligned in any direction if the transmitting and receiving antennas operate with circular polarization (such as the RF660A).
Page 430: Use Of The Transponder In The Hazardous Area
Transponder 7.14 SIMATIC RF680T 7.14.3.4 Use of the transponder in the hazardous area TÜV NORD CERT GmbH, appointed center no. 0044 as per Article 9 of the Directive 94/9/EC of the European Council of 23 March 1994, has confirmed the compliance with the essential health and safety requirements relating to the design and construction of equipment and protective systems intended for use in hazardous areas as per Annex II of the Directive.
Page 431 Transponder 7.14 SIMATIC RF680T Note Transponder labeling The labeling of the front of the transponder shown above is an example and can vary between batches produced at different times. This does not affect the hazardous area marking. Temperature class delineation for gases The temperature class of the transponder for hazardous atmospheres (gases) depends on the ambient temperature and the radiated power of an antenna in the 865 - 868 MHz frequency band within the hazardous area.
Page 432 Transponder 7.14 SIMATIC RF680T Temperature class assignment for gases and a radiated power less than 500 mW ERP If the radiated power of an antenna radiating into the hazardous area or located in the hazardous area and operating in the 865 - 868 MHz frequency band cannot exceed the value 500 mW, the temperature class assignment is as follows: Ambient temperature range Temperature class...
Page 433: Use Of The Transponder In The Hazardous Area For Dusts
Transponder 7.14 SIMATIC RF680T Temperature class assignment for gases and a radiated power of 10 mW to 2000 mW ERP If the radiated power of an antenna radiating into the hazardous area or of an antenna located in the hazardous area in the 865 - 868 MHz frequency band cannot exceed the radiated power selected in the following diagram, the maximum permitted ambient temperature range can be found in the corresponding temperature function of the diagram.
Page 434 Transponder 7.14 SIMATIC RF680T Temperature class delineation for dusts WARNING Ignitions of dust-air mixtures When using the RF680T transponder, check to make sure that the temperature values are adhered to in keeping with the requirements of the area of application Non-compliance with the permitted temperature ranges while using the transponder can lead to ignitions of dust- air mixtures.
Page 435 Transponder 7.14 SIMATIC RF680T Temperature class assignment for dusts and a radiated power of 10 mW ERP to 2000 mW ERP If the radiated power of an antenna radiating into the hazardous area or located in the hazardous area and operating in the 865 - 868 MHz frequency band can be between the values 10 mW ERP and 2000 mW ERP, the temperature class assignment is as follows: Ambient temperature range Temperature value...
Page 436: Technical Specifications
Transponder 7.14 SIMATIC RF680T 7.14.4 Technical specifications Table 7- 56 Technical specifications of the transponder SIMATIC RF680T 6GT2810-2HG80 Product type designation SIMATIC RF680T Radio frequencies Operating frequency ETSI 865 to 868 MHz • • 902 ... 928 MHz • • Memory Chip (manufacturer/type) NXP / G2XM...
Page 437 Transponder 7.14 SIMATIC RF680T 6GT2810-2HG80 Permitted ambient conditions Ambient temperature In operation, during write/read access -25 … +100 °C, permanent • • Special features: +100 ... +140 °C, 20 % reduction of the limit distance As of +140 °C, no processing possible Up to +200 °C, tested up to 5000 hours or 3000 cycles Up to +220 °C, tested up to 2000 hours or...
Page 438: Dimension Drawing
Transponder 7.14 SIMATIC RF680T 7.14.5 Dimension drawing Figure 7-41 Dimension drawing of SIMATIC RF680T All dimensions in mm Tolerances unless indicated otherwise ±0.5 mm. 7.14.6 Certificates and approvals Table 7- 57 6GT2810-2HG80 - RF680T Certificate Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Conformity with the ATEX directive 2014/34/EU Table 7- 58...
Page 439 The producing factory of the RF680T Version 1 has an ATEX quality assurance system recognized by the DEKRA EXAM GmbH with certificate number BVS 11 ATEX ZQS/E111. Manufacturer's address - distributor Manufacturer's address - factory Siemens Aktiengesellschaft (PD PA CI) Siemens Aktiengesellschaft (DF FA CE) Process Industries and Drives Division Digital Factory...
Page 440: Simatic Rf682T
Transponder 7.15 SIMATIC RF682T 7.15 SIMATIC RF682T 7.15.1 Characteristics The heat-proof SIMATIC RF682T is a passive and maintenance-free data carrier. The RF682T operates based on the UHF Class 1 Gen 2 technology and is used to store the "Electronic Product Code" (EPC) of 224 bits. The transponder also has a 3072-bit user memory.
Page 441: Planning Operation
Transponder 7.15 SIMATIC RF682T Delivery format The SIMATIC RF682T is available in the following form: ● 10 transponders per packaging unit Minimum order quantity: 1 packaging unit The mounting set for SIMATIC RF682T is available in the following form: ● 10 mounting sets per packaging unit Minimum order quantity: 1 packaging unit 7.15.3 Planning operation...
Page 442: Range When Mounted On Flat Metallic Carrier Plates
Transponder 7.15 SIMATIC RF682T NOTICE Mounting at a high temperature To relieve mechanical strain or tension on the transponder, when using the transponder at temperatures > 80 °C the transponder should be mechanically separated from the supporting surface by using the mounting brackets (due to the differing expansion coefficients of all materials).
Page 443: Technical Specifications
Transponder 7.15 SIMATIC RF682T 7.15.4 Technical specifications Table 7- 60 Technical specifications of SIMATIC RF682T 6GT2810-3HG80 Product designation SIMATIC RF682T Radio frequency Operating frequency ETSI 865 to 868 MHz • • 902 to 928 MHz • • Memory Chip (manufacturer/type) NXP UCode DNA Memory type EEPROM...
Page 444 Transponder 7.15 SIMATIC RF682T 6GT2810-3HG80 Permitted ambient conditions Ambient temperature In operation, during write/read access -25 to +100 °C permanently • • Special features: As of +140 °C, no processing possible In operation, outside write/read access -40 to +220 °C •...
Page 445: Dimension Drawing
Transponder 7.15 SIMATIC RF682T 7.15.5 Dimension drawing Figure 7-44 Dimension drawing of SIMATIC RF682T Figure 7-45 Dimension drawing mounting for SIMATIC RF68xT All dimensions in mm Tolerances unless indicated otherwise ±0.5 mm. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 446: Certificates And Approvals
Transponder 7.15 SIMATIC RF682T 7.15.6 Certificates and approvals Table 7- 61 Certificates and approvals Labeling Description Conformity with the RED directive 2014/53/EU Conformity with the RoHS directive 2011/65/EU Passive labels and transponders comply with the valid regulations; certification is not required. Federal Communications Commission SIMATIC RF600...
Page 447: Integration Into Networks
Configuration manual "SIMATIC RF600", section "OPC UA interface" section "OPC UA interface" You can find the "SIMATIC RF600" configuration manual on the pages of "Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/ps/15088/man)". Integration in IT networks via the user application Connecting the RF600 readers using XML If you want to create your own applications for the RF600 readers, you can do this using the XML-based demo application of the reader.
Page 448: Integration In Control Networks
Linux operating system integrated in the reader. For this function, you need special activation of the reader in the form of firmware. It is only available upon request. Contact your local Siemens office about this. Integration in control networks...
Page 449 Configuration graphic with SIMATIC RF680R (or RF685R) and PROFINET connection via an Ethernet/IP controller Figure 8-3 Configuration graphic with SIMATIC RF680R (or RF685R) and PROFIBUS connection You will find more information on the ASM 456 in the operating instructions "ASM 456 (https://support.industry.siemens.com/cs/ww/en/view/32629442)". SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 450 Integration into networks 8.3 Integration in control networks SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 451: System Diagnostics
System diagnostics Diagnostics via the LED displays of the reader Please note that only the RF680R/RF685R readers have LED status display. RF615R/RF650R readers have a "PRESENCE" display instead. With the help of the LED displays, you can read out the status and the error messages of the RF680R/RF685R readers.
Page 452 System diagnostics 9.1 Diagnostics via the LED displays of the reader Indicates that data is being sent and/or received via Ethernet RECEIVE/TRANSMIT 2 • interface "2". (R/T2) - only with RF680R/RF685R Figure 9-1 LED displays of the RF61xR, RF650R and RF68xR readers Functions of the "PRE"...
Page 453: How The Led Status Display Works
System diagnostics 9.1 Diagnostics via the LED displays of the reader ● Display of RF activity Indicates whether the reader is sending via the antenna (constant green), whether transponders were detected by the reader (flashing yellow) and whether a transponder was sent to the user application (constant yellow).
Page 454 System diagnostics 9.1 Diagnostics via the LED displays of the reader Example The error "0x12" (XML error message) is displayed. Converted to binary, this results in the value "0001 0010". This converted value is displayed in the LED status display. The value "0"...
Page 455: Diagnostics Via Led Operating Display
System diagnostics 9.1 Diagnostics via the LED displays of the reader 9.1.2 Diagnostics via LED operating display The operating states of the reader are displayed by the "RUN/STOP", "ERROR", "MAINTENANCE" and "PRESENCE" LEDs. The LEDs can adopt the colors green, red or yellow and the statuses off , on , flashing : Table 9- 1...
Page 456: Xml/Plc Error Messages
System diagnostics 9.2 XML/PLC error messages XML/PLC error messages Note that if there are error messages, the error LED ("ER") of the reader flashes. You can read the error using the XML or PLC error codes. As an alternative, you can also recognize the error using the LED status display of the RF680R and RF685R readers as described in the section "How the LED status display works (Page 453)".
Page 457 System diagnostics 9.2 XML/PLC error messages "ER" XML/ PLC block Error description (hex) (hex) 2 Hz 0xA4 0xE2FE84 The selected antenna is not enabled. 2 Hz 0xA5 0xE2FE85 The selected frequency is not enabled. 2 Hz 0xA6 0xE2FE86 The carrier signal is not activated. 2 Hz 0xA7 0xE2FE87...
Page 458 System diagnostics 9.2 XML/PLC error messages "ER" XML/ PLC block Error description (hex) (hex) 2 Hz 0xC1 0xE4FE81 The specified tag field of the transponder is unknown. 2 Hz 0xCA 0xE4FE8A General error 2 Hz 0xCB 0xE4FE8B No or bad configuration data/parameters were transferred. Possible cause: You are accessing a read point that is not configured.
Page 459 System diagnostics 9.2 XML/PLC error messages "ER" XML/ PLC block Error description (hex) (hex) 2 Hz 0x54 0xE5FE04 Invalid data block number (DBN) on the reader/communications module 0x55 0xE5FE05 Invalid data block number (DBN) in the Ident profile 2 Hz 0x56 0xE5FE06 Invalid data block length (DBL) on the reader/communications module...
Page 460 System diagnostics 9.2 XML/PLC error messages "ER" XML/ PLC block Error description (hex) (hex) 2 Hz 0x63 0xE6FE03 A parameter of an XML command has an invalid value or the parameter assignment of • the communications module or the reader was incorrect. Possible causes / action to be taken: –...
Page 461 System diagnostics 9.2 XML/PLC error messages "ER" XML/ PLC block Error description (hex) (hex) 0x65 0xE6FE05 An error has occurred that makes a Reset_Reader ("WRITE-CONFIG" with "Config = 3") necessary. Possible causes / action to be taken: The "WRITE-CONFIG" command is incorrect. •...
Page 462 System diagnostics 9.2 XML/PLC error messages "ER" XML/ PLC block Error description (hex) (hex) 0x97 0xE7FE09 Command repetition is not supported. 0x7A 0xE7FE0A Error during the transfer of the PDU (Protocol Data Unit). "--" means that the error is not displayed by the LEDs. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 463: Accessories
Furthermore, the US version has been UL-certified for the US and Canada. Table 10- 1 Wide-range power supply unit for SIMATIC RF systems Characteristics Area of application Voltage supply for Siemens Ident de- vices Degree of protection IP67 Design features Mechanically and electrically rug- •...
Page 464: Ordering Data
Accessories 10.1 Wide-range power supply unit for SIMATIC RF systems 10.1.3 Ordering data Table 10- 2 Ordering data for the wide-range power supply unit for SIMATIC RF systems Article number Wide-range power supply unit for SIMATIC RF systems EU: 6GT2898-0AC00 (100 - 240 VAC / 24 VDC / 3 A) UK: 6GT2898-0AC10 with 2 m connecting cable with country-specific power cable/plug...
Page 465: Safety Information
Accessories 10.1 Wide-range power supply unit for SIMATIC RF systems 10.1.4 Safety Information WARNING Danger to life It is not permitted to open the device or to modify the device. The following must also be taken into account: • Failure to observe this requirement shall constitute a revocation of the CE approval, UL certification for the US and Canada as well as the manufacturer's warranty.
Page 466: Mounting & Connecting
Safety notes for the US and Canada The readers of the SIMATIC RF600 series may only be operated with the wide range power supply unit for SIMATIC RF systems - as an optional component – or with power supply units that are UL-listed in combination with the safety standards specified below: ●...
Page 467 Accessories 10.1 Wide-range power supply unit for SIMATIC RF systems Follow the steps below to mount and connect the wide-range power supply unit: 1. Mount the wide-range power supply using the 4x screws. ④ Remember to make the grounding connection with the mounting hole provided by the metal shoe.
Page 468 Tighten the screw with a torque of ≃ 1.5 Nm. Grounding connection Hexagon-head screw (M5) Flat washer Cable lug Contact washer: To make ground contact, use contact wash- ers according to the Siemens standard: SN 70093-6-FStflNnnc- 480h, Siemens item no.: H70093-A60-Z3 SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 469: Pin Assignment Of Dc Outputs And Mains Connection
Accessories 10.1 Wide-range power supply unit for SIMATIC RF systems Degree of protection The wide-range power supply unit for SIMATIC RF systems meets degree of protection IP67. ● Dust-tight: No ingress of dust ● Protected against harm from temporary submersion in water: Water must not enter in amounts that can cause damage, if the housing is immersed in water 1 m deep for 30 minutes.
Page 470: Technical Specifications
Accessories 10.1 Wide-range power supply unit for SIMATIC RF systems 10.1.7 Technical specifications Table 10- 6 Technical specifications 6GT2898-0ACx0 Product type designation Wide-range power supply unit for SIMATIC RF systems Electrical data Insulation strength (prim./sec.) U AC 3.3 kV isol p/s Primary- secondary side are galvanically isolated Insulation resistance R >...
Page 471 Accessories 10.1 Wide-range power supply unit for SIMATIC RF systems 6GT2898-0ACx0 Noise immunity EN 61000-6-2 / EN 61000-4-2 • Contact discharge: 4 kV (air discharge): 8 kV EN 61000-6-2 / EN 61 000-4-4 Burst • Symmetrical: 2 kV Asymmetrical: 2 kV EN 61000-6-5 / EN 61 000-4-5 Surge •...
Page 472 Accessories 10.1 Wide-range power supply unit for SIMATIC RF systems 6GT2898-0ACx0 Regulation Line regulation ≤ 1.0% • • at U = min./max. Load regulation ≤ 1.0% • • at I = 10...90...10% Short-circuit current I 105 ... 130 % I at I = 3 A (+50 °C) Settling time t...
Page 473: Dimension Drawing
Accessories 10.1 Wide-range power supply unit for SIMATIC RF systems 10.1.8 Dimension drawing Figure 10-1 Dimension drawing wide-range power supply unit for SIMATIC RF systems All dimensions in mm SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 474: Certificates And Approvals
Accessories 10.1 Wide-range power supply unit for SIMATIC RF systems 10.1.9 Certificates and approvals Table 10- 8 Approvals for wide-range power supply unit for SIMATIC RF systems (Europe, UK): 6GT2898-0AC00, 6GT2898-0AC10 Marking Description CE approval acc. to 2004/108/EG - EMC •...
Page 475 Accessories 10.1 Wide-range power supply unit for SIMATIC RF systems Engineering Conditions of Acceptability For use only in or with complete equipment where the acceptability of the combination is determined by ULLLC. When installed in an end-product, consideration must be given to the following: ●...
Page 476: Power Splitter For Rf600 Systems
Accessories 10.2 Power splitter for RF600 systems 10.2 Power splitter for RF600 systems 10.2.1 Characteristics Using the power splitter, two antennas can be connected to one antenna connector of a reader. The power fed in at the input (S) is split over two outputs (1, 2). Power splitter Characteristics Application...
Page 477: Example Of A Configuration
Accessories 10.2 Power splitter for RF600 systems 10.2.3 Example of a configuration The following example of a configuration shows a setup with one RF680R reader, one power splitter and two RF640A antennas. Figure 10-2 Example of a configuration with an RF600 system with a power splitter The link between the reader and the power splitter (3.2 dB attenuation) is via a cable 1 m in length (0.5 dB cable attenuation).
Page 478: Technical Specifications
Accessories 10.2 Power splitter for RF600 systems 10.2.4 Technical specifications Table 10- 12 Technical specifications 6GT2890-0BC00 Product type designation Power splitter Electrical data Transmission frequency 500 ... 1000 MHz Max. input power 10 W Impedance 50 Ω Attenuation between 3.2 dB input and outputs Connector RTNC plug...
Page 479: Dimension Drawing
Accessories 10.3 Reader and antenna holders 10.2.5 Dimension drawing Figure 10-3 Power splitter dimension drawing All dimensions in mm 10.3 Reader and antenna holders 10.3.1 Overview The following read points (readers and antennas) have a standardized VESA 100 mounting system (4 x M4) and can be secured with a holder: ●...
Page 480: Antenna Mounting Kit
Accessories 10.3 Reader and antenna holders 10.3.3 Antenna mounting kit Flexible mounting is possible using the antenna mounting kit. An antenna can then be rotated in any direction in space. Antenna mounting kit Description Pivot range of antenna mounting kit ①...
Page 481: Simatic Antenna Holder
Accessories 10.3 Reader and antenna holders Antenna mounting kit Description VESA adapter plate From VESA 75 x 75 to VESA 100 x 100 The VESA adapter plate is required to fix the antenna to the antenna mounting kit. Hole drilling template for fixing the antenna mounting kit to the wall.
Page 482 Accessories 10.3 Reader and antenna holders 4. Mount the antenna mounting plate (C) into the articulated joint (B) and fasten it with the ② help of screws to the articulated joint (B). 5. Align the SIMATIC antenna holder by sliding the setting angle on the articulated joint (B) and tighten all the screws.
Page 483: Dimension Drawing
Accessories 10.3 Reader and antenna holders 10.3.4.2 Dimension drawing Figure 10-5 Front view SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 484 Accessories 10.3 Reader and antenna holders Figure 10-6 Top view with section A-A SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 485 Accessories 10.3 Reader and antenna holders Figure 10-7 Section A-A All dimensions in mm. SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 486 Accessories 10.3 Reader and antenna holders SIMATIC RF600 System Manual, 11/2018, J31069-D0171-U001-A21-7618...
Page 487: Appendix
DIN ISO 9001 certificate The quality assurance system for the entire production process (development, production, and marketing) at Siemens fulfills the requirements of ISO 9001 (corresponds to EN29001: 1987). This has been certified by DQS (the German society for the certification of quality management systems).
Page 488 Appendix A.1 Certificates and approvals Labeling Description UL recognition mark Canadian Standard Association (CSA) according to the standard C22.2. No. 60950 (LR 81690) or acc. to C22.2 No. 142 (LR 63533) Canadian Standard Association (CSA) per American Standard UL 60950 (LR 81690) or per UL 508 (LR 63533) This product meets the requirements of the AS/NZS 3548 Norm.
Page 489 Appendix A.1 Certificates and approvals Federal Communications This equipment has been tested and found to comply with the limits Commission for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against Radio Frequency Interference harmful interference when the equipment is operated in a commercial Statement...
Page 490: Service & Support
Service & support Industry Online Support In addition to the product documentation, the comprehensive online information platform of Siemens Industry Online Support at the following Internet address: Link 1: (https://support.industry.siemens.com/cs/de/en/) Apart from news, there you will also find: ● Project information: Manuals, FAQs, downloads, application examples etc.
