Ryobi GD201 Addendum Manual

ADDENDUM FOR
RYOBI GARAGE DOOR OPENER
WARNING:
This addendum is not a substitute for reading the operator's
manual. To reduce the risk of injury or death, user must read
and understand operator's manual before installing or using this
product. All page references refer to the operator's manual.
NOTE: Install felt washer onto the drive shaft of the RYOBI garage door
opener prior to assembling the sprocket and the rails as described on
page 18 of the operator's manual.
INSTALLING THE FELT WASHER
See Figures 1 - 2.
When installed correctly, the felt washer can prolong the life of the
motor. To install:
 Place the power head on a towel or the packaging material with the
light cover facing down. Do not place the unit directly on hard surfaces
as this may damage the light cover and motion sensor.
 Remove the felt washer from the plastic bag.
NOTE: The felt washer has been premixed with sufficient lubricant.
No additional lubricant is required. Do not attempt to dry or "clean"
the felt washer.
 Slide the felt washer down the motor shaft and onto the base of the
power head.
991000982
1-6-17 (REV:04)
Fig. 1
A
A - Plastic Bag (sac en plastique , saco plástico)
B - Felt Washer (rondelle en feutre, arandela de fieltro)
Fig. 2
C
A - Felt Washer (rondelle en feutre, arandela de fieltro)
B - Shaft (arbre, eje)
C - Power Head (bloc moteur, cabezal motor)
B
B
A
