Model AV-28 media center setup

Figure 7
Lifestyle ® stereo amplifier
to AV-28 media center
connections
®
Lifestyle stereo amplifier rear panel
Setting Up Your Lifestyle
CAUTION: Before making connections, turn the Lifestyle
center from the AC (mains) power outlet. DO NOT plug the amplifier into an outlet until you have
completed all other connections.
1. Insert the 8-to-9-pin adapter into the SPEAKER ZONES 2 output jack on the rear panel of
the media center (Figure 7).
2. Insert one end of the Bose
3. Insert the other end of the Bose
panel of the Lifestyle ®
BoseLink
OUTPUT
BoseLink
INPUT
20-ft Bose
®
link A cable into the 8-to-9-pin adapter.
®
link A cable, into the Bose
stereo amplifier.
8-to-9-pin
DIN adapter
®
link A cable
®
Stereo Amplifier
®
system off and disconnect the media
®
link input jack on the rear
AV-28 media center rear panel
13
