U-MATCH B SERIES
WITH HIGH-STATIC B SERIES SLIM DUCT
DUCTED STYLE INDOOR UNITS
U-MATCH SERIES DC INVERTER AIR
CONDITIONERS SERVICE MANUAL
T1/R410A/60Hz
(GC201604 -
)
І

Advertisement

Table of Contents
loading

Related Manuals for Gree U-MATCH B Series

Summary of Contents for Gree U-MATCH B Series

  • Page 1 U-MATCH B SERIES WITH HIGH-STATIC B SERIES SLIM DUCT DUCTED STYLE INDOOR UNITS U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL T1/R410A/60Hz (GC201604 - І...

  • Page 2: Table Of Contents

    CONTENTS PRODUCT ................................. 2 1 MODELS LIST ............................2 1.1 Outdoor Unit ............................2 1.2 Indoor Unit ............................3 2 NOMENCLATURE ............................4 2.1 Outdoor Unit ............................4 2.2 Intdoor Unit ............................5 3 PRODUCT DATA ............................6 3.1 Product Data of Indoor Unit ......................6 3.2 Operation Range ..........................
  • Page 3 1.2 Description of Drive Malfunction ....................75 2 FLOW CHART OF TROUBLESHOOTING ....................76 2.1 Troubleshooting Flow Chart of Main Control Malfunction ............76 2.2 Troubleshooting Flow Chart of Drive Malfunction ............... 83 2.3 Interface ............................88 2.4 IPM, PFC Testing Method ........................ 92 3 WIRING DIADRAM ...........................
  • Page 4 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL PRODUCT...

  • Page 5: Product

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL PRODUCT 1 MODELS LIST 1.1 Outdoor Unit Power Supply Appearance Model Name Product Code (V, Ph, Hz) UMAT18HP230V1BO CF090W1040 208/230V~60Hz UMAT24HP230V1BO CF090W1060 208/230V~60Hz UMAT30HP230V1BO CF090W1050 208/230V~60Hz UMAT36HP230V1BO CF090W1030 208/230V~60Hz UMAT42HP230V1BO CF090W1020 208/230V~60Hz UMAT48HP230V1BO CF090W1070 208/230V~60Hz...

  • Page 6: Indoor Unit

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 1.2 Indoor Unit Nominal Capacity Power Type Model Name Product Code Cooling/Heating Supply Appearance (Btu/h) (V, Ph, Hz) 17000/19000 208/230V~60Hz UMAT18HP230V1BD CF022N0950 23800/27200 208/230V~60Hz UMAT24HP230V1BD CF022N0940 28300/31300 208/230V~60Hz UMAT30HP230V1BD CF022N1000 Duct Type 34100/40900 208/230V~60Hz UMAT36HP230V1BD...

  • Page 7: Nomenclature

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 2 NOMENCLATURE 2.1 Outdoor Unit Description Options Gree Electric Appliances Inc Capital Letter :G Unit Type U=U-Match Outdoor Unit C=Cool Only Product Type H=Heat Pump without Aux Electric Heaters N=Constant Frequency Compressor Power Supply...

  • Page 8: Intdoor Unit

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 2.2 Intdoor Unit Description Options Gree Electric Appliances Inc Capital Letter :G Unit Type F=Duct Type; K=Cassette Type; T= Floor-ceiling Type C=Cool Only Product Type H=Heat Pump without Aux Electric Heaters Nominal Cooling Capacity Nominal Cooling Capacity =Number×1000Btu/h...

  • Page 9: Product Data

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 3 PRODUCT DATA 3.1 Product Data of Indoor Unit Duct Type UMAT18HP230V1BD UMAT24HP230V1BD Indoor unit Product Code CF022N1000 CF022N0940 Model UMAT18HP230V1BO UMAT24HP230V1BO Outdoor unit Product Code CF090W1040 CF090W1060 Cooling Capacity 5.0(1.60-5.80) 7.0(2.40-8.20) Capacity Heating Capacity 5.6(1.40-6.80)
  • Page 10 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL UMAT36HP230V1BD UMAT30HP230V1BD Indoor unit Product Code CF022N0950 CF022N0930 Model UMAT30HP230V1BO UMAT36HP230V1BO Outdoor unit Product Code CF090W1050 CF090W1030 Cooling Capacity 8.30(2.60-9.20) 10.0(3.20-11.50) Capacity Heating Capacity 9.20(2.40-9.90) 12.0(2.90-14.50) Cooling 3.30(0.85-3.70) 3.60(0.70-4.50) Power Input Heating 3.10(0.80-3.50) 3.40(0.70-4.60) SEER / HSPF...
  • Page 11 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL UMAT42HP230V1BD UMAT48HP230V1BD Indoor unit Product Code CF022N0900 CF022N0990 Model UMAT42HP230V1BO UMAT48HP230V1BO Outdoor unit Product Code CF090W1020 CF090W1070 Cooling Capacity 12.0(3.90-12.50) 14.0(6.00-14.50) Capacity Heating Capacity 13.8(3.90-15.50) 16.0(5.20-17.00) Cooling 4.00(0.65-4.70) 5.15(1.40-5.60) Power Input Heating 3.10(0.76-4.75) 5.15(1.30-5.50) SEER / HSPF...

  • Page 12: Operation Range

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Note: Nominal capacities are based on the follow conditions. Outdoor ℃(℉) Indoor ℃(℉) Mode DB:26.7(80.0) DB:35.0(95.0) Cooling WB:19.4(67.0) WB:23.9(75.0) DB:21.1(70.0) DB:8.33(47.0) Heating WB:15.6(60.0) WB:6.11(43.0) Piping Length 18-48k 7.6m(25.0ft) The air volume is measured at the relevant standard external static pressure. Noise is tested in the Semianechoic room, so it should be slightly higher in the actual operation due to environmental change.

  • Page 13: Piping Diagram

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Notes: RLA: Rated load amperes LRA: Locked rotor amperes FLA: Full load current ①. The fuse is located on the main board. ②. Install the disconnect device with a contact gap of at least 3mm (1/8inch) in all poles nearby the units (Both indoor unit and outdoor unit).The appliance must be positioned so that the plug is accessible.
  • Page 14 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL CONTROL...

  • Page 15: Control

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL CONTROL 1 OPERATION FLOWCHART 1.1 Cooling/Dry Operation Power Open unit running at cool or dry mode Indoor fan run Satisfying open Comp. condition Comp. and outdoor fan run Temp of indoor ≤Set temp Comp.

  • Page 16: Heating Operation

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 1.2 Heating Operation Power Open unit running at heat mode Satisfying open comp. condition Comp. and outdoor fan run Avoid cool wind (only when comp. start) Temp of indoor ≥Set temp Comp. and outdoor fan stop Comp.

  • Page 17: Wireless Remote Controller

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 2 WIRELESS REMOTE CONTROLLER 2.1 Operation and Display View Table 2-2-1 Operation instruction of wireless remote controller Name Function Description Signal  Signal transmitter transmitter  Press this button and the unit will be turned on; press it once more, and the unit will be turned ON/OFF off.
  • Page 18 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL  Preset temperature can be increased by pressing this button. Pressing and holding this button for more than 2 seconds can make the temperature changed quickly until release the button + button and then transmit this order.

  • Page 19: Wired Controller

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL  In the Cool or Heat mode, pressing this button can activate or deactivate the TURBO function. TURBO When the TURBO function is activated, its symbol will be displayed; when the running button mode or the fan speed is changed, this function will be canceled automatically.(This function is applicable to partial of models).
  • Page 20 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Figure 2-3-2 LCD display of wired controller Table 2-3-1 Instruction to LCD Display Icons Introduction Left and right swing function Up and down swing function Air exchange function Sleep function Auto mode COOL mode DRY mode FAN mode...

  • Page 21: Operation View

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Ambient/setting temperature Electric heater Blow function Defrosting function Filter cleaning Timer Setting Keycard control / Detected status sensed by human body Quiet function Lock function 3.2 Operation View 3.2.1 Silk Screen of Buttons Figure 2-3-3 Silk screen of buttons 3.3.2 Instruction to Function of Buttons Table 2-3-2 Instruction to buttons of wired controller...
  • Page 22 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Mode Setting of auto/cooling/heating/fan/dry mode of indoor unit. Switch over among these functions swing/air/sleep/health/ Function I-Demand/out/turbo/save/e-heater/X-fan/clean/quiet. Timer Timer setting. On/Off Turn on/off indoor unit. Press Mode and ▲ buttons at the same time for 5s under off state of the unit 4 Mode to enter/cancel memory function (If memory function is set, indoor unit will Memory...
  • Page 23 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 3.2.3 Setting of Wired Controller’s Address 3.2.3.1 Enquiry and Setting of Wired Controller’s Address Under off state of the unit, press Function and Mode buttons at the same time for 5s to enter setting interface of wired controller‘s address.

  • Page 24: Operation Instruction Of Special Functions

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Setting of master/slave wired controller‘s address is shown as Figure 2-3-5 below: Figure 2-3-5 Enquiry and setting of master/slave wired controller‘s address 4 OPERATION INSTRUCTION OF SPECIAL FUNCTIONS 4.1 Setting of Filter Clean Reminder Function When unit is on, press Function button to switch to filter clean reminder function.
  • Page 25 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Figure 2-4-1 Setting of filter clean reminder function When setting the filter clean reminder function, timer zone will display 2 digits, of which the former indicates the pollution degree of operating place and the latter indicates the accumulated operating time of indoor unit.

  • Page 26: Low Temperature Drying Function

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL indicates the accumulated operating time is 1400hr. Each time the latter digit increases 1, the accumulated operating time increases 400hr. When it reaches 9, it means the accumulated operating time is 5000hr; (4) Heavy pollution: the former digit in timer zone shows 3 while the latter one shows 0, which indicates the accumulated operating time is 100hr.

  • Page 27: Lock Function

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 4.3 Lock Function When unit is turned on normally or turned off, pressing ▲ and ▼ buttons at the same time for 5s will . Pressing ▲ and ▼ buttons at the same time for 5s to turn off turn on Lock function.

  • Page 28: Enquiry Of Historical Malfunction

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL zone displays ambient temperature type 01 or 02. Ambient temperature zone displays the corresponding temperature of that type. 01 stands for outdoor ambient temperature and 02 stands for the indoor ambient temperature after compensation. Press Mode button to switch between 01 and 02. Pressing other buttons except Mode button or receiving remote control signal will exit enquiry state.
  • Page 29 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 4.9.3 Displaying setting of freeze protection error code Under debugging state, press Mode button to adjust to ―02‖ in temperature displaying zone. Timer zone displays setting state and press ▲ or ▼ button to adjust. There are 2 selections: ①...
  • Page 30 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 4.9.8 Selecting door control function Under debugging state, press Mode button to adjust to ―08‖ in temperature displaying zone. Timer zone displays setting state and press ▲ or ▼ button to adjust. There are 2 selections: ①...

  • Page 31: Installation Of Wired Controller

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 4.9.12 Selecting compensation of temperature sensor at air return Under debugging state, press Mode button to adjust to ―12‖ in temperature displaying zone. Timer zone displays setting state and press ▲ or ▼ button to adjust. There are 16 selections: (1) Compensate 0℃(32℉) (LCD displays 00).

  • Page 32: Installation Position And Requirement

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Figure 2-5-1 5.2 Installation Position and Requirement (1) Prohibit installing the wired controller at the misty place or the place with direct sunlight. (2) Prohibit installing the wired controller at the place near high temperature objects or water-splashing places.

  • Page 33: Removal Of Wired Controller

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Figure 2-5-2 Installation of wired controller Brief instructions of installation procedure: 1) Pull out the 2-core signal wire in the installation hole of the wall and then let this wire go through the hole at the back of wired controller‘s base plate.

  • Page 34: Troubleshooting

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 6 TROUBLESHOOTING 6.1 Display of Error Code Table 2-6-1 Error Code List Error Code Error Compressor high pressure protection Freeze protection Compressor low pressure protection, refrigerant lacking protection, refrigerant recycling mode Compressor high discharge temperature protection Communication malfunction Malfunction of indoor fan motor Full water protection...

  • Page 35: Centralized Controller

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL When there is a malfunction during operation, error will be displayed on the temperature displaying zone of LCD. When several malfunctions occur at the same time, these error code will be displayed circularly.
  • Page 36 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 7.1.3 Functions of Press Buttons Table 2-7-1 Functions of Press Buttons Name Function Description Mode It is used for the switchover among different modes. It is used to set the fan speed, high, medium, low or auto. On/Off It is used to set the on/off status of the indoor unit.
  • Page 37 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 7.1.4.2 Introduction to Symbols on the LCD Figure 2-7-3 Table 2-7-2 Introduction to the Symbols on the LCD Name Description Fan speed It displays the fan speed of the indoor unit, high, medium, low and auto. Running mode It displays the running mode of the indoor unit, auto, cool, dry, fan and heat.

  • Page 38: Additional Special Functions

    7.2.1 Door control function Door control function is available for this series. In order to achieve this function, please select the door control accessories from Gree. (1) Interface instructions 1) The interface printing is DOOR-C and the type is B2B-XH-B. The wires of door control accessories must be connected to this interface;...
  • Page 39 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL X2 in the following Figure). X1 is AC 220V signal input and X2 is DC +5V to 24V. You can only choose X1 or X2. Definition of interface is as shown in Figure below: Figure 2-7-6 Illustration of door control port Table 2-7-3 Door control wiring port Terminal name...
  • Page 40 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Figure 2-7-7 Note: You can purchase the accessory from Gree. The information is as below: Name Product code Remark Controller for door One controller for one MC207022 control function (MK03) unit 7.2.2 Human sensitive function You can purchase the module of human sensitive function for this series.
  • Page 41 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL will control the ON/OFF of unit according to the detected information. (3) Setting method: Under off state of the unit, press Function and Timer buttons at the same time for 5s to go to the debugging menu.
  • Page 42 7.2.3 MODBUS interface The indoor unit of this series has MODBUS interface. If the user needs to connect the unit to the management system of the building, please enquire Gree for the MODBUS protocol. Figure 2-7-9 (1) 1. Interface instruction: 1) The printing is COM-BMS1 and the interface type is B4B-XH-K3;...
  • Page 43 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL shown in the Figure below: Figure 2-7-10 4) Address setting of each unit: when the address mode is set to be long-distance control address mode. The address setting value range is 01~255. The setting method is: Under off state of the unit, press Function and Mode buttons at the same time for 5s to enter setting interface of wired controller address.
  • Page 44 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Figure 2-7-11 Note: ① In order to realize the MODBUS interface function, the address mode of the unit must be set into long-distance control address mode; you can not set it into centralized control address mode, otherwise, this function can not be realized;...
  • Page 45 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL refer to Point 3 for the setting method. The address mode is defaulted to be connecting to centralized controller mode and the defaulted address is 1; When the centralized controller is connected, centralized control of the unit can be realized to control unit ON/OFF, operation mode, set fan speed/temperature and weekly timer.
  • Page 46 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 2) Address setting of each unit: when the address mode is set to be centralized controller address mode. The address setting value range is 01~16. The setting method is: Under off state of the unit, press Function and Mode buttons at the same time for 5s to enter setting interface of wired controller address.
  • Page 47 7.2.5 Light board control: Light board interface is reserved on the mainboard of duct type unit. You can purchase Gree light board to realize control of the unit. When wired control is also connected, you can realize control of the unit through light board and wired controller.
  • Page 48 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL unit directly. If dry contact detection of unit malfunction is needed, please connect this interface into the monitoring system. When the closed signal is detected when malfunction occurs, this signal can be seen in monitoring system.
  • Page 49 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Figure 2-7-15 Table 2-7-4 Corresponding interfaces of mainboard Interface Evaporator temperature sensor Swing motor Human sensitive Door control Full water detection Interface of light board Communication port of centralized controller MOUDBUS interface Interface of annunciator live wire ON interface of fresh air valve OFF interface of fresh air valve...
  • Page 50 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 7.2.7 Reserved fresh air valve interface for duct type unit For the reserved connection way of air valve performer, connect it to F, C, O of wiring board according to the wiring diagram. Connect the public port of air valve to F, connect CLOSE to C and connect OPEN to O.
  • Page 51 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 7.2.9 Chassis electric heating belt of outdoor unit is optional When outdoor ambient temperature is very low, electric heating belt can be equipped on the chassis to prevent freezing of the chassis. Figure 2-7-18...
  • Page 52 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL INSTALLATION...

  • Page 53: Installation

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL INSTALLATION 1 INDOOR UNIT INSTALLATION 1.1 Installation of Duct Type 1.1.1 Before Installation After receiving the machine, please check for any transport damage. If finding any surface or internal damage, please immediately report to the transport company or equipment company in writing. After receiving the machine, please check the unit and accessories in reference to the packing list.
  • Page 54 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Air-conditioning Unit Ceiling-mount Screw Hanger Figure 3-1-1 Figure 3-1-2 Screw Hook Figure 3-1-3 Install the hanger onto the indoor unit as Figure 3-1-2 and Figure 3-1-3 shows. Install the indoor unit at the ceiling as Figure Figure 3-1-4 shows. Screw Hanger Air Supply...
  • Page 55 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Level Instrument Condensate Air Intake Air Supply Drainpipes As the inside of the unit is in the negative Enlarged View pressure status, it is required to set up a Condensate Drainpipe backwater elbow. The requirements is: A=B≥(0.145P/10000+20)/25.4(inch) P is the absolute pressure inside the unit.
  • Page 56 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL For the units: 36~ 48k Figure 3-1-7 Table 3-1-1 Unit: mm (inch) Item Model 1100 1160 1280 1000 (43-3/8) (20-3/8) (32-1/4) (45-5/8) (50-3/8) (22) (39-1/2) (6-1/4) (9-1/4) (10-1/2) UMAT18HP230V1BD UMAT24HP230V1BD 1010 1115 1225 (39-3/4) (29-1/2)
  • Page 57 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Table 3-1-2 Installation Accessories List for Duct-type Indoor Unit Name & Shape Notes Installation and Operating Instructions Insulation materials for gas pipe Used for gas pipe connector on indoor unit Insulation materials for liquid pipe Used for liquid pipe connector on indoor unit Used for wrapping the condensate pipe and rubber Insulation materials for drainage pipe...
  • Page 58 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 1.1.6 Drain Piping Work Installation of Drainage Pipeline: CAUTION! Install the drain hose in accordance with the instructions in this installation manual and keep the area warm enough to prevent condensation. Problems with the piping may lead to water leaks. (1) Install the drain hose with downward gradient (1/50 to 1/100) and no risers or traps are used for the hose.
  • Page 59 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Condensate Drainpipe As the inside of the unit is in the negative pressure status, it is required to set up a backwater elbow. The requirements is: Enlarged View A=B≥(0.145P/10000+20)/25.4(inch) Condensate Drainpipe P is the absolute pressure inside the unit.
  • Page 60 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL it the insulation can be directly attached to the drain hose. (12) Considerations for the unit with the condensate pump: 1) For the unit with the condensate pump, only one drain port at the side close to the electric box is prepared and only through it the drain hose can be connected.
  • Page 61 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL T-joint converging drain pipes T-joint converging drain pipes Figure 3-1-17 1.1.7 Installation of air duct Dimensions of the Supply Air Outlet/Return Air Inlet 21mm(7/8inch) Figure 3-1-18 Supply Air Outlet Figure 3-1-19 Return Air Inlet Table 3-1-3 Unit: mm (inch) Supply Air Outlet...
  • Page 62 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 1.1.8 Installation of the Supply Air Duct (1) Installation of the Rectangular Duct. Name Name Hanger Filter Air Intake Main Air Pipe Supply Pipe Canvas Air Air Supply Pipe Outlet Air Intake Figure 3-1-20 CAUTION! ①.

  • Page 63: Outdoor Unit Installation

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Figure 3-1-22 Table 3-1-4 Installation of the return air duct Name Name Return Air Inlet (with filter) Indoor unit Canvas Duct Supply Air Duct Return Air Duct Grille 2 OUTDOOR UNIT INSTALLATION 2.1 Before Installation After receiving the machine, please check for any transport damage.

  • Page 64: Caution For Installation

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL (3) Install the outdoor unit where the condensate water can be drained out freely during heating operation. (4) Do not place animals and plants in the path of the warm air. (5) Take the air conditioner weight into account and select a place where noise and vibration are small.

  • Page 65: Dimension Data

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 2.4 Dimension Data Figure 3-2-2 Table 3-2-1 Unit: mm (inch) Item Model UMAT18HP230V1BO 955(37-5/8) 395(15-5/8) 700(27-1/2) 560(22) 360(14-1/8) UMAT24HP230V1BO 980(38-5/8) 425(16-3/4) 790(31-1/8) 610(24) 390(15-1/2) UMAT30HP230V1BO UMAT36HP230V1BO 1105(43-5/8) 440(17-3/8) 1100(43-1/4) 630(24-7/8) 400(15-3/4) UMAT42HP230V1BO 960(37-3/4) 410(16-1/4) 1350(53-1/8)
  • Page 66 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 3.1.2 Bending Pipes (1) The pipes are shaped by your hands. Be careful not to collapse them. Figure 3-2-4 (2) Do not bend the pipes in an angle more than 90° . (3) When pipes are repeatedly bent or stretched, the material will harden, making it difficult to bend or stretch them any more.
  • Page 67 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Examine the connection pipe to see if it leaks, then take the treatment of heat insulation, as shown in the Figure 3-2-6. Use the medium-sized sponge to insulate the coupler of the gas pipe. Figure 3-2-6 Table 3-2-2 Flare nut tightening torque Pipe Diameter...
  • Page 68 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 3.1.6 Heat Insulation on the Pipe Joints (Indoor Side Only) Stick coupler heat insulation (large and small) to the place where connecting pipes. Figure 3-2-3 3.1.7 Vacuum and Gas Leakage Inspection CAUTION! Do not purge the air with refrigerants but use a vacuum pump to vacuum the installation! There is no extra refrigerant in the outdoor unit for air purging! 3.1.7.1 Vacuum...
  • Page 69 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Figure 3-2-4 Note: For the large-sized unit, it has the service port for both the gas valve and the liquid valve. During evacuation, it is available to connect two hoses of the manifold valve assembly to two service ports to quicken the evacuating speed.

  • Page 70: Specification Of Connection Pipe

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 3.2 Specification of Connection Pipe Table 3-2-4 Max. Height Size of Fitting Pipe Drainage Item Difference inch Max. Pipe pipe(Outer between Indoor Length Diameter × wall Unit and m(feet) thickness) Model Outdoor Unit Liquid m(feet) UMAT18HP230V1BO...

  • Page 71: Electrical Wiring

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 4.2 Electrical Wiring (1) For solid core wiring (Figure 3-2-6) 1) Cut the wire end with a wire cutter or wire-cutting pliers, then strip the insulation about 25 mm (15/16 inch). 2) Using a screwdriver, remove the terminal screw(s) on the terminal board. 3) Using pliers, bend the solid wire to form a loop suitable for the terminal screw.
  • Page 72 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL WARNING! ①. Before starting work, check that power is not being supplied to the indoor unit and outdoor unit. ②. Match the terminal block numbers and connection cord colors with those of the indoor unit side. ③.
  • Page 73 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL CAUTION! ①. The power cord and the wire of the fresh air valve are high-voltage, while the communication cord and connection wire of the wired controller are low-voltage. They should run separately against electromagnetic interference.
  • Page 74 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Single phase: 1) Separate Power Supply for indoor unit and outdoor unit: 24k~60k Figure 3-2-13 2) The Power supply for indoor units from outdoor unit. Power lines should go along the right side plate. Communication lines between indoor and outdoor units also should go along the right side plate and keep away from power lines.
  • Page 75 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL MAINTENANCE...

  • Page 76: Maintenance

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL MAINTENANCE 1 TROUBLE TABLE 1.1 Main Control Malfunction Table 1 Fault Display on Indoor Wired Controller Origin of Error Malfunction malfunction Control description code name signal When outdoor unit detects the high pressure switch is cut off for 3s successively, high pressure protection will occur.
  • Page 77 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Origin of Error Malfunction malfunction Control description code name signal If the indoor evaporator temperature sensor is detected of open Malfunction of circuit or short circuit for 5s successively, evaporator temperature Evaporator evaporator sensor malfunction will be reported.

  • Page 78: Description Of Drive Malfunction

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Origin of Error Malfunction malfunction Control description code name signal Communicatio Communication n between If the outdoor main control board does not receive data from drive malfunction main control board, communication malfunction between main control and drive between main board and will be reported.

  • Page 79: Flow Chart Of Troubleshooting

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 2 FLOW CHART OF TROUBLESHOOTING 2.1 Troubleshooting Flow Chart of Main Control Malfunction  E1 High Pressure Protection protection Reconnect wire according to the circuit diagram Check if the system high Check if the wiring Check if the high Replace the high pressure is...
  • Page 80 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL  E2 Freeze Protection Freeze protection is normal protection but not abnormal malfunction. If freeze protection occurs frequently during operation, please check if the indoor filter is with filth blockage or if the indoor air outlet is abnormal.
  • Page 81 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL  E4 Discharge Protection E4 protection Replace the discharge temperature sensor Check if the discharge Check if the temperature around discharge Replace the outdoor compressor discharge temperature sensor main control board temperature sensor is normal exceeds 115℃...
  • Page 82 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL  E9 Full Water Protection E9 protection Short circuit the full water If the unit is protection interface on indoor installed with mainboard according to the circuit water pump diagram Check if the water pump Replace the water pump works normally...
  • Page 83 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL  F1 Malfunction of Evaporator Temperature Sensor Malfunction of evaporator temperature sensor Check if the evaporator Correctly insert the temperature sensor on temperature mainboard is inserted on the sensor on the needle stand correctly needle stand Disconnect Replace the...
  • Page 84 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL  F3 Malfunction of Outdoor Ambient Temperature Sensor Malfunction of outdoor ambient temperature sensor Check Correctly insert the if the outdoor ambient temperature sensor on temperature sensor on mainboard the needle stand is inserted on the needle stand correctly Disconnect...
  • Page 85 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL  F5 Malfunction of Wired Controller Temperature Sensor Malfunction of wired controller temperature sensor Replace the wired controller  H6 Malfunction of Outdoor Fan Motor Malfunction of discharge temperature sensor Check if the Correctly connect the control wire of outdoor fan motor is control wire of fan motor...

  • Page 86: Troubleshooting Flow Chart Of Drive Malfunction

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL  E8 Malfunction of Indoor Fan Motor Malfunction of indoor fan motor Check if the Correctly connect the control wire of indoor fan motor is control wire of fan motor connected on the outdoor on the mainboard mainboard correctly Replace...
  • Page 87 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL  P8 IPM or PFC over-temperature protection P8 is displayed on the wired controller P8 is displayed in the mainboard 88 Indicating lamp Is the IPM or PFC module of mainboard tightened？ Replace the Tighten the IPM mainboard...
  • Page 88 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL  P6 Drive-to-main-control communication error  Lc Compressor Startup Failure Lc is displayed on the wired controller Lc is displayed in the mainboard 88 indicating lamp Replace the mainboard. Does it work normally? Replace the compressor Work normally...
  • Page 89 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL  PU Charging circuit error PU is displayed on the wired controller PU is displayed in the mainboard 88 indicating lamp Is the PFC wire tightened or is the sequence right? Tighten the PFC Replace the wire or adjust the mainboard...
  • Page 90 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL  H6 DC fan error H6 is displayed on the wired controller H6 is displayed in the mainboard 88 indicating lamp Is the motor phase Adjust the motor sequence right? phase sequence Is the Fan wire terminal Tighten the fan loose？...

  • Page 91: Interface

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 2.3 Interface UMAT18HP230V1BO/UMAT24HP230V1BO/ UMAT30HP230V1BO/ UMAT36HP230V1BO / UMAT42HP230V1BO /UMAT48HP230V1BO Main Control Board NO. SILK-SCREEN INTERFACE INTERFACE INSTRUCTION AC-L Live wire input Live wire input AC-N Neutral wire input Neutral wire input Power supply interface to the drive Control power output[1-...
  • Page 92 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Communication interface (reserved): Communication line with 1-pin plus 1-pin: +12V, 2-pin: B, 12V, 2-pin B, 3-pin A and 4-pin GND 3-pin: A, 4-pin: GND High pressure switch for fan speed H-PRESS Pressure protection switch for fan speed adjustment adjustment High pressure...
  • Page 93 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Compressor Phase U (2). Filtering Board Printing Interface Printing Interface N-OUT1 Neutral wire output 1 (white) (only for 18K) N-OUT Neutral wire output (white) L-OUT Live wire output (red) Grounding wire (Reserved) AC-L Live wire input (red) AC-N...
  • Page 94 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Printing Interface Printing Interface AC-L Live wire input (red) L1-1 PFC induction wire (brown) Neutral wire input (white) L2-2 PFC induction wire (blue) L2-1 PFC induction wire (yellow) L1-2 PFC induction wire (white) Control power input JTAG1 (Reserved)

  • Page 95: Ipm, Pfc Testing Method

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 2.4 IPM, PFC Testing Method 2.4.1 Method of Testing IPM Module (1) Preparation before test: prepare a universal meter and turn to its diode option, and then remove the wires U, V, W of the compressor after it is powered off for one minute. (2) Testing Steps Step 1: put the black probe on the place P and the red one on the wiring terminal U, V, W respectively as shown in the following figure to measure the voltage between UP, VP and WP.
  • Page 96 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL...

  • Page 97: Wiring Diadram

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL UMAT36HP230V1BO/ UMAT42HP230V1BO/UMAT48HP230V1BO 3 WIRING DIADRAM 3.1 Outdoor unit The actual wiring should always refer to the wiring diagram of the unit. Model: UMAT36HP230V1BO...

  • Page 98: Indoor Unit

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Model: UMAT42HP230V1BO 3.2 Indoor unit The actual wiring should always refer to the wiring diagram of the unit. 3.2.1 Duct Type Model: UMAT18HP230V1BD, UMAT24HP230V1BD, UMAT30HP230V1BD Model: UMAT36HP230V1BD, UMAT42HP230V1BD, UMAT48HP230V1BD...

  • Page 99: Disassembly And Assembly Procedure Of Main Parts

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 4 DISASSEMBLY AND ASSEMBLY PROCEDURE OF MAIN PARTS 4.1 Outdoor Unit Disassembly and Assembly of external casing Remark : Step Illustration Handling Instruction 1. Remove the top cover and handle; 1. Remove external casing 2.
  • Page 100 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Assemble unit reverse 4. Assemble unit procedures of disassembly. 24/30k Disassembly and Assembly of external casing Remark : Step Illustration Handling Instruction 1. Remove the top cover and handle; 1. Remove external casing 2.
  • Page 101 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Assemble the unit in the reverse 4. Assemble unit procedures of disassembly. Disassembly and Assembly of external casing Remark : Step Illustration Handling Instruction 1. Remove the top cover and handle; 1. Remove external casing 2.
  • Page 102 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 1. Discharge the refrigerant inside the pipeline and recycle the refrigerant during discharging; 4. Remove compressor 2. Unsolder the 4-way valve assy from compressor; 3. Remove the nut fixing compressor; 4. Take away the compressor from chassis. Assemble the unit in the reverse 5.

  • Page 103: Indoor Unit

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 1. Discharge the refrigerant inside the pipeline and recycle the refrigerant during discharging; 3. Remove gas liquid 2. Unsolder the 4-way valve assy from separator. gas liquid separator; 3. Remove the gas liquid separator.
  • Page 104 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Cut off the power supply of indoor unit. Use screwdriver to remove the electric 1. Unplug the motor cables box cover and unplug the motor cables in electric box. Remove filter Remove the filter sub-assembly from sub-assembly and air inlet the air inlet frame and use screwdriver cover board...
  • Page 105 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Step Illustration Handling Instruction Compress the filter screen for return air down on the guide slot sponge, 1.Disassembly of filter screen for and remove according to the direction return air shown by the arrow. There are 2 filter screen for return air.
  • Page 106 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Disassembly of fan and motor Remark: Make sure that the power supply is cut off before disassembling and protect all the parts during disassembly. Step Illustration Handling Instruction Disassemble the fixing screws on the fan components.

  • Page 107: Exploded Views And Spare Part List

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 5 EXPLODED VIEWS AND SPARE PART LIST 5.1 Outdoor Unit Model: UMAT18HP230V1BO Exploded Views and spare parts list:...
  • Page 108 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL UMAT18HP230V1BO Name of Part Product Code CF090W1040 Part Code Quantity Front Grill 01473049 Front Panel 01535013P Axial Flow Fan 10335008 Chassis Sub-assy 01195200028P Electrical Heater 7651300403 Drainage hole Cap 06813401 Drainage Connecter 06123401 Compressor Overload Protector(External) 00180030 / 00183051 / 00183032 / 00183031...
  • Page 109 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Model: UMAT24HP230V1BO Exploded Views and spare parts list:...
  • Page 110 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL UMAT24HP230V1BO Name of Part Product Code CF090W1060 Part Code Quantity Front Grill 01473050 Cabinet 01435004P Left Handle 26235401 Front Side Plate 01305086P Axial Flow Fan 10335014 Fan Motor 15702802 Electrical Heater(Compressor) 7651873209 Chassis Sub-assy 0119520001301P Drainage hole Cap...
  • Page 111 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Model: UMAT30HP230V1BO Exploded Views and spare parts list:...
  • Page 112 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL UMAT30HP230V1BO Name of Part Product Code CF090W1050 Part Code Quantity Front Grill 01473050 Cabinet 01435004P Left Handle 26235401 Front Side Plate 01305086P Axial Flow Fan 10335014 Chassis Sub-assy 01195200013P Drainage hole Cap 06813401 Electrical Heater(Compressor) 7651873209...
  • Page 113 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Filter Board 30221000007 Radiator 49018000042 PFC Inductance 43128003 Inductance Box Sub-assy 01395200176 Electric Box Assy 01395200488 Motor Support Assy 01805200160 Fan Motor 15702802 Left Side Plate 01305043P Model: UMAT36HP230V1BO Exploded Views and spare parts list:...
  • Page 114 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL UMAT36HP230V1BO Name of Part Product Code CF090W1030 Part Code Quantity Front Grill 01574106 Cabinet 01435007P Handle 26235253 Front Side Plate Sub-Assy 01305508 Axial Flow Fan 10335010 Chassis Sub-assy 01195244P Electrical Heater(Compressor) 7651873209 Drainage Joint 26113009 Compressor Overload Protector(External)
  • Page 115 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Model: UMAT42HP230V1BO /UMAT48HP230V1BO Exploded Views and spare parts list:...
  • Page 116 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL UMAT42HP230V1BO/UMAT48HP230V1BO Name of Part Product Code CF090W1020/CF090W1070 Part Code Quantity Front Grill 01574100009 Diversion Circle 10474100001 Cabinet Assy 01514100006 Handle 26235253 Front Side Plate 01314100021P Axial Flow Fan 10434100003 Chassis Sub-assy 01195200020P electrical heater 765152123 Drainage hole Cap...

  • Page 117: Indoor Unit

    U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL 5.2 Indoor Unit Duct Type Model: GFH18D3F2I exploded view and spare parts list...
  • Page 118 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL GFH18D3F2I Name of Part Product Code CF022N0980 Part Code Quantity Blower 15012454 Blower Mounting Plate Sub-Assy 01325200039 Support Sub-assy 01805200164 Supporter 01804100140 Brushless DC Motor 15705200006 Blower 15012458 Centrifugal fan assy 15405200029 Lower Cover Plate Sub-Assy 01265304 Water Tray Assy...
  • Page 119 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Model: UMAT18HP230V1BD (with water pump) exploded view and spare parts list...
  • Page 120 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL UMAT18HP230V1BD Name of Part Product Code CF022N0950 Part Code Quantity Filter Sub-Assy 11125303 Choke Plug of Drain Pipe 76712455 Lower Cover Plate Sub-Assy 01265304 Water Tray Assy 01285317 Evaporator Assy 01025200050 Water Level Switch 450127011 Water Pump 43138220...
  • Page 121 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Model: GFH24D3F2I/GFH30D3F2I exploded view and spare parts list...
  • Page 122 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL GFH24D3F2I/GFH30D3F2I Product Code CF022N0970/ CF022N1010 Name of Part part Code Quantity Filter Sub-Assy '111253031 Choke Plug of Drain Pipe '76712455 Water Tray Assy '01285323 Lower Cover Plate Sub-Assy '15265301 Strainer '07415210 Propeller Housing(Lower) '26904100052 Right Side Plate Sub-Assy '0131520015501...
  • Page 123 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Model: UMAT24HP230V1BD/UMAT30HP230V1BD exploded view and spare parts list...
  • Page 124 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL UMAT24HP230V1BD/UMAT30HP230V1BD Product Code CF022N0940/ CF022N1000 Name of Part part Code Quantity Filter Sub-Assy '111253031 Choke Plug of Drain Pipe '76712455 Water Tray Assy '01285323 Liquid Level Switch '4501801203 Pump Drainpipe '05235301 Water Pump '43138220 Lower Cover Plate Sub-Assy '15265301...
  • Page 125 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Model: GFH36D3F2I exploded view and spare parts list...
  • Page 126 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL GFH36D3F2I Product Code CF022N0920 Name of Part part Code Quantity Display Board '30294000007 Ambient Temperature Sensor '3900012123 Tube sensor '3900012128 Hook '02205209 Left Side Plate Sub-Assy '01315200064 Propeller Housing(Upper) '26905200010 Centrifugal Fan '10425200002 Front Side Plate Sub-Assy '01315200091...
  • Page 127 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Model: UMAT36HP230V1BD exploded view and spare parts list...
  • Page 128 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL UMAT36HP230V1BD Product Code CF022N0930 Name of Part part Code Quantity Display Board '30294000007 Ambient Temperature Sensor '3900012123 Tube sensor '3900012128 Hook '02205209 Left Side Plate Sub-Assy '01315200064 Propeller Housing(Upper) '26905200010 Centrifugal Fan '10425200002 Front Side Plate Sub-Assy '01315200091...
  • Page 129 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Model: GFH42D3F2I/GFH48D3F2I exploded view and spare parts list...
  • Page 130 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL GFH42D3F2I/GFH48D3F2I CF022N0910/ Name of Part Product Code CF022N0960 Part Code Quantity Display Board 30294000007 Tube sensor 3900012128 Ambient Temperature Sensor 3900012123 Left Side Plate Sub-Assy 01315200064 Hook 02205209 Propeller Housing(Upper) 26905200010 Centrifugal Fan 10425200002 Brushless DC Motor 15709400008...
  • Page 131 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL Model: UMAT42HP230V1BD/UMAT48HP230V1BD exploded view and spare parts list...
  • Page 132 U-MATCH SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL UMAT42HP230V1BD/UMAT48HP230V1BD Name of Part CF022N0900/ Product Code CF022N0990 Main Board 30224000039 Main Board 30221000011 Terminal Board 4201025301 Terminal Board 42010194 Electric Box Assy 01395200471 Right Side Plate Sub-Assy 01315200078 Water Pump Assy 15405200081 Water Pump 4313822001...
  • Page 133 JF00302978 Contractor Support Number for Gree Branded Equipment Sold in the U.S. Cat no: GREE_UMAT_B_SERVICE_010119 888-850-7928 info@greecomfort.com www,greecomfort.com...

This manual is also suitable for:

U-match umat18hp230v1boU-match umat24hp230v1boU-match umat30hp230v1boU-match umat36hp230v1boU-match umat42hp230v1boU-match umat48hp230v1bo ... Show all

Table of Contents
