- Page 1 USING NS6 WITH NUMARK CUE or VIRTUALDJ...
- Page 2 Select the Mappers tab and verify that the Numark NS6 is listed in the drop down on the top left. [Optional] To use the NS6 in a 4 deck configuration, select the Skins tab and select a 4 deck skin from the list of available chioces.
-
Page 3: Phono Inputs
For a suggested setup diagram, see the CONNECTION DIAGRAM in the NS6 Quickstart Guide. POWER IN – Use the included power cable to connect NS6 to a power outlet. While the power is switched off, plug the cable into NS6 first, then plug the cable into a power outlet. -
Page 4: Useful Terms
INPUT SELECTOR – Set this switch to the desired audio source from this channel – "PC" (a track playing on that layer in the software) or "LINE/MIC" or "LINE/PHONO" (a device connected to the LINE/PHONO or MIC input on NS6's rear panel). -
Page 5: Playback Controls
PLAYBACK CONTROLS LAYER – Selects which software Deck is controlled by that hardware Deck. The left Deck can control software Deck 1 or 3; the right Deck can control software Deck 2 or 4. PLATTER – The platter controls the tracks playback motion in the software. PLAY / PAUSE –... -
Page 6: Track Controls
MODE – MANUAL/AUTOLOOP: Press this to switch between Manual Mode and Autoloop Mode, which changes the functions of the four buttons on its right. Note: When the track is currently looping, the IN/1 and OUT/2 buttons will blink and the RELOOP/4 button will be lit white to indicate a loop is active (regardless of the actual length of the loop). -
Page 7: Effects Controls
LOAD PREPARE (LOAD SIDELIST) – Press to move a track to the SideList. BROSWER PAGE SCROLL - Press and hold the View button then press the LOAD PREPARE button repeatedly to scroll through the BROWSER / SAMPLER / EFFECTS / RECORD pages. VIEW –... - Page 8 www.virtualdj.com MANUAL VERSION 1.0...
