Installation instructions
Taking off the housing and changing
the batteries
1. Remove the metal ring (3) with
guide ring (4) and housing (2)
from the mechatronic unit (1)
whilst pushing against the square
of the coupling unit.
2. Take out the batteries (7) and
replace them with new ones.
Ensure correct battery polarity!
3. Push the housing (2), metal ring
(3) and guide ring (4) onto the
mechatronic unit and re-fit the
lever handle.
ATTENTION
As old batteries can leak, it is advisable to check the condition of the batteries at
regular intervals. Kaba cannot provide compensation for any consequential
damage caused by faulty batteries (batteries cannot be guaranteed).

6.1.2 Setting the clock

The programmer is required in order to check and set the clock in the actuator.
Always check the time following a change of batteries or at least once a year. A
detailed description can be found in the Programmer user manual. It is essential
that the clock is set precisely for the system to work correctly in CardLink
authorisation mode.

6.1.3 Reading Traceback

The Traceback (event list) of the most recent 2000 events can be read using the
Programmer, provided that the function has not been previously deactivated in
the KEM software.
See Programmer user manual.
The events and data that are registered in the Traceback are listed in the kaba
evolo system description.
Kaba c-lever compact k2evo703en-2011-05
Maintenance and troubleshooting
1 7
2 3 4
18
