Installation instructions
3.5

c-lever compact assembly

13 12
14
Exploded diagram
Position
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
3.6

Dimensions

60
114.7
Scale drawing
Kaba c-lever compact
11 10 8
Description
Mechatronic unit
Housing
Metal ring
Plastic guide ring
External handle
Direction pin
Batteries, type AAA Lithium (2 pieces)
Spindle
Fastening screw
Internal rosette "round" (optional)
Fixing screw for internal rosette (2 pieces)
Internal rosette cover (optional)
Inside handle (optional)
Fixing screw for handle (optional)
Centring sleeve (2 pieces 7-8 mm, 2 pieces 7-9 mm)
5
k2evo703en-2011-05
9 1 7
15
25.8
Product description
6 2 3 4 5
38
11
