GranBaristo
GranBaristo V2
Avanti V2
Service Manual
240 V~ 50 Hz 1900W - 230 V~ 50/60 Hz 1900 W 120 V~ 60 Hz 1300 W
(NTC) variable resistor sensor - transmits the value to the electronic card
2 thermostats at 190°C one shot
(230 V~) 1900 W - (120 V~) 1300 W - (100 V~) 1100 W
210 x 360 x 460 mm
< 0,5W
13 kg
1.7 l
270 g. of coffee beans
20
Approx. 45 sec.
Approx. 15 sec Max. on first filling cycle
During heating phase- approx. 5.6 A
Dose adjustment controlled by the electronic system
Page 1
Coffee Machine GranBaristo GranBaristo V2 GranBaristo GranBaristo Avanti V2 Avanti Service Service Manual Rev. 05 MAY 2016 TECHNICAL INFORMATION Power supply and output: 240 V~ 50 Hz 1900W - 230 V~ 50/60 Hz 1900 W 120 V~ 60 Hz 1300 W Temperature monitoring: (NTC) variable resistor sensor - transmits the value to the electronic card Safety system:...
GRAN BARISTO Table of contents Page Table of contents Page Introduction Service Mode 5.1.1. Test Mode Gran BaristoV2 and AvantiV2 1.1. Documentation required 5.1.2. Diagnostic Mode Gran BaristoV2 and AvantiV2 1.2. Tools and equipment required Test Mode in GranBaristo Avanti 1.3.
GRAN BARISTO 01 INTRODUCTION Documentation required The following documentation is needed for repair procedures: • Instruction booklet for specific model • Technical documentation for specific model (diagrams, exploded view, sympton cure and service manual) Tools and equipment required As well as the standard equipment, the following is required: Qty.
GRAN BARISTO 01 INTRODUCTION Water Hot water /steam From this point circuit in pressure Compensation valve water outlet From this point circuit High temperaure Water tank Flow-meter Steam Pump Service POLICY grid as used for coffee machine For IN WARRANTY repairs is raccomanded to use when and where possible the single compo- nents, available in the exploded views of the coffee machines or of the specific components.
GRAN BARISTO 01 INTRODUCTION 1.6.1 External machine parts GranBaristo V2 Coffee bean hopper lid Water tank + lid Pre-ground coffee Control compartment panel Removable dispenser Power cable socket spout and main switch Full drip tray indicator Cup holder grille Cup-warming surface Drip tray (internal)
GRAN BARISTO 01 INTRODUCTION 1.6.2. External machine parts GranBaristo Coffee bean hopper locking/removal selector switch (depending on the model) Water tank + lid Removable coffee bean Control hopper lid (depending panel on the model) Removable Pre-ground coffee dispenser compartment Hot water spout Cup-warming dispensing spout...
GRAN BARISTO CHAPTER 2 TECHNICAL SPECIFICATIONS...
Page 10
GRAN BARISTO 02 TECHNICAL SPECIFICATIONS 2.1. Technical specifications 240 V~ 50 Hz 1900W - 230 V~ 50/60 Hz 1900 W Power supply and output: 120 V~ 60 Hz 1300 W (NTC) variable resistor sensor - transmits the value to the Temperature monitoring: electronic card Safety system: 2 thermostats at 190°C one shot...
GRAN BARISTO 02 TECHNICAL SPECIFICATIONS 2.2.1. Specification for the measurement of the coffee products temperature. The temperature is influenced by the flow from the dispenser and stratification of temperatures in the glass. In order to consider these phenomena and to introduce measures that allow comparisons in controlled conditions, below guidelines must be followed: Conditions: a) Water temperature in tank: 23°C (+/-2°C).
GRAN BARISTO 02 TECHNICAL SPECIFICATIONS 2.2.2. Specification for the measurement of the Milk products temperature. Milk evaluation To carry out the test, a partially skimmed UHT milk with a percentage of grease between 1.5-1.8% at a refrigerator temperature Trefr. (between 4 to 10°C) must be used. The milk product must be checked on a beaker of 250 ml of capability and with an inner diameter of 70mm, brewing 100gr of product.
Page 13
GRAN BARISTO 02 TECHNICAL SPECIFICATIONS How to measure the milk cream. The temperature (Trefr or Tamb) of the milk doesn’t affect as much the test result on measuring the milk cream; by convection is assumed to always use milk at refrigerator temperature Trefr.. Manual systems (Pannarello) Pour 100cc.
GRAN BARISTO 02 TECHNICAL SPECIFICATIONS 2.5. How to Check for oil leakage in piston assembly. In case of return because the machine indicates no coffee one of the causes could be the loss of oil from the piston assembly. To check this, proceed as follows: To enter Test Mode When the display is turning ON, press the key- board buttons in the order described below: Press UP (...
GRAN BARISTO 03 BRIEF INSTRUCTIONS 3.1.1. Customer menu in the Gran Baristo BaseV2 and AvantiV2 “ESC” “UP” and ”DOWN “ button button “Espresso” “Cappuccino” button button “Espresso Macchiato” “Long Espresso ” button button LCD Display “Latte Macchiato” “Coffee” button button “Hot Milk”...
Page 19
GRAN BARISTO 03 BRIEF INSTRUCTIONS BLUETOOTH CONNECTION Download the application on your mobile device to access the machine functions. To connect GranBaristo Avanti with your mobile device, download the Saeco Avanti App available on the App Store and Google Play or scan the QR code on the cover with your mobile device.
GRAN BARISTO 03 BRIEF INSTRUCTIONS 3.1.2. Customer menu in the Gran Baristo Avanti “ESC” “UP” and ”DOWN “ button button “Espresso” “Cappuccino” button button “Espresso Macchiato” “Long Espresso ” button button LCD Display “Latte Macchiato” “American Coffee” button button “Hot Milk” “Coffee”...
Page 21
RESTART TO SOLVE 3 times. If the machine does not start, contact the Philips SAECO hotline in your country and quote the code shown on the display. Contact details can be found in the war- ranty booklet packed separately or at www.philips.com/support.
Page 22
GRAN BARISTO 03 BRIEF INSTRUCTIONS BLUETOOTH The “BLUETOOTH” management menu is displayed. ENABLE BLUETOOTH PIN CODE Press “ ” to enable the function in the machine and to allow the connection ADDRESS of your mobile device. ENABLE BLUETOOTH Press the “ ”...
GRAN BARISTO 04 OPERATING LOGIC 4.1.2. Milk Carafe The steam passes through the pipe creating a sucking effect that pulls the milk upwards The milk is heated by the steam and taken towards the emulsion chamber where it is mixed with air and transformed into foam Milk Carafe GranBaristo V2 1) Steam input 2)Bring the cappuccino maker into dispensing position 3) Milk tank Milk Carafe GranBaristo...
GRAN BARISTO 04 OPERATING LOGIC 4.2. Coffee cycle Main switch ON START STOP Time Coffee grinder Pulses (Dosage) Heating approx. 45 sec. Pump Pump operation (flow meter pulses) in accordance with the amount of product selected. Brewing unit gear motor Heating Ready Coffee cycle...
GRAN BARISTO 04 OPERATING LOGIC 4.3. Single microswitch The gear motor is powered by a direct current motor that engages with the smaller double toothed wheel using a worm screw. The unit is mounted on the axle of the large gear wheel and when a coffee is requested, it moves from the standby position to the dispensing posi- tion, and then back to the standby posi-...
GRAN BARISTO 04 OPERATING LOGIC 4.5. Coffee grinder The coffee grinder is driven by a direct current motor (1) using a worm screw helicoidal wheel transmission (2). The worm screw (2) drives a plastic gear wheel (3), which turns the lower grinder (4) and the increment pin (5) 4.6. Water level detection (water tank) “Water low”...
GRAN BARISTO 04 OPERATING LOGIC “Descaling” – message with water filter 4.7. Descaling request inserted (appliances with display only) Flow meter pulses The water hardness is set on the basis of the regional water hardness analysis (1, 2, 3, 4). Filter off: If the function is turned off the electronics Filter assembly monitors the flow meter pulses, recording one pulse each turn.
Page 31
GRAN BARISTO 04 OPERATING LOGIC 4.9. AquaClean water filter GranBaristo V2 and GranBaristo Avanti V2 (Cod. 421944050461 ACC SAE WATER FILTER LGV 1UNIT EU) The SAECO AquaClean water filter purifies the water your machines uses for brewing coffee. This results in a greater coffee taste. Moreover it prevents mineral deposits in the water to build up, which eliminates the need of descaling your machine for 500000ml of water.
GRAN BARISTO 05 SERVICE MODE 5.1.1. Test Mode Gran BaristoV2 and AvantiV2 To enter Test Mode When the display turns ON, press the keyboard buttons in the order described below: Description When the machine is in Factory Test Mode appears a windows divided in several sectors: CPU SW xx.yy.zz Debug msg P Off BootC V.jj BootP...
Page 34
GRAN BARISTO 05 SERVICE MODE Activation of loads In Test Mode all loads are initially disabled. To activate a load press the corresponding button on keyboard, to deactivate press again the same button. Other conditions for which a load may be switched off automatically without key presses are: ·...
Page 35
GRAN BARISTO 05 SERVICE MODE Keyboard KEYBOARD xx.yy.zz KEY 1 KEY 2 KEY 5 KEY 6 KEY 3 KEY 4 KEY 7 KEY 8 This page allow to test each button of keyboard (is shown its version) with the following corre- spondence: When is pressed a button the corresponding box becomes with background colored and the led of keyboard is turned ON, if it is pressed again becomes with black background and the led of key-...
Page 36
GRAN BARISTO 05 SERVICE MODE Info: mA: indicates the maximum current (in mA) absorbed by the brew unit in motion. The value must not exceed the following values: - 600 mA with new the brew unit - 450 mA with a brew unit with at least 5 product executed - 130 mA without brew unit Encoder Pulses Home-Work: indicate the number of encoder pulses from Home to Work posi- tion or vice versa.
Page 37
GRAN BARISTO 05 SERVICE MODE Grinder Time during grinding This page allow to test the functionality of grinder: GRINDER GTest A/AA Grinder Time for Zero crossing selected coffee 3500 DDoor 230 V Z-Cr FAIL strength Voltage power supply read The meaning of the sectors are the following: Command: A1: Selected Coffee Strength.
Page 38
GRAN BARISTO 05 SERVICE MODE Bluetooth This page allow to check the BT module Bluetooth module FW version Bluetooth MAC address Bluetooth Status (ON/OFF) BLUETOOTH xxxxxxxxxxxxx Vx.x Data exchange with remote CONN device in progress The meaning of the sectors are the following: Command: I/O: enable/disable Bluetooth module.
Page 39
GRAN BARISTO 05 SERVICE MODE Steam Out Not mandatory, but if necessary, before executing the steam out procedure, descale the machine taking care to remouve the Aquaclean filter from the appliance. In case the filter on the machine is active (or it’s in the machine) provide the consumer with a new one.
GRAN BARISTO 05 SERVICE MODE 5.1.2. Diagnostic Mode Gran BaristoV2 and AvantiV2 To enter Diagnostic Mode When the display turns ON, press the keyboard buttons in the order described below: Menu Structure DIAGNOSTIC MODE 1. Product counters Espresso (default values 0) Espresso lungo Cafe Creme Coffee Cappuccino Latte macchiato Froth milk Espresso Macchiato Hot water Ristretto Espresso Mild...
Page 41
GRAN BARISTO 05 SERVICE MODE Detailed description of the diagnosis menu 1. Product counters “Product counters” represents the total number of deliveries performed by the machine for each product from the production. 2. Error counters “Error counters” displays the total number of errors “out of service” (fail) occurred in the system (see “Errors log”), and allows you to reset the drive (see “Errors reset”).
Page 42
GRAN BARISTO 05 SERVICE MODE Coffee temp. sensor short circuit (E10): occurs when the temperature of the coffee boiler sensor is short-circuited. This error causes a total shutdown of the machine to start up. Coffee temp. sensor open circuit (E11): occurs when the temperature of the coffee boiler sensor is not detected.
Page 43
GRAN BARISTO 05 SERVICE MODE Number of execution: represents the number of cleaning cycles (liters) performed on the ma- chine group. Liters since last clean: represents the total number of liters of water consumed since the last cleaning cycle group. It is reset after the execution of a complete cleaning cycle group The submenu “Water filter”...
GRAN BARISTO 05 SERVICE MODE 5.1.3. Error codes ERROR DESCRIPTION CODES Grinder blocked Brewing UNIT blocked work Brewing UNIT blocked home Water circuit interrupted DC valve short circuit Coffee temp. sensor short circuit Coffee temp. sensor open circuit Boiler coffee timeout Zero crossing error Boiler coffee overheating BU Encoder Error 12/30...
GRAN BARISTO 05 SERVICE MODE 5.2.1. Test Mode Gran Baristo Avanti To enter Test Mode When the display turns ON, press the keyboard buttons in the order described below: Description When the machine is in Factory Test Mode appears a windows divided in several sectors: CPU SW xx.yy.zz Debug msg P Off BootC V.jj BootP V.kk...
Page 46
GRAN BARISTO 05 SERVICE MODE Activation of loads In Test Mode all loads are initially disabled. To activate a load press the corresponding button on keyboard, to deactivate press again the same button. Other conditions for which a load may be switched off automatically without key presses are: ·...
Page 47
GRAN BARISTO 05 SERVICE MODE Keyboard KEYBOARD xx.yy.zz KEY 1 KEY 2 KEY 5 KEY 6 KEY 3 KEY 4 KEY 7 KEY 8 This page allow to test each button of keyboard (is shown its version) with the following corre- spondence: When is pressed a button the corresponding box becomes with background colored and the led of keyboard is turned ON, if it is pressed again becomes with black background and the led of key-...
Page 48
GRAN BARISTO 05 SERVICE MODE Info: mA: indicates the maximum current (in mA) absorbed by the brew unit in motion. The value must not exceed the following values: - 600 mA with new the brew unit - 450 mA with a brew unit with at least 5 product executed - 130 mA without brew unit Encoder Pulses Home-Work: indicate the number of encoder pulses from Home to Work posi- tion or vice versa.
Page 49
GRAN BARISTO 05 SERVICE MODE Grinder This page allow to test the functionality of grinder: Time during grinding GRINDER GTest A/AA Grinder Time for Zero crossing selected coffee 3500 DDoor Z-Cr FAIL strength The meaning of the sectors are the following: Command: A1: Selected Coffee Strength.
Page 50
GRAN BARISTO 05 SERVICE MODE Bluetooth This page allow to check the BT module Bluetooth module FW version Bluetooth MAC address Bluetooth Status (ON/OFF) BLUETOOTH xxxxxxxxxxxxx Vx.x Data exchange with remote CONN device in progress The meaning of the sectors are the following: Command: I/O: enable/disable Bluetooth module.
Page 51
GRAN BARISTO 05 SERVICE MODE Steam Out This page allow to execute the steam out process: STEAM OUT Start Boiler Temperature (°C) 93.3 Boiler The meaning of the sectors are the following: Command: Start: start the steamout process. At the end of process appears: Switch Off at the bottom of the display (so it’s possible to restart the machine with the default values) Info: Boiler: It’s enabled when the boiler is activated...
GRAN BARISTO 05 SERVICE MODE 5.2.2. Test Mode Gran Baristo To enter Test Mode When the display turns ON, press the keyboard buttons in the order described below: Description When the machine is in Factory Test Mode appears a windows divided in several sectors: CPU SW xx.yy.zz Debug msg P Off BootC V.jj BootP V.kk POWER SW...
Page 53
GRAN BARISTO 05 SERVICE MODE Activation of loads In Test Mode all loads are initially disabled. To activate a load press the corresponding button on keyboard, to deactivate press again the same button. Other conditions for which a load may be switched off automatically without key presses are: ·...
Page 54
GRAN BARISTO 05 SERVICE MODE Keyboard KEYBOARD xx.yy.zz KEY 1 KEY 2 KEY 5 KEY 6 KEY 3 KEY 4 KEY 7 KEY 8 This page allow to test each button of keyboard (is shown its version) with the following corre- spondence: When is pressed a button the corresponding box becomes with background colored and the led of keyboard is turned ON, if it is pressed again becomes with black background and the led of key-...
Page 55
GRAN BARISTO 05 SERVICE MODE Info: mA: indicates the maximum current (in mA) absorbed by the brew unit in motion. The value must not exceed the following values: - 600 mA with new the brew unit - 450 mA with a brew unit with at least 5 product executed - 130 mA without brew unit Encoder Pulses Home-Work: indicate the number of encoder pulses from Home to Work posi- tion or vice versa.
Page 56
GRAN BARISTO 05 SERVICE MODE Grinder This page allow to test the functionality of grinder: Time during grinding GRINDER GTest A/AA Grinder Time for Zero crossing selected coffee 3500 DDoor Z-Cr FAIL strength The meaning of the sectors are the following: Command: A1: Selected Coffee Strength.
Page 57
GRAN BARISTO 05 SERVICE MODE Press UP ( ): go to next page Steam Out This page allow to execute the steam out process: STEAM OUT Start Boiler Temperature (°C) 93.3 Boiler The meaning of the sectors are the following: Command: Start: start the steamout process.
GRAN BARISTO 05 SERVICE MODE 5.2.3. Diagnostic Mode Gran Baristo/Gran Baristo Avanti To enter Diagnostic Mode When the display turns ON, press the keyboard buttons in the order described below: Menu Structure DIAGNOSTIC MODE 1. Product counters Espresso (default values 0) Caffè Cafe Creme Hot water Cappuccino Latte macchiato Hot milk American Coffee Espresso Macchiato Ristretto Espresso Mild...
Page 59
GRAN BARISTO 05 SERVICE MODE Detailed description of the diagnosis menu 1. Product counters “Product counters” represents the total number of deliveries performed by the machine for each product from the production. 2. Error counters “Error counters” displays the total number of errors “out of service” (fail) occurred in the system (see “Errors log”), and allows you to reset the drive (see “Errors reset”).
Page 60
GRAN BARISTO 05 SERVICE MODE Coffee temp. sensor short circuit (E10): occurs when the temperature of the coffee boiler sensor is short-circuited. This error causes a total shutdown of the machine to start up. Coffee temp. sensor open circuit (E11): occurs when the temperature of the coffee boiler sensor is not detected.
Page 61
GRAN BARISTO 05 SERVICE MODE Number of execution: represents the number of cleaning cycles performed on the machine group. Liters since last clean: represents the total number of gallons of water consumed since the last cleaning cycle group. It is reset after the execution of a complete cleaning cycle group The submenu “Water filter”...
GRAN BARISTO 05 SERVICE MODE 5.2.4. Error codes ERROR DESCRIPTION CODES Grinder blocked Brewing UNIT blocked work Brewing UNIT blocked home Water circuit interrupted DC valve short circuit Coffee temp. sensor short circuit Coffee temp. sensor open circuit Boiler coffee timeout Zero crossing error Boiler coffee overheating BU Encoder Error 5.3. Saeco Service Center - Quick Start Guide Saeco Service Center (SSC) is a tool with which you can re-program the machine and check the...
Page 63
GRAN BARISTO CHAPTER 6 RERVICING AND MAINTENANCE...
Final inspection test 13 Steam out before shipping out, if temperature is below 0° to prevent any demaged due to frozen water. No need for those families Minuto family (all platform); Incanto family new; Pico Baristo; 14 Gran Baristo; Intelia V2; Philips 2000‐2100; Incanto Executive; Moltio family (all platform). Please also check for GDA_113455 Provide precise IRIS code, according dedicated code table for Coffee products. The location code from the part you have worked on MUST be completed always with the part 15 ...
Page 65
Grinder Is the grinder noise normal Steam Steam Does the steam work Hot Water Does the hot water work GRAN BARISTO 06 SERVICING AND MAINTENANCE Milk (if applicable) Cappuchino Does the cappuccinatore produce good froth Leakage Leakage 14 Did the product leak during the testing 15 Draining the circuit (in winter) ...
GRAN BARISTO 07 DISASSEMBLY 7.1. Outer Shell in Gran Baristo and GranBaristo V2 Remove the water tank, coffee container and cover, drip tray, dreg drawer, brewing unit, hot water dispenser, Milk carafe. Lateral panels Unscrew the Remove the left, right Unscrew the Remove the cover.
Page 68
GRAN BARISTO 07 DISASSEMBLY Disconnect all electrical and water circuit Remove the reed sensor. connections and remove the top cover. Lateral panels Gran Baristo V2 Remove the cup warning lid making sure to rise it near the hooks highlighted Remove the water container door Unscrew the screws shown and remove the lateral panels...
GRAN BARISTO 07 DISASSEMBLY Disconnect the hydraulic and electrical connections highlighted 7.2. Service door Remove the high- Lift the pin with a screwdriver and remove it Unscrew the screws shown. lighted frame. through the top of the door. Graft milk carafe and hot water In the reassembling make sure the Unscrew the screws Unscrew the screws spring is repositioned correctly (see...
GRAN BARISTO 07 DISASSEMBLY Remove the dispenser, remove the insert and unhook the anchors. 7.3. Coffee grinder When reassembling the coffee grinder, make sure the spring is repositioned correctly (see photo). Remove the Raise the coffee grinder and remove the cover.
GRAN BARISTO 07 DISASSEMBLY 7.5. Coffee grinder adjustment Removable coffee bean hopper (depending on the model) The grinding adjustment can be set by the user (only with the coffee grinder in operation) by pressing and turning (only by one click at a time) the insert inside the coffee bean hopper with the aid of the wrench supplied.
GRAN BARISTO 07 DISASSEMBLY 7.7. The piston assembly. Loosen screws highlighted and dis- connect the silicone tube. Piston assembly Remove the assembly and disconnect the electrical / idraulics connections. 7.8. Pin boiler Loosen the screws highlighted and slide out the fork as illustrated. 7.9.
GRAN BARISTO 07 DISASSEMBLY 7.10. Pump Slip off the pump Remove the pump off the support. extension. Disconnect the electrical / idraulics connections. 7.11. Flow-meter Lift the flow meter out of the casing assembly and remove the electrical and water circuit connections.
Page 74
GRAN BARISTO 07 DISASSEMBLY Microswitch present brew unit. Lift the assembly and in the back there is the microswitch. Loosen the screws highlighted and remove the gearmotor assembly. Loosen the screws highlighted and remove the gearmotor cover. The following are located inside the compartment protected by the casing: - Electric motor (A) with gears (B) and (C) for trans- mission and timing of the dispenser.
GRAN BARISTO 07 DISASSEMBLY 7.13. CPU board and KYB interface and display Lateral panels Remove the left, right Unscrew the Unscrew the Remove the cover. and posterior panels screws shown. screw shown. Top cover Remove the cover. Unscrew the screw shown. Unscrew the screws shown.
GRAN BARISTO 07 DISASSEMBLY 7.14. Bluetooth board in Granbaristo Avanti Unscrew the screw shown and Disconnect the electrical connections remove the cover. and remove the bluetooth board. 7.15. Fitting and removing Oetiker clamps 1) Boiler connection. 2) Other connections. Use a suitable pair of pliers to remove the Tighten the clamp as illustrated.
