THE WHISTLER GROUP, INC.
CORPORATE HEADQUARTERS
13016 N. Walton Blvd.
Bentonville, AR 72712
TEL (479) 273-6012 FX (479) 273-2927
www.whistlergroup.com
CUSTOMER RETURN CENTER
1201 N. Dixieland Rd.
Rogers, AR 72756
Consumer Relations Tel (800) 531-0004
Email: info@whistlergroup.com
P/N 20562
© 2004 The Whistler Group, Inc.
OWNER'S MANUAL
1200/2000/3000
WATT SERIES
HIGH SURGE POWER INVERTERS
Advertisement
Table of Contents
Related Manuals for Whistler 1200 WATT
Summary of Contents for Whistler 1200 WATT
- Page 1 TEL (479) 273-6012 FX (479) 273-2927 www.whistlergroup.com CUSTOMER RETURN CENTER 1201 N. Dixieland Rd. Rogers, AR 72756 Consumer Relations Tel (800) 531-0004 Email: info@whistlergroup.com P/N 20562 © 2004 The Whistler Group, Inc. OWNER’S MANUAL 1200/2000/3000 WATT SERIES HIGH SURGE POWER INVERTERS...
- Page 2 Our mission is to provide products that improve your driving experience. Whistler offers a complete line of DC to AC inverters ranging in capacity from 75 Watts to 3000 Watts. These inverters offer advanced technology, dependable operation and will provide years of reliable service when used in accordance with our operating instructions.
-
Page 3: Table Of Contents
“modified sine wave”. See “Technical Operating Principles” section for more information. Depending on the model and its rated capacity, Whistler inverters draw power either from standard 12 volt automobile and marine batteries or from portable high power 12 volt sources. - Page 4 The inverter is designed to be operated from a remote location via the WHISTLER PP015DC Remote Control Switch which plugs into this socket. This optional accessory is available through WHISTLER or your WHISTLER dealer. 2000 watt series shown d). Wattage & Voltage Wattage Indicator.
- Page 5 FEATURES e). Standard North American 110 AC Outlets are provided. f). High Speed Cooling Fan. This fan will turn on automatically when the internal temperature exceeds design parameters for safe operation. The Cooling Fan will automatically turn off when the temperature drops to a safe operating level.
-
Page 6: Important Information
Never attempt to connect your Whistler inverter to any other power source, including any AC power source. • 110 volts can be lethal. Improper use of your Whistler inverter may result in property damage, personal injury or loss of life. -
Page 7: Don't Push It
INVERTER INFORMATION Don’t Push It. Although your Whistler power inverter has the capacity to provide power output (excess current) equal to approximately two times its rated wattage capacity for a very brief period, it is designed to operate equipment and appliances with start up load wattage ratings no higher than its own maximum continuous wattage rating. -
Page 8: Battery Information
10. The WHISTLER 1200 watt model utilizes 50 amps of battery power to operate an appliance with a 500 watt continuous load requirement. (500 divided by 10 = 50). -
Page 9: Cable Information
CABLE INFORMATION Adapter." Use of #0 gauge wire to make the connections to the inverter may require a "0 to 4 Gauge Adapter." Both adapters are available through electronic supply stores including Radio Shack. Radio Shack part number is listed below: O Ring Adapter: RSU11538139 0 to 4 Gauge Adapter:... -
Page 10: Operation
Reverse polarity will blow the internal fuses in the inverter and may cause permanent damage to the inverter. Damage caused by reverse polarity is not covered under the Whistler warranty. • Making the connection between the Positive (+) terminals may cause a spark as a result of current flowing to the capacitors in the inverter. - Page 11 OPERATION • Check frequently to ensure that the input and output connections are secure. Loose connections may damage the inverter, the power source, or may generate excessive heat. • The following precautions apply to the 3000 watt models only. a). The AC receptacles are equipped with 15 amp circuit breakers.
- Page 12 Some Powerful Advice. Your Whistler inverter will work best when placed on a reasonably flat surface. The floor or wall of your vehicle are good locations. When driving with the inverter in operation, make certain that neither the inverter nor the power cords will impede safe operation of your vehicle.
- Page 13 For You Technical Types. 1. Basic Operating Principles: Whistler inverters work in two stages. During the first stage, the DC to DC converter increases the DC input voltage from the power source (e.g. a 12 volt battery) to 145 volts DC. In...
-
Page 14: Operation Summary
A true sine wave typical of home AC outlet. In Review. • Never attempt to operate your Whistler inverter from any power source other than a 12 volt battery or a group of batteries that total 12 volts. •... -
Page 15: Troubleshooting
OPERATION SUMMARY • Avoid placing the inverter near sources of heat or in direct sunlight. • When in use, make certain that the inverter is properly ventilated. • Do not use the inverter near flammable materials, fumes, or gases. • Always operate the inverter in accordance with the instructions in this manual. -
Page 16: Specifications
Reduce the load on the inverter to rated continuous power output. SPECIFICATION WHISTLER 1200 WATT INVERTER SPECIFICATIONS Maximum Continuous Power……………………………1200 Watts Maximum Surge Capability (Peak Power)...2400 Watts No Load Current Draw………………………………...0.50 A Waveform………………………………...Modified Sine Wave Operating Input Voltage Range……………...10-15 Volts DC AC Receptacle……………………...Dual 3 Prong Grounded... - Page 17 All express or implied warranties for this product are limited to (2) two years. Whistler is not liable for damages arising from the use, misuse, or operation of this product.
- Page 18 WARRANTY MEMO The out of warranty service fee for your 1200 Whistler inverter is $90.00, 2000 Whistler inverter is $150.00 and 3000 Whistler inverter is $250.00. If you require out of warranty service, please return your inverter as outlined in the section “Service Under Warranty”...
