OWNER'S MANUAL
200/400 WATT
POWER INVERTERS
THE WHISTLER GROUP, INC.
CORPORATE HEADQUARTERS
13016 N. Walton Blvd.
Bentonville, AR 72712
TEL (479) 273-6012 FX (479) 273-2927
www.whistlergroup.com
CUSTOMER RETURN CENTER
1201 N. Dixieland Rd.
Rogers, AR 72756
Consumer Relations Tel (800) 531-0004
Email: info@whistlergroup.com
P/N 205563
© 2006 The Whistler Group, Inc.
Advertisement
Table of Contents
Related Manuals for Whistler 200/400 WATT
Summary of Contents for Whistler 200/400 WATT
- Page 1 CORPORATE HEADQUARTERS 13016 N. Walton Blvd. Bentonville, AR 72712 TEL (479) 273-6012 FX (479) 273-2927 www.whistlergroup.com CUSTOMER RETURN CENTER 1201 N. Dixieland Rd. Rogers, AR 72756 Consumer Relations Tel (800) 531-0004 Email: info@whistlergroup.com P/N 205563 © 2006 The Whistler Group, Inc.
- Page 2 Your new Whistler power inverter allows you to run most AC appliances right from your car, boat or RV. They’re great for weekend use and life on the road. They’re also great for...
-
Page 3: Table Of Contents
AC output is called “modified sine wave”. See “Technical Operating Principles” section for more information. Depending on the model and its rated capacity, WHISTLER inverters draw power either from standard 12 volt automobile and marine batteries or from portable high power 12 volt sources. -
Page 4: Important Information
WHISTLER inverter and keep the manual on file for future reference. Notes: Your WHISTLER inverter is designed to operate from a 12 volt power source only. Never attempt to connect your Whistler inverter to any other power source, including any AC power source. -
Page 5: Don't Push It
INVERTER BASICS Don’t Push It. Although your WHISTLER inverter has the capacity to pro- vide power output (excess current) equal to approximately two times its rated wattage capacity for a very brief period, it is designed to operate equipment and appliances with start up load wattage ratings no higher than its own maxi- mum continuous wattage rating. -
Page 6: Operation
Reverse polarity will blow the internal fuses in the invert- er and may cause permanent damage to the inverter. Damage caused by reverse polarity is not covered under the WHISTLER warranty. • Making the connection between the Positive terminals may cause a spark as a result of current flowing to the capacitors in the inverter. - Page 7 OPERATION • 400 watt model - If the supplied cables are too short to allow for placement of the inverter in a desired location, the inverter may be connected to the power source using a #8 wire, up to 12’ - #4 wire for longer lengths.
-
Page 8: Additional Safety Features
OPERATION within the appliance or equipment being operated. If the fuse(s) does blow, turn off and disconnect the appliance or equipment from the inverter immediately, repair the related problem and replace the fuse(s). The internal fuses are replaceable, however, only electronically knowledgeable people should attempt fuse replacement Note: •... -
Page 9: Care & Maintenance
Some Powerful Advice. Your WHISTLER inverter will work best when placed on a rea- sonably flat surface. The floor or seat of your car or truck both are good locations. - Page 10 Consequently, these meters will not read the RMS modified sine wave voltage correctly and, when measuring your WHISTLER inverter output, the meters will read about 20 to 30 volts too low. To accurately measure the output volt- age of your inverter, use a true RMS reading voltmeter such as a Fluke 87, Fluke 8060A, Beckman 4410, Triplett 4200 or any multimeter identified as "True RMS."...
-
Page 11: Operation Summary
OPERATION SUMMARY • This inverter is designed to be connected to the power source with the supplied cables or with #8 wire up to 12’ - #4 wire for longer length. When utilizing the supplied cables do not attempt to modify or lengthen them. •... -
Page 12: Troubleshooting
TROUBLESHOOTING Please visit our Inverter FAQ page on our website (www.w w h h i i s s t t l l e e r r g g r r o o u u p p .com), for more troubleshooting informa- tion and FYI topics. -
Page 13: Specifications
TV is compatible with a modified sine wave. A larger inverter may be required. SPECIFICATIONS WHISTLER 200 WATT INVERTER SPECIFICATIONS Maximum Continuous Power ...200 Watts Maximum Surge Capability (Peak Power) 400 Watts* * No Load Current Draw...<0.3 A Waveform ...Modified Sine Wave Operating Input Voltage Range ...11–... - Page 14 All express or implied warranties for this product are limited to two years. Whistler is not liable for damages arising from the use, misuse, or operation of this product.
- Page 15 • The unit has been abused, modified, installed improperly, or had its housing removed. The minimum out of warranty service fee for your Whistler 200 watt inverter is $15.00 (U.S.) and the 400 watt inverter is $25.00 (U.S.). If you require out of warranty service, please return your unit as outlined in the section “Service...
