DMH-Z5350BT RDS AV RECEIVER Operation Manual...
Page 2
Contents Thank you for buying this Pioneer product. Please read through these instructions so you will know how to operate your model properly. After you have finished reading the instructions, keep this document in a safe place for future reference.
Page 4
• If you notice smoke, a strange noise or odour from this product, or any other abnormal signs on the LCD screen, turn off the power immediately and consult your dealer or the nearest authorised Pioneer Service Station. Using this product in this condition may result in permanent damage to the system.
Page 5
vehicle in a safe location and apply the handbrake before making the necessary adjustments. • Never set the volume of this product so high that you cannot hear outside traffic and emergency vehicles. • To promote safety, certain functions are disabled unless the vehicle is stopped and the handbrake is applied.
Page 6
• To prevent data loss and damage to the storage device, never remove it from this product while data is being transferred. • Pioneer cannot guarantee compatibility with all USB mass storage devices and assumes no responsibility for any loss of data on media players, iPhone, smartphone, or other devices while using this product.
Page 7
• We offer the latest information about PIONEER CORPORATION on our website. • Pioneer regularly provides software updates to further improve it’s products. Please check the support section of the Pioneer website for all available software updates. Protecting the LCD panel and screen •...
Page 8
About this manual This manual uses diagrams of actual screens to describe operations. However, the screens on some units may not match those shown in this manual depending on the model used. Meanings of symbols used in this manual This indicates to touch the appropriate soft key on the touch screen. This indicates to touch and hold the appropriate soft key on the touch screen.
Page 9
Parts and controls Main unit Touch to display the top menu screen. Touch and hold to power off. To power back on, touch any button. Touch to switch between the Application screen and the AV operation screen. Touch and hold to turn off the display. Touch to display the menu bar (page 14).
Page 10
MODE Press to switch between the Application screen and the AV operation screen. Press and hold to turn off the display. Press to cycle through all the available sources. Press and hold to turn the source off. TOP MENU Not used. MENU Not used.
Page 11
Basic operation Preparing the remote control Remove the insulation sheet before use. How to replace the battery Insert the CR2025 (3 V) battery with the plus (+) and minus (-) poles orientated properly. WARNING Batteries (battery pack or batteries installed) must not be exposed to excessive heat such as sunshine, fire or the like.
Page 12
• Do not let the remote control fall onto the floor, where it may become jammed under the brake or accelerator. Starting up the unit Start the engine to boot up the system. The [Select Program Language] screen appears. NOTE From the second time on, the screen shown will differ depending on the previous conditions.
Page 13
Using the touch panel You can operate this product by touching the keys on the screen directly with your fingers. NOTE To protect the LCD screen from damage, be sure to touch the screen only with your finger gently. Common touch panel keys : Returns to the previous screen.
Page 14
Operating the time bar You can change the playback point by dragging the key. The playback time corresponding to the position of the key is displayed while dragging the key. Operating the menu bar Touch The menu bar pops up on the screen. NOTE The menu bar availability may vary depending on the activating source.
Page 15
Top menu screen Switches the top menu screen layout. Touch and hold appears at the top of the screen. Touch When you finish switching the layout, touch Favourite source icons If you select [Power OFF], you can turn off almost all functions. The [Power OFF] mode is released in the following cases: •...
Page 16
Settings (page 61) and Favourite menu (page 77) Connected device key Displays connected device. Switches the source or application with connected devices such as WebLink, Apple CarPlay and Android Auto. When a device with a compatible application is connected, the favourite application key appears.
Page 17
Bluetooth Bluetooth connection Turn on the Bluetooth function on the device. Touch Touch then The Bluetooth screen appears. Touch [Connection]. Touch The unit starts to search for available devices, then displays them in the device list. Touch the Bluetooth device name. After the device is successfully registered, a Bluetooth connection is established by the system.
Page 18
CAUTION Never turn this product off and disconnect the device while the Bluetooth setting operation is being processed. Menu Item Description [Connection] Connect, disconnect, or delete registered Bluetooth device manually. Touch to delete registered device. To connect a registered Bluetooth device manually, touch the name of the device.
Page 19
registered devices are already connected, you can connect the remaining third device to use the audio function only from the switch devices key on the audio source screen. • The icon for the mobile phone currently being used is displayed on the Phone menu screen.
Page 20
The following items are displayed. • Name of the current mobile phone • List number of the current mobile phone • Reception status of the current mobile phone • Battery status of the current mobile phone If you connect two mobile phones to this product at the same time, you can switch between the mobile phones using the switch devices key.
Page 21
Touch Touch On the [Phone Book] screen, touch the desired name to display the contact’s phone number. Touch ▶Dialling from the preset dial list Touch Touch the desired entry on the list to make a call. The dial screen appears and dialling starts. ▶Deleting a phone number Touch Touch...
Page 22
Touch Touch Touch The voice recognition function launches and the voice control screen appears. TIPS • You can also launch the voice recognition function by touching button. • If two mobile phones are automatically connected to this product with the Bluetooth device auto connect function, the voice recognition function (Siri Eyes Free Mode) will be set on the second phone.
Page 23
Touch to turn private mode on or off. NOTES • If two mobile phones are connected to this product and the first phone is set to private mode, you can receive incoming calls on the second phone while maintaining the call in progress on the first phone.
Page 24
▶The received call and dialled number histories • You cannot make a call to the entry of an unknown user (no phone number) in the received call history. • If calls are made by operating your mobile phone, no history data will be recorded in this product.
Page 25
The Bluetooth audio playback screen appears. Basic operation Bluetooth audio playback screen Track number indicator Switches between playback and pause. Skips files forwards or backwards. • By touching then touch , you can also skip files forwards or backwards. • By touching then touch and hold , you can also perform fast reverse or fast forwards.
Page 26
AV source Supported AV source You can play or use the following sources with this product. • Radio • USB The following sources can be played back or used by connecting an auxiliary device. • iPod • Spotify® • Bluetooth® audio •...
Page 27
Selecting a source Source on the AV source selection screen Touch then touch Touch the source icon. When you select [Source OFF], the AV source is turned off. Source on the source list Touch then touch the AV operation key. Touch Touch the source key.
Page 28
Adjusting the range of favourite source icons area NOTE This function is available only when you stop your vehicle in a safe place and apply the handbrake. Touch Touch and hold appears at the top left of the favourite source icons. Drag to the desired position.
Page 29
Radio Starting procedure Touch then touch Touch [Radio]. The Radio screen appears. Basic operation Radio screen Recalls the preset channel stored to a key from memory. Stores the current broadcast frequency to a key. Displays the preset channel list. Select an item on the list ([1] to [6]) to switch to the preset channel. Selects the FM1, FM2, FM3, or AM band.
Page 30
Manual tuning Seek tuning or non stop seek tuning Releasing the key in a few seconds skips to the nearest station from the current frequency. Keep holding the key for long seconds to perform non stop seek tuning. Searches for a broadcast by PTY information (page 30). TIPS •...
Page 31
To cancel the storage process Touch [Cancel]. Radio settings Touch Touch then The system setting screen appears. Touch [AV Source Settings]. Touch [Radio settings]. The menu items vary according to the source. Menu Item Description [Local] Local seek tuning allows you to only tune into [Off] radio stations with sufficiently strong signals.
Page 32
Menu Item Description [Alarm Interrupt ]*2 The alarm broadcast can be received from the [On] [Off] last selected frequency, interrupting the other sources. [TA Interrupt]*2 Receives the traffic announcement from the last [On] [Off] selected frequency, interrupting the other sources. [News Interrupt]*2 Interrupt the currently selected source with [On] [Off]...
Page 33
Compressed files Plugging/unplugging a USB storage device You can play compressed audio, compressed video, or still image files stored in an external storage device. Plugging a USB storage device Pull out the plug from the USB port of the USB cable. Plug a USB storage device into the USB cable.
Page 34
Plug the USB storage device into the USB cable (page 33). Touch [USB]. Playback is performed in order of folder numbers. Folders are skipped if they contain no playable files. Basic operation TIPS • By touching then touch , you can also skip files/chapters forwards or backwards. •...
Page 35
Sets a repeat play range for all files/the current folder/the current file. Plays files or does not play in random order. Displays the hidden function bar. You can also display the hidden function bar by flicking the bar from the right to the left.
Page 36
Selects the previous folder or the next folder. Constructs the database for using the Music Browse mode (page 36). Switches the current music information display. ▶Selecting a file using Music Browse mode You can select files to play back using the category list if the files contain tag information.
Page 37
Video source screen Hides the touch panel keys. To display the keys again, touch anywhere on the screen. Switches between playback and pause. Performs fast reverse or fast forwards. Touch again to change the playback speed. Stops playback. Performs frame-by-frame playback. Performs slow-motion playback.
Page 38
Selects a file from the list. Touch a file on the list to playback. Touching a folder on the list shows its contents. You can play a file on the list by touching it. Skips files forwards or backwards. Still image source TIPS •...
Page 39
Saves the current images as the wallpaper. Touch the following items then touch [Yes] to overwrite the image. [As AV Screen]: Saves the image as the wallpaper for the AV screen. [As HomeScreen]: Saves the image as the wallpaper for the top menu screen. [As Both]: Saves the image as the wallpaper for both the AV screen and top menu screen.
Page 40
iPod Connecting your iPod When connecting an iPod to this product, the settings are automatically configured according to the device to be connected. For details of the compatiblity, refer to Compatible iPod/iPhone models (page 90). NOTES • Depending on the generation or version of the iPod, some functions may not be available. •...
Page 41
Displays the link search screen. Select a song from the list related to the song currently playing. If you touch the artwork, the list of songs in the album is displayed. NOTE This function is not available while playing Apple Music Radio. Switches between playback and pause.
Page 42
Audio source screen 2 Changes the audiobook speed. Normal—Fast—Slow NOTE This function may not operate correctly depending on the iOS version of the connected iPod/iPhone. Displays the hidden function bar. Apple Music® Radio source Important Apple Music Radio may not be available in your country or region. For details about Apple Music Radio, visit the following site: https://www.apple.com/music/ NOTE This function is only available when using the iPod function with iOS 8 or higher (up to iOS 12) installed...
Page 43
Switches between playback and pause. Displays the pop-up menu for Apple Music Radio. • Touch [Play More Like This] to play back songs similar to the current song. • Touch [Play Less Like This] to set it not to play back the current song again. •...
Page 44
Using WebLink Important • Pioneer is not liable for any issues that may arise from incorrect or flawed app-based content. • The content and functionality of the supported applications are the responsibility of the App providers. • In WebLink, functionality through the product is limited while driving, with available functions determined by the App providers.
Page 45
WebLink Displays the main menu of the WebLink source screen. When the rear display is connected to this unit, video from the WebLink screen can be displayed to the rear display except while the AV source with video content is active even while driving. For iPhone users System requirement iOS 10.0 or higher (up to iOS 12.x)
Page 46
• The video playback capability depends on the connected Android device. Unlock your smartphone and connect it to this product via USB. Refer to the Quick start guide. Touch Touch Touch [WebLink]. Touch desired icon in the tab. The WebLink app is launched. Using the audio mix function You can output the audio mixing AV source and an application for iPhone when WebLink is used.
Page 47
• Apple CarPlay allows access to applications other than those listed that are subject to limitations while driving. • PIONEER IS NOT RESPONSIBLE AND DISCLAIMS LIABILITY FOR THIRD PARTY (NON-PIONEER) APPS AND CONTENT, INCLUDING WITHOUT LIMITATION ANY INACCURACIES OR INCOMPLETE INFORMATION.
Page 48
Touch [Driving Position]. Touch the item. [Left] Select for a left-hand drive vehicle. [Right] Select for a right-hand drive vehicle. Starting procedure Connect an Apple CarPlay compatible device to this product via USB. Touch Touch Touch [Apple CarPlay]. Touch Apple CarPlay icon in the tab. The application screen appears.
Page 49
Touch to mute. Touch again to cancel mute. Touch [+]/[-] to adjust the guidance volume. Displays the main sound volume. To adjust the main sound volume, touch VOL (+/-) on the unit or touch [+]/[-]. NOTE The volume menu is displayed for four seconds. If the menu disappears, touch VOL (+/-) again. The menu reappears.
Page 50
• Android Auto allows access to applications other than those listed that are subject to limitations while driving. • PIONEER IS NOT RESPONSIBLE AND DISCLAIMS LIABILITY FOR THIRD PARTY (NON-PIONEER) APPS AND CONTENT, INCLUDING WITHOUT LIMITATION ANY INACCURACIES OR INCOMPLETE INFORMATION.
Page 51
Touch [Driving Position]. Touch the item. [Left] Select for a left-hand drive vehicle. [Right] Select for a right-hand drive vehicle. Starting procedure Connect an Android Auto™ compatible device to this product via USB. Touch Touch Touch [Android Auto]. Touch Android Auto icon in the tab. The application screen appears.
Page 52
Touch to mute. Touch again to cancel mute. Touch [+]/[-] to adjust the guidance volume. Displays the main sound volume. To adjust the main sound volume, touch VOL (+/-) on the unit or touch [+]/[-]. NOTE The volume menu is displayed for four seconds. If the menu disappears, touch VOL (+/-) again. The menu reappears.
Page 53
• Certain functions of the Spotify service are not available when accessing the service through Pioneer car audio/video products. • Spotify is a music service not affiliated with Pioneer. More information is available at https://support.spotify.com/. • The Spotify application is available for most iPhone and smartphone, please visit https://support.spotify.com/ for the latest compatibility information.
Page 54
Touch then Touch [AV Source Settings]. Confirm that [Spotify] is turned on. Touch then touch Touch [Spotify]. NOTES • For details on Bluetooth connection, see page 17. • For details on USB connection for iPhone, refer to the Quick start guide. Basic operation Playback screen 1 (Track) Switches between playback and pause.
Page 55
Displays the hidden function bar. You can also display the hidden function bar by flicking the bar from the right to the left. Switches among connected devices. Selects a track or station from the list. Your Music: Selects a track or station from the list of saved song information. Browse: Selects a track from the category list.
Page 56
Playback screen 1 (Radio mode) Switches between playback and pause. Skips tracks forwards or backwards. By touching then touch , you can skip songs forwards. NOTE The number of tracks that are skipped varies depending on the application. Starts new radio mode. Saves or deletes the current song information to or from Your Music.
Page 57
Playback screen 2 (Radio mode) Displays the hidden function bar. You can also display the hidden function bar by flicking the bar from the left to the right. Gives a Thumbs Up to the playing track. Gives a Thumbs Down to the playing track and skips to the next track. NOTE The number of tracks that are skipped varies depending on the application.
Page 58
You can display the video image output by the device connected to video input. CAUTION For safety reasons, video images cannot be viewed while your vehicle is in motion. To view video images, stop in a safe place and apply the handbrake. NOTE A Mini-jack AV cable (sold separately) is required for connection.
Page 59
Hides the touch panel keys. To display the keys again, touch anywhere on the screen. You can set the screen size for the video image (page 78). Switches between the video input and audio input. - 59 -...
Page 60
AV input You can display the video image output by the device connected to video or camera input. For details, refer to the Quick start guide. CAUTION For safety reasons, video images cannot be viewed while your vehicle is in motion. To view video images, stop in a safe place and apply the handbrake.
Page 61
Settings You can adjust various settings in the main menu. Displaying the setting screen Touch Touch Touch one of the following categories, then select the options. System settings (page 61) Theme settings (page 68) Audio settings (page 70) Video settings (page 76) Bluetooth settings (page 17) System settings The menu items vary according to the source.
Page 62
[Auto Mix] Menu Item Description [Auto Mix] Select whether to perform mixing the sound output from [On] [Off] WebLink and AV source sound automatically. NOTE This function is only available when WebLink is used with an iPhone. [Input/Output settings] Menu Item Description [USB MTP] Select whether or not to activate USB MTP (Media Transfer...
Page 63
CAUTION Pioneer recommends the use of a camera which outputs mirror reversed images, otherwise the screen image may appear reversed. • Immediately verify whether the display changes to the rear view camera image when the gearstick is moved to REVERSE (R) from another position.
Page 64
Menu Item Description [Parking Assist Guide Adjusting the guidelines by dragging or touching Adjust] on the screen. Touch [Default] to reset the settings. CAUTION • When adjusting the guidelines, be sure to park the vehicle in a safe place and apply the handbrake. •...
Page 65
• Depending on your vehicle, this function may not work properly. In this case, contact your dealer or an authorised PIONEER Service Station. • Please use a PIONEER wiring harness for each car model when [With Adapter] mode is engaged, otherwise select [W/o Adapter].
Page 66
[Dimmer Settings] NOTE This setting is available only when you stop your vehicle in a safe place and apply the handbrake. Menu Item Description [Dimmer Trigger] Setting the dimmer brightness. [Auto] Switches the dimmer to on or off automatically according to your vehicle’s headlight turning on or off.
Page 67
[Android Auto Auto-launch] Menu Item Description [Android Auto Auto- Select [On] to automatically launch Android Auto when an launch] Android device is connected to the unit. [On] [Off] [Picture Adjustment] You can adjust the picture for each source and rear view camera. CAUTION For safety reasons, you cannot use some of these functions while your vehicle is in motion.
Page 68
[System Information] Menu Item Description [Firmware Information] Displaying the firmware version. [Firmware Update] CAUTION • The USB storage device for updating must contain only the correct update file. • Never turn this product off, disconnect the USB storage device while the firmware is being updated. •...
Page 69
Menu Item Description [Background] Select the wall paper from the preset items in this product or original pictures via the external device. The wall paper can be set from selections for the top menu screen and AV operation screen. The preset image located on the far left changes randomly depending on the playback song and the station.
Page 70
Audio settings The menu items vary according to the source. Some of the menu items become unavailable when the volume is set to mute. Menu Item Description [Graphic EQ] Select or customise the equaliser curve. [Super Bass (S.Bass)] Select a curve that you want to use as the basis of [Powerful] [Natural] customising then touch the frequency that you want to [Vocal] [Flat] [Custom1]...
Page 71
Menu Item Description [Source Level Adjuster] Adjust the volume level of each source to prevent radical [-4] to [+4] changes in volume when switching between sources other than FM. Touch to adjust the source volume after comparing the FM tuner volume level with the level of the source.
Page 72
Menu Item Description [Time Alignment] Select or customise the time alignment settings to reflect [On] [Off] the distance between the listener’s position and each Listening Position*1*2 speaker. You need to measure the distance between the [Off] [Front Left] [Front head of the listener and each speaker unit. Right] [Front] [All] Touch to select the listening position then...
Page 73
Menu Item Description [Automatic Level Control] Corrects automatically the audio level difference between the music files or the sources. [Off] Turns the auto level control setting off. [Mode1] Corrects a little the audio level difference between the music files or the sources (for the narrow dynamic range audio signal).
Page 74
▶Before operating the Auto EQ function • Perform Auto EQ in a quiet place with the vehicle engine and air conditioning switched off. Also, cut the power of car phones or mobile phones in the vehicle, or remove them in advance. Surrounding sounds may prevent correct measurement of the vehicle’s acoustics.
Page 75
Disconnect the iPhone or smartphone device. Turn on the ignition switch (ACC ON). If the vehicle’s air conditioner or heater is turned on, turn it off. Switch the AV source to [Source OFF] (page 27). Touch Touch then Touch [A-EQ&TA Measurement]. Connect the microphone for acoustical measurement (sold separately) with this product.
Page 76
NOTE [Subwoofer Settings] is available only when [Subwoofer] is [On]. Touch Touch then Touch [Crossover] or [Subwoofer Settings]. Touch to switch the speaker. Drag the graph line to set the cutoff position. Drag the lowest point of the graph to set the cutoff slope. The following items can also be set.
Page 77
Favourite menu Registering your favourite menu items in shortcuts allows you to quickly jump to the registered menu screen by a simple touch on the [Favourites] screen. NOTE Up to 12 menu items can be registered in the favourite menu. Creating a shortcut Touch then touch...
Page 78
Other functions Setting the time and date Touch the current time on the screen. Touch to set the correct time and date. You can operate the following items: Year, month, date, hour, minute. TIPS • You can change the time display format to [12hour] or [24hour]. •...
Page 79
[Trimming] An image is displayed across the entire screen with the horizontal-to-vertical ratio left as is. If the screen ratio differs from the image, the image may be displayed partly cut off either at the top/bottom or sides. NOTE [Trimming] is for image files only. TIPS •...
Page 80
→ The operation is not compatible with here, contact your dealer or the nearest the video configuration. authorised Pioneer service facility. Random playback in Music Browse mode is released in the USB storage device. Common problems →...
Page 81
If the error persists, record the error message and contact your Problems with Application dealer or your nearest Pioneer service screen centre. A black screen is displayed. Common →...
Page 82
Spotify USB storage device Skip limit reached. Error-02-9X/-DX → Skip limit reached. → Communication failed. – Do not exceed the skip limit. – Turn the ignition switch OFF and back – Spotify limits the total number of skips per hour. –...
Page 83
– Disconnect the USB storage device Pioneer Service Station. and do not use it. Turn the ignition switch to OFF, then to ACC or ON and Apple CarPlay then connect a compliant USB storage device.
Page 84
If the error message is still displayed after instructions, please reconnect the performing the above action, please device. contact your dealer or an authorised Pioneer Service Station. Detailed information for playable media Android Auto Android Auto has stopped. → The connected device is not compatible Compatibility with Android Auto.
Page 85
become jammed under the brake or However, if there is only one DivX file and accelerator. one subtitle file in a single folder, the files • There may be a slight delay when starting are associated even if the file names are playback of audio files encoded with not the same.
Page 86
MP3 compatibility without video data, DivX files encoded with LPCM (Linear PCM) audio codec • Ver. 2.x of ID3 tag is prioritised when both • If a file contains more than 4 GB, playback Ver. 1.x and Ver. 2.x exist. stops before the end.
Page 87
30 fps word mark and logos are registered trademarks owned by Bluetooth SIG, .mov Inc. and any use of such marks by PIONEER CORPORATION is under license. Other Compatible video codec MPEG4, H.264, trademarks and trade names are those of their H.263...
Page 89
U.S. and other countries. App Store • Pioneer accepts no responsibility for data lost from an iPod, even if that data is lost App Store is a service mark of Apple Inc. while using this product. Please back up your iPod data regularly.
Page 90
Important Requirements to access app-based connected content services using this product: • Latest version of the Pioneer compatible Apple CarPlay is a trademark of Apple Inc. connected content application(s) for the Use of the Works with Apple badge means smartphone, available from the service...
Page 91
Content application(s) or author’s rights as protected by the service by its provider. Copyright Law. • Pioneer is not liable for any issues that may arise from incorrect or flawed app- Using the LCD screen based content. correctly • The content and functionality of the supported applications are the responsibility of the App providers.
Page 92
Preout output level (max): 4.0 V dimmer and the image will no longer be Equaliser (13-Band Graphic Equaliser): visible. In that case, please consult your Frequency: dealer or the nearest authorised Pioneer 50 Hz/80 Hz/125 Hz/200 Hz/315 Hz/ Service Station. - 92 -...
