Functional Description and Specifications

Disconnect the plug from the power source before making any
WARNING
!
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
SPLINE TOOL HOLDER
(Model 11248 only)
DUST SHIELD
AUXILIARY
Model number
Shank style
Maximum Capacities:
Carbide tipped bits
Thick wall core bits
NOTE: For tool specifications refer to the nameplate on your tool.
12:37 PM Page 6
Combination Hammer
FIG. 1
SELECTOR LEVER
LOCKING
SLEEVE
HANDLE
VENTILATION
OPENINGS
HAND GRIP
11241EVS
SDS Max
1 9/16"
4"
-6-
TRIGGER
SWITCH
TRIGGER
RELEASE
SWITCH
VARIABLE
SPEED DIAL
SERVICE
REMINDER
LIGHT
POWER
INDICATOR
LIGHT
11248EVS
Spline
1 9/16"
4"
