Prince Castle 625-OS Operating Manual

Operating
Manual
On/Off Rocker Switch
(left-side of unit)
Spatula
Control Panel
LIMITED WARRANTY
This product (with the exception of the water tube, part no. 625-197S) is
warranted to be free from defects in material and/or workmanship for a
period of two (2) years from date of original installation, not to exceed 30
months from date of shipment from our factory. P.C. Boards and Heater
Assemblies are warranted for three (3) years from date of installation, not
to exceed 42 months from date of shipment. Any component which proves
to be faulty in material and/or workmanship will be replaced or repaired (at
the option of Prince Castle, Inc.) without cost to the customer for parts or
labor. This warranty covers on location service (i.e. trip charges and/or
mileage). Travel mileage is limited to 100 miles (200 kilometers) round trip
(one trip warranty) from an authorized service agency or its sub-service
agency.
This warranty is subject to the following exceptions/conditions:
• Use of any non-genuine Prince Castle parts voids this warranty.
• All labor shall be performed during regular work hours. Overtime
premium will be charged to the buyer.
• Damage caused by carelessness, neglect, and/or abuse (e.g.,
dropping, tampering or altering parts, equipment damaged in shipment,
by fire, flood or an act of God) is not covered under this warranty.
625-525revG-EN
Product Identification
PRINCE CASTLE
Logo Button
Product Buttons
(1 thru 4)
External Meter Plug Inlet
(for calibration)
SANITATION
355 East Kehoe Blvd. • Carol Stream, IL 60188 USA
Telephone: 630-462-8800 • Toll Free: 1-800-PCASTLE
Fax: 630-462-1460 • www.princecastle.com
Temperature and UP
Arrow Button
LED Display
TABLE OF CONTENTS
Product Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
View Firmware Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Programming Product Name and Water Cycle . . . . . . . . . . . . . . . . . .
Factory Pre-Set Temperatures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Regulator Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Programming New Water Cycle for Existing Products . . . . . . . . . . . .
Cleaning — Daily . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exploded View and Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Water Tube Cleaning and Replacement . . . . . . . . . . . . . . . . . . . .
Steamer
625-OS
Celsius/Fahrenheit and
DOWN Arrow Button
RAPID STEAMER
Logo Button
START Button
