Harman JBL EON ONE Compact Quick Start Manual

EON ONE Compact
1 . CHARGE THE UNIT
1. Connect the power cord to the
Receptacle (H).
2. The Battery Level Meter (I)
in sequence from bottom to top,
indicating the unit is charging.
3. The unit is charged when the
Level Meter (I)
powered on or of f.
Power Switch A
Mic/Line Inputs B
Line Input C
Aux Input D
Pass Thru Output E
Headphone Output F
G
USB Ports
Power Receptacle H
BA TTERY POWERED | UNPARALELLED PORT ABILITY | BLUETOOTH AUDIO
QUICKST ART GUIDE
Power
will illuminate
Battery
is fully illuminated when
Battery Level
Meter
Channel Select
LEDs
Channel Select
Button
Mic/Line
Button
Phantom Power
Switch
Ducking
On/Off Button
Bluetooth
Button
2. PLUG IN THE INPUTS
1. Turn the Master Volume Control (P)
the way to the left before connecting any
inputs.
2. Connect your devices to the
(B-D).
3. POWER ON THE UNIT
1. Hold the Power Switch (A)
The Bluetooth button (O)
indicating the unit is powering on. After 3
seconds, all LEDs will illuminate, indicating
the unit is fully powered.
I
J
K
L
M
N
O
all
Input Jacks
for 1 second.
will flash,
P Master Volume Control
Input Gain Control /
Q
Mix Mode Channel 1
Treble Control/ Mix
R
Mode Channel 2
Bass Control/ Mix
S
Mode Channel 3
Reverb Control/ Mix
T
Mode Channel 4
