- Page 1 SPLIT-TYPE AIR CONDITIONERS INDOOR UNIT MSZ-AP15VG MSZ-AP20VG OPERATING INSTRUCTIONS English...
- Page 2 ● OPERATING INSTRUCTIONS ● ENGLISH IS ORIGINAL ONTENTS ■ SAFETY PRECAUTIONS ■ DISPOSAL ■ NAME OF EACH PART ■ PREPARATION BEFORE OPERATION ■ SELECTING OPERATION MODES ■ FAN SPEED AND AIRFLOW DIRECTION ADJUSTMENT ■ I-SAVE OPERATION ■ ECONO COOL OPERATION ■...
- Page 3 To use this unit correctly and safely, be sure to read these operating instructions before use. AFETY PRECAUTIONS This appliance is not intended for use by persons (including Do not use the unit for special purposes, such as storing food, children) with reduced physical, sensory or mental capabilities, raising animals, growing plants, or preserving precision devices or lack of experience and knowledge, unless they have been...
- Page 4 Immediately stop operating the air conditioner and consult your dealer. ISPOSAL To dispose of this product, consult your dealer. Your MITSUBISHI ELECTRIC product is designed and manufactured with high quality materials and components which can be recycled and/or reused. Note:...
- Page 5 AME OF EACH PART Indoor unit Remote controller Battery replacement indicator Signal transmitting Page 5 Air inlet section Distance of signal : Front panel About 6 m Beep(s) is (are) heard Air fi lter from the indoor unit when the signal is received.
- Page 6 ● OPERATING INSTRUCTIONS ● REPARATION BEFORE OPERATION Before operation: Insert the power supply plug into the power outlet and/or turn the breaker on. Installing the remote controller batteries Setting current time Press the DAY button to set the day. Press RESET. Press CLOCK.
- Page 7 ELECTING OPERATION MODES DRY mode Dehumidify your room. The room may be cooled slightly. Temperature cannot be set during DRY mode. HEAT mode Enjoy warm air at your desired temperature. FAN mode Circulate the air in your room. Note: After COOL/DRY mode operation, it is recommended to operate in the FAN mode to dry inside the indoor unit.
- Page 8 ● OPERATING INSTRUCTIONS ● AN SPEED AND AIRFLOW DIRECTION ADJUSTMENT Up-down Airflow direction to select airfl ow direction. Each press Press changes airfl ow direction in the following order: (AUTO) (SWING) (AUTO) ..The vane is set to the most effi cient airfl ow direction. COOL/ DRY:horizontal position.
- Page 9 -SAVE OPERATION CONO COOL OPERATION • A simplified set back function enables to recall the preferred (preset) setting Swing airfl ow (change of air fl ow) makes you feel cooler than stationary airfl ow. with a single push of the button.
- Page 10 ● OPERATING INSTRUCTIONS ● IGHT MODE OPERATION NIGHT MODE operation changes the brightness of the operation indicator, disables the beep sound and limits the noise level of the outdoor unit. Press during operation to activate NIGHT MODE operation. • The operation indicator lamp dims. •...
- Page 11 EEKLY TIMER OPERATION • A maximum of 4 ON or OFF timers can be set for individual days of the week. • A maximum of 28 ON or OFF timers can be set for a week. Press , and to set ON/OFF, time, and temperature.
- Page 12 ● OPERATING INSTRUCTIONS ● MERGENCY OPERATION When the remote controller cannot be used... Emergency operation can be activated by pressing the emergency operation switch (E.O. SW) on the indoor unit. Each time the E.O. SW is pressed, the operation changes in the following order: Operation indicator lamp Emergency COOL...
- Page 13 LEANING Instructions: • Switch off the power supply or turn off the breaker before cleaning. • Do not soak or rinse the horizontal vane. • Be careful not to touch the metal parts with your hands. • Do not use water hotter than 50°C. •...
- Page 14 ● OPERATING INSTRUCTIONS ● HEN YOU THINK THAT TROUBLE HAS OCCURRED Even if these items are checked, when the unit does not recover from the Symptom Explanation & Check points trouble, stop using the air conditioner and consult your dealer. Does not cool or heat The room cannot be cooled •...
- Page 15 HEN THE AIR CONDITIONER IS NOT NSTALLATION PLACE AND GOING TO BE USED FOR A LONG TIME ELECTRICAL WORK Installation place Operate by COOL mode with the highest temperature Avoid installing the air conditioner in the following places. set or FAN mode for 3 to 4 hours. •...
- Page 16 ● OPERATING INSTRUCTIONS ● PECIFICATIONS Indoor MSZ-AP15VG MSZ-AP20VG Model Outdoor — MUZ-AP20VG Cooling Cooling Function Heating Heating Power supply ~ /N, 230 V, 50 Hz Capacity — 0.017 0.46 Input Indoor Weight Outdoor — Refrigerant fi lling capacity (R32) 0.55 —...
- Page 17 MADE IN THAILAND HEAD OFFICE: TOKYO BUILDING, 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN JG79Y597H02...
