Model No. WCTL39102
Serial No.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, please call:
1-888-936-4266
Mon.–Fri. 8h00 until 18h30 EST
(excluding holidays).
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.weslo.com
Advertisement
Table of Contents
Related Manuals for Weslo WCTL39102
Summary of Contents for Weslo WCTL39102
- Page 1 Model No. WCTL39102 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, please call: 1-888-936-4266 Mon.–Fri. 8h00 until 18h30 EST (excluding holidays).
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN . - Page 3 12. Never move the walking belt while the power is turned off. Do not operate the treadmill if the power cord or plug is damaged, or if the treadmill is not working properly. (See BEFORE YOU BEGIN on page 4 if the tread- mill is not working properly.) 13.
-
Page 4: Before You Begin
The model number is WCTL39102. The serial number can be found on a decal attached to the treadmill (see the front cover of this manual for the location). -
Page 5: Assembly
ASSEMBLY Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Refer to the drawings below to identify small parts used in assembly. Assembly requires an adjustable wrench 3/8"... -
Page 6: Proper Exercise Form
5. The Console (3) requires two "AA" batteries (not included). Alkaline batteries are recommended. Slide the Battery Cover (15) up as shown. Press two batteries into the battery compartment, with the negative (–) ends of the batteries touching the springs. Close the battery cover. 6. -
Page 7: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to the walking belt or the walking plat- form. Such substances will deteriorate the walking belt and cause excessive wear. - Page 8 DIAGRAM OF THE CONSOLE Note: If there is a thin sheet of clear plastic on the console, remove it. CAUTION: Before operating the con- sole, read the following important precautions. • Do not stand on the walking belt when turning on the power.
- Page 9 Carefully step onto the walking belt and begin walking. Change the speed of the walking belt as desired by sliding the speed control. Note: To stop the walking belt, slide the speed control to the "RESET" position. Monitor your progress with the two displays. Time/Distance dis- play—The left display shows the elapsed...
-
Page 10: Troubleshooting And Storage
TROUBLESHOOTING AND STORAGE Most treadmill problems can be solved by following the simple steps below. Find the symptom that applies to your treadmill and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll-free at 1-888-936-4266, Monday through Friday, 8h00 until 18h30 east- ern time (excluding holidays). - Page 11 5. SYMPTOM: THE WALKING BELT IS OFF-CENTER a. If the walking belt has shifted to the left, first remove the key and UNPLUG THE POWER CORD. Using the allen wrench, turn the rear roller adjustment bolt clockwise 1/4 of a turn. Plug in the power cord, insert the key and run the treadmill for a few min- utes.
-
Page 12: Conditioning Guidelines
CONDITIONING GUIDELINES WARNING: Before beginning this or any exercise program, consult your physi- cian. This is especially important for individu- als over the age of 35 or individuals with pre- existing health problems. The pulse sensor is not a medical device. Various factors, including your movement, may affect the accuracy of heart rate readings. -
Page 13: Part List
PART LIST—Model No. WCTL39102 Key No. Qty. Description Left Handrail 3/8” x 1 3/4” Bolt Console Upright Wire Harness Console Cage Nut Console Screw Pot Wire Console Cable Loom Key/Clip Right Handrail Upright Motor Swivel Bolt Upright Cage Nut Motor Swivel Nut... -
Page 14: Exploded Drawing
EXPLODED DRAWING—Model No. WCTL39102 R1003A... -
Page 15: Ordering Replacement Parts
Friday 8h00 until 18h30 Eastern Time (excluding holidays). When ordering parts, please be prepared to give the following information: • The MODEL NUMBER of the product (WCTL39102) • The NAME of the product (WESLO CADENCE • The SERIAL NUMBER of the product (see the front cover of this manual) •... -
Page 16: Limited Warranty
7) What was the primary reason for purchasing this ICON product? Store Employee Electronic Features Product Design Other Features WESLO is a registered trademark of ICON Health & Fitness, Inc. Part No. 204163 R1003A LIMITED WARRANTY ® PRODUCT WARRANTY REGISTRATION...
