Model No. WCTL25071
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal
If you require SERVICE for
this product, please call
SEARS:
1-800-4 MY HOME
(469-4663)
If you are MISSING PARTS or
require INFORMATION on how
to operate this product, call
1-888-936-ICON
(936-4266)
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.weslo.com

Advertisement

Table of Contents
loading

Related Manuals for Weslo CADENCE DX5

Summary of Contents for Weslo CADENCE DX5

  • Page 1 If you are MISSING PARTS or require INFORMATION on how to operate this product, call 1-888-936-ICON (936-4266) CAUTION Read all precautions and instruc- tions in this manual before using Visit our website at this equipment. Save this manual for future reference. www.weslo.com...
  • Page 2 TABLE OF CONTENTS IMPORTANT PRECAUTIONS ............. 2 BEFORE YOU BEGIN .
  • Page 3 15. The treadmill is capable of high speeds. the rear roller. Remove the key and adjust Adjust the speed in small increments to the roller guards, if necessary. avoid sudden jumps in speed. 21. Never insert any object into any opening. 16.

  • Page 4: Before You Begin

    And when number of the treadmill is WCTL25071. The serial you’re not exercising, the unique CADENCE DX5 can number can be found on a decal attached to the tread- be folded up, requiring less than half the floor space of mill (see the front cover of this manual for the loca- other treadmills.

  • Page 5: Assembly

    ASSEMBLY Before beginning assembly, carefully read the The following tools (not included) are required following information and instructions: for assembly: • Assembly requires two people. • Two adjustable wrenches • Place all parts in a cleared area and remove the •...
  • Page 6 3. Place the Console Base (45) in the position shown. Insert four Handrail Bolts (68) through the Console Base and the Uprights (37). The Handrail Bolts must be inserted from the inside as shown. Attach a Handrail Washer (41) and a Handrail Nut (77) to each Handrail Bolt.

  • Page 7: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a Your treadmill features a walking belt coated with grounding plug. Plug the power cord into a surge PERFORMANT LUBE , a high-performance lubricant.
  • Page 8 DIAGRAM OF THE CONSOLE Monitor Display Speed Control Clip Follow the steps below to operate the console. CAUTION: Before operating the Insert the key fully into the power switch. console, read the following precautions. • Do not stand on the walking belt when turn- Note: Inserting the key ing on the power.
  • Page 9 HOW TO SELECT KILOMETRES AND MILES Follow your progress with the monitor modes The console can display distance and speed in either When the power is kilometres or miles. To change the unit of measure- turned on, the con- ment, first UNPLUG THE POWER CORD. Next, sole will scan through remove the six screws attaching the console to the the five modes auto-...

  • Page 10: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) in order to raise, lower, or move the treadmill. 1.
  • Page 11 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, slide open the storage latch. Pivot the treadmill until the frame guide and the foot rail are past the storage latch. Storage Opened Latch...

  • Page 12: Maintenance And Trouble-Shooting

    MAINTENANCE AND TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-888-936-4266, Monday through Friday, 8h00 until 18h30. Eastern Standard Time (excluding holi- days).
  • Page 13 PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt has shifted to the left, first remove the key and UNPLUG THE POWER CORD. Using the allen wrench, turn the left rear roller adjust- ment bolt clockwise, and the right bolt counterclock- wise, 1/4 of a turn each.

  • Page 14: Conditioning Guidelines

    CONDITIONING GUIDELINES Aerobic Exercise WARNING: Before beginning If your goal is to strengthen your cardiovascular sys- this or any exercise program, consult your tem, your exercise must be “aerobic.” Aerobic exercise physician. This is especially important for is activity that requires large amounts of oxygen for individuals over the age of 35 or individuals prolonged periods of time.

  • Page 15: Ordering Replacement Parts

    • The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST and the EXPLODED DRAWING in the center of this manual). PLACE STAMP HERE ICON of Canada Inc. 900 de l’Industrie St-Jérôme, Québec Canada, J7Y 4B8 WESLO is a registered trademark of ICON Health & Fitness, Inc.
  • Page 16 PART LIST—Model No. WCTL25071 R0103A Key No. Qty. Description Key No. Qty. Description Hood Latch Decal Adhesive Clip Belly Pan Screw Motor Belt Console Base Motor Pivot Nut Console Screw Pulley/Flywheel/Fan Reed Switch Bracket Motor/Pulley/Flywheel/Fan Battery Cover Motor Console Assembly Reed Switch Speed Potentiometer Clip Screw...
  • Page 17 REMOVE THIS EXPLODED DRAWING AND PART LIST FROM THE MANUAL Save this EXPLODED DRAWING and PART LIST for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see page 15 of the User’s Manual.
  • Page 18 EXPLODED DRAWING—Model No. WCTL25071 R0103A...

  • Page 19: Limited Warranty

    LIMITED WARRANTY ICON OF CANADA INC., (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of one (1) year days from the date of purchase. This warranty extends only to the original purchaser. ICON's obligation under this warranty is limited to replacing or repairing, at ICON's option, the product at one of its authorized service centers.
