Model No. WESY75741
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (under seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satis-
faction through direct assis-
tance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge.
CUSTOMER HOT LINE:
1-877-992-5999
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before
using this equipment. Save this
manual for future reference.
V
USER'S MANUAL
Visit our website at
www.weiderplatinum.com
Advertisement
Table of Contents
Related Manuals for Weider WESY75741
Summary of Contents for Weider WESY75741
- Page 1 Model No. WESY75741 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (under seat) QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...
-
Page 2: Table Of Contents
Note: A PART IDENTIFICATION CHART and a PART LIST/EXPLODED DRAWING are attached in the center of this manual. Remove the PART IDENTIFICATION CHART and PART LIST/EXPLODED DRAWING before begin- ning assembly. WEIDER is a registered trademark of ICON IP, Inc. -
Page 3: Warning Decal Placement
WARNING DECAL PLACEMENT The decals shown here have been placed on the resistance system. If a decal is missing or illegible, please call our Customer Service Department toll- free at 1-877-992-5999, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time, to order a free replacement decal. -
Page 4: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the resistance system. 1. Read all instructions in this manual before using the resistance system. Use the resist- ance system only as described in this manual. 2. -
Page 5: Before You Begin
Time (excluding holidays). To help us assist you, please note the product model number and serial number before calling. The model number is WESY75741. The serial number can be found on a decal attached to the resistance system (see the front cover of this manual). -
Page 6: Assembly
ASSEMBLY Make Things Easier for Yourself This manual is designed to ensure that the resist- ance system can be assembled successfully by most people. However, it is important to realize that the versatile resistance system has many parts and that the assembly process will take time. - Page 7 2. Insert the connector of the Lower Wire Harness (113) into the socket of the Upper Wire Harness (71). The connector should slide easily into the socket and snap into place. If the connector does not slide easily and snap into place, turn the con- nector over and then insert it.
- Page 8 5. Insert the Squat Pin (66) into the Upright (2). Slide the Squat Carriage (19) onto the Upright. 6. Attach the Top Frame (37) to the Upright (2) with two M10 x 25mm Button Screws (88), an M10 x 75mm Button Screw (84), three M10 Lock Washers (75), and an M10 Washer (106).
- Page 9 8. Attach a Large Pulley (14) and the Pulley Plate (68) to the Upright (2) with an M12 x 62mm Button Bolt (81) and an M12 Nylon Locknut (13). Do not tighten the Locknut yet. 9. Pull the Upper Cable (115), which is attached inside of the Mech Frame (not shown), up between the Upright (2) and the Pulley Plate (68).
- Page 10 11. Insert the Resistance Bar (9) between the Crossbar Guides (15), and center it on the Crossbar Block (not shown). Press a Pulley Bracket (10) onto the Resistance Bar (9). Screw a 3/8” x 38mm Tension Screw (59) into the Pulley Bracket a couple of turns. Make sure the hexagonal hole in the Screw is on the outside of the Bracket.
- Page 11 15. Slide a Pad Tube (50) into the Leg (5). Slide two Large Foam Pads (52) onto the Pad Tube. Attach the other Pad Tube (50) to the Leg Lever (56) in the same manner. 16. Insert the rod on the Backrest Frame (32) into the slot in the Seat Carriage (44).
-
Page 12: Upper Cable Adjustment
UPPER CABLE ADJUSTMENT After completing the assembly of the resistance system, the tension on the Upper Cable (115) will need to be adjusted. Also, the Upper Cable can stretch slightly when it is first used. When this occurs, the Upper Cable ten- sion will need to be readjusted. -
Page 13: Adjustments
ADJUSTMENTS This section explains how to adjust the resistance system. See the EXERCISE GUIDELINES on page 20 for important information about how to get the most benefit from your exercise program. Also, see the accompanying exercise guide to see the correct form for each exercise. Make sure all parts are properly tightened each time the resistance system is used. - Page 14 ATTACHING THE ACCESSORIES To attach the Handle (96) to the high pulleys, first attach the high pulley to the resistance system (see ATTACHING THE HIGH PULLEYS on page 13). Then, attach the Handle to a High Cable (101) with a Cable Clip (94).
- Page 15 ADJUSTING THE SQUAT ARM To adjust the Squat Arm (20), remove the Squat Knob (27) from the Squat Carriage (19). Move the Arm to the up or down position, and reengage the Knob into the Squat Carriage. ADJUSTING THE SEAT The Seat (45) can be secured at various positions on the Rail (4).
-
Page 16: Console Operation
CONSOLE OPERATION FEATURES OF THE CONSOLE Console Program Buttons Main Display Resistance Display Sets Display Reps Display The heart of the resistance system is the digital resist- ance training console. The console offers both a manu- al mode and nine workout programs. When the manual mode is selected, the resistance setting can be changed with the touch of a button. - Page 17 Note: The resistance system uses progressive resistance. As the resistance bar begins to bend, the amount of resistance will increase gradually. As the bar bends further, the resistance will increase rapidly up to 340 pounds. 3. Enter the numbers of sets and repetitions that you plan to complete for an exercise.
-
Page 18: Cable Diagram
CABLE DIAGRAM The cable diagram shows the proper routing of the Upper Cable (115). Use the diagram to make sure Upper Cable (115) that the Cable has been assembled correctly. If the Cable has not been correctly routed, the resistance system will not function properly and damage may occur. -
Page 19: Troubleshooting
TROUBLESHOOTING RECALIBRATING THE CONSOLE To recalibrate the Console (67), first plug in the resist- ance system (see PLUGGING IN THE RESISTANCE SYSTEM on page 16). Then, press and hold the NEXT button and the MOTORIZED WEIGHT ADJUSTMENT + button for five seconds. When the buttons are released, a number will appear in the REPS display. -
Page 20: Exercise Guidelines
EXERCISE GUIDELINES THE FOUR BASIC TYPES OF WORKOUTS Muscle Building To increase the size and strength of your muscles, push them close to their maximum capacity. Your mus- cles will continually adapt and grow as you progres- sively increase the intensity of your exercise. You can adjust the intensity level of an individual exercise in two ways: •... - Page 21 Rest for a short period of time after each set. The ideal resting periods are: • Rest for three minutes after each set for a muscle building workout. • Rest for one minute after each set for a toning work- out.
- Page 22 EXERCISE MONDAY Date: AEROBIC EXERCISE TUESDAY Date: EXERCISE WEDNESDAY Date: THURSDAY AEROBIC EXERCISE Date: EXERCISE FRIDAY Date: Make photocopies of this page for scheduling and recording your workouts. WEIGHT WEIGHT WEIGHT SETS REPS SETS REPS SETS REPS...
- Page 23 EXERCISE MONDAY Date: AEROBIC EXERCISE TUESDAY Date: EXERCISE WEDNESDAY Date: THURSDAY AEROBIC EXERCISE Date: EXERCISE FRIDAY Date: Make photocopies of this page for scheduling and recording your workouts. WEIGHT WEIGHT WEIGHT SETS REPS SETS REPS SETS REPS...
- Page 24 REMOVE THIS PART IDENTIFICATION CHART AND PART LIST/ EXPLODED DRAWING. SAVE THIS PART IDENTIFICATION CHART AND PART LIST/EXPLODED DRAWING FOR FUTURE REFERENCE. PART IDENTIFICATION CHART—Model No. WESY75741 M10 x 25mm Button Screw (88) 38mm Spacer (90) 31mm Spacer (30) 1/2" Lock Washer (12)
- Page 25 PART LIST—Model No. WESY75741 Key Qty. Description Base Plate Upright Upright Cover Rail Mech Frame Front Mech Cover Back Mech Cover Resistance Bar Pulley Bracket M10 x 58mm Button Screw 1/2” Lock Washer M12 Nylon Locknut Large Pulley Crossbar Guide...
- Page 26 EXPLODED DRAWING—Model WESY75741 R0404A...
-
Page 27: Ordering Replacement Parts
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information: • The MODEL NUMBER of the product (WESY75741) • The NAME of the product (WEIDER •...
