Page 1 ORDER NO. BSD0108M017 Sec. 1 Service Information Sec. 2 Disassembly Procedures Sec. 3 Mechanical Adjustment Camera/VTR Sec. 4 Electrical Adjustment AJ-HDC27VP Sec. 5 Block Diagrams Sec. 6 Schematic Diagrams Sec. 7 Circuit Board Diagrams Sec. 8 Exploded Views & Replacement Parts List ©...
Page 2 WARNING This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product. Products powered by electricity should be serviced or repaired only by experienced professional technicians.
Page 3 - 3 -...
Page 4 - 4 -...
Page 5 SAFETY PRECAUTIONS GENERAL GUIDELINES ELECTROSTATICALLY SENSITIVE (ES) DEVICES 1. When servicing, observe the original lead dress. If a Some semiconductor (solid state) devices can be damaged short circuit is found, replace all parts which have been easily by static electricity. Such components commonly are over-heated or damaged by the short circuit.
Page 6 - 6 -...
Page 7 Printed in Japan FCD0108NCKK71...
Page 8: Table Of Contents
SERVICE INFORMATION CONTENTS 1. Servicing Fixtures & Tools ......................INF-1 1-1. How to use VFK1604 and VFK1611 .................INF-4 2. Alignment Tape ...........................INF-5 2-1. DVCPRO Alignment Tape..................INF-5 3. List of Recommended Measuring and Instruments ..............INF-5 4. Maintenance Schedule........................INF-6 5. Layout of the Maintenance Parts & Sensors................INF-7 6.
Page 9 17. Blemish Compensation Method....................INF-38 17-1. Preparation ....................... INF-38 17-2. Connection........................ INF-38 17-3. Compensation flow ....................INF-39 17-4. Compensation Procedures ..................INF-40 17-5. Remarks ........................INF-44 17-6. Trouble Shooting ...................... INF-45 17-7. FAQ (Frequently Asked Question) ................INF-45...
Page 10: Servicing Fixtures & Tools
1. Servicing Fixtures & Tools Part No. Fixture & Tool Name Remarks VFK1145A Back Tension Meter (T2-M30-P) VFK1149A Post Driver (2.5mm) VFK71A Dial Torque Gauge (1.5cN-m) 150g VFK1191A Dial Torque Gauge (0.45cN-m) VFK1152 Dial Torque Gauge Adapter VFK0357 Eccentric Driver (1.5mm) VFK1154 Post Height Fixture VFK1586...
Page 11 VFK1145A (T2-M30-P) VFK1149A (2.5mm) VFK71A (1.5cN-m) Back Tension Meter (150g) Post Driver VFK1191A (0.45cN-m) Dial Torque Gauge (45g) VFK1152 VFK0357 VFK1154 VFK1586 Dial Torque Gauge Eccentric Driver Post Height Fixture Mech. Neutral Plate (L) Adapter (1.5mm) VFK1155 VFK1208 VFK1150 VFK1151 REV Position Tool (Silver) Neutral Position Tool Nut Driver (5.5mm)
Page 12 VFK1375 VFK1300 VFM3580KL AJ-CL12P AD Board Cleaning Tape Hex. Bit VFM3581KL (DAQ-12 Quatech) VFM3582KL Alignment Tape VFK1481B VFK1186 VFK0369 VFK0371 LISTA Software LISTA Cable Radio Prier Tweezers VFK0372 VFK0337 VFK1369 VFK0906 Tape Sensor Cutter Prier Phillips Driver Lubrication Oil Adjustment Cassette VFK0338 Phillips Driver VFK1642...
Page 13: How To Use Vfk1604 And Vfk1611
1-1. How to use VFK1604 and VFK1611 When servicing the soldering side of DSP3 P.C.Board, VFK1604 and VFK1611 are needed. How to use VFK1604 and VFK1611 is shown below. 1. Removal of DSP3 P.C.Board 3. Connection of DSP3 P.C.Board 1. Remove 4 Screws (A). 1.
Page 14: Alignment Tape
2. Alignment Tape 2-1. DVCPRO Alignment Tape 2-1-1. VFM3580KL Time VIDEO (min.) SIGNAL PORPOSE SIGNAL PORPOSE SIGNAL PORPOSE Color Bar Confirmation of 0:00 SMPTE (75%) the Composite Video Level 1KHz 0VU Confirmation of the CUE Level Color Bar Confirmation of 7:00 Confirmation of (100%)
Page 15: Maintenance Schedule
4. Maintenance Schedule Hours of Use (unit hours) Part Name 1,000H 2,000H 4,000H 6,000H 8,000H 10,000H 12,000H Cleaning of the tape transport "C": every 500 hours Cylinder Ass’y R, Y, G R, Y, G R, Y, G R, Y, G R, Y, G R, Y, G Pinch Arm Unit...
Page 16: Layout Of The Maintenance Parts & Sensors
5. Layout of the Maintenance Parts & Sensors Cleaning Solenoid Cleaning Arm Unit Loading Motor Cylinder Unit A/C Head Pinch Solenoid DEW Sensor Capstan Motor Thrust Screw Unit Tape End Tape BEG/END Detect Sensor Detect Sensor Pinch Arm Tension Unit Sensor T Reel Motor T Reel...
Page 17: Emergency Eject
6. Emergency Eject Remove the cassette. If the cassette cannot be ejected by pressing the Return the rubber cap to its original position. EJECT button, use a screwdriver or similar tool to press and turn the EMERGENCY screw. This enables the cassette to be removed.
Page 18: Cleaning Method
7. Cleaning Method Note: Turn the power OFF during cleaning. Make sure the power is OFF before cleaning. Use ethanol (more than 99% purity) as cleaning liquid. 7-1. Cylinder Head Cleaning Method: (Daily) Clean heads by applying even pressure and rotating 7-4.
Page 19: Basic Setting Menu Operations
8. Basic Setting Menu Operations 8-1. Service Menu Operation 1. Press the “SHIFT” and “+” buttons of the Time Code Operation Button simultaneously and press the MENU button, and CAMERA unit’s SERVICE MENU screen is displayed. 2. When the MENU button is pressed again, the VTR unit’s SERVICE MENU screen is displayed. Press the “SHIFT”...
Page 20: Design Menu Operation
8-2. Design Menu Operation Press the “SHIFT” and “RESET” buttons of the Time Code Operation Button simultaneously and press the MENU button, and switch to the CAMERA unit’s SERVICE MENU screen display mode. At first “CAM MAIN MENU1” screen is displayed as shown below, but by pressing the JOG Dial button following screen through the “CAM DESIGN MENU”...
Page 21: Displaying Sub-Menus And Setting Procedures
8-3. Displaying Sub-Menus and 2. Move the cursor to the desired SUB MENU item, Setting Procedures and press the JOG Dial button. The SUB MENU is now displayed. Setting procedures are same for both the USER (The cursor appears besidce the title part of the MENU and ENGINEER MENU.
Page 22 3. Turn the JOG Dial button to move the cursor to the 7. To move to the another SUB MENU, turn the JOG desired item to be set, and press the JOG Dial Dial button to move the cursor to the title part of the button.
Page 23: Setting Menu Configurations
8-5.Setting Menu Configurations CAM SERVICE MENU SERVICE ADJ R GAMMA (SERV) G GAMMA (SERV) B GAMMA (SERV) DEFECT COMPENSATION COMPENSATION COMP ON GAIN INTERLACE MODE R CH G CH B CH TRIPLE OFFSET CURSOR BOX READ DATA WRITE DATA ENTRY (AUTO) PICKUP LEVEL R PICKUP LEVEL G PICKUP LEVEL B...
Page 24 CAM DESIGN MENU VDRIVE 1 R_0G R_SUB VDRIVE 2 R_RESET DC VA13M G_0G VA24M G_SUB G_RESET DC B_0G B_SUB B_RESET DC H1DC P16V H2DC R_PADC VSHIN G_PADC B_PADC DA RESET PREPRO 1 G_WS_OFFSET B_WS_OFFSET PREPRO 2 R_GAIN R_WS_OFFSET G_GAIN G_PRE_CLIP B_GAIN B_PRE_CLIP R_PED...
Page 25 VTR SERVICE MENU VTR SERVICE 1/3 CONCEAL INNER ECC OUTER ECC VITERBI ADJUST ADDRESS ADJUST DATA BER ADJ BER SPEED CW REC AUTO EQ RDS. REC ADJ RDS TYPE SERVO MODE VTR SERVICE 2/3 T TORQUE S TORQUE PG SHIFT 100 HSW_A_RIZE HSW_A_FALL HSW_C_RIZE...
Page 26: Service Menu Item Contents
9. Service Menu Item Contents < CAMERA Section > 9-1. CAM SERVICE MENU SETTING INIT. MEANING of SETTING & ITEM RANGE VALUE OUTLINE of FUNCTION SERVICE ADJ R GAMMA (SERV) -30-+30 Adjustment for R GAMMA. G GAMMA (SERV) -30-+30 Adjustment for G GAMMA. B GAMMA (SERV) -30-+30 Adjustment for B GAMMA.
Page 27: Cam Design Menu
9-2. CAM DESIGN MENU SETTING INIT. MEANING of SETTING & ITEM OUTLINE of FUNCTION RANGE VALUE VDRIVE 1 R_OG 00-FF OG voltage setting of R CCD. R_SUB 00-FF Sub voltage setting of R CCD. R_RESET DC 00-FF Reset DC voltage setting of R CCD. G_OG 00-FF OG voltage setting of G CCD.
Page 28 (CAM DESIGN MENU) SETTING INIT. MEANING of SETTING & ITEM RANGE VALUE OUTLINE of FUNCTION LSI REG SET1 A (0) or B (1) ----- ----- Not used MEMORY SEL ----- ----- Not used ADR_H ----- ----- Data address of Flash memory (at CAM_SYS) ADR_L ----- -----...
Page 29: Vtr Service 1/3
(CAM DESIGN MENU) SETTING INIT. MEANING of SETTING & ITEM OUTLINE of FUNCTION RANGE VALUE DSP D/A SET GAIN G ----- ----- G A/D converter input gain adjustment GAIN B ----- ----- B A/D converter input gain adjustment GAIN R ----- ----- R A/D converter input gain adjustment...
Page 30: Vtr Design Menu
9-4. VTR SERVICE 2/3 SETTING INIT. Backup MEANING of SETTING & ITEM Backup RANGE VALUE (INH.) OUTLINE of FUNCTION T TORQUE -128-+127 Take-up reel torque adjustment S TORQUE -128-+127 Supply reel torque adjustment PG SHIFT 100 ----- ----- PG shifter adjustment HSW_A_RIZE 0-4095 0x500...
Page 31: Test Mode
9-7. TEST MODE MEANING of SETTING & ITEM SETTING RANGE INIT. VALUE OUTLINE of FUNCTION ON : TEST MODE (VTR RUNNING TEST) AGING MODE OFF/ON (Repeat 5 minutes REC and 1 minute STAND-BY) 9-8. ERROR LOG MEANING of SETTING & ITEM SETTING RANGE INIT.
Page 32: Adjustment After Optical Unit Replacement
10. Adjustment after Optical Unit Replacement When replace the Optical Unit (PRE AMP, CCD 10-2. Electrical Adjustment PULSE, DRIVE Board included), execute adjustment as following procedures. Execute the Confirmation and Adjustment as following In this case, do not need to execute the Optical Unit items.
Page 33: Diag-Menu Display
11.DIAG-MENU Display 11-1-1. Version Display Operation Procedure (CAMERA Part) 1. Open the “ENG menu” (Press “MENU Button” more than 3 second.) 2. Open “CAM MAIN MENU 4” page (Press JOG Dial) 3. Select “DIAGNOSTIC” page (Turn and Press JOG Dial), then the Software version for each item can be comfirmed.
Page 34 11-2-3. How to Reset Hour Meter 1. Open the “Design Menu” and then press “MENU Button”. 2. Open “VTR DESIGN MENU” page. (Press JOG Dial) 3. Select “VTR DESIGN MENU” item. (Turn & press JOG Dial) **** VTR DESIGN MENU **** ®VTR DESIGN MENU TEST MDOE ERROR LOG...
Page 35: Error Rate Display And Confirmation Method
12. Error Rate Display and Confirmation Method 12-1. Error Rate Display Method 1. Open the “VTR SERVICE MENU”. 2. Select “VTR SERVICE 1/3” page.(Turn & press JOG Dial) 3. Confirm “BER SPEED” setting is “SLOW”. 4. Select "BER ADJ" by rotating JOG Dial and Select R/P head to be confirmed. BER ADJ item OFF / L1L3 / R1R3 / L2L4 / R2R4 (exept OFF) 5.
Page 36: Internal Switch Setting Method
13. Internal Switch Setting Method The switche settings on each circuit board are shown below. “Factory use only” switches must be set to the “Factory setting”. FACTORY BOARD Ref. No. FEATURE SETTING AUDIO LCD ON (FIXED) Factory use only SW40001 Not used OFF(FIXED) Factory use only SW40002...
Page 37: Circuit Board Layout
14. Circuit board layout E12. SERVO P.C.BOARD E9. VTR MOTHER P.C.BOARD E11. SERVO FLEX P.C.BOARD E13. HEAD BUFF P.C.BOARD E32. OPERATE P.C.BOARD E38. BACK TALLY P.C.BOARD E39. SIDE BNC P.C.BOARD E40. SDI BNC P.C.BOARD E30. REAR SW P.C.BOARD E5. CAMERA MOTHER P.C.BOARD E31.
Page 38: Pld Version Upgrade Method
15. PLD Version Upgrade Method The AJ-HDC27VP has two Programmable Logic Devices (PLD) by ALTERA Corporation on CAM_SYS P.C.Board (IC100) and VM (Video Main) P.C.Board (IC321). See following procedures for details. 15-1. Preparation Equipment Remarks VFK1590 (Interface board) CPLD WRITER VFK1590P2 (Connection cable: Supplied with VFK1590) D-sub 25pin-25pin Cable Straight type (male - female), Length must be within 1meter...
Page 39: Version-Up Procedures
15-3. Version-up Procedures 1. Boot up MAX+plus II 9.6 programmer only. 2. On main window, select tab “MAX-plus II” and then ”Programmer”. 3. On main window (Programmer window is displayed), select tab “Options” and then “Hardware Setup”. 4. On Hardware Setup dialog, set Hardware Type to “ByteBlaster (MV)”. 5.
Page 40 Click “Program button” on Programmer dialog. When Progress bar reaches at point of “100”, the message “Programming completed” appears, then PLD version upgrade is completed. Click “OK Button” on “Programming complete” message dialog. Progress bar 10. Turn the power of camcorder OFF and ON. 11.
Page 41: Flash Memory Version Upgrade Method
16. Flash Memory Version Upgrade Method The AJ-HDC27VP has Flash memories IC202 on CAM_SYS P.C.Board, IP100 on VTR_SYS P.C.Board and IC100 on ERVO P.C.Board. Version upgrade procedures for each Memory is shown below. IC 202 IP 100 P6100 P2 Connector Connector VTR_SYS P.C.B (Component side) (Component side)
Page 42: Version Upgrade For Cam_Sys P.c.board
16-1-2. Setting of VFK1304A Before executing version upgrade, Set “Cable type setting” and ”Writing function setting” on VFK1304A as shown below. If any settings are wrong, it can not communicate to PC. Cable type Writing function setting (SW1) Board setting (R1, R2, R3, R4) CAM_SYS R1 = OPEN...
Page 43 16-2-3. Software Version Upgrading 1. Copy all files in “Version up data (vvvsi file)” to arbitrary directory. (Please make a directory) 2. Type “xxxxx.bat” and then hit RETURN key. 3. Data transfer will be started from PC to camcorder. Data transferring scheme is shown below. Scheme of Flash memory writing ERASE : Data all clear on Flash memory WIRTE : Data writing to Flash memory...
Page 44: Version Upgrade For Vtr_Sys P.c.board
16-3. Version Upgrade for VTR_SYS P.C.Board 16-3-1. Connection 1. Connect RS-232C Cable between connector P2 on VFK1304A and COM1 port on PC. (Refer to Figure. 16- 2. Connect Flat cable between connector P1 on VFK1304A and connector P6100 on VTR_SYS P.C.Board, and then set SW1 on VFK1304A according to Figure.
Page 45 5. When settings on the “Setup panel” is completed, click “OK(O)” button. “VSI212E Main panel” will be opened as shown below. 6. Click “Start (S)” button on the “Main panel” window, (Click “Exit” button to quit, Click “Setup (Z) to RETURN to Setup panel”) 7.
Page 46: Version Upgrading For Servo P.c.board
16-4. Version Upgrading for SERVO P.C.Board 16-4-1. Connection 1. Connect RS-232C Cable between connector P2 on VFK1304A and COM1 port on PC. (Refer to Figure. 16- 2. Connect Flat cable between connector P1 on VFK1304A and connector P9811 on VTR MOTHER P.C.Board, and then set SW1 on VFK1304A according to Figure.
Page 47: Blemish Compensation Method
Position No. “1” 3. Close LENS Iris and then execute “ABB” by the front switch. 17-2. Connection To facilitate blemish compensation’s work, connect the camcorder and the HD TV-monitor through HD SDI output. (With 75-ohm termination.) HD-SDI Panasonic HD TV-monitor INF-38...
Page 48: Compensation Flow
17-3. Compensation flow The AJ-HDC27VP has Automatic blemish compensation function. Execution procedure of Automatic compensation is shown below. <DEFECT COMPENSATION>menu setting Execute automatic compensation “<ENTRY (AUTO)> menu” Automatic Blemish detection through compensation in whole screen. Result confirmation (at TV monitor) Fine adjustment by cursor manually.
Page 49: Compensation Procedures
17-4. Compensation Procedures 17-4-1. Initial setting (Menu setting of DEFECT COMPENSATON page) Before start an adjustment, Set items (CAM SERVICE level) following portion. ( portion , Sometimes it isn’t possible to compensate blemish (es) in case of wrong setting.) <DEFECT COMPENSATION> →...
Page 50 17-4-3. Result confirmation After execution of automatic compensation the number of detection result and the number of blemish which wasn’t compensated will be displayed in lower part of “ENTRY (AUTO)” page as the result status table. (Refer to Figure Ble-3) Please confirm whether all blemishes were compensated with this status display by viewing the TV-monitor.
Page 51 17-4-4. Manual compensation procedure In case it couldn’t compensate all blemish in automatic compensation, it is also possible to perform blemish compensation manually by using cursor. Following shows concrete manual compensation procedures by the case required. I ) Manual compensation for position which was not detected automatically 1.
Page 52 II ) When compensation is fully impossible In this case, there are two solutions by manual compensation. a ) Re-setup of PICKUP LEVEL 1. Open “<ENTRY (AUTO)>” page in CAM SERVICE level. 2. Re-Setup “PICKUP LEVEL R/ G or B” items to level down (down detection level). 3.
Page 53: Remarks
17-5. Remarks 17-5-1. Delete all cursor position data in the built-in memory 1. Open “<EDIT / DELETE>” page in CAM SERVICE level. 2. Set “ALL DATA CLEAR?” item to ON by JOG DIAL operation. 3. Set “REALY ALL CLEAR?” item to ON by JOG DIAL operation. 4.
Page 54: Trouble Shooting
17-6. Trouble Shooting Symptom Cause Check point Blemish can’t be compensated Wrong setting of fixed setting <DEFECT COMPENSATION> page has items which must have even COMPENSATION item item. fixed setting. on menu is set to “ON”. Confirm if those items are fixed as factory default. (See "4-1. Initial Setting”...
Page 55 DISASSEMBLY PROCEDURES CONTENTS 1. Disassembly Procedures.................... DIS-1 Disassembly Procedures Flowchart................DIS-1 1-1. Removal of the Cassette Cover................. DIS-1 1-2. Removal of the Left Side Panel ................. DIS-1 1-3. Removal of the Right Side Panel............... DIS-1 1-4. Removal of the Cassette-up Unit............... DIS-2 1-5.
Page 56: Disassembly Procedures
1. Disassembly Procedures DisassemblyProcedures Flowchart 1-2. Removal of theLeft Side Panel 1. After remove the Cassette Cover, loosen the 5 screws (A) and remove the Left Side Panel. 1. Removal of the Cassette Cover SCREW (A) 2. Removal of the Left Side Panel 3.
Page 57: Removal Of The Cassette-Up Unit
2. After remove the Left Side Panel, unscrew the 4 1-4. Removal of the Cassette-up screws (A) and remove the BNC Terminal Unit. Unit 1. After remove the Left Side Panel, unscrew the 4 screws (A) and remove the Cassette-up Unit. SCREW (A) 3.
Page 58: Removal Of The Cylinder Unit
4. Lift up the Mechanism Unit carefully, disconnect the 2. Unscrew the 3 screws (A) on the back side of the 2 connectors and remove the Mechanism Unit. Mechanism Unit. CONNECTOR SCREW (A) 3. Disconnect the Flexible Cable on the top side of the 1-6.
Page 59 3. Unscrew the 4 screws (A) and remove the Camera 1-7. Removal Camera Assembly. Assembly 1. Disconnect the Flexible Cable and Connector. SCREW FLEXIBLE CABLE CONNECTOR 2. Unscrew the 2 screws (A). SCREW DIS-4...
Page 60 MECHANICAL ADJUSTMENT CONTENTS 1. Name of Tape Transportation..................... MECH-1 2. Table of Test Point........................MECH-2 3. Test Point and VR Location......................MECH-3 4. Mechanical Adjustment Procedures ................... MECH-4 4-1. Post Height Pre-Adjustment..................... MECH-4 4-2. Tension Adjustment Flowchart..................MECH-4 4-3. Tension Arm Offset Adjustment ..................MECH-4 4-4.
Page 61 5-8. Pinch Solenoid Position Adjustment................. MECH-37 5-9. Pinch Arm Unit Replacement ................... MECH-37 5-10. Loading Motor Unit Replacement..................MECH-38 5-11. Mode SW Unit Replacement .................... MECH-38 5-12. Main Cam Gear Replacement..................MECH-39 5-13. Thrust Screw Replacement and Adjustment..............MECH-39 5-14. S5 Post Base Unit Replacement ..................MECH-40 5-15.
Page 62: Name Of Tape Transportation
1. Name of Tape Transportation Cylinder Unit T1 Post S1 Post T2 Post S2 Post A/C HEAD T3 Post S3 Post 21.7mm Capstan shaft S4 Post T4 Post S5 Post DVCPRO (L) :VFK1149 (Post Driver) :VFK1151 (Nut Driver) NAME LIMIT S1 Post UPPER S2 Post...
Page 63: Table Of Test Point
2. Table of Test Point <Table of Test Point> Name AJ-HDC27VP [ Reel Torque Adjustment ] S-REEL Reel output Voltage SERVO C.B.A : TP301 Adjustment Point SERVO C.B.A : VR502 T-REEL Reel output Voltage SERVO C.B.A : TP302 Adjustment Point SERVO C.B.A : VR501 SERVO C.B.A...
Page 64: Test Point And Vr Location
3. Test Point and VR Location VR401 VR402 VR950 VR503 TP102 TP103 TG300 TP301 TP503 VR501 TP302 TP504 VR502 TP501 TP601 VR503 TP502 TP602 TP113 TP402 TP114 TP901 MECH-3...
Page 65: Mechanical Adjustment Procedures
4. Mechanical Adjustment Procedures 4-1. Post Height Pre-adjustment 4-2. Tension Adjustment Flowchart MODE EJECT (POWER OFF) TOOL VFK1149 or VFK1149A (Post Driver) START VFK1151 (2.5mm Nut Driver) VFK1154 (Post Height Fixture) 4-3. Tension Arm Offset Adjustment Confirm that the post is in unloading condition. Confirm that the Reel Table is located at M- Cassette position.
Page 66: Tension Arm Neutral Position Adjustment
4-4. Tension Arm Neutral Position Adjustment SPEC 2.5 V ± 0.1 V TEST POINT Tension: TP402 ADJ. Base position of Tension Regulator Board MODE STOP TOOL Digital Volt Meter VFK1208 (black with hole) NOTE: Do not use magnetized tweezers and Screw Driver.
Page 67: Tension Arm Play And Rev Voltage Adjustment And Confirmation
4-5. Tension Arm PLAY and REV 4-6. Tension Regulator Spring Voltage Adjustment and Adjustment Confirmation SPEC 110 ± 10 mN-m (11 ± 1gf) TEST POINT Tension: TP402 SPEC PLAY : 3.8 V ± 0.05 V ADJ. Tension Regulator Spring hook (B) REV : 1.2 V ±...
Page 68: Rev Tension Confirmation
4-7. REV Tension Confirmation SPEC 180mN ± 20mN (18gf ± 2gf) TEST POINT Tension: TP402 MODE STOP TOOL VFK1188A (Dial Tension Gauge) Digital Volt Meter Remove the Cassette Up Unit. Place the VTR into no tape loading mode. Push the tension post to the direction R by the tension gauge as shown in Figure 4-7 until the voltage at the test point becomes 1.2V (If means REV position).
Page 69: Tension Confirmation
Play back the beginning portion of the tape. 4-8. Tension Confirmation Insert the tension meter between S3 post and S4 post as shown in figure 4-8-2. SPEC PLAY: 0.06N ± 0.01N (6gf ± 1gf) Confirm that the tension value is within the REV: 0.09N ±...
Page 70: Photo Sensor Voltage Adjustment
4-9. Photo Sensor Voltage Adjustment SPEC 3.2 VDC ± 0.8 VDC TEST POINT S-Reel: TP301 T-Reel: TP302 ADJ. VR503: S-Reel VR501: T-Reel MODE STOP TAPE VFK1423 (Tape Beg./End M Cassette) VFK1369 (Tape Beg./End L Cassette) M. EQ Oscilloscope Insert the VFK1423 or VFK1369 (For only L- Cassette playback models) and measure the voltage at the test point.
Page 71: Tape Path Adjustment Procedure
4-10.Tape Path Adjustment Procedure START Each Post Limit Conf. and A/C Head Adj. 4-11. Envelope Waveform Adj. 4-22. PLAY Tape Path Limit Conf. 4-12. Post Limit Confirmation (PLAY) S4 Post Conf. 4-23. Conf. of ENV on 4-14. A/C Head Tilt Adjustment REV/REW FF mode 4-15.
Page 72: Envelope Waveform Adjustment
[ Adjustment Procedure ] 4-11. Envelope Waveform 1. Adjust both channels envelope by connecting the Adjustment test point Lch and Rch alternately. 2. Playback the alignment tape. V1/Vmax, V2/Vmax, V3/Vmax ≥ 0.8 SPEC 3. Adjust S1 and T1 post height so that the envelope signal is within the specification.
Page 73 4-12. Post Limit Confirmation (PLAY) Post limit is shown in the following table. SPEC Curl does not appear on tape edge MODE PLAY TAPE Blank tape TOOL VFK1149 or VFK1149A (Post Driver) VFK1151 (Nut Driver) 1. Confirm that the tape path limit meets specification in following table.
Page 74: A/C Head Adjustment
4-13. A/C Head Adjustment Adjustment SCREW Adjustment Method Torque item !. Adjust screw A after loosen screw G. Tilt adjustment Tighten direction : Decrease Cue level Loosen direction : Increase Cue level None ". Tighten screw G after finish adjustment screw A. (refer to following item “Azimuth adjustment &...
Page 75 1. For Tilt and Azimuth adjustment, loosen the screw Confirm the screw (A) isn’t loose, before perform A/C (G) first and tighten the screw (G) after finish Head Tilt adjustment. The screw (A) should be always adjustment. And if need to turn the screw (A) and touch to top of A/C Head.
Page 76: A/C Head Tilt Adjustment
4-14. A/C Head Tilt Adjustment 4-15. A/C Head Height Adjustment C1, C2 ³ 1.6V SPEC SPEC Curl does not appear on tape edge. Lower limit at T3 post TEST CUE AUDIO: TP4 ADJ. POINT SCREW A, G (A/C Head) CTL: TP901 MODE PLAY ADJ.
Page 77: A/C Head Tilt Confirmation
4-16.A/C Head Tilt Confirmation 4-17.A/C Head Height Confirmation A/Amax ³ 0.8 SPEC TEST C1, C2 ³ 1.6V CUE AUDIO: TP4 SPEC POINT TEST CUE AUDIO: TP4 ADJ. SCREW A, G (A/C Head) POINT CTL: TP901 MODE PLAY ADJ. SCREW B, H (A/C Head) TAPE VFM3580KM or VFM3580KL MODE...
Page 78 4-18.A/C Head Azimuth and X Value Adjustment SPEC As shown in figure below TEST R/P-ENV L13: TP400 R/P-HSW L13: TP500 POINT R/P-ENV R13: TP401 R/P-HSW R13: TP501 -250µs £ t1, t2 £ +250µs R/P-ENV L24: TP402 R/P-HSW L24: TP502 R/P-ENV R24: TP403 R/P-HSW R24: TP503 CUE: TP4 CTL: TP901...
Page 79 4-19.REV Tape Path Confirmation and Adjustment (T4 Post Height Adjustment) •. C1, C2 ³ Cp1, Cp2´0.75 SPEC NOTE: C1, C2: CTL output REV (-1) mode A: UPPER B: FREE C: LOWER Cp1, Cp2: CTL output PLAY (+1) mode. ‚. Lower limit at T3 post on REV mode. ƒ.
Page 80: A/C Head Height Confirmation
4-20. REV (-1) Mode Setting Procedure Set the VTR to STILL mode by press “PLAY” button twice. Press “PLAY” “RESET” button simultaneously. NOTE: Above setting only apply to item “REV Tape Pass Confimation and Adjustment (T4 post height adjustment)”. All models should be set to 25M mode with REV (-1) speed playback.
Page 81: Play Tape Path Limit Confirmation
4-22.Play Tape Path Limit Confirmation SPEC Each post limit shown in figure below. MODE PLAY TAPE VFM3580KM/L or Blank Tape Tape limit (refer to figure) Adjustment Adjustment Post Name Point Item S5 post S4, S5 post Post Height Pre-Adjustment S4 (Tension) post S1 post S1, T1 post ENV Waveform Adjustment...
Page 82: Confirmation Of Play Start Envelope
4-24. Confirmation of Play Start Envelope SPEC Envelope Waveform signal should be rising up immediately at PLAY mode. TEST POINT TP400: R/P-ENV L13 TP402: R/P-ENV L24 TP401: R/P-ENV R13 TP403: R/P-ENV R24 REW/REV ® PLAY FF® Loading completion ® PLAY MODE TAPE L Cassette (123min, Recorded tape) Tape beginning portion...
Page 83: Ff, Rew Mode Tape Path Limit Confirmation
4-26.FF, REW mode Tape Path Limit 4-27.Screw Lock Tight of A/C Head Confirmation and T3, T4 Post <Screw Lock Tight of A/C Head> SCREW A OTHER SPEC Each post limit shown in below figure SCREWS MODE FF, REW Lock Tight Grew 1/3 of the 1/3 of the TAPE...
Page 84: Lista Adjustment Procedures
4-29. LISTA Adjustment Procedure NOTE : 1. Refer to the item “4-32. LISTA Sensitivity Adjustment and Sensitivity Detection” about procedure of the sensitivity adjustment and sensitivity detection. 2. Refer to the item “4-33. LISTA Linearity Adjustment and Waving Measurement” about procedure of the linearity adjustment.
Page 85: Lista Connection And Boot Up
4-30. LISTA Connection and Boot Up TEST ATF ERR L13: TP601 POINT ATF ERR L24: TP602 R/P-HSW L13: TP113 R/P-HSW L24: TP114 M. EQ. PC (Personal Computer) (A/D board should be installed) TAPE VFM3581KM or VFM3581KL (LISTA) TOOL VFK1481B (LISTA Software), VFK1186 (LISTA Cable) 1.
Page 86 6. Next, select the Serial number of the Alignment tape on the screen. If LISTA software does not have alignment tape data registered, data entry is needed. Press the ESC key, then main menu is displayed on the screen. And select the item “<4>...
Page 87: How To Entry The Attachment Data Of Alignment Tape
4-31. How to Entry the Attachment Data of Alignment Tape 1. Select the item “<4> Alignment Tape” on the LISTA main menu. 2. Select the item “<2> ENTRY” on the alignment menu. 3. After the screen of <<Alignment Tape Data Entry>>is displayed, first input the Serial Number of Alignment tape printed on the label.
Page 88: Lista Sensitivity Adjustment And Sensitivity Detection
4-32. LISTA Sensitivity Adjustment and Sensitivity Detection TEST POINT ATF ERR L13: TP601 ATF ERR L24: TP602 R/P-HSW L13: TP113 R/P-HSW L24: TP114 TG300 VTR MODE PLAY ADJ. MODE RPL GAIN 100 150 ± 15 mV/um ADJUST (ATF GAIN) TAPE VFM3581KL (LISTA) Sensitivity Adjustment Procedure 1.
Page 89 Sensitivity Detection Procedures 1. Set the adjustment mode. (Refer to [LISTA Adjustment Modes] of the “Table of Test Point”.) 2. Playback the LISTA Alignment Tape. 3. Select the item “<1> Sensitivity Measurement” on the LISTA main menu, and then “1.2% Speed. . .” appears on the screen.
Page 90: Lista Linearity Adjustment And Waving Measurement
4-33. LISTA Linearity Adjustment and Waving Measurement SPEC. Linearity: less than 3um, Waving: less than 1.5um TEST POINT ATF ERR L13: TP601 ATF ERR L24: TP602 R/P-FSW L13: TP113 R/P-HSW L24: TP114 TG300 VTR MODE PLAY ADJ. MODE ADJUST S1 and T1 Post Height TOOL VFK1149 or VFK1149A (Post Driver) TAPE...
Page 91 POINT : The part of left side of waveform (entrance side) is adjusted by height of S1 post and part of right side of waveform (exit side) is adjusted by height of T1 post. Lower part of above waveform of figure is displayed lead of Cylinder. When the post driver is removed from upper part of post, linearity waveform may be changed.
Page 92: Self-Rec/Play Envelope Waveform Confirmation
4-34. Self-REC/PLAY Envelope Waveform Confirmation All of the head output are within the specification as shown below. Confirm in the 50M mode when the VTR or Camera Recorder is 50M models. × When using the M Cassette (66 min.) or L Cassette (126 min.) SPEC.
Page 93: Major Mechanical Parts Replacement & Adjustment Procedures
5. Major Mechanical Parts Replacement & Adjustment Procedures When mechanical parts are replaced, pay attention to the following notes. 1. Always turn power off before replacing any parts. 2. If any adjustment is required after replacing parts, perform the required adjustment. 3.
Page 94: Cleaning Arm Unit Replacement
5-2. Cleaning Arm Unit 5-3. T1 Guide Position Adjustment Replacement 1. Place the unit to loading condition without the tape. (Removal) 2. Observe the clearance (B) between T1 Guide and 1. Unscrew the 2 screws (A) and remove the T1 T1 post as shown in Figure 5-3, and make sure Guide as shown in Figure 5-2.
Page 95: Adjustment Flow Chart After Cylinder Unit Replacement
5-4. Adjustment Flow Chart After Cylinder Unit Replacement After change the Cylinder Unit, please perform the adjustment and confirmation as following flow chart. 4-28. Tape Damage Confirmation (Long Play Type) START Mechanical Adjustment (Section 4) Note: Envelope level Adjustment 4-8. Tension Confirmation Note: PG Shifter Adjustment 4-11.
Page 96: Supply & Take-Up Reel Rotor Unit Replacement
5-5. Supply & Take-up Reel Rotor Unit Replacement <Supply Reel Rotor Unit Replacement> <Take Up Reel Rotor Unit Replacement> (Removal) (Removal) Disconnect the connector P2614 on the Disconnect the connector P2615 on the Servo Servo P.C.Board. P.C.Board. Turn the Emergency Gear until S1 Post move Unscrews the 2 screws (E) and then remove to center loading position and remove the S5 the Take Up Reel Stopper.
Page 97: Main Brake Torque Confirmation
5-6. Main Brake Torque 5-7. Pinch Solenoid Replacement Confirmation (Removal) S Reel, T Reel TEST Remove the Cassette Cover, both Side Panel, MODE EJECT (Power OFF) Cassette Up Unit and open the VTR MAIN. TOOL Torque Gauge (VFK71A, VFK1191A) Disconnect the connector P610 on the Servo Torque Gauge Adapter (VFK1152) P.C.Board.
Page 98: Pinch Solenoid Position Adjustment
5-8. Pinch Solenoid Position 5-9. Pinch Arm Unit Replacement Adjustment (Removal) SPEC. T = 0.3 mm Refer to item “5-7.Pinch Solenoid Replacement” TEST Gap T to remove the Pinch Solenoid Unit. ADJUST Remove the cut washer (A) and remove the Pinch Screw (A) and Hole (B) Solenoid Lever as shown in Figure 5-9.
Page 99: Loading Motor Unit Replacement
5-10. Loading Motor Unit 5-11. Mode SW Unit Replacement Replacement (Removal) Disconnect the connector P612 on the Servo (Removal) P.C.Board (B). Disconnect the connector P611 on the Servo Remove the Pinch Solenoid Unit and Loading P.C.Board. Motor Unit. (Refer to item 5-7 and 5-10.) Remove the Pinch Solenoid Unit.
Page 100: Main Cam Gear Replacement
5-12. Main Cam Gear Replacement 5-13. Thrust Screw Replacement and Adjustment (Removal) Remove the Thrust Adjustment Screw. Remove the Pinch Solenoid Unit and Loading Clean the capstan shaft with an applicator. Motor Unit. (Refer to item 5-8 and 5-10.) Put the oil (VFK0906) on a new Thrust Remove the Main Cam Gear as shown in Figure Adjustment Screw and install the upper end of the 5-12.
Page 101: S5 Post Base Unit Replacement
5-14. S5 Post Base Unit Replacement (Removal) Unscrew the screw (A) and remove the S5 Post Base Unit as shown in Figure 5-14. (Installation) Install the S5 post Base Unit follow the removal steps in reverse order. Note: Be careful the S5 Post Base Unit is installed to mech.
Page 102: Tension Arm Unit Replacement
5-15. Tension Arm Unit <Tension Arm Adjustment Flow Chart> Replacement (Removal) START Remove the Cut Washer (A) and hang off the Tension Regulator Spring, and then remove the Tension Arm Unit as shown in Figure 5-15. (Installation) 4-3. Tension Arm Offset Voltage Adjustment Install the new Tension Arm Unit following the removal steps in reveres order.
Page 103: S1 Post Loading Arm Unit Replacement & Adjustment
5-16. S1 Post Loading Arm Unit (Installation) Replacement & Adjustment Install the new S1 Loading Arm Unit following the removal steps in reverse order, and then S1 Post (Removal) Loading Arm Unit Phase Adjustment should be Remove the S5 Post Base Unit. (Refer to item 5- performed as follows.
Page 104: T1 Boat Unit Replacement And Adjustment
5-17. T1 Boat Unit Replacement (Confirmation and Adjustment Procedure) and Adjustment Tool : T Arm Height Adj. Tool A (VFK1542) T Arm Height Adj. Tool B (VFK1543) (Removal) T1 boat replacing procedure Unscrew the screw (C) and remove the T1 Post Turn clockwise emergency red screw and set from Loading Rail as shown in Figure 5-16 on the the hole of T1 Boat Unit to match line of take up side...
Page 105 (2) Checking smooth movement of T1 Boat Unit. Check X-Value. Check smooth loading and unloading operations. If not smooth (especially, at curve of rail), take the following steps. Check deformation of T1 boat joint. If no deformation, then reposition the loading rail as describe below.
Page 106: T1 Loading Arm Unit Replacement & Adjustment
5-18. T1 Loading Arm Unit 5-19. A/C head Replacement Replacement & Adjustment & Adjustment (Removal) <Tools required> Remove the cylinder Unit. (Refer to item 1-1) Nut Driver (5.5mm: VFK1150) Move the T1 Post to loading direction by manual Hex Driver (VFK1148) ejecting method until the screw (D) can be Hex Wrench (VFK1190) removal position as shown in Figure 5-16.
Page 107 Remove the 2 screws (A) and disconnect the 2 (Installation) connector on the REAR JACK P.C.Board and Remove the Shield Case from the New A/C Head SERVO P.C.Board, and then remove the A/C and solder the lead wires to New A/C Head. Head from the A/C Head Plate as shown in Figure (Refer to Figure 5-19-3) 5-19-2.
Page 108 <A/C Head Adjustment> After change the A/C Head, please perform the following steps. START 4-14. A/C Head Tilt Adjustment 4-15. A/C Head Height Adjustment 4-18. A/C Head Azimuth & X-value Adjustment NOTE: PG Shifter Adjustment 4-29. to 4-33. LISTA Adjustment 4-34.
Page 109: Cleaner Solenoid Replacement & Adjustment
5-20. Cleaner Solenoid 5-20-1. Cleaner Solenoid Position Replacement & Adjustment Adjustment <Tools required> (Removal) Eccentric Driver (VFK0357) Disconnect the connector P618 on the SERVO P.C.Board. Press the iron core of Cleaner Solenoid. Unscrew the 2 screws (A) and remove the Observe the clearance (D) between Cleaning Arm Cleaner Solenoid Unit as shown in Figure 5-20-1.
Page 110: Mic Bas Unit Replacement
5-21. MIC Base Unit Replacement (Removal) Disconnect the connector P607 on the Servo P.C.Board. Unscrew the 2 screws (A) and remove the MIC Base Unit as shown in Figure 5-21. (Installation) Install the new MIC Base Unit according to the opposite procedures of removing.
Page 111 ELECTRICAL ADJUSTMENT CONTENTS 1. OPTICAL UNIT............ELE-1 6. SERVO ..............ELE-16 1-1. Initial Setting ..........ELE-1 6-1. T and S Reel Torque Offset Adjustment ... ELE-16 1-2. R, G, B RESET DC Adjustment....ELE-1 6-2. Adjustment of the Tape Beginning 1-3.
Page 112: Optical Unit
< CAMERA > 1. OPTICAL UNIT 1-1. Initial Setting 1-2. R, G, B RESET DC Adjustment Unless otherwise specified, implement the adjustment BOARD ----- of the optical unit by the following setting. SDI OUT (G,B,R) 75ohm termination ADJUST Service Menu F NUMBER F5.6 <...
Page 113: R, G, B Response Confirmation
1-3. R, G, B Response 1-4. H1DC Adjustment Confirmation BOARD ----- SDI OUT (G,B,R) 75ohm termination BOARD ----- ADJUST Service Menu SDI OUT (G,B,R) 75ohm termination F NUMBER F11-1/2 (2000LUX) ADJUST Service Menu MODE ----- F NUMBER OPEN (2000LUX) CHART Gray Scale Chart MODE -----...
Page 114: R, G, B Pre Amp Dc Adjustment
1-5. R, G, B PRE AMP DC 1-6 R, G, B PREPRO Level Adjustment Adjustment BOARD BOARD PRE AMP PRE PROCESS (Use the Extender Board) TP102: R DC TP102: R LEV TP202: G DC TP202: G LEV TP302: B DC TP302: B LEV ADJUST ADJUST...
Page 115: R, G, B Sub Adjustment
1-7. R, G, B SUB Adjustment BOARD PRE AMP IRIS = F11-1/2 TP102: R TP302: B TP202: G ADJUST Service Menu F NUMBER ----- MODE ----- CHART Gray Scale Chart M. EQ SPEC. As shown below < Switch Setting > AUTO W/B BAL : AWB, ABB IRIS = OPEN...
Page 116: Camera Main Unit
2. CAMERA MAIN UNIT 1. Set the TEST SAW to “ON". 2. Set the MASTER PED to “0". 2-1. Initial setting 3. Adjust R, G, B PEDESTAL so that the step A is within the specification at the each test point. Unless otherwise specified, implement the adjustment of the optical unit by the following setting.
Page 117: R, G, B Ad Level Adjustment
2-4. R, G, B AD Level Adjustment 2-5. R, G, B Pre Knee-point Adjustment BOARD DSP 3 SDI OUT 75ohm termination BOARD PRE PROCESS ADJUST Service Menu SDI OUT 75ohm termination F NUMBER ----- ADJUST Service Menu MODE TEST Mode F NUMBER CLOSE CHART...
Page 118: Ire Ped Adjustment
2-6. 0 IRE PED Adjustment 2-7. R, G, B PRE AMP DC Adjustment BOARD ----- SDI OUT 75ohm termination BOARD PRE AMP, PRE PROCESS ADJUST Service Menu TP100: R DC [PRE PROCESS] F NUMBER CLOSE TP200: G DC [PRE PROCESS] MODE ----- TP300: B DC [PRE PROCESS]...
Page 119: R, G, B Prepro Level Adjustment (Coarse)
2-8. R, G, B PREPRO Level 2-9. R, G, B PED TRACK Adjustment (COARSE) Adjustment BOARD BOARD PRE PROCESS (Use Extender board) PRE PROCESS TP102: R LEV [PRE PROCESS] SDI OUT 75ohm termination TP202: G LEV [PRE PROCESS] ADJUST VR404: R TRACK TP302: B LEV [PRE PROCESS] VR405: B TRACK, and Service Menu ADJUST...
Page 120: R, G, B Prepro Level Adjustment (Fine)
2-10. R, G, B PREPRO Level 2-11. Confirmation of the Adjustment (FINE) Modulation Factor BOARD BOARD PRE PROCESS (Use Extender board) ----- TP102: R LEV [PRE PROCESS] SDI OUT (Y OUT) 75ohm termination TP202: G LEV [PRE PROCESS] ADJUST Service Menu TP302: B LEV [PRE PROCESS] F NUMBER F5.6...
Page 121: R, G, B W/S Offset Adjustment (1)
2-12. R, G, B W/S Offset 2-13. R, G, B W/S Offset Adjustment (1) Adjustment (2) BOARD BOARD ----- ----- SDI OUT 75ohm termination SDI OUT 75ohm termination ADJUST ADJUST Service Menu Service Menu F NUMBER F NUMBER ----- CLOSE MODE ----- MODE...
Page 122: R, G, B W/S Offset Adjustment (3)
2-14. R, G, B W/S Offset 2-15. R, G, B W/S Offset Adjustment (3) Adjustment (4) BOARD BOARD ----- ----- SDI OUT 75ohm termination SDI OUT 75ohm termination ADJUST ADJUST Service Menu Service Menu F NUMBER F NUMBER CLOSE CLOSE MODE ----- MODE...
Page 123: Digital White Shading Adjustment
2-16. Digital White Shading 2-17. Digital Dark Shading Adjustment Adjustment BOARD BOARD ----- ----- SDI OUT 75ohm termination SDI OUT 75ohm termination ADJUST ADJUST Service Menu Service Menu F NUMBER F NUMBER ----- CLOSE MODE ----- M. EQ The color monitor TV, WFM, the vector scope CHART Special Light Box (Spherical Type)
Page 124: Flare Adjustment
2-18. Flare Adjustment 2-19. R, B GAMMA Adjustment BOARD ----- BOARD PRE PROCESS SDI OUT 75ohm termination SDI OUT 75ohm termination ADJUST ADJUST Service Menu Service Menu F NUMBER As shown below VR101 : R LEV [PRE PROCESS] VR501 : B LEV [PRE PROCESS] MODE ----- F NUMBER...
Page 125: Nd Compensation Adjustment
the vector dots are within the specification. 2-20. ND Compensation 12. Set the ND filter as follows. Adjustment ND Filter: 4 13. Adjust iris so that the white level of the signal is BOARD ----- 60%. SDI OUT 75 ohm termination 14.
Page 126: Video Out
3. VIDEO OUT 3-1. VF Y Output Adjustment 3-3. VTR Playback Output Level Adjustment BOARD VODEO OUT TP14 (VIDEO OUT) ADJUST BOARD VIDEO OUT F NUMBER ----- TP14 MODE ----- ADJUST CHART ----- F NUMBER ----- M. EQ Oscilloscope MODE ----- SPEC.
Page 127: Vtr Syscon
< VTR > 6. SERVO 4. VTR SYSCON 6-1. T and S Reel Torque Offset 4-1. Initial Setting of DIP SW Adjustment (Release Data Saving Prohibition) BOARD SERVO 1. Turn OFF the power supply of main unit and set TP302 (T Reel), TP301 (S Reel), TG300 the DIP SW on the VTR SYSCON P.C.Board as (GND) shown below.
Page 128: Adjustment Of The Tape Beginning And End Detection Sensitivity
6-2. Adjustment of the 6-4. PG Shifter Adjustment Tape Beginning and End and Confirmation Detection Sensitivity BOARD SERVO TP113 (HSW A), TP102 (SPA A), BOARD SERVO TP114 (HSW C), TP103 (SPA C) TP503 : Vs, TP504 : Vt ADJUST SERVICE MENU : PG SHIFT 100 ADJUST VR503 : S PHOTO, VR504 : T PHOTO INPUT...
Page 129: Rf Eq
7. RF EQ 7-1. DRC Input Level Adjustment 7-2. ATF Input Level Adjustment BOARD RFEQ BOARD RFEQ TP401, TP403, TP405, TP407, TP400, TP402, TP404, TP406, TP660 (Trigger) TP660 (Trigger) ADJUST VR401, VR403, VR405, VR407 ADJUST VR400, VR402, VR404, VR406 INPUT Internal Color Bar INPUT Internal Color Bar...
Page 130: Hse Input Adjustment
7-3. HSE Input Adjustment 7-4. PLAY Error Rate Confirmation (Manual Adjustment) BOARD RFEQ TP820, TP821, TP822, TP823, BOARD RFEQ TP660 (Trigger) ADJUST VR820, VR821, VR822, VR823 INPUT Internal Color Bar INPUT Internal Color Bar MODE PLAY MODE TAPE Alignment Tape (VFM3580KL) TAPE Blank Tape M.
Page 131: Rec Signal Detection System Position Adjustment
7-5. REC Signal Detection System 7-6. REC Signal Detection System Position Adjustment Level Adjustment BOARD RFEQ BOARD RFEQ IC104-5PIN, TP102 TP100, TP102 ADJUST VR108 Trigger (TP660 : L1L3, TP661 : R1R3, TP662 : L2L4, TP663 : R2R4) INPUT Internal Color Bar ADJUST VR101 : L1, VR100 : L3, VR103 : R1, MODE...
Page 132 < Adjustment of the R1R3 Head > < Adjustment of the R2R4 Head > 1. Connect the Oscilloscope to TP100, TP102 and 1. Connect the Oscilloscope to TP100, TP102 and TP660 (trigger). TP660 (trigger). 2. Switch the item RDS. REC ADJ to "R1". 2.
Page 133: Rec Signal Detection System Operation Confirmation
< Detection Confirmation at SHORT PLAY Mode > 7-7. REC Signal Detection System 1. Open the SERVICE MENU and set the RDS TYPE Operation Confirmation to “S PLAY". 2. Perform confirmation by steps 1 to 8 of the BOARD RFEQ "Detection Confirmation at REC Mode".
Page 134: Audio Lcd
< AUDIO > 8. AUDIO LCD 8-1. Initial Setting 8-2. Real Time Clock Adjustment < Side Switch Setting > MONITOR SELECT : 1/2, ST BOARD AUDIO LCD AUDIO SELECT (CH1/2) : MAN TP62007 (RTC TP) AUDIO IN (CH1/2) : REAR ADJUST VC62001 : CH1...
Page 135: Audio Level Meter Adjustment
8-4. Audio Level Meter Adjustment 8-6. CUE REC level adjustment BOARD AUDIO LCD BOARD AUDIO LCD TP46001 : CH1, TP46002 : CH2 TP48001 ADJUST VR46001 : CH1, VR46002 : CH2 ADJUST VR48001 INPUT +4dBu, 1kHz (REAR CH1/2) INPUT +4dBu, 1kHz (REAR CH1/CH2) MODE STOP MODE...
Page 136: Tp, Vr And Sw Location
9. TP, VR and SW Location AUDIO LCD P.C.BOARD (VEP84331B) (COMPONENT SIDE) (FOIL SIDE) ELE-25...
Page 137: Video Out P.c.board (Vep23500B)
VIDEO OUT P.C.BOARD (VEP23500B) (COMPONENT SIDE) VTR SYSCON P.C.BOARD (VEP86303C) (FOIL SIDE) ELE-26...
Page 138: Servo P.c.board (Vep82224B)
SERVO P.C.BOARD (VEP82224B) (COMPONENT SIDE) (FOIL SIDE) ELE-27...
Page 139: Video Main P.c.board (Vep83462C)
VIDEO MAIN P.C.BOARD (VEP83462C) (COMPONENT SIDE) (FOIL SIDE) ELE-28...
Page 140: Dsp Main P.c.board (Vep23530B)
DSP MAIN P.C.BOARD (VEP23530B) (COMPONENT SIDE) (FOIL SIDE) ELE-29...
Page 141: Vtr Mother P.c.board (Vep80B10A)
VTR MOTHER P.C.BOARD (VEP80B10A) (COMPONENT SIDE) RF EQ P.C.BOARD (VEP87104B) (COMPONENT SIDE) ELE-30...
Page 142: Cue P.c.board (Vep84353A)
CUE P.C.BOARD (VEP84353A) (COMPONENT SIDE) (FOIL SIDE) PRE PROCESS P.C.BOARD (VEP23534B) (COMPONENT SIDE) (FOIL SIDE) ELE-31...
Page 143: Hd Sdi Tx P.c.board (Vep83460B)
HD SDI TX P.C.BOARD (VEP83460B) (COMPONENT SIDE) PRE AMP P.C.BOARD (VEP20857A) REAR SW P.C.BOARD (VEP80B45A) (COMPONENT SIDE) (COMPONENT SIDE) CAMERA SYSCON P.C.BOARD (VEP26234C) (FOIL SIDE) ELE-32...
Page 144 HEAD BUFF P.C.BOARD (VEP85179B) SD CARD P.C.BOARD (VEP23532A) MEMORY P.C.BOARD (VEP23531B) (COMPONENT SIDE) (COMPONENT SIDE) ELE-33...
Page 145 BLOCK DIAGRAMS CONTENTS OVERALL BLOCK DIAGRAM ..................BLK-1 CCD SENSOR/TG (CCD PULSE)/DRIVE BLOCK DIAGRAM ........BLK-2 PRE PROCESS/PRE AMP BLOCK DIAGRAM ............BLK-3 DSP MAIN/MEMORY BLOCK DIAGRAM ..............BLK-4 VIDEO OUT BLOCK DIAGRAM .................BLK-5 HD BUFFER BLOCK DIAGRAM ................BLK-6 RF EQ BLOCK DIAGRAM ..................BLK-7 HD SDI TX/VIDEO MAIN BLOCK DIAGRAM .............BLK-8 AUDIO LCD/CUE BLOCK DIAGRAM.................BLK-9 SERVO BLOCK DIAGRAM ..................BLK-10...
Page 146: Overall Block Diagram
OVERALL BLOCK DIAGRAM DSP MAIN P.C.BOARD CCD SENSOR PRE AMP P.C.BOARD PRE PROCESS P.C.BOARD VIDEO MAIN P.C.BOARD RF EQ P.C.BOARD H BUFF. P.C.BOARD P.C.BOARD MEMORY P.C.B R,G,B 10bit COMP L Ch HSE A BLACK/ FRAME BLEMISH COMP. REC/PB SAMPLE R,G,B R,G,B GAIN WHITE...
Page 147: Ccd Sensor/Tg (Ccd Pulse)/Drive Block Diagram
CCD SENSOR/TG (CCD PULSE)/DRIVE BLOCK DAIGRAM IC22 READY (CCD PULSE) IC19 CCD DRIVE PULSE GENERATOP V-CCD PULSE GEN. DRIVE MEMORY DCLK D GND H CLR TD 0 CHARGE CONNECT PULSE GEN. IC16 DATA HCLR TD 1 BUFFER OBCP D GND IC20 OPTICAL BLACK...
Page 148: Pre Process/Pre Amp Block Diagram
PRE PROCESS/PRE AMP BLOCK DIAGRAM TP100 <1> P1 P1 Q105,106,107 TP102 <1> Q104 IC108 <1> DSP MAIN R ADS Q103 <1> Q109 VR404 IC115 <1> -6dB Q108 <1> Q109 <1> <1> R PED 24dB 12dB TRACK TP200 <2> IC201 <2> IC202 <2>...
Page 149: Dsp Main/Memory Block Diagram
DSP MAIN/MEMORY BLOCK DIAGRAM DSP MAIN IC509<4> IC521<4> IC522<4> IC523<4> MEMORY IC1-6<1> IC9<1> IC1-6<1> P101 P101 VIDEO GLHD 1 2-11 ROAD 0-9 2A-11A 2B-11B ROLSI 0-9 82-91 FRAME MEMORY 1 12-21 READ 0-9 12A-21A 23-32 GOAD 0-9 23A-32A 23B-32B GOLSI 0-9 103-112 IC8<1>...
Page 150: Video Out Block Diagram
VIDEO OUT BLOCK DIAGRAM TERMINAL (20pin) EE/PB-RET DSP MAIN EE-PB SELECT SELECT DSP MAIN IC29<1> VC0-CONL DSP MAIN DSP MAIN...
Page 151: Hd Buffer Block Diagram
HEAD BUFFER BLOCK DIAGRAM...
Page 152: Rf Eq Block Diagram
RF EQ BLOCK DIAGRAM...
Page 153: Hd Sdi Tx/Video Main Block Diagram
HD SDI TX/VIDEO MAIN BLOCK DIAGRAM DSP MAIN DSP MAIN DSP MAIN DSP MAIN HD SDI TX...
Page 154: Audio Lcd/Cue Block Diagram
AUDIO LCD/CUE BLOCK DIAGRAM DF SLAVE TCG HOLD EMPHASIS TAPE BATT RF SERVO HUMID SLACK...
Page 155: Servo Block Diagram
SERVO BLOCK DIAGRAM...
Page 156: Camera Syscon Block Diagram
CAMERA SYSCON BLOCK DIAGRAM GLVD UDSP RSV1 DSP MAIN IC300 NOT USED IC100 VBLKM LENS CONNECTOR IC304 CARD S3 CARD S1 CARD S2 CARD S3 CARD SENS SD CARD BORD CARD CS CARD RDAT CARD WDAT CARD CLK DSP MAIN PROCESS ECU CONNECTOR IC305...
Page 157: Vtr Syscon/Sd Card Block Diagram
VTR SYSCON/SD CARD BLOCK DIAGRAM USED USED SD CARD...
Page 158: Power Main/Sub Block Diagram
POWER MAIN/SUB BLOCK DIAGRAM...
Page 159 SCHEMATIC DIAGRAMS NOTE: BE SURE TO MAKE YOUR ORDERS OF REPLACEMENT PARTS ACCORDING TO PARTS LIST, SECTION 8...
Page 160 CONTENTS CAM SYS (4/6)........SCM032 OVERALL CAM SYS (5/6)........SCM033 CAM OVERALL (1/1)......SCM001 CAM SYS (6/6)........SCM034 VTR OVERALL (1/1)......SCM002 VIDEO OUT VIDEO OUT (1/3) ........SCM035 CAMERA MOTHER VIDEO OUT (2/3) ........SCM036 CAMERA MOTHER (1/1) ...... SCM003 VIDEO OUT (3/3) ........
Page 161 VM (SYNC CLK) (8/11) ......SCM079 SERVO FLEX VM (CLOCK DIST) (9/11).......SCM080 SERVO FLEX (1/1) ........ SCM116 VM (CONNECTOR) (10/11) ....SCM081 VM (POWER) (11/11)......SCM082 HD SDI TX HD SDI TX (1/2)........SCM117 VTR SYSCON HD SDI TX (2/2)........SCM118 VTR SYSCON (1/8)........SCM083 VTR SYSCON (2/8)........SCM084 SD CARD VTR SYSCON (3/8)........SCM085...
Page 163 COMPONENT CAM OVERALL 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR9H41 (1/1) SCM001...
Page 165 COMPONENT VTR OVERALL 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR9H41 (1/1) SCM002...
Page 166 COMPONENT CAMERA MOTHER 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N32 (1/1)-1 VEP000G7B SCM003...
Page 167 COMPONENT VTR MOTHER 01/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M54 (1/3) VEP80B10A SCM004...
Page 168 COMPONENT VTR MOTHER 02/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M54 (2/3) VEP80B10A SCM005...
Page 169 COMPONENT VTR MOTHER 03/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M54 (3/3) VEP80B10A SCM006...
Page 170 AJ-HDC27VP 10V1500 COMPONENT INT CONNECT 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N41 (1/1) VEP20804A SCM007...
Page 171 COMPONENT CCD SENSOR 01/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q52 (1/4)-1 VEP20854A SCM008...
Page 172 COMPONENT CCD SENSOR 02/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q52 (2/4)-1 VEP20854A SCM009...
Page 173 COMPONENT CCD SENSOR 03/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q52 (3/4)-1 VEP20854A SCM010...
Page 174 COMPONENT CCD SENSOR 04/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q52 (4/4) VEP20854A SCM011...
Page 175 AJ-HDC27VP COMPONENT 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q53 (1/1)-1 VEP20855B SCM012...
Page 176 AJ-HDC27VP COMPONENT MEMORY (MEM-720P) 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR30105 (1/1)-2 VEP23531B SCM013...
Page 177 COMPONENT DRIVE 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q54 (1/1)-1 VEP20856A SCM014...
Page 178 COMPONENT PRE AMP 01/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q55 (1/4)-1 VEP20857A SCM015...
Page 179 COMPONENT PRE AMP 02/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q55 (2/4)-1 VEP20857A SCM016...
Page 180 COMPONENT PRE AMP 03/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q55 (3/4)-1 VEP20857A SCM017...
Page 181 COMPONENT PRE AMP 04/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q55 (4/4) VEP20857A SCM018...
Page 182 COMPONENT PRE PROCESS 01/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30128 (1/5) VEP23534B SCM019...
Page 183 COMPONENT PRE PROCESS 02/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30128 (2/5) VEP23534B SCM020...
Page 184 COMPONENT PRE PROCESS 03/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30128 (3/5) VEP23534B SCM021...
Page 185 COMPONENT PRE PROCESS 04/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30128 (4/5) VEP23534B SCM022...
Page 186 C0ABGA000019 C0ABGA000019 C0ABGA000019 COMPONENT PRE PROCESS 05/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30128 (5/5) VEP23534B SCM023...
Page 187 COMPONENT DSP MAIN (DSP-720P) 01/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30104 (1/5) VEP23530B SCM024...
Page 188 AJ-HDC27VP AJ-HDC27VP COMPONENT DSP MAIN (DSP-720P) 02/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30104 (2/5)-2 VEP23530B SCM025...
Page 189 COMPONENT DSP MAIN (DSP-720P) 03/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30104 (3/5) VEP23530B SCM026...
Page 190 AJ-HDC27VP COMPONENT DSP MAIN (DSP-720P) 04/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30104 (4/5)-2 VEP23530B SCM027...
Page 191 COMPONENT DSP MAIN (DSP-720P) 05/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30104 (5/5) VEP23530B SCM028...
Page 192: Vep26234C
AJ-HDC27VP AJ-HDC27VP COMPONENT CAMERA SYSCON 01/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S27 (1/6)-3 VEP26234C SCM029...
Page 193 AJ-HDC27VP AJ-HDC27VP AJ-HDC27VP COMPONENT CAMERA SYSCON 02/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S27 (2/6)-4 VEP26234C SCM030...
Page 194 AJ-HDC27VP AJ-HDC27VP COMPONENT CAMERA SYSCON 03/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S27 (3/6)-5 VEP26234C SCM031...
Page 195 AJ-HDC27VP COMPONENT CAMERA SYSCON 04/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S27 (4/6)-2 VEP26234C SCM032...
Page 196 AJ-HDC27VP COMPONENT CAMERA SYSCON 05/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S27 (5/6)-2 VEP26234C SCM033...
Page 197 AJ-HDC27VP AJ-HDC27VP AJ-HDC27VP AJ-HDC27VP COMPONENT CAMERA SYSCON 06/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S27 (6/6)-4 VEP26234C SCM034...
Page 198 AJ-HDC27VP AJ-HDC27VP AJ-HDC27VP COMPONENT VIDEO OUT 01/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR3Y47 (1/3)-2 VEP23500B SCM035...
Page 199 AJ-HDC27VP COMPONENT VIDEO OUT 02/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR3Y47 (2/3)-1 VEP23500B SCM036...
Page 200 COMPONENT VIDEO OUT 03/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR3Y47 (3/3)-1 VEP23500B SCM037...
Page 201 COMPONENT HEAD BUFF (FE) 01/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR5543 (1/6) VEP85179B SCM038...
Page 202 SHIELD CASE SHIELD CASE COMPONENT HEAD BUFF (RA) 02/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR5543 (2/6)-3 VEP85179B SCM039...
Page 203 SHIELD CASE SHIELD CASE COMPONENT HEAD BUFF (RA) 03/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR5543 (3/6)-3 VEP85179B SCM040...
Page 204 SHIELD CASE COMPONENT HEAD BUFF (RP HA) 04/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR5543 (4/6) VEP85179B SCM041...
Page 205 COMPONENT HEAD BUFF (LOGIC) 05/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR5543 (5/6) VEP85179B SCM042...
Page 206 COMPONENT HEAD BUFF (CONNECTOR) 06/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR5543 (6/6) VEP85179B SCM043...
Page 207 COMPONENT RF EQ (EQ Ach) 01/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (1/18)-1 VEP87104B SCM044...
Page 208 COMPONENT RF EQ (EQ Bch) 02/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (2/18)-1 VEP87104B SCM045...
Page 209 COMPONENT RF EQ (EQ Cch) 03/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (3/18)-1 VEP87104B SCM046...
Page 210 COMPONENT RF EQ (EQ Dch) 04/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (4/18)-1 VEP87104B SCM047...
Page 211 COMPONENT RF EQ (AMP) 05/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (5/18) VEP87104B SCM048...
Page 212 COMPONENT RF EQ (EVR) 06/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (6/18) VEP87104B SCM049...
Page 213 COMPONENT RF EQ (LOGIC 1) 07/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (7/18) VEP87104B SCM050...
Page 214 COMPONENT RF EQ (LOGIC 2) 08/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (8/18) VEP87104B SCM051...
Page 215 COMPONENT RF EQ (HSE) 09/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (9/18) VEP87104B SCM052...
Page 216 COMPONENT RF EQ (REC DATA SELECT) 10/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (10/18)-1 VEP87104B SCM053...
Page 217 COMPONENT RF EQ (FE1) 11/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (11/18)-1 VEP87104B SCM054...
Page 218 COMPONENT RF EQ (ENVDET) 12/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (12/18)-1 VEP87104B SCM055...
Page 219 COMPONENT RF EQ (POWER 1) 13/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (13/18) VEP87104B SCM056...
Page 220 COMPONENT RF EQ (POWER 2) 14/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (14/18) VEP87104B SCM057...
Page 221 COMPONENT RF EQ (POWER 3) 15/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (15/18) VEP87104B SCM058...
Page 222 COMPONENT RF EQ (POWER 4) 16/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (16/18)-1 VEP87104B SCM059...
Page 223 COMPONENT RF EQ (PLD) 17/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (17/18)-1 VEP87104B SCM060...
Page 224 COMPONENT RF EQ (CONNECTOR) 18/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (18/18)-1 VEP87104B SCM061...
Page 225 VSI***** COMPONENT SERVO 01/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (1/10)-2 VEP82224B SCM062...
Page 226 COMPONENT SERVO 02/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (2/10) VEP82224B SCM063...
Page 227 COMPONENT SERVO (REEL DRIVE) 03/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (3/10) VEP82224B SCM064...
Page 228 COMPONENT SERVO (REEL FG, TENSION) 04/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (4/10)-1 VEP82224B SCM065...
Page 229 VSI***** COMPONENT SERVO 05/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (5/10) VEP82224B SCM066...
Page 230 COMPONENT SERVO 06/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (6/10) VEP82224B SCM067...
Page 231 COMPONENT SERVO 07/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (7/10)-1 VEP82224B SCM068...
Page 232 COMPONENT SERVO 08/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (8/10) VEP82224B SCM069...
Page 233 COMPONENT SERVO 09/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (9/10) VEP82224B SCM070...
Page 234 COMPONENT SERVO 10/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (10/10) VEP82224B SCM071...
Page 235 AJ-HDC27VP COMPONENT VIDEO MAIN (L VDS, HD SDI IF) 01/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (1/11) VEP83462C SCM072...
Page 236 COMPONENT 02/11 VIDEO MAIN (CHARA, HDSDI TX, DAC) NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (2/11) VEP83462C SCM073...
Page 237 COMPONENT VIDEO MAIN (PREP) 03/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (3/11) VEP83462C SCM074...
Page 238 COMPONENT VIDEO MAIN (COMPA) 04/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (4/11) VEP83462C SCM075...
Page 239 COMPONENT VIDEO MAIN (COMPB) 05/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (5/11) VEP83462C SCM076...
Page 240 COMPONENT VIDEO MAIN (PLD) 06/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (6/11)-1 VEP83462C SCM077...
Page 241 COMPONENT VIDEO MAIN (ECC) 07/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (7/11) VEP83462C SCM078...
Page 242 COMPONENT VIDEO MAIN (SYNC CLK) 08/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (8/11) VEP83462C SCM079...
Page 243 COMPONENT VIDEO MAIN (CLOCK DIST) 09/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (9/11) VEP83462C SCM080...
Page 244 AJ-HDC27VP COMPONENT VIDEO MAIN (CONNECTOR) 10/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (10/11) VEP83462C SCM081...
Page 245 COMPONENT VIDEO MAIN (POWER) 11/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (11/11) VEP83462C SCM082...
Page 246 COMPONENT VTR SYSCON 01/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (1/8) VEP86303C SCM083...
Page 247 COMPONENT VTR SYSCON 02/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (2/8) VEP86303C SCM084...
Page 248 COMPONENT VTR SYSCON 03/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (3/8) VEP86303C SCM085...
Page 249 COMPONENT VTR SYSCON 04/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (4/8) VEP86303C SCM086...
Page 250 COMPONENT VTR SYSCON 05/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (5/8) VEP86303C SCM087...
Page 251 COMPONENT VTR SYSCON 06/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (6/8) VEP86303C SCM088...
Page 252 COMPONENT VTR SYSCON 07/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (7/8) VEP86303C SCM089...
Page 253 COMPONENT VTR SYSCON 08/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (8/8) VEP86303C SCM090...
Page 254 COMPONENT AUDIO LCD (CH1 INPUT) 01/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (1/12) VEP84331B SCM091...
Page 255 COMPONENT AUDIO LCD (CH2 INPUT) 02/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (2/12) VEP84331B SCM092...
Page 256 COMPONENT AUDIO LCD (LIM/AGC) 03/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (3/12) VEP84331B SCM093...
Page 257 COMPONENT AUDIO LCD (A/D D/A) 04/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (4/12) VEP84331B SCM094...
Page 258 COMPONENT AUDIO LCD (OUTPUT) 05/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (5/12) VEP84331B SCM095...
Page 259 C46021 C46022 COMPONENT AUDIO LCD (MONITOR) 06/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (6/12) VEP84331B SCM096...
Page 260 COMPONENT AUDIO LCD (CUE DELAY) 07/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (7/12) VEP84331B SCM097...
Page 261 COMPONENT AUDIO LCD (CUE) 08/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (8/12) VEP84331B SCM098...
Page 262 COMPONENT AUDIO LCD (CONNECTOR) 09/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (9/12) VEP84331B SCM099...
Page 263 IC60010 C0EBJ0000049 COMPONENT AUDIO LCD (uCOM) 10/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (10/12) VEP84331B SCM100...
Page 264 DP61000 L5AAAGE00001KB COMPONENT AUDIO LCD (LCD DRIVE) 11/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (11/12) VEP84331B SCM101...
Page 265 COMPONENT AUDIO LCD (RTC) 12/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (12/12) VEP84331B SCM102...
Page 266 COMPONENT REAR JACK 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M57 (1/1) VEP80B13B SCM103...
Page 267 COMPONENT REAR SW 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N42 (1/1) VEP80B45A SCM104...
Page 268 COMPONENT 01/01 NAME IMPORTANT SAFETY NOTICE: CIRCUIT BOARD NO. DRAWING NO. COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS FOR SAFETY. KR4J28 (1/1) VEP84353A WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE SAME TYPE. SCM105...
Page 269 VRE0221H22MT AJ-HDC27VP COMPONENT POWER MAIN 01/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR1D67 (1/4) VEP81192C SCM106...
Page 270 AJ-HDC27VP COMPONENT POWER MAIN 02/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR1D67 (2/4) VEP81192C SCM107...
Page 271 COMPONENT POWER MAIN 03/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR1D67 (3/4) VEP81192C SCM108...
Page 272 AJ-HDC27VP AJ-HDC27VP COMPONENT POWER MAIN 04/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR1D67 (4/4)-1 VEP81192C SCM109...
Page 273 AJ-HDC27VP COMPONENT POWER SUB 01/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR1E00 (1/3) VEP81204B SCM110...
Page 274 COMPONENT POWER SUB 02/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR1E00 (2/3) VEP81204B SCM111...
Page 275 AJ-HDC27VP COMPONENT POWER SUB 03/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR1E00 (3/3)-1 VEP81204B SCM112...
Page 276 AJ-HDC27VP AJ-HDC27VP COMPONENT FRONT TOGGLE 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M60 (1/1) VEP80B16B SCM113...
Page 277 COMPONENT JOG MENU 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N50 (1/1) VEP80B52A SCM114...
Page 278 POWER EXT SMALL P.C.BOARD VEP80B81A FOIL CUT POWER SW P.C.BOARD VEP80B49A COMPONENT MONITOR SW (MONITOR VR) 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N45 (1/1) VEP80B47A SCM115...
Page 279 COMPONENT SERVO FLEX 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M93 (1/1) VEP80B38A SCM116...
Page 280 COMPONENT HD SDI TX (ENC) 01/02 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X20 (1/2) VEP83460B SCM117...
Page 281 COMPONENT HD SDI TX (P/S, DRV) 02/02 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X20 (2/2)-1 VEP83460B SCM118...
Page 282 COMPONENT SD CARD 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR30106 (1/1) VEP23532A SCM119...
Page 283 COMPONENT TOGGLE SW 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M59 (1/1) VEP80B15A SCM120...
Page 284 COMPONENT SYNCHRO SW 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N48 (1/1) VEP80B50A SCM121...
Page 285 COMPONENT USER SW 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N49 (1/1) VEP80B51A SCM122...
Page 286 COMPONENT MENU SW 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N56 (1/1) VEP80B53A SCM123...
Page 287 COMPONENT FRONT MIC 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M61 (1/1) VEP80B17A SCM124...
Page 288 COMPONENT EXT DC (DC INPUT) 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0P37 (1/1) VEP80B75A SCM125...
Page 289 CIRCUIT BOARD DIAGRAMS NOTE: BE SURE TO MAKE YOUR ORDERS OF REPLACEMENT PARTS ACCORDING TO PARTS LIST, SECTION 8 CONTENTS CAMERA MOTHER P.C.BOARD POWER MAIN P.C.BOARD (VEP81192C) ..CBA-25 (VEP000G7B)........... CBA-1 POWER SUB P.C.BOARD (VEP81204B) ..CBA-26 VTR MOTHER P.C.BOARD (VEP80B10A) ..CBA-2 HD SDI TX P.C.BOARD (VEP83460B) ...
Page 290 CAMERA MOTHER P.C. BOARD (VEP000G7B) COMPONENT SIDE (COMPONENT SIDE) FOIL SIDE (FOIL SIDE) CBA-1...
Page 291: Vtr Mother P.c.board (Vep80B10A)
VTR MOTHER P.C. BOARD (VEP80B10A) COMPONENT SIDE IC9903 QR9902 IC9904 QR9903 P9803 QR9904 P9805 TG9801 P9809 TG9802 P9810 TP9801 P9811 TP9802 P9812 TP9803 P9813 TP9804 P9814 TP9805 P9816 TP9806 P9819 TP9807 P9820 TP9808 P9822 TP9809 P9823 TP9810 P9825 TP9811 P9902 TP9812 Q9801 TP9813...
Page 292 VTR MOTHER P.C. BOARD (VEP80B10A) FOIL SIDE IC9901 IC9902 P9801 P9806 P9807 P9808 P9815 P9817 P9818 P9820 P9824 P9901 Q9901 Q9902 Q9903 Q9904 (FOIL SIDE) CBA-3...
Page 293 CCD SENSOR P.C. BOARD (VEP20854A) COMPONENT SIDE IC302 Q201 IC303 Q202 IC304 Q203 IC101 IC305 Q204 IC102 IC306 Q205 IC103 Q206 IC104 Q207 IC105 Q101 Q301 IC201 Q102 Q302 IC202 Q103 Q303 IC203 Q104 Q304 IC204 Q105 Q305 IC205 Q106 Q306 IC301 Q107...
Page 294 CCD SENSOR P.C. BOARD (VEP20854A) FOIL SIDE IC101 IC201 IC301 (FOIL SIDE) CBA-5...
Page 295 TG P.C. BOARD (VEP20855B) COMPONENT SIDE IC24 IC25 IC26 IC27 IC10 IC11 IC12 IC13 IC14 IC15 IC16 IC17 IC18 IC19 IC20 IC21 IC22 IC23 (COMPONENT SIDE) FOIL SIDE (FOIL SIDE) CBA-6...
Page 296 DRIVE P.C. BOARD (VEP20856A) FOIL SIDE COMPONENT SIDE IC11 IC10 IC12 IC13 (COMPONENT SIDE) (FOIL SIDE) CBA-7...
Page 297 PRE AMP P.C. BOARD (VEP20857A) COMPONENT SIDE FOIL SIDE Q303 Q107 Q304 Q111 Q308 Q112 Q309 Q113 Q310 Q205 Q205 IC101 Q207 IC102 Q211 Q101 IC103 Q212 Q102 IC104 Q213 Q103 IC201 Q305 Q104 TP101 IC202 Q306 Q108 TP102 IC203 Q307 Q109 TP201...
Page 298 PRE PROCESS P.C. BOARD (VEP23534B) COMPONENT SIDE IC101 Q311 IC102 Q404 IC103 Q405 IC104 Q406 IC106 Q505 IC108 Q506 IC109 Q507 IC115 QR402 IC202 QR403 IC203 TG502 IC204 TP100 IC206 TP101 IC208 TP102 IC209 TP200 IC211 TP201 IC215 TP202 IC301 TP300 IC302 TP301...
Page 299 DSP MAIN P.C. BOARD (VEP23530B) COMPONENT SIDE IC101 IC701 TP321 IC102 IC702 TP322 IC103 P100 TP325 IC104 P300 TP326 To backside through IC105 P301 TP327 board edge IC106 P700 TP328 Jumper IC110 Q500 TP329 IC324 IC111 Q504 TP330 IC112 Q505 TP331 IC113 Q506...
Page 300 DSP MAIN P.C. BOARD (VEP23530B) FOIL SIDE IC100 Q501 IC107 Q502 IC108 Q503 IC109 TP119 IC307 TP302 P101 IC308 TP303 IC311 TP304 IC314 TP510 IC501 TP512 IC503 TP517 IC504 TP518 IC505 TP519 IC506 TP710 IC507 TP712 IC509 TP715 IC511 TP717 IC518 TP721 To backside through...
Page 301 CAMERA SYSCON P.C. BOARD (VEP26234C) COMPONENT SIDE FOIL SIDE IC14 IC100 IC10 IC201 IC11 IC202 IC13 IC15 IC203 IC205 IC16 IC206 IC17 IC301 IC200 IC304 IC207 IC308 IC208 IC401 IC211 IC300 IC302 P100 IC303 QR100 IC305 QR101 IC306 TG401 IC307 IC309 IC402 TP200...
Page 302 VIDEO OUT P.C. BOARD (VEP23500B) COMPONENT SIDE FOIL SIDE IC13 IC26 IC34 IC501 IC502 IC503 IC505 IC507 IC509 IC10 IC510 IC11 IC513 IC12 IC518 IC14 IC702 IC15 IC704 IC16 IC705 IC17 IC18 Q706 IC19 QR701 IC20 TG701 IC21 IC22 IC23 IC24 IC25 IC27...
Page 303: Head Buff P.c.board (Vep85179B)
HEAD BUFF P.C. BOARD (VEP85179B) FOIL SIDE COMPONENT SIDE IC502 Q215 Q405 IC400 Q110 Q216 Q406 IC401 Q111 Q218 Q407 IC402 Q114 Q100 Q300 Q408 IC403 Q115 Q101 Q301 TG400 IC404 Q204 Q104 Q302 TP100 IC405 Q205 Q105 Q303 TP101 IC406 Q206 Q108...
Page 304 RF EQ P.C. BOARD (VEP87104B) COMPONENT SIDE IC3003 IC829 Q952 Q3308 TP400 VR103 IC3004 IC830 Q957 Q3309 TP401 VR104 IC3005 Q958 Q3312 TP402 VR105 IC3006 Q961 Q3313 TP403 VR106 IC12 IC3007 Q964 Q3315 TP404 VR107 IC15 IC3201 P820 Q965 Q3316 TP405 VR108 IC100...
Page 305 RF EQ P.C. BOARD (VEP87104B) FOIL SIDE IC772 Q603 Q628 Q831 Q3306 QR3306 IC820 Q604 Q629 Q941 Q3310 QR3307 IC940 Q605 Q630 Q946 Q3314 QR3401 IC941 Q606 Q631 Q947 Q3405 QR3402 IC11 IC3008 Q607 Q660 Q948 Q3406 QR3403 IC102 IC3202 Q608 Q661 Q953...
Page 306 SERVO P.C. BOARD (VEP82224B) COMPONENT SIDE IC2100 P2615 IC2305 P2616 IC2410 P2617 IC2704 P2618 IC2957 P2619 IC2958 P2620 IC2959 P2621 Q2304 P2500 Q2701 P2600 Q2811 P2601 P2602 Q2816 P2603 Q2817 P2604 Q2818 P2605 Q2821 P2606 Q2822 P2607 Q2830 P2608 Q2954 P2609 QR2701 P2610...
Page 307 SERVO P.C. BOARD (VEP82224B) FOIL SIDE IC2101 IC2703 Q2306 Q2842 QR2953 IC2102 IC2801 Q2307 Q2843 QR702 IC2103 IC2802 Q2308 Q2856 QR705 IC2104 IC2803 Q2309 Q2950 QR814 IC2105 IC2805 Q2310 Q2951 QR849 IC2109 IC2807 Q2311 Q2952 TG2300 IC2201 IC2831 Q2312 Q2953 TP2102 IC2202 IC2900...
Page 308 VIDEO MAIN P.C. BOARD (VEP83462C) COMPONENT SIDE IC11 Q552 IC71 Q553 IC73 Q554 IC74 Q555 IC80 QR550 IC150 QR551 IC151 QR552 IC152 TP70 IC200 TP200 IC321 TP324 IC401 TP327 IC450 TP330 IC451 TP331 IC452 TP332 IC453 TP339 IC455 TP354 IC456 TP450 IC457 TP451...
Page 309 VIDEO MAIN P.C. BOARD (VEP83462C) FOIL SIDE TP72 TP201 TP202 IC70 TP320 IC76 TP353 IC77 TP355 IC78 TP356 IC153 TP357 IC154 TP358 IC250 TP359 IC350 TP360 IC351 TP501 IC400 TP502 IC550 TP503 TP504 TP505 P502 TP511 P503 TP514 Q550 TP515 Q551 Q556 TG500...
Page 310 VTR SYSCON P.C. BOARD (VEP86303C) COMPONENT SIDE IC6102 IC6103 IC6104 IC6200 IC6201 IC6301 IC6302 IC6304 IC6306 IC6307 IC6309 IC6400 IC6500 IC6600 IC6602 P6700 QR500 (COMPONENT SIDE) FOIL SIDE IC6101 IC6102 IC6109 IC6302 IC6303 IC6308 IC6401 IC6800 IC6801 IC6901 IP100 P6100 P6701 P6800 P6801...
Page 311 AUDIO LCD P.C. BOARD (VEP84331B) COMPONENT SIDE IC41002 P40011 IC41003 Q41001 IC41004 Q42001 IC42002 Q46001 IC42003 Q46002 IC42004 Q46005 IC43006 Q62003 IC44002 Q62004 IC44005 Q62005 IC44007 Q62006 IC44008 Q62007 IC45007 Q62008 IC45008 Q62009 IC47002 Q62010 IC47003 Q64001 IC47004 QR41002 IC48002 QR42002 IC48003 QR46002...
Page 312 AUDIO LCD P.C. BOARD (VEP84331B) FOIL SIDE IC40001 IC45002 IC61002 Q40004 Q46004 QR43005 TP61001 IC41001 IC45003 IC62001 Q40005 Q47001 QR43006 TP61002 IC41005 IC45005 IC62002 Q43001 Q61000 QR43007 TP61003 IC41006 IC45006 IC62003 Q43001 Q61001 QR43008 TP61004 IC41007 IC46001 IC62007 Q43002 Q62001 QR45001 TP62001 IC42001...
Page 313 CUE P.C. BOARD (VEP84353A) COMPONENT SID IC1001 P1002 P1005 P1006 P1008 Q1004 Q1010 Q1011 Q1012 QR1003 QR1004 TG1001 TP1001 TP1002 TP1003 VR1001 VR1002 (COMPONENT SIDE) FOIL SIDE P1001 P1003 P1004 P1005 P1006 P1007 P1009 Q1001 Q1002 Q1003 Q1005 Q1006 Q1007 Q1008 Q1009 Q1010...
Page 314 POWER MAIN P.C. BOARD (VEP81192C) COMPONENT SIDE IC1001 IC1002 IC1101 IC1201 P1002 P1003 P1004 TG1001 (COMPONENT SIDE) FOIL SIDE IC1003 IC1004 P1003 P1004 Q1001 Q1003 Q1004 Q1101 Q1102 Q1104 Q1201 Q1202 Q1203 QR1101 (FOIL SIDE) CBA-25...
Page 315 POWER SUB P.C. BOARD (VEP81204B) COMPONENT SIDE IC1301 IC1302 P1301 Q1401 Q1402 Q1403 Q1411 Q1412 QR1402 QR1402 TG1301 TP1301 (COMPONENT SIDE) FOIL SIDE Q1304 Q1307 Q1310 Q1311 Q1406 Q1407 Q1409 QR1301 QR1303 QR1304 QR1404 QR1407 QR1408 (FOIL SIDE) CBA-26...
Page 316 HD SDI TX P.C. BOARD (VEP83460B) COMPONENT SIDE IC10 IC13 IC14 (COMPONENT SIDE) FOIL SIDE (FOIL SIDE) CBA-27...
Page 317 INT CONNECT P.C. BOARD FRONT MIC P.C. BOARD (VEP20804A) (VEP80B17A) (COMPONENT SIDE) (FOIL SIDE) (COMPONENT SIDE) FRONT TOGGLE P.C. BOARD (VEP80B16B) (COMPONENT SIDE) (FOIL SIDE) JOG MENU P.C. BOARD (VEP80B52A) (COMPONENT SIDE) (FOIL SIDE) CBA-28...
Page 318 MONITOR VR P.C. BOARD (VEP80B47A) (COMPONENT SIDE) (FOIL SIDE) TOGGLE SW P.C. BOARD (VEP80B15A) (COMPONENT SIDE) (FOIL SIDE) USER SW P.C. BOARD (VEP80B51A) (COMPONENT SIDE) (FOIL SIDE) SYNCHRO SW P.C. BOARD MENU SW P.C. BOARD (VEP80B50A) (VEP80B53A) (COMPONENT SIDE) (FOIL SIDE) (COMPONENT SIDE) (FOIL SIDE) CBA-29...
Page 319 SERVO FLEX P.C. BOARD (VEP80B38A) (COMPONENT SIDE) (FOIL SIDE) REAR JACK P.C. BOARD (VEP80B13B) (COMPONENT SIDE) (FOIL SIDE) REAR SW P.C. BOARD (VEP80B45A) (COMPONENT SIDE) (FOIL SIDE) CBA-30...
Page 320: Sd Card P.c.board (Vep23532A)
SD CARD P.C. BOARD (VEP23532A) (COMPONENT SIDE) MEMORY P.C. BOARD (VEP23531B) (COMPONENT SIDE) (FOIL SIDE) CBA-31...
Page 321 EXPLODED VIEWS & REPLACEMENT PARTS LIST CONTENTS SERVICING FIXTURES & TOOLS............... PRT-1 MECHANICAL CHASSIS ASSEMBLY (1) ............PRT-3 MECHANICAL CHASSIS ASSEMBLY (2) ............PRT-5 CHASSIS FRAME ASSEMBLY (1)............... PRT-7 CHASSIS FRAME ASSEMBLY (2)............... PRT-9 CHASSIS FRAME ASSEMBLY (3)............... PRT-11 CASSETTE COMPARTMENT ASSEMBLY............PRT-13 PACKING PARTS ASSEMBLY ................
Page 322 SERVICING FIXTURES & TOOLS Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VFK1145A BACK TENSION METER 1 (T2-M30-P) VFK1149A POST DRIVER (2.5mm) VFK71A DIAL TORQUE GAUGE 1 (1.5cN-m) VFK1191A DIAL TORQUE GAUGE 1 (0.45cN-m) VFK1152 DIAL TORQUE GAUGE ADAPTER...
Page 323 MECHANICAL CHASSIS ASSEMBLY (1) PRT-2...
Page 324 MECHANICAL CHASSIS ASSEMBLY (1) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VDG1189 IDLER GEAR A VXL2614 IDLER ARM ASS'Y VMB3011 IDLER SPRING VXP1700 IDLER GEAR ASS'Y VMM0422 E-E ROD VEM0658 S REEL MOTOR ASS'Y 1 (M) VEM0659 T REEL MOTOR ASS'Y...
Page 325 MECHANICAL CHASSIS ASSEMBLY (2) PRT-4...
Page 326 MECHANICAL CHASSIS ASSEMBLY (2) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks XVE2B4FZ HEX SCREW VXA6630 A/C HEAD BASE (1) ASS'Y XVE2B6FP HEX SCREW VED0419 A/C HEAD 1 (M) XVE2B12FP HEX SCREW VXA6067 A/C HEAD BASE (2) ASS'Y VXQ0439...
Page 327 CHASSIS FRAME ASSEMBLY (1) PRT-6...
Page 328 CHASSIS FRAME ASSEMBLY (1) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks J0KE00000012 FERRITE CORE VYH0280 HANDLE ASS'Y J0KE00000033 FERRITE CORE VJF1319 SHOE VSC5159 BNC GND VGL0783 TALLY COVER VWJ12C2120L0 FLEXIBLE CABLE VMP5585 P.C.BOARD ANGLE VEE0L56...
Page 329 CHASSIS FRAME ASSEMBLY (2) PRT-8...
Page 330 CHASSIS FRAME ASSEMBLY (2) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VWJ15C2038L0 CABLE VEQ2750 HEAD OPTICAL VEE0K11 CABLE VYK9465 FRONT CASE U J0KG00000011 FERRITE CORE VMP6764 P.C.B HOLDER ANGLE(UPPER) VKN0149 SPEAKER NET VMP6765 P.C.B HOLDER ANGLE(LOWER) VGH4396...
Page 331 CHASSIS FRAME ASSEMBLY (3) PRT-10...
Page 332 CHASSIS FRAME ASSEMBLY (3) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VYF2689 CASSETTE COVER ASS'Y VEP23534B PRE PROCESS P.C.BOARD VYP7703 SIDE CASE (L) ASS'Y VEP000G7B CAMERA MOTHER P.C.BOARD VMG1334 PROTECT RUBBER VEP26234C CAMERA SYSCON P.C.BOARD VMG1270...
Page 333 CASSETTE COMPARTMENT ASSEMBLY PRT-12...
Page 334 CASSETTE COMPARTMENT ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VXA6870 CASSETTE UP ASS'Y VXA6890 HOLDER ASS'Y VXA6893 TOP PLATE VXL2696 PRESSURE LEVER VMB3063 PRESSURE LEVER SPRING VXA6728 PROTECTOR SHAFT (2) L VXA6729 PROTECTOR SHAFT (2) R VMS6198...
Page 335 PACKING PARTS ASSEMBLY PRT-14...
Page 336 PACKING PARTS ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VYQ2047 CUSHION (U) VPF0230 POLYETHYLENE BAG VQT9419 OPERATING INSTRUCTIONS VYQ2048 CUSHION (B) VPG0A84 PACKING CASE VEJ1672 BATTERY ADAPTOR ASS'Y VFC3443 SHOULDER BELT VPK2298 ACCESSORY BOX (B) VPK2280...
Page 337 ELECTRICAL REPLACEMNT PARTS LIST Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VEP20857A PRE AMP P.C.BOARD 1 (RTL) VEP83462C VIDEO MAIN P.C.BOARD 1 (RTL) VEP81225A VTR SYSCON P.C.BOARD 1 (RTL)FOR VEP83462C VEP20855B TG P.C.BOARD 1 (RTL) VEP20884A...
Page 338 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks FL102 J0E1605B0002 FILTER VEP20857A PRE AMP P.C.BOARD 1 (RTL) FL201 J0E3005B0002 FILTER FL202 J0E1605B0002 FILTER FL301 J0E3005B0002 FILTER ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U FL302 J0E1605B0002 FILTER ECST1CY685Z...
Page 339 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R106,07 ERJ3RBD102 M.RESISTOR CH 1/16W R308 ERJ3RBD203 M.RESISTOR CH 1/16W 20K R108 ERJ3RBD203 M.RESISTOR CH 1/16W 20K R309 ERJ3GEY0R00 M.RESISTOR CH 1/16W R109 ERJ3GEY0R00 M.RESISTOR CH 1/16W R310,11 ERJ3RBD101...
Page 340 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ECST1CY685Z T.CAPACITOR CH 16V 6.8U ERJ3RBD113 M.RESISTOR CH 1/16W 11K 1 FOR VEP20884A C48,49 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U ERJ3GEYJ105 M.RESISTOR CH 1/16W ECST1CV476 E.CAPACITOR CH 16V ERJ3RBD102 M.RESISTOR CH 1/16W...
Page 341 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C6-C8 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2SB1073-R TRANSISTOR ECST1CY685Z T.CAPACITOR CH 16V 6.8U 2SC4176 TRANSISTOR 1 B1ABDB000014 C10,11 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2SC3736 TRANSISTOR ECST1AX226Z T.CAPACITOR CH 10V...
Page 342 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ERJ3RBD333 M.RESISTOR CH 1/16W 33K C132,33 ECST1CY685Z T.CAPACITOR CH 16V 6.8U ERJ3RBD823 M.RESISTOR CH 1/16W 82K C135,36 ECST1AX226Z T.CAPACITOR CH 10V ERJ3RBD123 M.RESISTOR CH 1/16W 12K C137 ECST1CX106Z T.CAPACITOR CH 16V...
Page 343 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C325 ECUX1H010CCV C.CAPACITOR CH 50V IC214 THC4053FT C326 ECUX1H0R5CCV C.CAPACITOR CH 50V 0.5P IC215 TC7S00FU C327 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U IC301 C0ABAB000086 C328,29 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC302 CLC505AJE...
Page 344 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks QR402-06 UN5112 TRANSISTOR-RESISTOR R177 ERJ3RBD472 M.RESISTOR CH 1/16W 4.7K QR407 UN5212 TRANSISTOR-RESISTOR R178 ERJ3RBD101 M.RESISTOR CH 1/16W 100 R179 ERJ3RBD162 M.RESISTOR CH 1/16W 1.6K ERJ3GEY0R00 M.RESISTOR CH 1/16W R180...
Page 345 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R265 ERJ3RBD272 M.RESISTOR CH 1/16W 2.7K R350 ERJ3RBD303 M.RESISTOR CH 1/16W 30K R266 ERJ3RBD562 M.RESISTOR CH 1/16W 5.6K R351 ERJ3RBD102 M.RESISTOR CH 1/16W R267 ERJ3RBD391 M.RESISTOR CH 1/16W 390 R352...
Page 346 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R470 ERJ3RBD132 M.RESISTOR CH 1/16W 1.3K VJP4395D008 CONNECTOR (MALE) R471 ERJ3RBD113 M.RESISTOR CH 1/16W 11K VJS2907D015 CONNECTOR (FEMALE) 1 K1MN15B00011 R473 ERJ3RBD272 M.RESISTOR CH 1/16W 2.7K VJS4064K020E CONNECTOR (FEMALE) R474...
Page 347 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C338 VCK0152 C.CAPACITOR 1 F1L1C1060016 ERJ3RBD682 M.RESISTOR CH 1/16W 6.8K C339-41 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U ERJ3RBD203 M.RESISTOR CH 1/16W 20K C401 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U ERJ3RBD101 M.RESISTOR CH 1/16W 100 C402-04...
Page 348 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R322 ERJ3RBD103 M.RESISTOR CH 1/16W 10K C145 ECST1AX336 E.CAPACITOR 6.3V 120U R324,25 ERJ3RBD103 M.RESISTOR CH 1/16W 10K C146,47 ECHU1C104J P.CAPACITOR 16V 0.1U R326 ERJ3RBD102 M.RESISTOR CH 1/16W C148 ECST1AX336...
Page 349 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks IC101-06 CLC505AJE 6 C0ABAB000024 R140 ERJ3RBD104 M.RESISTOR CH 1/16W 100K IC107-09 TC4W53FU R141 ERJ3RBD202 M.RESISTOR CH 1/16W IC110-15 AD9203ARURL7 IC R142 ERJ3RBD104 M.RESISTOR CH 1/16W 100K IC116-18 NJM072BV R143...
Page 350 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R505 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K R507 ERJ3GEYJ100 M.RESISTOR CH 1/16W IC1-C6 C0ZBZ0000554 R509 ERJ3GEY0R00 M.RESISTOR CH 1/16W C1ZBZ0001730 R510 ERJ3RBD202 M.RESISTOR CH 1/16W IC8,C9 C3ABPJ000009 R511...
Page 351 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C555-57 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R111 ERJ3RBD162 M.RESISTOR CH 1/16W 1.6K C559 ECST1CY475Z T.CAPACITOR CH 16V 4.7U R112 ERJ3GEY0R00 M.RESISTOR CH 1/16W C561-63 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R113 ERJ3RBD331...
Page 352 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R551 ERJ3RBD823 M.RESISTOR CH 1/16W 82K P9822 VJP4395D012 CONNECTOR (MALE) R553 ERJ3RBD183 M.RESISTOR CH 1/16W 18K P9823 VJP4395D015 CONNECTOR (MALE) R554,55 ERJ3RED100 M.RESISTOR CH 1/16W P9824 VJS2907B008 CONNECTOR (FEMALE)
Page 353 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C6504-10 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R6129 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K C6600,01 VCK0152 C.CAPACITOR 2 F1L1C1060016 R6131,32 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K C6602 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U R6134,35 ERJ3GEYJ473...
Page 354 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R6622 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K C233-38 ECUX1E104KBN C.CAPACITOR CH 25V 0.1U R6623 ERJ3RBD332 M.RESISTOR CH 1/16W 3.3K C242 F1J0J3350002 C.CAPACITOR CH6.3V 3.3U R6624 ERJ3RBD182 M.RESISTOR CH 1/16W 1.8K C243...
Page 355 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C804-06 ECUX1E104KBN C.CAPACITOR CH 25V 0.1U IC302 TA75W393FU C807,08 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U IC303,04 TB6519F 2 C0GBY0000011 C809 F1L0J2260002 C.CAPACITOR CH6.3V IC305 TC7W126F C811 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U IC401,02...
Page 356 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q307 2SB1073-R TRANSISTOR R100,01 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K Q308 2SD1119-R TRANSISTOR R102 ERJ3GEYG471 M.RESISTOR CH 1/16W 470 Q309 2SB1073-R TRANSISTOR R103 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K Q310 2SD1119-R TRANSISTOR...
Page 357 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R265 ERJ3GEYG102 M.RESISTOR CH 1/16W R376 ERJ3GEYJ393 M.RESISTOR CH 1/16W 39K R266 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K R380,81 ERJ8GEYJ1R0 M.RESISTOR CH 1/8W R267 ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K R382 ERJ3GEY0R00...
Page 358 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R715 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R871,72 ERJ8GEYJ391 M.RESISTOR CH 1/8W 390 R716,17 ERJ8GEYJ101 M.RESISTOR CH 1/8W 100 R873 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R718 ERJ8GEYJ300 M.RESISTOR CH 1/8W...
Page 359 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks TH200,01 ERJ12Y0R00 M.RESISTOR CH 1/2W C409-16 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U TH300,01 ERJ12Y0R00 M.RESISTOR CH 1/2W C417,18 ECUX1H272KBV C.CAPACITOR CH 50V 2700P C419 ECUX1H470JCV C.CAPACITOR CH 50V TP102,03 EYF6CU TEST POINT...
Page 360 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q319 2SC2954 TRANSISTOR R316 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K Q401-08 XN1504 TRANSISTOR-RESISTOR R317 ERJ3GEYJ221 M.RESISTOR CH 1/16W 220 R318 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K ERJ3GEY0R00 M.RESISTOR CH 1/16W R319...
Page 361 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C106-09 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U C473 ECUX1H152KBV C.CAPACITOR CH 50V 1500P C110-12 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C474 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U C113 ECUX1H820JCV C.CAPACITOR CH 50V C475...
Page 362 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C955 ECUM1C105KBM C.CAPACITOR CH 16V IC550 M62370GP 1 C0FBBD000082 C956 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC551-54 THC4053FT C958,59 ECST1AY475 T.CAPACITOR CH 10V 4.7U IC555 THC4052FT C960 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U...
Page 363 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q410,11 2SC3930 TRANSISTOR QR761 UN5113 TRANSISTOR-RESISTOR Q412 2SA1532-B TRANSISTOR QR762,63 UN5213 TRANSISTOR-RESISTOR Q413-15 2SC3930 TRANSISTOR QR820-23 UN5213 TRANSISTOR-RESISTOR Q416,17 2SC3935 TRANSISTOR QR3001-04 UN5213 TRANSISTOR-RESISTOR Q418,19 2SC3930 TRANSISTOR...
Page 364 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R181 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K R360 ERJ3GEYJ681 M.RESISTOR CH 1/16W 680 R182 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R361,62 ERJ3GEYG102 M.RESISTOR CH 1/16W R183 ERJ3GEY0R00 M.RESISTOR CH 1/16W R363...
Page 365 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R472 ERJ3GEYJ470 M.RESISTOR CH 1/16W R788 ERJ3GEYG682 M.RESISTOR CH 1/16W 6.8K R473 ERJ3GEY0R00 M.RESISTOR CH 1/16W R789,90 ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K R474 ERJ3GEYJ470 M.RESISTOR CH 1/16W R791,92 ERJ3GEYG682...
Page 366 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R964 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K R3136 ERJ3GEY0R00 M.RESISTOR CH 1/16W R965 ERJ3GEYG822 M.RESISTOR CH 1/16W 8.2K R3148 ERJ3GEYJ104 M.RESISTOR CH 1/16W 100K R967 ERJ3GEYJ470 M.RESISTOR CH 1/16W R3152...
Page 367 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks MISCELLANEOUS C1224 EEFCD0J470R E.CAPACITOR 6.3V C1225 ECUX1C106KBP C.CAPACITOR CH 16V XYN26+K6 SCREW VSC5129 HEAT SINK D1001,02 MA142WK DIODE VMG1339 THERMO-CONDUCTIVE SHEET A D1003 MA142WA DIODE D1004 MA142WK...
Page 368 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R1022 ERJ3RBD223 M.RESISTOR CH 1/16W 22K C1409 ECUX1H681JCV C.CAPACITOR CH 50V 680P R1023 ERJ3RBD273 M.RESISTOR CH 1/16W 27K C1410 ECUX1H101JCV C.CAPACITOR CH 50V 100P R1024 ERJ3RBD223 M.RESISTOR CH 1/16W 22K...
Page 369 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks QR1301 UN5112 TRANSISTOR-RESISTOR R1430 ERJ14RSJR10 M.RESISTOR CH 1/4W 0.1 QR1302 UN5211 TRANSISTOR-RESISTOR R1431 ERJ3GEYJ100 M.RESISTOR CH 1/16W QR1303 UN5111 TRANSISTOR-RESISTOR R1432 ERJ3GEYJ333 M.RESISTOR CH 1/16W 33K QR1304 UN5211 TRANSISTOR-RESISTOR...
Page 370 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C42016 ECUX1H330JCV C.CAPACITOR CH 50V C45033,34 EEVHB1C470 E.CAPACITOR C42017,18 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C45035,36 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C42019 EEVHP0J100 E.CAPACITOR 6.3V C46001 EEVHB0J101 E.CAPACITOR 6.3V 100U...
Page 371 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks D40001 MA142WK DIODE IC60010 C0EBJ0000049 D41001,02 MA142K DIODE IC60011 LVX3245QSC D41003-06 MA3J14300L DIODE IC61000 UPD16431AGC 1 C0HBA0000023 D42001,02 MA142K DIODE IC61002 THC4053FT D42003-06 MA3J14300L DIODE IC62001 S81350HGKD...
Page 372 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks QR46002 UN5213 TRANSISTOR-RESISTOR R42044 ERJ3GEY0R00 M.RESISTOR CH 1/16W QR46003 UN5113 TRANSISTOR-RESISTOR R42046 EXB24V473J COMBI.R-R QR47001,02 UN5213 TRANSISTOR-RESISTOR R42047 ERJ3GEYJ154 M.RESISTOR CH 1/16W 150K QR61000,01 UN5113 TRANSISTOR-RESISTOR R42048 ERJ3GEYJ104...
Page 373 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R45006,07 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K R48007 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K R45008-11 ERJ3RBD332 M.RESISTOR CH 1/16W 3.3K R48008 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K R45012,13 ERJ3RBD333 M.RESISTOR CH 1/16W 33K...
Page 374 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks RY41001,02 VSY2070 RELAY P9601 VJP3172D002 CONNECTOR (MALE) 1 K1KA02B00051 RY42001,02 VSY2070 RELAY SW9601 VST0076 SWITCH 1 K0E112G00013 SW40001 VSS0367-08B SWITCH SW40002 VSS0367-06B SWITCH 1 K0D161A00001 SW41001,02 VSS0342 SWITCH 2 K0D112B00056...
Page 375 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VEP80B51A USER SW P.C.BOARD 1 (RTL) D301-04 MA142K DIODE FL101 F1L1H2040004 C.CAPACITOR 50V 0.1U P9301 VJP1607T CONNECTOR (MALE) FL102,03 VLF1441P207 FILTER FL201 F1L1H2040004 C.CAPACITOR 50V 0.1U SW9301,02 EVQQSB04B SWITCH...
Page 376 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks MISCELLANEOUS ERJ3RBD272 M.RESISTOR CH 1/16W 2.7K ERJ3RBD103 M.RESISTOR CH 1/16W 10K VMS6135 P.C.B. POST (26SP-6) ERJ3RBD151 M.RESISTOR CH 1/16W 150 XSB26+3 SCREW VEE0J47 P.C.B. INT CABLE EVQB1D10809B SWITCH VST0335 SWITCH...
Page 377 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q1005 2SB1220-R TRANSISTOR J9701 VJS3417 CONNECTOR (FEMALE) 1 K1AB103A0007 Q1006,07 2SD1821-R TRANSISTOR Q1008,09 2SD1979 TRANSISTOR P9701 VJP1610T CONNECTOR (MALE) Q1010-12 2SJ280L TRANSISTOR 3 B1DGJG000002 R9702-04 VLF1315A102 FILTER...
Page 378 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks F1K0J1060002 C.CAPACITOR CH6.3V C564,65 ECUX1H102JCV C.CAPACITOR CH 50V 1000P ECUX1H220JCV C.CAPACITOR CH 50V C566 VCEA0JSP151 E.CAPACITOR 6.3V 150U C70,71 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U C567 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U C74-79...
Page 379 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks L465-69 VLF1147A241 FILTER R172 ERJ3GEYJ181 M.RESISTOR CH 1/16W 180 L470 VLF1147A121 FILTER R173 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 L471 VLP0155 COIL R174 ERJ3GEYG471 M.RESISTOR CH 1/16W 470 L472 VLF1147A121 FILTER...
Page 380 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R557 ERJ3RBD752 M.RESISTOR CH 1/16W 7.5K C9ZB00000361 R558 ERJ3GEYJ104 M.RESISTOR CH 1/16W 100K LVTH244APW 1 C0JBBZ000174 R559 ERJ3RBD752 M.RESISTOR CH 1/16W 7.5K FMM4039XC R560 ERJ3RBD102 M.RESISTOR CH 1/16W IC10...
Page 381 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R143 ERJ3GEYJ330 M.RESISTOR CH 1/16W R144 ERJ3GEYJ470 M.RESISTOR CH 1/16W R145 VRE006622152 M.RESISTOR CH 1/10W 1.5K 1 D0YD152JA008 R146,47 ERJ3GEY0R00 M.RESISTOR CH 1/16W R150-53 ERJ3RED150 M.RESISTOR CH 1/16W R155...
Page 382 OVERALL BLOCK DIAGRAM DSP MAIN P.C.BOARD CCD SENSOR PRE AMP P.C.BOARD PRE PROCESS P.C.BOARD VIDEO MAIN P.C.BOARD RF EQ P.C.BOARD H BUFF. P.C.BOARD P.C.BOARD MEMORY P.C.B R,G,B 10bit COMP L Ch HSE A BLACK/ FRAME BLEMISH COMP. REC/PB SAMPLE R,G,B R,G,B MEMORY HSE B...
Page 383 CCD SENSOR/TG (CCD PULSE)/DRIVE BLOCK DAIGRAM IC22 READY (CCD PULSE) IC19 CCD DRIVE PULSE GENERATOP V-CCD PULSE GEN. DRIVE MEMORY DCLK D GND H CLR TD 0 CHARGE CONNECT PULSE GEN. IC16 DATA HCLR TD 1 BUFFER OBCP D GND IC20 OPTICAL BLACK...
Page 384 PRE PROCESS/PRE AMP BLOCK DIAGRAM TP100 <1> P1 P1 Q105,106,107 TP102 <1> Q104 IC108 <1> DSP MAIN R ADS Q103 <1> Q109 VR404 IC115 <1> -6dB Q108 <1> Q109 <1> <1> R PED 24dB 12dB TRACK TP200 <2> IC201 <2> IC202 <2>...
Page 385 DSP MAIN/MEMORY BLOCK DIAGRAM DSP MAIN IC509<4> IC521<4> IC522<4> IC523<4> MEMORY IC1-6<1> IC9<1> IC1-6<1> P101 P101 VIDEO GLHD 1 2-11 ROAD 0-9 2A-11A 2B-11B ROLSI 0-9 82-91 FRAME MEMORY 1 12-21 READ 0-9 12A-21A 23-32 GOAD 0-9 23A-32A 23B-32B GOLSI 0-9 103-112 IC8<1>...
Page 386 VIDEO OUT BLOCK DIAGRAM TERMINAL (20pin) EE/PB-RET DSP MAIN EE-PB SELECT SELECT DSP MAIN IC29<1> VC0-CONL DSP MAIN DSP MAIN...
Page 387 HEAD BUFFER BLOCK DIAGRAM...
Page 388 RF EQ BLOCK DIAGRAM...
Page 389 HD SDI TX/VIDEO MAIN BLOCK DIAGRAM DSP MAIN DSP MAIN DSP MAIN DSP MAIN HD SDI TX...
Page 390 AUDIO LCD/CUE BLOCK DIAGRAM DF SLAVE TCG HOLD EMPHASIS TAPE BATT RF SERVO HUMID SLACK...
Page 391 SERVO BLOCK DIAGRAM...
Page 392 CAMERA SYSCON BLOCK DIAGRAM GLVD UDSP RSV1 DSP MAIN IC300 NOT USED IC100 VBLKM LENS CONNECTOR IC304 CARD S3 CARD S1 CARD S2 CARD S3 CARD SENS SD CARD BORD CARD CS CARD RDAT CARD WDAT CARD CLK DSP MAIN PROCESS ECU CONNECTOR IC305...
Page 393 VTR SYSCON/SD CARD BLOCK DIAGRAM USED USED SD CARD...
Page 394 POWER MAIN/SUB BLOCK DIAGRAM...
Page 395 CAMERA MOTHER P.C. BOARD (VEP000G7B) COMPONENT SIDE (COMPONENT SIDE) FOIL SIDE (FOIL SIDE) CBA-1...
Page 396 VTR MOTHER P.C. BOARD (VEP80B10A) COMPONENT SIDE IC9903 QR9902 IC9904 QR9903 P9803 QR9904 P9805 TG9801 P9809 TG9802 P9810 TP9801 P9811 TP9802 P9812 TP9803 P9813 TP9804 P9814 TP9805 P9816 TP9806 P9819 TP9807 P9820 TP9808 P9822 TP9809 P9823 TP9810 P9825 TP9811 P9902 TP9812 Q9801 TP9813...
Page 397 VTR MOTHER P.C. BOARD (VEP80B10A) FOIL SIDE IC9901 IC9902 P9801 P9806 P9807 P9808 P9815 P9817 P9818 P9820 P9824 P9901 Q9901 Q9902 Q9903 Q9904 (FOIL SIDE) CBA-3...
Page 398: Ccd Sensor P.c.board (Vep20854A)
CCD SENSOR P.C. BOARD (VEP20854A) COMPONENT SIDE IC302 Q201 IC303 Q202 IC304 Q203 IC101 IC305 Q204 IC102 IC306 Q205 IC103 Q206 IC104 Q207 IC105 Q101 Q301 IC201 Q102 Q302 IC202 Q103 Q303 IC203 Q104 Q304 IC204 Q105 Q305 IC205 Q106 Q306 IC301 Q107...
Page 399 CCD SENSOR P.C. BOARD (VEP20854A) FOIL SIDE IC101 IC201 IC301 (FOIL SIDE) CBA-5...
Page 400: Tg P.c.board (Vep20855B)
TG P.C. BOARD (VEP20855B) COMPONENT SIDE IC24 IC25 IC26 IC27 IC10 IC11 IC12 IC13 IC14 IC15 IC16 IC17 IC18 IC19 IC20 IC21 IC22 IC23 (COMPONENT SIDE) FOIL SIDE (FOIL SIDE) CBA-6...
Page 401: Drive P.c.board (Vep20856A)
DRIVE P.C. BOARD (VEP20856A) FOIL SIDE COMPONENT SIDE IC11 IC10 IC12 IC13 (COMPONENT SIDE) (FOIL SIDE) CBA-7...
Page 402: Pre Amp P.c.board (Vep20857A)
PRE AMP P.C. BOARD (VEP20857A) COMPONENT SIDE FOIL SIDE Q303 Q107 Q304 Q111 Q308 Q112 Q309 Q113 Q310 Q205 Q205 IC101 Q207 IC102 Q211 Q101 IC103 Q212 Q102 IC104 Q213 Q103 IC201 Q305 Q104 TP101 IC202 Q306 Q108 TP102 IC203 Q307 Q109 TP201...
Page 403: Pre Process P.c.board (Vep23534B)
PRE PROCESS P.C. BOARD (VEP23534B) COMPONENT SIDE IC101 Q311 IC102 Q404 IC103 Q405 IC104 Q406 IC106 Q505 IC108 Q506 IC109 Q507 IC115 QR402 IC202 QR403 IC203 TG502 IC204 TP100 IC206 TP101 IC208 TP102 IC209 TP200 IC211 TP201 IC215 TP202 IC301 TP300 IC302 TP301...
Page 404: Dsp Main P.c.board (Vep23530B)
DSP MAIN P.C. BOARD (VEP23530B) COMPONENT SIDE IC101 IC701 TP321 IC102 IC702 TP322 IC103 P100 TP325 To backside through IC104 P300 TP326 board edge IC105 P301 TP327 Jumper IC106 P700 TP328 IC324 IC110 Q500 TP329 IC111 Q504 TP330 IC112 Q505 TP331 IC113 Q506...
Page 405 DSP MAIN P.C. BOARD (VEP23530B) FOIL SIDE IC100 Q501 IC107 Q502 IC108 Q503 IC109 TP119 P101 IC307 TP302 IC308 TP303 IC311 TP304 IC314 TP510 IC501 TP512 IC503 TP517 IC504 TP518 IC505 TP519 IC506 TP710 IC507 TP712 IC509 TP715 IC511 TP717 IC518 TP721 To backside through...
Page 406: Camera Syscon P.c.board (Vep26234C)
CAMERA SYSCON P.C. BOARD (VEP26234C) COMPONENT SIDE FOIL SIDE IC14 IC100 IC10 IC201 IC11 IC202 IC13 IC15 IC203 IC205 IC16 IC206 IC17 IC301 IC200 IC304 IC207 IC308 IC208 IC401 IC211 IC300 IC302 P100 IC303 QR100 IC305 QR101 IC306 TG401 IC307 IC309 IC402 TP200...
Page 407: Video Out P.c.board (Vep23500B)
VIDEO OUT P.C. BOARD (VEP23500B) COMPONENT SIDE FOIL SIDE IC13 IC26 IC34 IC501 IC502 IC503 IC505 IC507 IC509 IC10 IC510 IC11 IC513 IC12 IC518 IC14 IC702 IC15 IC704 IC16 IC705 IC17 IC18 Q706 IC19 QR701 IC20 TG701 IC21 IC22 IC23 IC24 IC25 IC27...
Page 408: Head Buff P.c.board (Vep85179B)
HEAD BUFF P.C. BOARD (VEP85179B) FOIL SIDE COMPONENT SIDE IC502 Q215 Q405 IC400 Q110 Q216 Q406 IC401 Q111 Q218 Q407 IC402 Q114 Q100 Q300 Q408 IC403 Q115 Q101 Q301 TG400 IC404 Q204 Q104 Q302 TP100 IC405 Q205 Q105 Q303 TP101 IC406 Q206 Q108...
Page 409: Rf Eq P.c.board (Vep87104B)
RF EQ P.C. BOARD (VEP87104B) COMPONENT SIDE IC3003 IC829 Q952 Q3308 TP400 VR103 IC3004 IC830 Q957 Q3309 TP401 VR104 IC3005 Q958 Q3312 TP402 VR105 IC3006 Q961 Q3313 TP403 VR106 IC12 IC3007 Q964 Q3315 TP404 VR107 IC15 IC3201 P820 Q965 Q3316 TP405 VR108 IC100...
Page 410 RF EQ P.C. BOARD (VEP87104B) FOIL SIDE IC772 Q603 Q628 Q831 Q3306 QR3306 IC820 Q604 Q629 Q941 Q3310 QR3307 IC940 Q605 Q630 Q946 Q3314 QR3401 IC941 Q606 Q631 Q947 Q3405 QR3402 IC11 IC3008 Q607 Q660 Q948 Q3406 QR3403 IC102 IC3202 Q608 Q661 Q953...
Page 411 SERVO P.C. BOARD (VEP82224B) COMPONENT SIDE IC2100 P2615 IC2305 P2616 IC2410 P2617 IC2704 P2618 IC2957 P2619 IC2958 P2620 IC2959 P2621 Q2304 P2500 Q2701 P2600 Q2811 P2601 P2602 Q2816 P2603 Q2817 P2604 Q2818 P2605 Q2821 P2606 Q2822 P2607 Q2830 P2608 Q2954 P2609 QR2701 P2610...
Page 412 SERVO P.C. BOARD (VEP82224B) FOIL SIDE IC2101 IC2703 Q2306 Q2842 QR2953 IC2102 IC2801 Q2307 Q2843 QR702 IC2103 IC2802 Q2308 Q2856 QR705 IC2104 IC2803 Q2309 Q2950 QR814 IC2105 IC2805 Q2310 Q2951 QR849 IC2109 IC2807 Q2311 Q2952 TG2300 IC2201 IC2831 Q2312 Q2953 TP2102 IC2202 IC2900...
Page 413 VIDEO MAIN P.C. BOARD (VEP83462C) COMPONENT SIDE IC11 Q552 IC71 Q553 IC73 Q554 IC74 Q555 IC80 QR550 IC150 QR551 IC151 QR552 IC152 TP70 IC200 TP200 IC321 TP324 IC401 TP327 IC450 TP330 IC451 TP331 IC452 TP332 IC453 TP339 IC455 TP354 IC456 TP450 IC457 TP451...
Page 414 VIDEO MAIN P.C. BOARD (VEP83462C) FOIL SIDE TP72 TP201 TP202 IC70 TP320 IC76 TP353 IC77 TP355 IC78 TP356 IC153 TP357 IC154 TP358 IC250 TP359 IC350 TP360 IC351 TP501 IC400 TP502 IC550 TP503 TP504 TP505 P502 TP511 P503 TP514 Q550 TP515 Q551 Q556 TG500...
Page 415 VTR SYSCON P.C. BOARD (VEP86303C) COMPONENT SIDE IC6102 IC6103 IC6104 IC6200 IC6201 IC6301 IC6302 IC6304 IC6306 IC6307 IC6309 IC6400 IC6500 IC6600 IC6602 P6700 QR500 (COMPONENT SIDE) FOIL SIDE IC6101 IC6102 IC6109 IC6302 IC6303 IC6308 IC6401 IC6800 IC6801 IC6901 IP100 P6100 P6701 P6800 P6801...
Page 416 AUDIO LCD P.C. BOARD (VEP84331B) COMPONENT SIDE IC41002 P40011 IC41003 Q41001 IC41004 Q42001 IC42002 Q46001 IC42003 Q46002 IC42004 Q46005 IC43006 Q62003 IC44002 Q62004 IC44005 Q62005 IC44007 Q62006 IC44008 Q62007 IC45007 Q62008 IC45008 Q62009 IC47002 Q62010 IC47003 Q64001 IC47004 QR41002 IC48002 QR42002 IC48003 QR46002...
Page 417 AUDIO LCD P.C. BOARD (VEP84331B) FOIL SIDE IC40001 IC45002 IC61002 Q40004 Q46004 QR43005 TP61001 IC41001 IC45003 IC62001 Q40005 Q47001 QR43006 TP61002 IC41005 IC45005 IC62002 Q43001 Q61000 QR43007 TP61003 IC41006 IC45006 IC62003 Q43001 Q61001 QR43008 TP61004 IC41007 IC46001 IC62007 Q43002 Q62001 QR45001 TP62001 IC42001...
Page 418 CUE P.C. BOARD (VEP84353A) COMPONENT SID IC1001 P1002 P1005 P1006 P1008 Q1004 Q1010 Q1011 Q1012 QR1003 QR1004 TG1001 TP1001 TP1002 TP1003 VR1001 VR1002 (COMPONENT SIDE) FOIL SIDE P1001 P1003 P1004 P1005 P1006 P1007 P1009 Q1001 Q1002 Q1003 Q1005 Q1006 Q1007 Q1008 Q1009 Q1010...
Page 419 POWER MAIN P.C. BOARD (VEP81192C) COMPONENT SIDE IC1001 IC1002 IC1101 IC1201 P1002 P1003 P1004 TG1001 (COMPONENT SIDE) FOIL SIDE IC1003 IC1004 P1003 P1004 Q1001 Q1003 Q1004 Q1101 Q1102 Q1104 Q1201 Q1202 Q1203 QR1101 (FOIL SIDE) CBA-25...
Page 420 POWER SUB P.C. BOARD (VEP81204B) COMPONENT SIDE IC1301 IC1302 P1301 Q1401 Q1402 Q1403 Q1411 Q1412 QR1402 QR1402 TG1301 TP1301 (COMPONENT SIDE) FOIL SIDE Q1304 Q1307 Q1310 Q1311 Q1406 Q1407 Q1409 QR1301 QR1303 QR1304 QR1404 QR1407 QR1408 (FOIL SIDE) CBA-26...
Page 421 HD SDI TX P.C. BOARD (VEP83460B) COMPONENT SIDE IC10 IC13 IC14 (COMPONENT SIDE) FOIL SIDE (FOIL SIDE) CBA-27...
Page 422 INT CONNECT P.C. BOARD FRONT MIC P.C. BOARD (VEP20804A) (VEP80B17A) (COMPONENT SIDE) (FOIL SIDE) (COMPONENT SIDE) FRONT TOGGLE P.C. BOARD (VEP80B16B) (COMPONENT SIDE) (FOIL SIDE) JOG MENU P.C. BOARD (VEP80B52A) (COMPONENT SIDE) (FOIL SIDE) CBA-28...
Page 423 MONITOR VR P.C. BOARD (VEP80B47A) (COMPONENT SIDE) (FOIL SIDE) TOGGLE SW P.C. BOARD (VEP80B15A) (COMPONENT SIDE) (FOIL SIDE) USER SW P.C. BOARD (VEP80B51A) (COMPONENT SIDE) (FOIL SIDE) SYNCHRO SW P.C. BOARD MENU SW P.C. BOARD (VEP80B50A) (VEP80B53A) (COMPONENT SIDE) (FOIL SIDE) (COMPONENT SIDE) (FOIL SIDE) CBA-29...
Page 424 SERVO FLEX P.C. BOARD (VEP80B38A) (COMPONENT SIDE) (FOIL SIDE) REAR JACK P.C. BOARD (VEP80B13B) (COMPONENT SIDE) (FOIL SIDE) REAR SW P.C. BOARD (VEP80B45A) (COMPONENT SIDE) (FOIL SIDE) CBA-30...
Page 425 SD CARD P.C. BOARD (VEP23532A) (COMPONENT SIDE) MEMORY P.C. BOARD (VEP23531B) (COMPONENT SIDE) (FOIL SIDE) CBA-31...
Page 426 1. Disassembly Procedures DisassemblyProcedures Flowchart 1-2. Removal of theLeft Side Panel 1. After remove the Cassette Cover, loosen the 5 screws (A) and remove the Left Side Panel. 1. Removal of the Cassette Cover SCREW (A) 2. Removal of the Left Side Panel 3.
Page 427 2. After remove the Left Side Panel, unscrew the 4 1-4. Removal of the Cassette-up screws (A) and remove the BNC Terminal Unit. Unit 1. After remove the Left Side Panel, unscrew the 4 screws (A) and remove the Cassette-up Unit. SCREW (A) 3.
Page 428 4. Lift up the Mechanism Unit carefully, disconnect the 2. Unscrew the 3 screws (A) on the back side of the 2 connectors and remove the Mechanism Unit. Mechanism Unit. CONNECTOR SCREW (A) 3. Disconnect the Flexible Cable on the top side of the 1-6.
Page 429 3. Unscrew the 4 screws (A) and remove the Camera 1-7. Removal Camera Assembly. Assembly 1. Disconnect the Flexible Cable and Connector. SCREW FLEXIBLE CABLE CONNECTOR 2. Unscrew the 2 screws (A). SCREW DIS-4...
Page 430 ELECTRICAL REPLACEMNT PARTS LIST Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VEP20857A PRE AMP P.C.BOARD 1 (RTL) VEP83462C VIDEO MAIN P.C.BOARD 1 (RTL) VEP81225A VTR SYSCON P.C.BOARD 1 (RTL)FOR VEP83462C VEP20855B TG P.C.BOARD 1 (RTL) VEP20884A...
Page 431 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks FL102 J0E1605B0002 FILTER VEP20857A PRE AMP P.C.BOARD 1 (RTL) FL201 J0E3005B0002 FILTER FL202 J0E1605B0002 FILTER FL301 J0E3005B0002 FILTER ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U FL302 J0E1605B0002 FILTER ECST1CY685Z...
Page 432 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R106,07 ERJ3RBD102 M.RESISTOR CH 1/16W R308 ERJ3RBD203 M.RESISTOR CH 1/16W 20K R108 ERJ3RBD203 M.RESISTOR CH 1/16W 20K R309 ERJ3GEY0R00 M.RESISTOR CH 1/16W R109 ERJ3GEY0R00 M.RESISTOR CH 1/16W R310,11 ERJ3RBD101...
Page 433 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ECST1CY685Z T.CAPACITOR CH 16V 6.8U ERJ3RBD113 M.RESISTOR CH 1/16W 11K 1 FOR VEP20884A C48,49 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U ERJ3GEYJ105 M.RESISTOR CH 1/16W ECST1CV476 E.CAPACITOR CH 16V ERJ3RBD102 M.RESISTOR CH 1/16W...
Page 434 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C6-C8 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2SB1073-R TRANSISTOR ECST1CY685Z T.CAPACITOR CH 16V 6.8U 2SC4176 TRANSISTOR 1 B1ABDB000014 C10,11 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2SC3736 TRANSISTOR ECST1AX226Z T.CAPACITOR CH 10V...
Page 435 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ERJ3RBD333 M.RESISTOR CH 1/16W 33K C132,33 ECST1CY685Z T.CAPACITOR CH 16V 6.8U ERJ3RBD823 M.RESISTOR CH 1/16W 82K C135,36 ECST1AX226Z T.CAPACITOR CH 10V ERJ3RBD123 M.RESISTOR CH 1/16W 12K C137 ECST1CX106Z T.CAPACITOR CH 16V...
Page 436 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C325 ECUX1H010CCV C.CAPACITOR CH 50V IC214 THC4053FT C326 ECUX1H0R5CCV C.CAPACITOR CH 50V 0.5P IC215 TC7S00FU C327 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U IC301 C0ABAB000086 C328,29 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC302 CLC505AJE...
Page 437 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks QR402-06 UN5112 TRANSISTOR-RESISTOR R177 ERJ3RBD472 M.RESISTOR CH 1/16W 4.7K QR407 UN5212 TRANSISTOR-RESISTOR R178 ERJ3RBD101 M.RESISTOR CH 1/16W 100 R179 ERJ3RBD162 M.RESISTOR CH 1/16W 1.6K ERJ3GEY0R00 M.RESISTOR CH 1/16W R180...
Page 438 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R265 ERJ3RBD272 M.RESISTOR CH 1/16W 2.7K R350 ERJ3RBD303 M.RESISTOR CH 1/16W 30K R266 ERJ3RBD562 M.RESISTOR CH 1/16W 5.6K R351 ERJ3RBD102 M.RESISTOR CH 1/16W R267 ERJ3RBD391 M.RESISTOR CH 1/16W 390 R352...
Page 439 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R470 ERJ3RBD132 M.RESISTOR CH 1/16W 1.3K VJP4395D008 CONNECTOR (MALE) R471 ERJ3RBD113 M.RESISTOR CH 1/16W 11K VJS2907D015 CONNECTOR (FEMALE) 1 K1MN15B00011 R473 ERJ3RBD272 M.RESISTOR CH 1/16W 2.7K VJS4064K020E CONNECTOR (FEMALE) R474...
Page 440 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C338 VCK0152 C.CAPACITOR 1 F1L1C1060016 ERJ3RBD682 M.RESISTOR CH 1/16W 6.8K C339-41 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U ERJ3RBD203 M.RESISTOR CH 1/16W 20K C401 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U ERJ3RBD101 M.RESISTOR CH 1/16W 100 C402-04...
Page 441 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R322 ERJ3RBD103 M.RESISTOR CH 1/16W 10K C145 ECST1AX336 E.CAPACITOR 6.3V 120U R324,25 ERJ3RBD103 M.RESISTOR CH 1/16W 10K C146,47 ECHU1C104J P.CAPACITOR 16V 0.1U R326 ERJ3RBD102 M.RESISTOR CH 1/16W C148 ECST1AX336...
Page 442 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks IC101-06 CLC505AJE 6 C0ABAB000024 R140 ERJ3RBD104 M.RESISTOR CH 1/16W 100K IC107-09 TC4W53FU R141 ERJ3RBD202 M.RESISTOR CH 1/16W IC110-15 AD9203ARURL7 IC R142 ERJ3RBD104 M.RESISTOR CH 1/16W 100K IC116-18 NJM072BV R143...
Page 443 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R505 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K R507 ERJ3GEYJ100 M.RESISTOR CH 1/16W IC1-C6 C0ZBZ0000554 R509 ERJ3GEY0R00 M.RESISTOR CH 1/16W C1ZBZ0001730 R510 ERJ3RBD202 M.RESISTOR CH 1/16W IC8,C9 C3ABPJ000009 R511...
Page 444 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C555-57 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R111 ERJ3RBD162 M.RESISTOR CH 1/16W 1.6K C559 ECST1CY475Z T.CAPACITOR CH 16V 4.7U R112 ERJ3GEY0R00 M.RESISTOR CH 1/16W C561-63 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R113 ERJ3RBD331...
Page 445 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R551 ERJ3RBD823 M.RESISTOR CH 1/16W 82K P9822 VJP4395D012 CONNECTOR (MALE) R553 ERJ3RBD183 M.RESISTOR CH 1/16W 18K P9823 VJP4395D015 CONNECTOR (MALE) R554,55 ERJ3RED100 M.RESISTOR CH 1/16W P9824 VJS2907B008 CONNECTOR (FEMALE)
Page 446 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C6504-10 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R6129 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K C6600,01 VCK0152 C.CAPACITOR 2 F1L1C1060016 R6131,32 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K C6602 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U R6134,35 ERJ3GEYJ473...
Page 447 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R6622 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K C233-38 ECUX1E104KBN C.CAPACITOR CH 25V 0.1U R6623 ERJ3RBD332 M.RESISTOR CH 1/16W 3.3K C242 F1J0J3350002 C.CAPACITOR CH6.3V 3.3U R6624 ERJ3RBD182 M.RESISTOR CH 1/16W 1.8K C243...
Page 448 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C804-06 ECUX1E104KBN C.CAPACITOR CH 25V 0.1U IC302 TA75W393FU C807,08 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U IC303,04 TB6519F 2 C0GBY0000011 C809 F1L0J2260002 C.CAPACITOR CH6.3V IC305 TC7W126F C811 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U IC401,02...
Page 449 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q307 2SB1073-R TRANSISTOR R100,01 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K Q308 2SD1119-R TRANSISTOR R102 ERJ3GEYG471 M.RESISTOR CH 1/16W 470 Q309 2SB1073-R TRANSISTOR R103 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K Q310 2SD1119-R TRANSISTOR...
Page 450 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R265 ERJ3GEYG102 M.RESISTOR CH 1/16W R376 ERJ3GEYJ393 M.RESISTOR CH 1/16W 39K R266 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K R380,81 ERJ8GEYJ1R0 M.RESISTOR CH 1/8W R267 ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K R382 ERJ3GEY0R00...
Page 451 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R715 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R871,72 ERJ8GEYJ391 M.RESISTOR CH 1/8W 390 R716,17 ERJ8GEYJ101 M.RESISTOR CH 1/8W 100 R873 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R718 ERJ8GEYJ300 M.RESISTOR CH 1/8W...
Page 452 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks TH200,01 ERJ12Y0R00 M.RESISTOR CH 1/2W C409-16 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U TH300,01 ERJ12Y0R00 M.RESISTOR CH 1/2W C417,18 ECUX1H272KBV C.CAPACITOR CH 50V 2700P C419 ECUX1H470JCV C.CAPACITOR CH 50V TP102,03 EYF6CU TEST POINT...
Page 453 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q319 2SC2954 TRANSISTOR R316 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K Q401-08 XN1504 TRANSISTOR-RESISTOR R317 ERJ3GEYJ221 M.RESISTOR CH 1/16W 220 R318 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K ERJ3GEY0R00 M.RESISTOR CH 1/16W R319...
Page 454 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C106-09 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U C473 ECUX1H152KBV C.CAPACITOR CH 50V 1500P C110-12 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C474 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U C113 ECUX1H820JCV C.CAPACITOR CH 50V C475...
Page 455 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C955 ECUM1C105KBM C.CAPACITOR CH 16V IC550 M62370GP 1 C0FBBD000082 C956 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC551-54 THC4053FT C958,59 ECST1AY475 T.CAPACITOR CH 10V 4.7U IC555 THC4052FT C960 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U...
Page 456 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q410,11 2SC3930 TRANSISTOR QR761 UN5113 TRANSISTOR-RESISTOR Q412 2SA1532-B TRANSISTOR QR762,63 UN5213 TRANSISTOR-RESISTOR Q413-15 2SC3930 TRANSISTOR QR820-23 UN5213 TRANSISTOR-RESISTOR Q416,17 2SC3935 TRANSISTOR QR3001-04 UN5213 TRANSISTOR-RESISTOR Q418,19 2SC3930 TRANSISTOR...
Page 457 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R181 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K R360 ERJ3GEYJ681 M.RESISTOR CH 1/16W 680 R182 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R361,62 ERJ3GEYG102 M.RESISTOR CH 1/16W R183 ERJ3GEY0R00 M.RESISTOR CH 1/16W R363...
Page 458 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R472 ERJ3GEYJ470 M.RESISTOR CH 1/16W R788 ERJ3GEYG682 M.RESISTOR CH 1/16W 6.8K R473 ERJ3GEY0R00 M.RESISTOR CH 1/16W R789,90 ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K R474 ERJ3GEYJ470 M.RESISTOR CH 1/16W R791,92 ERJ3GEYG682...
Page 459 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R964 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K R3136 ERJ3GEY0R00 M.RESISTOR CH 1/16W R965 ERJ3GEYG822 M.RESISTOR CH 1/16W 8.2K R3148 ERJ3GEYJ104 M.RESISTOR CH 1/16W 100K R967 ERJ3GEYJ470 M.RESISTOR CH 1/16W R3152...
Page 460 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks MISCELLANEOUS C1224 EEFCD0J470R E.CAPACITOR 6.3V C1225 ECUX1C106KBP C.CAPACITOR CH 16V XYN26+K6 SCREW VSC5129 HEAT SINK D1001,02 MA142WK DIODE VMG1339 THERMO-CONDUCTIVE SHEET A D1003 MA142WA DIODE D1004 MA142WK...
Page 461 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R1022 ERJ3RBD223 M.RESISTOR CH 1/16W 22K C1409 ECUX1H681JCV C.CAPACITOR CH 50V 680P R1023 ERJ3RBD273 M.RESISTOR CH 1/16W 27K C1410 ECUX1H101JCV C.CAPACITOR CH 50V 100P R1024 ERJ3RBD223 M.RESISTOR CH 1/16W 22K...
Page 462 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks QR1301 UN5112 TRANSISTOR-RESISTOR R1430 ERJ14RSJR10 M.RESISTOR CH 1/4W 0.1 QR1302 UN5211 TRANSISTOR-RESISTOR R1431 ERJ3GEYJ100 M.RESISTOR CH 1/16W QR1303 UN5111 TRANSISTOR-RESISTOR R1432 ERJ3GEYJ333 M.RESISTOR CH 1/16W 33K QR1304 UN5211 TRANSISTOR-RESISTOR...
Page 463 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C42016 ECUX1H330JCV C.CAPACITOR CH 50V C45033,34 EEVHB1C470 E.CAPACITOR C42017,18 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C45035,36 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C42019 EEVHP0J100 E.CAPACITOR 6.3V C46001 EEVHB0J101 E.CAPACITOR 6.3V 100U...
Page 464 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks D40001 MA142WK DIODE IC60010 C0EBJ0000049 D41001,02 MA142K DIODE IC60011 LVX3245QSC D41003-06 MA3J14300L DIODE IC61000 UPD16431AGC 1 C0HBA0000023 D42001,02 MA142K DIODE IC61002 THC4053FT D42003-06 MA3J14300L DIODE IC62001 S81350HGKD...
Page 465 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks QR46002 UN5213 TRANSISTOR-RESISTOR R42044 ERJ3GEY0R00 M.RESISTOR CH 1/16W QR46003 UN5113 TRANSISTOR-RESISTOR R42046 EXB24V473J COMBI.R-R QR47001,02 UN5213 TRANSISTOR-RESISTOR R42047 ERJ3GEYJ154 M.RESISTOR CH 1/16W 150K QR61000,01 UN5113 TRANSISTOR-RESISTOR R42048 ERJ3GEYJ104...
Page 466 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R45006,07 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K R48007 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K R45008-11 ERJ3RBD332 M.RESISTOR CH 1/16W 3.3K R48008 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K R45012,13 ERJ3RBD333 M.RESISTOR CH 1/16W 33K...
Page 467 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks RY41001,02 VSY2070 RELAY P9601 VJP3172D002 CONNECTOR (MALE) 1 K1KA02B00051 RY42001,02 VSY2070 RELAY SW9601 VST0076 SWITCH 1 K0E112G00013 SW40001 VSS0367-08B SWITCH SW40002 VSS0367-06B SWITCH 1 K0D161A00001 SW41001,02 VSS0342 SWITCH 2 K0D112B00056...
Page 468 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VEP80B51A USER SW P.C.BOARD 1 (RTL) D301-04 MA142K DIODE FL101 F1L1H2040004 C.CAPACITOR 50V 0.1U P9301 VJP1607T CONNECTOR (MALE) FL102,03 VLF1441P207 FILTER FL201 F1L1H2040004 C.CAPACITOR 50V 0.1U SW9301,02 EVQQSB04B SWITCH...
Page 469 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks MISCELLANEOUS ERJ3RBD272 M.RESISTOR CH 1/16W 2.7K ERJ3RBD103 M.RESISTOR CH 1/16W 10K VMS6135 P.C.B. POST (26SP-6) ERJ3RBD151 M.RESISTOR CH 1/16W 150 XSB26+3 SCREW VEE0J47 P.C.B. INT CABLE EVQB1D10809B SWITCH VST0335 SWITCH...
Page 470 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q1005 2SB1220-R TRANSISTOR J9701 VJS3417 CONNECTOR (FEMALE) 1 K1AB103A0007 Q1006,07 2SD1821-R TRANSISTOR Q1008,09 2SD1979 TRANSISTOR P9701 VJP1610T CONNECTOR (MALE) Q1010-12 2SJ280L TRANSISTOR 3 B1DGJG000002 R9702-04 VLF1315A102 FILTER...
Page 471 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks F1K0J1060002 C.CAPACITOR CH6.3V C564,65 ECUX1H102JCV C.CAPACITOR CH 50V 1000P ECUX1H220JCV C.CAPACITOR CH 50V C566 VCEA0JSP151 E.CAPACITOR 6.3V 150U C70,71 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U C567 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U C74-79...
Page 472 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks L465-69 VLF1147A241 FILTER R172 ERJ3GEYJ181 M.RESISTOR CH 1/16W 180 L470 VLF1147A121 FILTER R173 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 L471 VLP0155 COIL R174 ERJ3GEYG471 M.RESISTOR CH 1/16W 470 L472 VLF1147A121 FILTER...
Page 473 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R557 ERJ3RBD752 M.RESISTOR CH 1/16W 7.5K C9ZB00000361 R558 ERJ3GEYJ104 M.RESISTOR CH 1/16W 100K LVTH244APW 1 C0JBBZ000174 R559 ERJ3RBD752 M.RESISTOR CH 1/16W 7.5K FMM4039XC R560 ERJ3RBD102 M.RESISTOR CH 1/16W IC10...
Page 474 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R143 ERJ3GEYJ330 M.RESISTOR CH 1/16W R144 ERJ3GEYJ470 M.RESISTOR CH 1/16W R145 VRE006622152 M.RESISTOR CH 1/10W 1.5K 1 D0YD152JA008 R146,47 ERJ3GEY0R00 M.RESISTOR CH 1/16W R150-53 ERJ3RED150 M.RESISTOR CH 1/16W R155...
Page 475 < CAMERA > 1. OPTICAL UNIT 1-1. Initial Setting 1-2. R, G, B RESET DC Adjustment Unless otherwise specified, implement the adjustment BOARD ----- of the optical unit by the following setting. SDI OUT (G,B,R) 75ohm termination ADJUST Service Menu F NUMBER F5.6 <...
Page 476 1-3. R, G, B Response 1-4. H1DC Adjustment Confirmation BOARD ----- SDI OUT (G,B,R) 75ohm termination BOARD ----- ADJUST Service Menu SDI OUT (G,B,R) 75ohm termination F NUMBER F11-1/2 (2000LUX) ADJUST Service Menu MODE ----- F NUMBER OPEN (2000LUX) CHART Gray Scale Chart MODE -----...
Page 477 1-5. R, G, B PRE AMP DC 1-6 R, G, B PREPRO Level Adjustment Adjustment BOARD BOARD PRE AMP PRE PROCESS (Use the Extender Board) TP102: R DC TP102: R LEV TP202: G DC TP202: G LEV TP302: B DC TP302: B LEV ADJUST ADJUST...
Page 478 1-7. R, G, B SUB Adjustment BOARD PRE AMP IRIS = F11-1/2 TP102: R TP302: B TP202: G ADJUST Service Menu F NUMBER ----- MODE ----- CHART Gray Scale Chart M. EQ SPEC. As shown below < Switch Setting > AUTO W/B BAL : AWB, ABB IRIS = OPEN...
Page 479 2. CAMERA MAIN UNIT 1. Set the TEST SAW to “ON". 2. Set the MASTER PED to “0". 2-1. Initial setting 3. Adjust R, G, B PEDESTAL so that the step A is within the specification at the each test point. Unless otherwise specified, implement the adjustment of the optical unit by the following setting.
Page 480 2-4. R, G, B AD Level Adjustment 2-5. R, G, B Pre Knee-point Adjustment BOARD DSP 3 SDI OUT 75ohm termination BOARD PRE PROCESS ADJUST Service Menu SDI OUT 75ohm termination F NUMBER ----- ADJUST Service Menu MODE TEST Mode F NUMBER CLOSE CHART...
Page 481 2-6. 0 IRE PED Adjustment 2-7. R, G, B PRE AMP DC Adjustment BOARD ----- SDI OUT 75ohm termination BOARD PRE AMP, PRE PROCESS ADJUST Service Menu TP100: R DC [PRE PROCESS] F NUMBER CLOSE TP200: G DC [PRE PROCESS] MODE ----- TP300: B DC [PRE PROCESS]...
Page 482 2-8. R, G, B PREPRO Level 2-9. R, G, B PED TRACK Adjustment (COARSE) Adjustment BOARD BOARD PRE PROCESS (Use Extender board) PRE PROCESS TP102: R LEV [PRE PROCESS] SDI OUT 75ohm termination TP202: G LEV [PRE PROCESS] ADJUST VR404: R TRACK TP302: B LEV [PRE PROCESS] VR405: B TRACK, and Service Menu ADJUST...
Page 483 2-10. R, G, B PREPRO Level 2-11. Confirmation of the Adjustment (FINE) Modulation Factor BOARD BOARD PRE PROCESS (Use Extender board) ----- TP102: R LEV [PRE PROCESS] SDI OUT (Y OUT) 75ohm termination TP202: G LEV [PRE PROCESS] ADJUST Service Menu TP302: B LEV [PRE PROCESS] F NUMBER F5.6...
Page 484 2-12. R, G, B W/S Offset 2-13. R, G, B W/S Offset Adjustment (1) Adjustment (2) BOARD BOARD ----- ----- SDI OUT 75ohm termination SDI OUT 75ohm termination ADJUST ADJUST Service Menu Service Menu F NUMBER F NUMBER ----- CLOSE MODE ----- MODE...
Page 485 2-14. R, G, B W/S Offset 2-15. R, G, B W/S Offset Adjustment (3) Adjustment (4) BOARD BOARD ----- ----- SDI OUT 75ohm termination SDI OUT 75ohm termination ADJUST ADJUST Service Menu Service Menu F NUMBER F NUMBER CLOSE CLOSE MODE ----- MODE...
Page 486 2-16. Digital White Shading 2-17. Digital Dark Shading Adjustment Adjustment BOARD BOARD ----- ----- SDI OUT 75ohm termination SDI OUT 75ohm termination ADJUST ADJUST Service Menu Service Menu F NUMBER F NUMBER ----- CLOSE MODE ----- M. EQ The color monitor TV, WFM, the vector scope CHART Special Light Box (Spherical Type)
Page 487 2-18. Flare Adjustment 2-19. R, B GAMMA Adjustment BOARD ----- BOARD PRE PROCESS SDI OUT 75ohm termination SDI OUT 75ohm termination ADJUST ADJUST Service Menu Service Menu F NUMBER As shown below VR101 : R LEV [PRE PROCESS] VR501 : B LEV [PRE PROCESS] MODE ----- F NUMBER...
Page 488 the vector dots are within the specification. 2-20. ND Compensation 12. Set the ND filter as follows. Adjustment ND Filter: 4 13. Adjust iris so that the white level of the signal is BOARD ----- 60%. SDI OUT 75 ohm termination 14.
Page 489 3. VIDEO OUT 3-1. VF Y Output Adjustment 3-3. VTR Playback Output Level Adjustment BOARD VODEO OUT TP14 (VIDEO OUT) ADJUST BOARD VIDEO OUT F NUMBER ----- TP14 MODE ----- ADJUST CHART ----- F NUMBER ----- M. EQ Oscilloscope MODE ----- SPEC.
Page 490 < VTR > 6. SERVO 4. VTR SYSCON 6-1. T and S Reel Torque Offset 4-1. Initial Setting of DIP SW Adjustment (Release Data Saving Prohibition) BOARD SERVO 1. Turn OFF the power supply of main unit and set TP302 (T Reel), TP301 (S Reel), TG300 the DIP SW on the VTR SYSCON P.C.Board as (GND) shown below.
Page 491 6-2. Adjustment of the 6-4. PG Shifter Adjustment Tape Beginning and End and Confirmation Detection Sensitivity BOARD SERVO TP113 (HSW A), TP102 (SPA A), BOARD SERVO TP114 (HSW C), TP103 (SPA C) TP503 : Vs, TP504 : Vt ADJUST SERVICE MENU : PG SHIFT 100 ADJUST VR503 : S PHOTO, VR504 : T PHOTO INPUT...
Page 492 7. RF EQ 7-1. DRC Input Level Adjustment 7-2. ATF Input Level Adjustment BOARD RFEQ BOARD RFEQ TP401, TP403, TP405, TP407, TP400, TP402, TP404, TP406, TP660 (Trigger) TP660 (Trigger) ADJUST VR401, VR403, VR405, VR407 ADJUST VR400, VR402, VR404, VR406 INPUT Internal Color Bar INPUT Internal Color Bar...
Page 493 7-3. HSE Input Adjustment 7-4. PLAY Error Rate Confirmation (Manual Adjustment) BOARD RFEQ TP820, TP821, TP822, TP823, BOARD RFEQ TP660 (Trigger) ADJUST VR820, VR821, VR822, VR823 INPUT Internal Color Bar INPUT Internal Color Bar MODE PLAY MODE TAPE Alignment Tape (VFM3580KL) TAPE Blank Tape M.
Page 494 7-5. REC Signal Detection System 7-6. REC Signal Detection System Position Adjustment Level Adjustment BOARD RFEQ BOARD RFEQ IC104-5PIN, TP102 TP100, TP102 ADJUST VR108 Trigger (TP660 : L1L3, TP661 : R1R3, TP662 : L2L4, TP663 : R2R4) INPUT Internal Color Bar ADJUST VR101 : L1, VR100 : L3, VR103 : R1, MODE...
Page 495 < Adjustment of the R1R3 Head > < Adjustment of the R2R4 Head > 1. Connect the Oscilloscope to TP100, TP102 and 1. Connect the Oscilloscope to TP100, TP102 and TP660 (trigger). TP660 (trigger). 2. Switch the item RDS. REC ADJ to "R1". 2.
Page 496 < Detection Confirmation at SHORT PLAY Mode > 7-7. REC Signal Detection System 1. Open the SERVICE MENU and set the RDS TYPE Operation Confirmation to “S PLAY". 2. Perform confirmation by steps 1 to 8 of the BOARD RFEQ "Detection Confirmation at REC Mode".
Page 497 < AUDIO > 8. AUDIO LCD 8-1. Initial Setting 8-2. Real Time Clock Adjustment < Side Switch Setting > MONITOR SELECT : 1/2, ST BOARD AUDIO LCD AUDIO SELECT (CH1/2) : MAN TP62007 (RTC TP) AUDIO IN (CH1/2) : REAR ADJUST VC62001 : CH1...
Page 498 8-4. Audio Level Meter Adjustment 8-6. CUE REC level adjustment BOARD AUDIO LCD BOARD AUDIO LCD TP46001 : CH1, TP46002 : CH2 TP48001 ADJUST VR46001 : CH1, VR46002 : CH2 ADJUST VR48001 INPUT +4dBu, 1kHz (REAR CH1/2) INPUT +4dBu, 1kHz (REAR CH1/CH2) MODE STOP MODE...
Page 499 9. TP, VR and SW Location AUDIO LCD P.C.BOARD (VEP84331B) (COMPONENT SIDE) (FOIL SIDE) ELE-25...
Page 500: Vtr Syscon P.c.board (Vep86303C)
VIDEO OUT P.C.BOARD (VEP23500B) (COMPONENT SIDE) VTR SYSCON P.C.BOARD (VEP86303C) (FOIL SIDE) ELE-26...
Page 501 SERVO P.C.BOARD (VEP82224B) (COMPONENT SIDE) (FOIL SIDE) ELE-27...
Page 502 VIDEO MAIN P.C.BOARD (VEP83462C) (COMPONENT SIDE) (FOIL SIDE) ELE-28...
Page 503 DSP MAIN P.C.BOARD (VEP23530B) (COMPONENT SIDE) (FOIL SIDE) ELE-29...
Page 504 VTR MOTHER P.C.BOARD (VEP80B10A) (COMPONENT SIDE) RF EQ P.C.BOARD (VEP87104B) (COMPONENT SIDE) ELE-30...
Page 505: Cue P.c.board (Vep84353A)
CUE P.C.BOARD (VEP84353A) (COMPONENT SIDE) (FOIL SIDE) PRE PROCESS P.C.BOARD (VEP23534B) (COMPONENT SIDE) (FOIL SIDE) ELE-31...
Page 506: Hd Sdi Tx P.c.board (Vep83460B)
HD SDI TX P.C.BOARD (VEP83460B) (COMPONENT SIDE) PRE AMP P.C.BOARD (VEP20857A) REAR SW P.C.BOARD (VEP80B45A) (COMPONENT SIDE) (COMPONENT SIDE) CAMERA SYSCON P.C.BOARD (VEP26234C) (FOIL SIDE) ELE-32...
Page 507: Memory P.c.board (Vep23531B)
HEAD BUFF P.C.BOARD (VEP85179B) SD CARD P.C.BOARD (VEP23532A) MEMORY P.C.BOARD (VEP23531B) (COMPONENT SIDE) (COMPONENT SIDE) ELE-33...
Page 508: Servicing Fixtures & Tools
1. Servicing Fixtures & Tools Part No. Fixture & Tool Name Remarks VFK1145A Back Tension Meter (T2-M30-P) VFK1149A Post Driver (2.5mm) VFK71A Dial Torque Gauge (1.5cN-m) 150g VFK1191A Dial Torque Gauge (0.45cN-m) VFK1152 Dial Torque Gauge Adapter VFK0357 Eccentric Driver (1.5mm) VFK1154 Post Height Fixture VFK1586...
Page 509 VFK1145A (T2-M30-P) VFK1149A (2.5mm) VFK71A (1.5cN-m) Back Tension Meter (150g) Post Driver VFK1191A (0.45cN-m) Dial Torque Gauge (45g) VFK1152 VFK0357 VFK1154 VFK1586 Dial Torque Gauge Eccentric Driver Post Height Fixture Mech. Neutral Plate (L) Adapter (1.5mm) VFK1155 VFK1208 VFK1150 VFK1151 REV Position Tool (Silver) Neutral Position Tool Nut Driver (5.5mm)
Page 510 VFK1375 VFK1300 VFM3580KL AJ-CL12P AD Board Cleaning Tape Hex. Bit VFM3581KL (DAQ-12 Quatech) VFM3582KL Alignment Tape VFK1481B VFK1186 VFK0369 VFK0371 LISTA Software LISTA Cable Radio Prier Tweezers VFK0372 VFK0337 VFK1369 VFK0906 Tape Sensor Cutter Prier Phillips Driver Lubrication Oil Adjustment Cassette VFK0338 Phillips Driver VFK1642...
Page 511 1-1. How to use VFK1604 and VFK1611 When servicing the soldering side of DSP3 P.C.Board, VFK1604 and VFK1611 are needed. How to use VFK1604 and VFK1611 is shown below. 1. Removal of DSP3 P.C.Board 3. Connection of DSP3 P.C.Board 1. Remove 4 Screws (A). 1.
Page 512 2. Alignment Tape 2-1. DVCPRO Alignment Tape 2-1-1. VFM3580KL Time VIDEO (min.) SIGNAL PORPOSE SIGNAL PORPOSE SIGNAL PORPOSE Color Bar Confirmation of 0:00 SMPTE (75%) the Composite Video Level 1KHz 0VU Confirmation of the CUE Level Color Bar Confirmation of 7:00 Confirmation of (100%)
Page 513 4. Maintenance Schedule Hours of Use (unit hours) Part Name 1,000H 2,000H 4,000H 6,000H 8,000H 10,000H 12,000H Cleaning of the tape transport "C": every 500 hours Cylinder Ass’y R, Y, G R, Y, G R, Y, G R, Y, G R, Y, G R, Y, G Pinch Arm Unit...
Page 514 5. Layout of the Maintenance Parts & Sensors Cleaning Solenoid Cleaning Arm Unit Loading Motor Cylinder Unit A/C Head Pinch Solenoid DEW Sensor Capstan Motor Thrust Screw Unit Tape End Tape BEG/END Detect Sensor Detect Sensor Pinch Arm Tension Unit Sensor T Reel Motor T Reel...
Page 515 6. Emergency Eject Remove the cassette. If the cassette cannot be ejected by pressing the Return the rubber cap to its original position. EJECT button, use a screwdriver or similar tool to press and turn the EMERGENCY screw. This enables the cassette to be removed.
Page 516 7. Cleaning Method Note: Turn the power OFF during cleaning. Make sure the power is OFF before cleaning. Use ethanol (more than 99% purity) as cleaning liquid. 7-1. Cylinder Head Cleaning Method: (Daily) Clean heads by applying even pressure and rotating 7-4.
Page 517 8. Basic Setting Menu Operations 8-1. Service Menu Operation 1. Press the “SHIFT” and “+” buttons of the Time Code Operation Button simultaneously and press the MENU button, and CAMERA unit’s SERVICE MENU screen is displayed. 2. When the MENU button is pressed again, the VTR unit’s SERVICE MENU screen is displayed. Press the “SHIFT”...
Page 518 8-2. Design Menu Operation Press the “SHIFT” and “RESET” buttons of the Time Code Operation Button simultaneously and press the MENU button, and switch to the CAMERA unit’s SERVICE MENU screen display mode. At first “CAM MAIN MENU1” screen is displayed as shown below, but by pressing the JOG Dial button following screen through the “CAM DESIGN MENU”...
Page 519 8-3. Displaying Sub-Menus and 2. Move the cursor to the desired SUB MENU item, Setting Procedures and press the JOG Dial button. The SUB MENU is now displayed. Setting procedures are same for both the USER (The cursor appears besidce the title part of the MENU and ENGINEER MENU.
Page 520 3. Turn the JOG Dial button to move the cursor to the 7. To move to the another SUB MENU, turn the JOG desired item to be set, and press the JOG Dial Dial button to move the cursor to the title part of the button.
Page 521 8-5.Setting Menu Configurations CAM SERVICE MENU SERVICE ADJ R GAMMA (SERV) G GAMMA (SERV) B GAMMA (SERV) DEFECT COMPENSATION COMPENSATION COMP ON GAIN INTERLACE MODE R CH G CH B CH TRIPLE OFFSET CURSOR BOX READ DATA WRITE DATA ENTRY (AUTO) PICKUP LEVEL R PICKUP LEVEL G PICKUP LEVEL B...
Page 522 CAM DESIGN MENU VDRIVE 1 R_0G R_SUB VDRIVE 2 R_RESET DC VA13M G_0G VA24M G_SUB G_RESET DC B_0G B_SUB B_RESET DC H1DC P16V H2DC R_PADC VSHIN G_PADC B_PADC DA RESET PREPRO 1 G_WS_OFFSET B_WS_OFFSET PREPRO 2 R_GAIN R_WS_OFFSET G_GAIN G_PRE_CLIP B_GAIN B_PRE_CLIP R_PED...
Page 523 VTR SERVICE MENU VTR SERVICE 1/3 CONCEAL INNER ECC OUTER ECC VITERBI ADJUST ADDRESS ADJUST DATA BER ADJ BER SPEED CW REC AUTO EQ RDS. REC ADJ RDS TYPE SERVO MODE VTR SERVICE 2/3 T TORQUE S TORQUE PG SHIFT 100 HSW_A_RIZE HSW_A_FALL HSW_C_RIZE...
Page 524 9. Service Menu Item Contents < CAMERA Section > 9-1. CAM SERVICE MENU SETTING INIT. MEANING of SETTING & ITEM RANGE VALUE OUTLINE of FUNCTION SERVICE ADJ R GAMMA (SERV) -30-+30 Adjustment for R GAMMA. G GAMMA (SERV) -30-+30 Adjustment for G GAMMA. B GAMMA (SERV) -30-+30 Adjustment for B GAMMA.
Page 525 9-2. CAM DESIGN MENU SETTING INIT. MEANING of SETTING & ITEM OUTLINE of FUNCTION RANGE VALUE VDRIVE 1 R_OG 00-FF OG voltage setting of R CCD. R_SUB 00-FF Sub voltage setting of R CCD. R_RESET DC 00-FF Reset DC voltage setting of R CCD. G_OG 00-FF OG voltage setting of G CCD.
Page 526 (CAM DESIGN MENU) SETTING INIT. MEANING of SETTING & ITEM RANGE VALUE OUTLINE of FUNCTION LSI REG SET1 A (0) or B (1) ----- ----- Not used MEMORY SEL ----- ----- Not used ADR_H ----- ----- Data address of Flash memory (at CAM_SYS) ADR_L ----- -----...
Page 527 (CAM DESIGN MENU) SETTING INIT. MEANING of SETTING & ITEM OUTLINE of FUNCTION RANGE VALUE DSP D/A SET GAIN G ----- ----- G A/D converter input gain adjustment GAIN B ----- ----- B A/D converter input gain adjustment GAIN R ----- ----- R A/D converter input gain adjustment...
Page 528 9-4. VTR SERVICE 2/3 SETTING INIT. Backup MEANING of SETTING & ITEM Backup RANGE VALUE (INH.) OUTLINE of FUNCTION T TORQUE -128-+127 Take-up reel torque adjustment S TORQUE -128-+127 Supply reel torque adjustment PG SHIFT 100 ----- ----- PG shifter adjustment HSW_A_RIZE 0-4095 0x500...
Page 529 9-7. TEST MODE MEANING of SETTING & ITEM SETTING RANGE INIT. VALUE OUTLINE of FUNCTION ON : TEST MODE (VTR RUNNING TEST) AGING MODE OFF/ON (Repeat 5 minutes REC and 1 minute STAND-BY) 9-8. ERROR LOG MEANING of SETTING & ITEM SETTING RANGE INIT.
Page 530 10. Adjustment after Optical Unit Replacement When replace the Optical Unit (PRE AMP, CCD 10-2. Electrical Adjustment PULSE, DRIVE Board included), execute adjustment as following procedures. Execute the Confirmation and Adjustment as following In this case, do not need to execute the Optical Unit items.
Page 531 11.DIAG-MENU Display 11-1-1. Version Display Operation Procedure (CAMERA Part) 1. Open the “ENG menu” (Press “MENU Button” more than 3 second.) 2. Open “CAM MAIN MENU 4” page (Press JOG Dial) 3. Select “DIAGNOSTIC” page (Turn and Press JOG Dial), then the Software version for each item can be comfirmed.
Page 532 11-2-3. How to Reset Hour Meter 1. Open the “Design Menu” and then press “MENU Button”. 2. Open “VTR DESIGN MENU” page. (Press JOG Dial) 3. Select “VTR DESIGN MENU” item. (Turn & press JOG Dial) **** VTR DESIGN MENU **** ®VTR DESIGN MENU TEST MDOE ERROR LOG...
Page 533 12. Error Rate Display and Confirmation Method 12-1. Error Rate Display Method 1. Open the “VTR SERVICE MENU”. 2. Select “VTR SERVICE 1/3” page.(Turn & press JOG Dial) 3. Confirm “BER SPEED” setting is “SLOW”. 4. Select "BER ADJ" by rotating JOG Dial and Select R/P head to be confirmed. BER ADJ item OFF / L1L3 / R1R3 / L2L4 / R2R4 (exept OFF) 5.
Page 534 13. Internal Switch Setting Method The switche settings on each circuit board are shown below. “Factory use only” switches must be set to the “Factory setting”. FACTORY BOARD Ref. No. FEATURE SETTING AUDIO LCD ON (FIXED) Factory use only SW40001 Not used OFF(FIXED) Factory use only SW40002...
Page 535 14. Circuit board layout E12. SERVO P.C.BOARD E9. VTR MOTHER P.C.BOARD E11. SERVO FLEX P.C.BOARD E13. HEAD BUFF P.C.BOARD E32. OPERATE P.C.BOARD E38. BACK TALLY P.C.BOARD E39. SIDE BNC P.C.BOARD E40. SDI BNC P.C.BOARD E30. REAR SW P.C.BOARD E5. CAMERA MOTHER P.C.BOARD E31.
Page 536 15. PLD Version Upgrade Method The AJ-HDC27VP has two Programmable Logic Devices (PLD) by ALTERA Corporation on CAM_SYS P.C.Board (IC100) and VM (Video Main) P.C.Board (IC321). See following procedures for details. 15-1. Preparation Equipment Remarks VFK1590 (Interface board) CPLD WRITER VFK1590P2 (Connection cable: Supplied with VFK1590) D-sub 25pin-25pin Cable Straight type (male - female), Length must be within 1meter...
Page 537 15-3. Version-up Procedures 1. Boot up MAX+plus II 9.6 programmer only. 2. On main window, select tab “MAX-plus II” and then ”Programmer”. 3. On main window (Programmer window is displayed), select tab “Options” and then “Hardware Setup”. 4. On Hardware Setup dialog, set Hardware Type to “ByteBlaster (MV)”. 5.
Page 538 Click “Program button” on Programmer dialog. When Progress bar reaches at point of “100”, the message “Programming completed” appears, then PLD version upgrade is completed. Click “OK Button” on “Programming complete” message dialog. Progress bar 10. Turn the power of camcorder OFF and ON. 11.
Page 539 16. Flash Memory Version Upgrade Method The AJ-HDC27VP has Flash memories IC202 on CAM_SYS P.C.Board, IP100 on VTR_SYS P.C.Board and IC100 on ERVO P.C.Board. Version upgrade procedures for each Memory is shown below. IC 202 IP 100 P6100 P2 Connector Connector VTR_SYS P.C.B (Component side) (Component side)
Page 540 16-1-2. Setting of VFK1304A Before executing version upgrade, Set “Cable type setting” and ”Writing function setting” on VFK1304A as shown below. If any settings are wrong, it can not communicate to PC. Cable type Writing function setting (SW1) Board setting (R1, R2, R3, R4) CAM_SYS R1 = OPEN...
Page 541 16-2-3. Software Version Upgrading 1. Copy all files in “Version up data (vvvsi file)” to arbitrary directory. (Please make a directory) 2. Type “xxxxx.bat” and then hit RETURN key. 3. Data transfer will be started from PC to camcorder. Data transferring scheme is shown below. Scheme of Flash memory writing ERASE : Data all clear on Flash memory WIRTE : Data writing to Flash memory...
Page 542 16-3. Version Upgrade for VTR_SYS P.C.Board 16-3-1. Connection 1. Connect RS-232C Cable between connector P2 on VFK1304A and COM1 port on PC. (Refer to Figure. 16- 2. Connect Flat cable between connector P1 on VFK1304A and connector P6100 on VTR_SYS P.C.Board, and then set SW1 on VFK1304A according to Figure.
Page 543 5. When settings on the “Setup panel” is completed, click “OK(O)” button. “VSI212E Main panel” will be opened as shown below. 6. Click “Start (S)” button on the “Main panel” window, (Click “Exit” button to quit, Click “Setup (Z) to RETURN to Setup panel”) 7.
Page 544 16-4. Version Upgrading for SERVO P.C.Board 16-4-1. Connection 1. Connect RS-232C Cable between connector P2 on VFK1304A and COM1 port on PC. (Refer to Figure. 16- 2. Connect Flat cable between connector P1 on VFK1304A and connector P9811 on VTR MOTHER P.C.Board, and then set SW1 on VFK1304A according to Figure.
Page 545 Position No. “1” 3. Close LENS Iris and then execute “ABB” by the front switch. 17-2. Connection To facilitate blemish compensation’s work, connect the camcorder and the HD TV-monitor through HD SDI output. (With 75-ohm termination.) HD-SDI Panasonic HD TV-monitor INF-38...
Page 546 17-3. Compensation flow The AJ-HDC27VP has Automatic blemish compensation function. Execution procedure of Automatic compensation is shown below. <DEFECT COMPENSATION>menu setting Execute automatic compensation “<ENTRY (AUTO)> menu” Automatic Blemish detection through compensation in whole screen. Result confirmation (at TV monitor) Fine adjustment by cursor manually.
Page 547 17-4. Compensation Procedures 17-4-1. Initial setting (Menu setting of DEFECT COMPENSATON page) Before start an adjustment, Set items (CAM SERVICE level) following portion. ( portion , Sometimes it isn’t possible to compensate blemish (es) in case of wrong setting.) <DEFECT COMPENSATION> →...
Page 548 17-4-3. Result confirmation After execution of automatic compensation the number of detection result and the number of blemish which wasn’t compensated will be displayed in lower part of “ENTRY (AUTO)” page as the result status table. (Refer to Figure Ble-3) Please confirm whether all blemishes were compensated with this status display by viewing the TV-monitor.
Page 549 17-4-4. Manual compensation procedure In case it couldn’t compensate all blemish in automatic compensation, it is also possible to perform blemish compensation manually by using cursor. Following shows concrete manual compensation procedures by the case required. I ) Manual compensation for position which was not detected automatically 1.
Page 550 II ) When compensation is fully impossible In this case, there are two solutions by manual compensation. a ) Re-setup of PICKUP LEVEL 1. Open “<ENTRY (AUTO)>” page in CAM SERVICE level. 2. Re-Setup “PICKUP LEVEL R/ G or B” items to level down (down detection level). 3.
Page 551 17-5. Remarks 17-5-1. Delete all cursor position data in the built-in memory 1. Open “<EDIT / DELETE>” page in CAM SERVICE level. 2. Set “ALL DATA CLEAR?” item to ON by JOG DIAL operation. 3. Set “REALY ALL CLEAR?” item to ON by JOG DIAL operation. 4.
Page 552 17-6. Trouble Shooting Symptom Cause Check point Blemish can’t be compensated Wrong setting of fixed setting <DEFECT COMPENSATION> page has items which must have even COMPENSATION item item. fixed setting. on menu is set to “ON”. Confirm if those items are fixed as factory default. (See "4-1. Initial Setting”...
Page 553 SERVICING FIXTURES & TOOLS Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VFK1145A BACK TENSION METER 1 (T2-M30-P) VFK1149A POST DRIVER (2.5mm) VFK71A DIAL TORQUE GAUGE 1 (1.5cN-m) VFK1191A DIAL TORQUE GAUGE 1 (0.45cN-m) VFK1152 DIAL TORQUE GAUGE ADAPTER...
Page 554: Mechanical Chassis Assembly (1)
MECHANICAL CHASSIS ASSEMBLY (1) PRT-2...
Page 555: Mechanical Chassis Assembly (2)
MECHANICAL CHASSIS ASSEMBLY (1) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VDG1189 IDLER GEAR A VXL2614 IDLER ARM ASS'Y VMB3011 IDLER SPRING VXP1700 IDLER GEAR ASS'Y VMM0422 E-E ROD VEM0658 S REEL MOTOR ASS'Y 1 (M) VEM0659 T REEL MOTOR ASS'Y...
Page 556 MECHANICAL CHASSIS ASSEMBLY (2) PRT-4...
Page 557 MECHANICAL CHASSIS ASSEMBLY (2) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks XVE2B4FZ HEX SCREW VXA6630 A/C HEAD BASE (1) ASS'Y XVE2B6FP HEX SCREW VED0419 A/C HEAD 1 (M) XVE2B12FP HEX SCREW VXA6067 A/C HEAD BASE (2) ASS'Y VXQ0439...
Page 558: Chassis Frame Assembly (1)
CHASSIS FRAME ASSEMBLY (1) PRT-6...
Page 559: Chassis Frame Assembly (2)
CHASSIS FRAME ASSEMBLY (1) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks J0KE00000012 FERRITE CORE VYH0280 HANDLE ASS'Y J0KE00000033 FERRITE CORE VJF1319 SHOE VSC5159 BNC GND VGL0783 TALLY COVER VWJ12C2120L0 FLEXIBLE CABLE VMP5585 P.C.BOARD ANGLE VEE0L56...
Page 560: Chassis Frame Assembly (3)
CHASSIS FRAME ASSEMBLY (2) PRT-8...
Page 561 CHASSIS FRAME ASSEMBLY (2) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VWJ15C2038L0 CABLE VEQ2750 HEAD OPTICAL VEE0K11 CABLE VYK9465 FRONT CASE U J0KG00000011 FERRITE CORE VMP6764 P.C.B HOLDER ANGLE(UPPER) VKN0149 SPEAKER NET VMP6765 P.C.B HOLDER ANGLE(LOWER) VGH4396...
Page 562 CHASSIS FRAME ASSEMBLY (3) PRT-10...
Page 563 CHASSIS FRAME ASSEMBLY (3) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VYF2689 CASSETTE COVER ASS'Y VEP23534B PRE PROCESS P.C.BOARD VYP7703 SIDE CASE (L) ASS'Y VEP000G7B CAMERA MOTHER P.C.BOARD VMG1334 PROTECT RUBBER VEP26234C CAMERA SYSCON P.C.BOARD VMG1270...
Page 564: Cassette Compartment Assembly
CASSETTE COMPARTMENT ASSEMBLY PRT-12...
Page 565 CASSETTE COMPARTMENT ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VXA6870 CASSETTE UP ASS'Y VXA6890 HOLDER ASS'Y VXA6893 TOP PLATE VXL2696 PRESSURE LEVER VMB3063 PRESSURE LEVER SPRING VXA6728 PROTECTOR SHAFT (2) L VXA6729 PROTECTOR SHAFT (2) R VMS6198...
Page 566: Packing Parts Assembly
PACKING PARTS ASSEMBLY PRT-14...
Page 567 PACKING PARTS ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VYQ2047 CUSHION (U) VPF0230 POLYETHYLENE BAG VQT9419 OPERATING INSTRUCTIONS VYQ2048 CUSHION (B) VPG0A84 PACKING CASE VEJ1672 BATTERY ADAPTOR ASS'Y VFC3443 SHOULDER BELT VPK2298 ACCESSORY BOX (B) VPK2280...
Page 568 1. Name of Tape Transportation Cylinder Unit T1 Post S1 Post T2 Post S2 Post A/C HEAD T3 Post S3 Post 21.7mm Capstan shaft S4 Post T4 Post S5 Post DVCPRO (L) :VFK1149 (Post Driver) :VFK1151 (Nut Driver) NAME LIMIT S1 Post UPPER S2 Post...
Page 569 2. Table of Test Point <Table of Test Point> Name AJ-HDC27VP [ Reel Torque Adjustment ] S-REEL Reel output Voltage SERVO C.B.A : TP301 Adjustment Point SERVO C.B.A : VR502 T-REEL Reel output Voltage SERVO C.B.A : TP302 Adjustment Point SERVO C.B.A : VR501 SERVO C.B.A...
Page 570 3. Test Point and VR Location VR401 VR402 VR950 VR503 TP102 TP103 TG300 TP301 TP503 VR501 TP302 TP504 VR502 TP501 TP601 VR503 TP502 TP602 TP113 TP402 TP114 TP901 MECH-3...
Page 571 4. Mechanical Adjustment Procedures 4-1. Post Height Pre-adjustment 4-2. Tension Adjustment Flowchart MODE EJECT (POWER OFF) TOOL VFK1149 or VFK1149A (Post Driver) START VFK1151 (2.5mm Nut Driver) VFK1154 (Post Height Fixture) 4-3. Tension Arm Offset Adjustment Confirm that the post is in unloading condition. Confirm that the Reel Table is located at M- Cassette position.
Page 572 4-4. Tension Arm Neutral Position Adjustment SPEC 2.5 V ± 0.1 V TEST POINT Tension: TP402 ADJ. Base position of Tension Regulator Board MODE STOP TOOL Digital Volt Meter VFK1208 (black with hole) NOTE: Do not use magnetized tweezers and Screw Driver.
Page 573 4-5. Tension Arm PLAY and REV 4-6. Tension Regulator Spring Voltage Adjustment and Adjustment Confirmation SPEC 110 ± 10 mN-m (11 ± 1gf) TEST POINT Tension: TP402 SPEC PLAY : 3.8 V ± 0.05 V ADJ. Tension Regulator Spring hook (B) REV : 1.2 V ±...
Page 574 4-7. REV Tension Confirmation SPEC 180mN ± 20mN (18gf ± 2gf) TEST POINT Tension: TP402 MODE STOP TOOL VFK1188A (Dial Tension Gauge) Digital Volt Meter Remove the Cassette Up Unit. Place the VTR into no tape loading mode. Push the tension post to the direction R by the tension gauge as shown in Figure 4-7 until the voltage at the test point becomes 1.2V (If means REV position).
Page 575 Play back the beginning portion of the tape. 4-8. Tension Confirmation Insert the tension meter between S3 post and S4 post as shown in figure 4-8-2. SPEC PLAY: 0.06N ± 0.01N (6gf ± 1gf) Confirm that the tension value is within the REV: 0.09N ±...
Page 576 4-9. Photo Sensor Voltage Adjustment SPEC 3.2 VDC ± 0.8 VDC TEST POINT S-Reel: TP301 T-Reel: TP302 ADJ. VR503: S-Reel VR501: T-Reel MODE STOP TAPE VFK1423 (Tape Beg./End M Cassette) VFK1369 (Tape Beg./End L Cassette) M. EQ Oscilloscope Insert the VFK1423 or VFK1369 (For only L- Cassette playback models) and measure the voltage at the test point.
Page 577 4-10.Tape Path Adjustment Procedure START Each Post Limit Conf. and A/C Head Adj. 4-11. Envelope Waveform Adj. 4-22. PLAY Tape Path Limit Conf. 4-12. Post Limit Confirmation (PLAY) S4 Post Conf. 4-23. Conf. of ENV on 4-14. A/C Head Tilt Adjustment REV/REW FF mode 4-15.
Page 578 [ Adjustment Procedure ] 4-11. Envelope Waveform 1. Adjust both channels envelope by connecting the Adjustment test point Lch and Rch alternately. 2. Playback the alignment tape. V1/Vmax, V2/Vmax, V3/Vmax ≥ 0.8 SPEC 3. Adjust S1 and T1 post height so that the envelope signal is within the specification.
Page 579 4-12. Post Limit Confirmation (PLAY) Post limit is shown in the following table. SPEC Curl does not appear on tape edge MODE PLAY TAPE Blank tape TOOL VFK1149 or VFK1149A (Post Driver) VFK1151 (Nut Driver) 1. Confirm that the tape path limit meets specification in following table.
Page 580 4-13. A/C Head Adjustment Adjustment SCREW Adjustment Method Torque item !. Adjust screw A after loosen screw G. Tilt adjustment Tighten direction : Decrease Cue level Loosen direction : Increase Cue level None ". Tighten screw G after finish adjustment screw A. (refer to following item “Azimuth adjustment &...
Page 581 1. For Tilt and Azimuth adjustment, loosen the screw Confirm the screw (A) isn’t loose, before perform A/C (G) first and tighten the screw (G) after finish Head Tilt adjustment. The screw (A) should be always adjustment. And if need to turn the screw (A) and touch to top of A/C Head.
Page 582 4-14. A/C Head Tilt Adjustment 4-15. A/C Head Height Adjustment C1, C2 ³ 1.6V SPEC SPEC Curl does not appear on tape edge. Lower limit at T3 post TEST CUE AUDIO: TP4 ADJ. POINT SCREW A, G (A/C Head) CTL: TP901 MODE PLAY ADJ.
Page 583 4-16.A/C Head Tilt Confirmation 4-17.A/C Head Height Confirmation A/Amax ³ 0.8 SPEC TEST C1, C2 ³ 1.6V CUE AUDIO: TP4 SPEC POINT TEST CUE AUDIO: TP4 ADJ. SCREW A, G (A/C Head) POINT CTL: TP901 MODE PLAY ADJ. SCREW B, H (A/C Head) TAPE VFM3580KM or VFM3580KL MODE...
Page 584 4-18.A/C Head Azimuth and X Value Adjustment SPEC As shown in figure below TEST R/P-ENV L13: TP400 R/P-HSW L13: TP500 POINT R/P-ENV R13: TP401 R/P-HSW R13: TP501 -250µs £ t1, t2 £ +250µs R/P-ENV L24: TP402 R/P-HSW L24: TP502 R/P-ENV R24: TP403 R/P-HSW R24: TP503 CUE: TP4 CTL: TP901...
Page 585 4-19.REV Tape Path Confirmation and Adjustment (T4 Post Height Adjustment) •. C1, C2 ³ Cp1, Cp2´0.75 SPEC NOTE: C1, C2: CTL output REV (-1) mode A: UPPER B: FREE C: LOWER Cp1, Cp2: CTL output PLAY (+1) mode. ‚. Lower limit at T3 post on REV mode. ƒ.
Page 586 4-20. REV (-1) Mode Setting Procedure Set the VTR to STILL mode by press “PLAY” button twice. Press “PLAY” “RESET” button simultaneously. NOTE: Above setting only apply to item “REV Tape Pass Confimation and Adjustment (T4 post height adjustment)”. All models should be set to 25M mode with REV (-1) speed playback.
Page 587 4-22.Play Tape Path Limit Confirmation SPEC Each post limit shown in figure below. MODE PLAY TAPE VFM3580KM/L or Blank Tape Tape limit (refer to figure) Adjustment Adjustment Post Name Point Item S5 post S4, S5 post Post Height Pre-Adjustment S4 (Tension) post S1 post S1, T1 post ENV Waveform Adjustment...
Page 588 4-24. Confirmation of Play Start Envelope SPEC Envelope Waveform signal should be rising up immediately at PLAY mode. TEST POINT TP400: R/P-ENV L13 TP402: R/P-ENV L24 TP401: R/P-ENV R13 TP403: R/P-ENV R24 REW/REV ® PLAY FF® Loading completion ® PLAY MODE TAPE L Cassette (123min, Recorded tape) Tape beginning portion...
Page 589 4-26.FF, REW mode Tape Path Limit 4-27.Screw Lock Tight of A/C Head Confirmation and T3, T4 Post <Screw Lock Tight of A/C Head> SCREW A OTHER SPEC Each post limit shown in below figure SCREWS MODE FF, REW Lock Tight Grew 1/3 of the 1/3 of the TAPE...
Page 590 4-29. LISTA Adjustment Procedure NOTE : 1. Refer to the item “4-32. LISTA Sensitivity Adjustment and Sensitivity Detection” about procedure of the sensitivity adjustment and sensitivity detection. 2. Refer to the item “4-33. LISTA Linearity Adjustment and Waving Measurement” about procedure of the linearity adjustment.
Page 591 4-30. LISTA Connection and Boot Up TEST ATF ERR L13: TP601 POINT ATF ERR L24: TP602 R/P-HSW L13: TP113 R/P-HSW L24: TP114 M. EQ. PC (Personal Computer) (A/D board should be installed) TAPE VFM3581KM or VFM3581KL (LISTA) TOOL VFK1481B (LISTA Software), VFK1186 (LISTA Cable) 1.
Page 592 6. Next, select the Serial number of the Alignment tape on the screen. If LISTA software does not have alignment tape data registered, data entry is needed. Press the ESC key, then main menu is displayed on the screen. And select the item “<4>...
Page 593 4-31. How to Entry the Attachment Data of Alignment Tape 1. Select the item “<4> Alignment Tape” on the LISTA main menu. 2. Select the item “<2> ENTRY” on the alignment menu. 3. After the screen of <<Alignment Tape Data Entry>>is displayed, first input the Serial Number of Alignment tape printed on the label.
Page 594 4-32. LISTA Sensitivity Adjustment and Sensitivity Detection TEST POINT ATF ERR L13: TP601 ATF ERR L24: TP602 R/P-HSW L13: TP113 R/P-HSW L24: TP114 TG300 VTR MODE PLAY ADJ. MODE RPL GAIN 100 150 ± 15 mV/um ADJUST (ATF GAIN) TAPE VFM3581KL (LISTA) Sensitivity Adjustment Procedure 1.
Page 595 Sensitivity Detection Procedures 1. Set the adjustment mode. (Refer to [LISTA Adjustment Modes] of the “Table of Test Point”.) 2. Playback the LISTA Alignment Tape. 3. Select the item “<1> Sensitivity Measurement” on the LISTA main menu, and then “1.2% Speed. . .” appears on the screen.
Page 596 4-33. LISTA Linearity Adjustment and Waving Measurement SPEC. Linearity: less than 3um, Waving: less than 1.5um TEST POINT ATF ERR L13: TP601 ATF ERR L24: TP602 R/P-FSW L13: TP113 R/P-HSW L24: TP114 TG300 VTR MODE PLAY ADJ. MODE ADJUST S1 and T1 Post Height TOOL VFK1149 or VFK1149A (Post Driver) TAPE...
Page 597 POINT : The part of left side of waveform (entrance side) is adjusted by height of S1 post and part of right side of waveform (exit side) is adjusted by height of T1 post. Lower part of above waveform of figure is displayed lead of Cylinder. When the post driver is removed from upper part of post, linearity waveform may be changed.
Page 598 4-34. Self-REC/PLAY Envelope Waveform Confirmation All of the head output are within the specification as shown below. Confirm in the 50M mode when the VTR or Camera Recorder is 50M models. × When using the M Cassette (66 min.) or L Cassette (126 min.) SPEC.
Page 599 5. Major Mechanical Parts Replacement & Adjustment Procedures When mechanical parts are replaced, pay attention to the following notes. 1. Always turn power off before replacing any parts. 2. If any adjustment is required after replacing parts, perform the required adjustment. 3.
Page 600 5-2. Cleaning Arm Unit 5-3. T1 Guide Position Adjustment Replacement 1. Place the unit to loading condition without the tape. (Removal) 2. Observe the clearance (B) between T1 Guide and 1. Unscrew the 2 screws (A) and remove the T1 T1 post as shown in Figure 5-3, and make sure Guide as shown in Figure 5-2.
Page 601 5-4. Adjustment Flow Chart After Cylinder Unit Replacement After change the Cylinder Unit, please perform the adjustment and confirmation as following flow chart. 4-28. Tape Damage Confirmation (Long Play Type) START Mechanical Adjustment (Section 4) Note: Envelope level Adjustment 4-8. Tension Confirmation Note: PG Shifter Adjustment 4-11.
Page 602 5-5. Supply & Take-up Reel Rotor Unit Replacement <Supply Reel Rotor Unit Replacement> <Take Up Reel Rotor Unit Replacement> (Removal) (Removal) Disconnect the connector P2614 on the Disconnect the connector P2615 on the Servo Servo P.C.Board. P.C.Board. Turn the Emergency Gear until S1 Post move Unscrews the 2 screws (E) and then remove to center loading position and remove the S5 the Take Up Reel Stopper.
Page 603 5-6. Main Brake Torque 5-7. Pinch Solenoid Replacement Confirmation (Removal) S Reel, T Reel TEST Remove the Cassette Cover, both Side Panel, MODE EJECT (Power OFF) Cassette Up Unit and open the VTR MAIN. TOOL Torque Gauge (VFK71A, VFK1191A) Disconnect the connector P610 on the Servo Torque Gauge Adapter (VFK1152) P.C.Board.
Page 604 5-8. Pinch Solenoid Position 5-9. Pinch Arm Unit Replacement Adjustment (Removal) SPEC. T = 0.3 mm Refer to item “5-7.Pinch Solenoid Replacement” TEST Gap T to remove the Pinch Solenoid Unit. ADJUST Remove the cut washer (A) and remove the Pinch Screw (A) and Hole (B) Solenoid Lever as shown in Figure 5-9.
Page 605 5-10. Loading Motor Unit 5-11. Mode SW Unit Replacement Replacement (Removal) Disconnect the connector P612 on the Servo (Removal) P.C.Board (B). Disconnect the connector P611 on the Servo Remove the Pinch Solenoid Unit and Loading P.C.Board. Motor Unit. (Refer to item 5-7 and 5-10.) Remove the Pinch Solenoid Unit.
Page 606 5-12. Main Cam Gear Replacement 5-13. Thrust Screw Replacement and Adjustment (Removal) Remove the Thrust Adjustment Screw. Remove the Pinch Solenoid Unit and Loading Clean the capstan shaft with an applicator. Motor Unit. (Refer to item 5-8 and 5-10.) Put the oil (VFK0906) on a new Thrust Remove the Main Cam Gear as shown in Figure Adjustment Screw and install the upper end of the 5-12.
Page 607 5-14. S5 Post Base Unit Replacement (Removal) Unscrew the screw (A) and remove the S5 Post Base Unit as shown in Figure 5-14. (Installation) Install the S5 post Base Unit follow the removal steps in reverse order. Note: Be careful the S5 Post Base Unit is installed to mech.
Page 608 5-15. Tension Arm Unit <Tension Arm Adjustment Flow Chart> Replacement (Removal) START Remove the Cut Washer (A) and hang off the Tension Regulator Spring, and then remove the Tension Arm Unit as shown in Figure 5-15. (Installation) 4-3. Tension Arm Offset Voltage Adjustment Install the new Tension Arm Unit following the removal steps in reveres order.
Page 609 5-16. S1 Post Loading Arm Unit (Installation) Replacement & Adjustment Install the new S1 Loading Arm Unit following the removal steps in reverse order, and then S1 Post (Removal) Loading Arm Unit Phase Adjustment should be Remove the S5 Post Base Unit. (Refer to item 5- performed as follows.
Page 610 5-17. T1 Boat Unit Replacement (Confirmation and Adjustment Procedure) and Adjustment Tool : T Arm Height Adj. Tool A (VFK1542) T Arm Height Adj. Tool B (VFK1543) (Removal) T1 boat replacing procedure Unscrew the screw (C) and remove the T1 Post Turn clockwise emergency red screw and set from Loading Rail as shown in Figure 5-16 on the the hole of T1 Boat Unit to match line of take up side...
Page 611 (2) Checking smooth movement of T1 Boat Unit. Check X-Value. Check smooth loading and unloading operations. If not smooth (especially, at curve of rail), take the following steps. Check deformation of T1 boat joint. If no deformation, then reposition the loading rail as describe below.
Page 612 5-18. T1 Loading Arm Unit 5-19. A/C head Replacement Replacement & Adjustment & Adjustment (Removal) <Tools required> Remove the cylinder Unit. (Refer to item 1-1) Nut Driver (5.5mm: VFK1150) Move the T1 Post to loading direction by manual Hex Driver (VFK1148) ejecting method until the screw (D) can be Hex Wrench (VFK1190) removal position as shown in Figure 5-16.
Page 613 Remove the 2 screws (A) and disconnect the 2 (Installation) connector on the REAR JACK P.C.Board and Remove the Shield Case from the New A/C Head SERVO P.C.Board, and then remove the A/C and solder the lead wires to New A/C Head. Head from the A/C Head Plate as shown in Figure (Refer to Figure 5-19-3) 5-19-2.
Page 614 <A/C Head Adjustment> After change the A/C Head, please perform the following steps. START 4-14. A/C Head Tilt Adjustment 4-15. A/C Head Height Adjustment 4-18. A/C Head Azimuth & X-value Adjustment NOTE: PG Shifter Adjustment 4-29. to 4-33. LISTA Adjustment 4-34.
Page 615 5-20. Cleaner Solenoid 5-20-1. Cleaner Solenoid Position Replacement & Adjustment Adjustment <Tools required> (Removal) Eccentric Driver (VFK0357) Disconnect the connector P618 on the SERVO P.C.Board. Press the iron core of Cleaner Solenoid. Unscrew the 2 screws (A) and remove the Observe the clearance (D) between Cleaning Arm Cleaner Solenoid Unit as shown in Figure 5-20-1.
Page 616 5-21. MIC Base Unit Replacement (Removal) Disconnect the connector P607 on the Servo P.C.Board. Unscrew the 2 screws (A) and remove the MIC Base Unit as shown in Figure 5-21. (Installation) Install the new MIC Base Unit according to the opposite procedures of removing.
Page 617 COMPONENT CAM OVERALL 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR9H41 (1/1) SCM001...
Page 618 COMPONENT VTR OVERAL 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR9H14 (1/1) SCM002...
Page 619 COMPONENT CAMERA MOTHER 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N32 (1/1)-1 VEP000G7B SCM003...
Page 620 COMPONENT VTR MOTHER 01/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M54 (1/3) VEP80B10A SCM004...
Page 621 COMPONENT VTR MOTHER 02/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M54 (2/3) VEP80B10A SCM005...
Page 622 COMPONENT VTR MOTHER 03/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M54 (3/3) VEP80B10A SCM006...
Page 623 AJ-HDC27VP 10V1500 COMPONENT INT CONNECT 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N41 (1/1) VEP20804A SCM007...
Page 624 COMPONENT CCD SENSOR 01/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q52 (1/4)-1 VEP20854A SCM008...
Page 625 COMPONENT CCD SENSOR 02/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q52 (2/4)-1 VEP20854A SCM009...
Page 626 COMPONENT CCD SENSOR 03/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q52 (3/4)-1 VEP20854A SCM010...
Page 627 COMPONENT CCD SENSOR 04/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q52 (4/4) VEP20854A SCM011...
Page 628 AJ-HDC27VP COMPONENT 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q53 (1/1)-1 VEP20855B SCM012...
Page 629 AJ-HDC27VP COMPONENT MEMORY (MEM-720P) 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR30105 (1/1)-2 VEP23531B SCM013...
Page 630 COMPONENT DRIVE 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q54 (1/1)-1 VEP20856A SCM014...
Page 631 COMPONENT PRE AMP 01/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q55 (1/4)-1 VEP20857A SCM015...
Page 632 COMPONENT PRE AMP 02/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q55 (2/4)-1 VEP20857A SCM016...
Page 633 COMPONENT PRE AMP 03/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q55 (3/4)-1 VEP20857A SCM017...
Page 634 COMPONENT PRE AMP 04/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q55 (4/4) VEP20857A SCM018...
Page 635 COMPONENT PRE PROCESS 01/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30128 (1/5) VEP23534B SCM019...
Page 636 COMPONENT PRE PROCESS 02/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30128 (2/5) VEP23534B SCM020...
Page 637 COMPONENT PRE PROCESS 03/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30128 (3/5) VEP23534B SCM021...
Page 638 COMPONENT PRE PROCESS 04/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30128 (4/5) VEP23534B SCM022...
Page 639 C0ABGA000019 C0ABGA000019 C0ABGA000019 COMPONENT PRE PROCESS 05/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30128 (5/5) VEP23534B SCM023...
Page 640 COMPONENT DSP MAIN (DSP-720P) 01/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30104 (1/5) VEP23530B SCM024...
Page 641 AJ-HDC27VP AJ-HDC27VP COMPONENT DSP MAIN (DSP-720P) 02/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30104 (2/5)-2 VEP23530B SCM025...
Page 642 COMPONENT DSP MAIN (DSP-720P) 03/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30104 (3/5) VEP23530B SCM026...
Page 643 AJ-HDC27VP COMPONENT DSP MAIN (DSP-720P) 04/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30104 (4/5)-2 VEP23530B SCM027...
Page 644 COMPONENT DSP MAIN (DSP-720P) 05/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR30104 (5/5) VEP23530B SCM028...
Page 645 AJ-HDC27VP AJ-HDC27VP COMPONENT CAMERA SYSCON 01/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S27 (1/6)-3 VEP26234C SCM029...
Page 646 AJ-HDC27VP AJ-HDC27VP AJ-HDC27VP COMPONENT CAMERA SYSCON 02/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S27 (2/6)-4 VEP26234C SCM030...
Page 647 AJ-HDC27VP AJ-HDC27VP COMPONENT CAMERA SYSCON 03/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S27 (3/6)-5 VEP26234C SCM031...
Page 648 AJ-HDC27VP COMPONENT CAMERA SYSCON 04/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S27 (4/6)-2 VEP26234C SCM032...
Page 649 AJ-HDC27VP COMPONENT CAMERA SYSCON 05/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S27 (5/6)-2 VEP26234C SCM033...
Page 650 AJ-HDC27VP AJ-HDC27VP AJ-HDC27VP AJ-HDC27VP COMPONENT CAMERA SYSCON 06/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S27 (6/6)-4 VEP26234C SCM034...
Page 651 AJ-HDC27VP AJ-HDC27VP AJ-HDC27VP COMPONENT VIDEO OUT 01/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR3Y47 (1/3)-2 VEP23500B SCM035...
Page 652 AJ-HDC27VP COMPONENT VIDEO OUT 02/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR3Y47 (2/3)-1 VEP23500B SCM036...
Page 653 COMPONENT VIDEO OUT 03/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR3Y47 (3/3)-1 VEP23500B SCM037...
Page 654 COMPONENT HEAD BUFF (FE) 01/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR5543 (1/6) VEP85179B SCM038...
Page 655 SHIELD CASE SHIELD CASE COMPONENT HEAD BUFF (RA) 02/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR5543 (2/6)-3 VEP85179B SCM039...
Page 656 SHIELD CASE SHIELD CASE COMPONENT HEAD BUFF (RA) 03/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR5543 (3/6)-3 VEP85179B SCM040...
Page 657 SHIELD CASE COMPONENT HEAD BUFF (RP HA) 04/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR5543 (4/6) VEP85179B SCM041...
Page 658 COMPONENT HEAD BUFF (LOGIC) 05/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR5543 (5/6) VEP85179B SCM042...
Page 659 COMPONENT HEAD BUFF (CONNECTOR) 06/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR5543 (6/6) VEP85179B SCM043...
Page 660 COMPONENT RF EQ (EQ Ach) 01/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (1/18)-1 VEP87104B SCM044...
Page 661 COMPONENT RF EQ (EQ Bch) 02/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (2/18)-1 VEP87104B SCM045...
Page 662 COMPONENT RF EQ (EQ Cch) 03/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (3/18)-1 VEP87104B SCM046...
Page 663 COMPONENT RF EQ (EQ Dch) 04/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (4/18)-1 VEP87104B SCM047...
Page 664 COMPONENT RF EQ (AMP) 05/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (5/18) VEP87104B SCM048...
Page 665 COMPONENT RF EQ (EVR) 06/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (6/18) VEP87104B SCM049...
Page 666 COMPONENT RF EQ (LOGIC 1) 07/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (7/18) VEP87104B SCM050...
Page 667 COMPONENT RF EQ (LOGIC 2) 08/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (8/18) VEP87104B SCM051...
Page 668 COMPONENT RF EQ (HSE) 09/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (9/18) VEP87104B SCM052...
Page 669 COMPONENT RF EQ (REC DATA SELECT) 10/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (10/18)-1 VEP87104B SCM053...
Page 670 COMPONENT RF EQ (FE1) 11/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (11/18)-1 VEP87104B SCM054...
Page 671 COMPONENT RF EQ (ENVDET) 12/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (12/18)-1 VEP87104B SCM055...
Page 672 COMPONENT RF EQ (POWER 1) 13/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (13/18) VEP87104B SCM056...
Page 673 COMPONENT RF EQ (POWER 2) 14/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (14/18) VEP87104B SCM057...
Page 674 COMPONENT RF EQ (POWER 3) 15/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (15/18) VEP87104B SCM058...
Page 675 COMPONENT RF EQ (POWER 4) 16/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (16/18)-1 VEP87104B SCM059...
Page 676 COMPONENT RF EQ (PLD) 17/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (17/18)-1 VEP87104B SCM060...
Page 677 COMPONENT RF EQ (CONNECTOR) 18/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR7D55 (18/18)-1 VEP87104B SCM061...
Page 678 VSI***** COMPONENT SERVO 01/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (1/10)-2 VEP82224B SCM062...
Page 679 COMPONENT SERVO 02/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (2/10) VEP82224B SCM063...
Page 680 COMPONENT SERVO (REEL DRIVE) 03/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (3/10) VEP82224B SCM064...
Page 681 COMPONENT SERVO (REEL FG, TENSION) 04/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (4/10)-1 VEP82224B SCM065...
Page 682 VSI***** COMPONENT SERVO 05/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (5/10) VEP82224B SCM066...
Page 683 COMPONENT SERVO 06/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (6/10) VEP82224B SCM067...
Page 684 COMPONENT SERVO 07/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (7/10)-1 VEP82224B SCM068...
Page 685 COMPONENT SERVO 08/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (8/10) VEP82224B SCM069...
Page 686 COMPONENT SERVO 09/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (9/10) VEP82224B SCM070...
Page 687 COMPONENT SERVO 10/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR2D40 (10/10) VEP82224B SCM071...
Page 688 AJ-HDC27VP COMPONENT VIDEO MAIN (L VDS, HD SDI IF) 01/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (1/11) VEP83462C SCM072...
Page 689 COMPONENT 02/11 VIDEO MAIN (CHARA, HDSDI TX, DAC) NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (2/11) VEP83462C SCM073...
Page 690 COMPONENT VIDEO MAIN (PREP) 03/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (3/11) VEP83462C SCM074...
Page 691 COMPONENT VIDEO MAIN (COMPA) 04/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (4/11) VEP83462C SCM075...
Page 692 COMPONENT VIDEO MAIN (COMPB) 05/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (5/11) VEP83462C SCM076...
Page 693 COMPONENT VIDEO MAIN (PLD) 06/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (6/11)-1 VEP83462C SCM077...
Page 694 COMPONENT VIDEO MAIN (ECC) 07/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (7/11) VEP83462C SCM078...
Page 695 COMPONENT VIDEO MAIN (SYNC CLK) 08/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (8/11) VEP83462C SCM079...
Page 696 COMPONENT VIDEO MAIN (CLOCK DIST) 09/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (9/11) VEP83462C SCM080...
Page 697 AJ-HDC27VP COMPONENT VIDEO MAIN (CONNECTOR) 10/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (10/11) VEP83462C SCM081...
Page 698 COMPONENT VIDEO MAIN (POWER) 11/11 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X23 (11/11) VEP83462C SCM082...
Page 699 COMPONENT VTR SYSCON 01/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (1/8) VEP86303C SCM083...
Page 700 COMPONENT VTR SYSCON 02/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (2/8) VEP86303C SCM084...
Page 701 COMPONENT VTR SYSCON 03/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (3/8) VEP86303C SCM085...
Page 702 COMPONENT VTR SYSCON 04/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (4/8) VEP86303C SCM086...
Page 703 COMPONENT VTR SYSCON 05/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (5/8) VEP86303C SCM087...
Page 704 COMPONENT VTR SYSCON 06/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (6/8) VEP86303C SCM088...
Page 705 COMPONENT VTR SYSCON 07/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (7/8) VEP86303C SCM089...
Page 706 COMPONENT VTR SYSCON 08/08 NAME CIRCUIT BOARD NO. DRAWING NO. KR6S44 (8/8) VEP86303C SCM090...
Page 707 COMPONENT AUDIO LCD (CH1 INPUT) 01/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (1/12) VEP84331B SCM091...
Page 708 COMPONENT AUDIO LCD (CH2 INPUT) 02/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (2/12) VEP84331B SCM092...
Page 709 COMPONENT AUDIO LCD (LIM/AGC) 03/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (3/12) VEP84331B SCM093...
Page 710 COMPONENT AUDIO LCD (A/D D/A) 04/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (4/12) VEP84331B SCM094...
Page 711 COMPONENT AUDIO LCD (OUTPUT) 05/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (5/12) VEP84331B SCM095...
Page 712 C46021 C46022 COMPONENT AUDIO LCD (MONITOR) 06/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (6/12) VEP84331B SCM096...
Page 713 COMPONENT AUDIO LCD (CUE DELAY) 07/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (7/12) VEP84331B SCM097...
Page 714 COMPONENT AUDIO LCD (CUE) 08/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (8/12) VEP84331B SCM098...
Page 715 COMPONENT AUDIO LCD (CONNECTOR) 09/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (9/12) VEP84331B SCM099...
Page 716 IC60010 C0EBJ0000049 COMPONENT AUDIO LCD (uCOM) 10/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (10/12) VEP84331B SCM100...
Page 717 DP61000 L5AAAGE00001KB COMPONENT AUDIO LCD (LCD DRIVE) 11/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (11/12) VEP84331B SCM101...
Page 718 COMPONENT AUDIO LCD (RTC) 12/12 NAME CIRCUIT BOARD NO. DRAWING NO. KR4H63 (12/12) VEP84331B SCM102...
Page 719 COMPONENT REAR JACK 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M57 (1/1) VEP80B13B SCM103...
Page 720 COMPONENT REAR SW 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N42 (1/1) VEP80B45A SCM104...
Page 721 COMPONENT 01/01 NAME IMPORTANT SAFETY NOTICE: CIRCUIT BOARD NO. DRAWING NO. COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS FOR SAFETY. KR4J28 (1/1) VEP84353A WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE SAME TYPE. SCM105...
Page 722 VRE0221H22MT AJ-HDC27VP COMPONENT POWER MAIN 01/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR1D67 (1/4) VEP81192C SCM106...
Page 723 AJ-HDC27VP COMPONENT POWER MAIN 02/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR1D67 (2/4) VEP81192C SCM107...
Page 724 COMPONENT POWER MAIN 03/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR1D67 (3/4) VEP81192C SCM108...
Page 725 AJ-HDC27VP AJ-HDC27VP COMPONENT POWER MAIN 04/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR1D67 (4/4)-1 VEP81192C SCM109...
Page 726 AJ-HDC27VP COMPONENT POWER SUB 01/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR1E00 (1/3) VEP81204B SCM110...
Page 727 COMPONENT POWER SUB 02/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR1E00 (2/3) VEP81204B SCM111...
Page 728 AJ-HDC27VP COMPONENT POWER SUB 03/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR1E00 (3/3)-1 VEP81204B SCM112...
Page 729 AJ-HDC27VP AJ-HDC27VP COMPONENT FRONT TOGGLE 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M60 (1/1) VEP80B16B SCM113...
Page 730 COMPONENT JOG MENU 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N50 (1/1) VEP80B52A SCM114...
Page 731 POWER EXT SMALL P.C.BOARD VEP80B81A FOIL CUT POWER SW P.C.BOARD VEP80B49A COMPONENT MONITOR SW (MONITOR VR) 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N45 (1/1) VEP80B47A SCM115...
Page 732 COMPONENT SERVO FLEX 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M93 (1/1) VEP80B38A SCM116...
Page 733 COMPONENT HD SDI TX (ENC) 01/02 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X20 (1/2) VEP83460B SCM117...
Page 734 COMPONENT HD SDI TX (P/S, DRV) 02/02 NAME CIRCUIT BOARD NO. DRAWING NO. KR3X20 (2/2)-1 VEP83460B SCM118...
Page 735 COMPONENT SD CARD 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR30106 (1/1) VEP23532A SCM119...
Page 736 COMPONENT TOGGLE SW 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M59 (1/1) VEP80B15A SCM120...
Page 737 COMPONENT SYNCHRO SW 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N48 (1/1) VEP80B50A SCM121...
Page 738 COMPONENT USER SW 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N49 (1/1) VEP80B51A SCM122...
Page 739 COMPONENT MENU SW 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0N56 (1/1) VEP80B53A SCM123...
Page 740 COMPONENT FRONT MIC 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0M61 (1/1) VEP80B17A SCM124...
Page 741 COMPONENT EXT DC (DC INPUT) 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0P37 (1/1) VEP80B75A SCM125...

Panasonic DVCPRO HD AJ-HDC27VP Service Manual

English

1 Servicing Fixtures & Tools

2 Alignment Tape

3 List of Recommended Measuring and Instruments

4 Maintenance Schedule

5 Layout of the Maintenance Parts & Sensors

6 Emergency Eject

7 Cleaning Method

8 Basic Setting Menu Operations

9 Service Menu Item Contents

10 Adjustment after Optical Unit Replacement

11 DIAG-MENU Display

12 Error Rate Display and Confirmation Method

13 Internal Switch Setting Method

14 Circuit Board Layout

15 PLD Version Upgrade Method

16 Flash Memory Version Upgrade Method

17 Blemish Compensation Method

Unknown

Quick Links

Chapters

Related Manuals for Panasonic DVCPRO HD AJ-HDC27VP

Summary of Contents for Panasonic DVCPRO HD AJ-HDC27VP
