Chapter 8: VPN—Virtual Private Networking
terminating at the local SOHO 6. The SOHO 6 also allows users on
the Trusted network to access networks on Branch Office VPN
tunnels terminating at the local SOHO 6. If you purchase the
VPNforce Port, you receive one MUVPN connection to the
Optional network as well. Additional VPNforce Port user licenses
can be purchase separately. Complete documentation on
configuring your SOHO 6 once this upgrade option is purchased
and redeemed are at:
http://support.watchguard.com/sohoresources/

View the VPN Statistics

The SOHO 6 has a configuration page that displays a variety of
VPN statistics to assist you in monitoring VPN traffic as well as
troubleshooting potential problems.
To view the VPN Statistics page:
1 With your Web browser, go to the System Status page using the
Trusted IP address of the SOHO 6.
For example, if using the default IP address, go to: http://192.168.111.1.
2 From the navigation bar on the left side, select VPN = > VPN
Statistics.
The VPN Statistics page appears.
94 WatchGuard Firebox SOHO 6.1
