VTech VT1121 User Manual

FEATURE
20
21
19
11. LCD PANEL
12. < Scroll Key
1. HOOK Switch
13. > Scroll Key
2. M1 Button (one - Touch Memory)
14. DELETE Button
3. M2 Button (one - Touch Memory)
15. DIAL Button
4. M3 Button (one - Touch Memory)
16. Handset cord Jack
5. Dial Keys
17. Volume Switch
6. FLASH Button
18. TONE/PULSE Switch
7. STORE Button
19. Coiled cord Jack
8. AUTO Button
20. RINGER Hi/Low Switch
9. REDIAL Button
21. Line modular Jack
10. NEW CALL Indicator
3
IMPORTANT SAFETY INSTRUCTIONS
When useing your phone equipement,basic 11. Do not overload wall outlets and exlension
precautions should always be followed to re- cords as this can result in the risk of fire or
duce the risk of fire,electic shock and injury to electric shock.
persons,including the following: 12. Unplug this product from the wall outlet and
refer servicing to a VTECH authorized ser-
1. Read and understand all instructions. vice facility under the following conditions:
2. Following all warnings and instructions marked A. When the power supply cord or plug is dam-
on the product. aged or frayed.
B. IF liquid has been spilled into the product.
3. Unplug this product from the wall outlet before
cleaning. Do not use liquid,cleaners or aerosol C. IF the product has been exposed to rain or
cleaners.Use a damp cloth for cleaning. water.
4. Do not use this product near water(for ex- D. IF the product does not operate normally by
ample; near a bath tub,kitchen sink,or swim- following the operating instructions. Adjust
only those controls that are covered by the
ming pool).
5. Do not place this product on unstable stand,or operating instructions.Adjust only those con-
table. the product may fall,causing serious trols that are covered by the operating
damage to the product. instructions,because improper adjustment of
other controls may result in damage and will
6. Stols and openings in the cabinet and the back
or bottom are provided for ventilation.To pro- often require extensive work by a VTech au-
tect it from overheating, these openings must thorized technician to restore the product to
not be blocked by placing the product on a normal operation.
E. IF the product has been dropped and the cabi-
sofa, rug, or other similar surface.This prod-
net has been damaged.
uct should never be placed near or over a
radiator or heat register.This product should F. IF the product exhibits a distinct change in per-
not be placed in a built-in installation where formance.
proper ventilation is not provided. 13. Avoid using a telephone (other than a cordless
type)during an electrical storm. There may be
7. This product should be operated only from the
type of power source indicated on the mark- a remote risk of electric shock from lighting.
ing label.If you are not sure of the type of 14. Do not use the telephone to report a gas leak
power supply,consult your dealer or local in the vicinity of the leak.
power company.
VTECH TELECOMMUNICATIONS LTD.
8. Do not allow anything to rest on the power
cord. Do not locate this product where the cord
will be abused by persons walking on it. SERVICE DEPT. In the US
9. Never push objects of any kind into this prod- at 1-800-595-9511.
In Canada,call VTech Electronics Ltd
uct through cabinet slots as they may touch
dangerous voltage points or short out part that at 1-800-267- 7377.
could result in a risk of fire or electric
shock.Never spill liquid of any kind on the prod- SAVE THESE INSTRUCTIONS
uct.
10. To reduce the risk of electric shock, do not
disassemble this product,but take it to a VTech
authorized service facility.Opening or remov-
ing cabinet parts other than specified access
doors may expose you to dangerous voltages
or other risks.Incorrect reassembling can
cause electric shock when the appliance is
subsequently used.
1
INSTALLATION
A. Installing the Batteries
1. Insert a flat blade screwdriver into the battery
door lock and open the battery cover located
on the top of the base. Please note this con-
struction is for compliance with safety regula-
tions. Install the batteries according to the il-
lustrated diagram.
Desktop Usage
1. Unwrap the telephone line cord.
2. Insert one plug of the telephone line cord
into the Line Modular Jack on the bottom of
the base.
3. Insert the other modular plug into the tele-
phone wall jack.
FEATURES
* 50 Name and Number Caller ID
* Caller ID data includes (name, phone num-
ber,date,and time of the call).
* Clock and call timer.
IMPORTANT: Be sure that the batteries are
* Display number dialing capability.
installed correctly. Wrong polarity may dam-
* Emergency dialing capability at power fail-
age the unit.
ure
2. For better performance and longer operat-
* 3 language operation (English, French, and
ing time, we recommend the use of alka-
Spanish)
line batteries.
* Flash function
(a) Do not mix old and new batteries.
* A 32-digit last number redial.
(b) Do not mix alkaline, standard (carbon-zinc)
* 3 one touch memories.
or rechargeable (nickel-cadmium)batteries.
* 10 three touch memories.
3. If the unit is not to be used for an extended
* NEW CALL indicator.
period of time, remove all the batteries.
* Tone and pulse select switch.
Connecting the Telephone Line Cords:
* Ringer Hi/low select switch.
One coiled handset cord, and a telephone * Handset volume NORM/LOUD switch
line cord are packed with this unit. Insert
* Temporary Tone Feature.
one modular plug of the coiled cord into the
* Message waiting indicator.
handset jack and the other plug into the on * "Low battery" indicator.
the left side of the base. * Repeat Call indicator.
4
CAUTION
TO REDUCE THE RISK OF INJURY TO PER- 9. Do not store this product, or the batteries pro-
vided with or identified for use with this prod-
SONS, READ AND FOLLOW THESE
uct, in high-temperature areas. Batteries that
INSTRUCTIO NS .
are stored in a freezer or refrigerator for the
purpose of extending shell life should be pro-
1. Use only the type and size batteries designed
tected from condensation during storage and
for this product.
defrosting. Batteries should be stabilized at
Do not dispose of the batteries in a fire. The
room temperature prior to use after cold
cell may explode. Check with local codes for
storage.
possible special disposal instructions.
2. Do not open or mutilate the batteries Released
electrolyte is corrosive and may cause dam-
age to the eyes or skin. It may be toxic if swal-
lowed
3. Exercise care in handing batteries in order not
to short the battery with conducting materials
such as the rings, bracelets and keys. The
battery or conductor may overhead and cause
burns.
4. Do not attempt to recharge the batteries pro-
vided with or identified for use with this prod-
uct. The batteries may leak corrosive electro-
lyte or explode.
5. Do not attempt to recharge the batteries pro-
vided with or identified for use with this prod-
uct by heating them. Sudden release of the
battery electrolyte may occur causing burns
or irritation to eyes or skin.
6. When replacing batteries, all batteries should
be replaced at the same time. Mixing fresh and
discharged batteries could increase cell pres-
sure and rupture the discharged batteries.
(Applies to products employing more than one
separately replaceable primary battery.)
7. When inserting batteries into this product, the
proper polarity or direction must be observed.
Reverse insertion of batteries can cause
charging, and that may result in leakage or
explosion. (Applies to product employing more
than one separately replaceable primary bat-
tery.)
8. Remove the batteries from this product if the
product will not be used for a long period of
time (several months or more) since during
this time the battery could leak in the product.
Discard "dead" batteries as soon as possible,
since "dead" batteries are more likely to leak
in a product.
2
SETTING
SETTING THE CALLER ID:
Note: Only input area codes 2 and 3 if
there is more than one local area code
Note: We recommend that you disconnect tele-
within the same area. Otherwise press
phone line when programming your telephone.
the DEL Button to skip Area Codes 2 and 3.
Enter Long Distance Code
Setting the CALLER ID includes language se-
7. The display will show "- - - -" above "LONG
lection, area code pre-set (area code 1,2,3
DIST CODE" and the leftmost digit will flash
and long distance code) and Time/Date set-
to prompt for the Long Distance Code to be
ting in this order. To start, press and hold < , >
set.
and DEL Buttons simultaneously for about 6
seconds until 'ENTER LANGUAGE' appears
Note: Users located in the United States
in the display. Please note this is for initial set-
and Canada are required to input "1" as
up only. If you need to edit the settings later,
their Long Distance Code.
follow the instructions TO CHANGE THE
CALLER ID at the end of this section in or-
8. Input your area code using the dialing keys
der to avoid deleting all previous CID setti-
or press < or > to select, Press DEL Button
ngs.
to confirm.
9. The display will then show "12:00AM 1/01"
Note: If you do not press any button within
above "ENTER TIME DATE". The Hour digit
30 seconds , your unit will automatically ter-
will flash to prompt for the Time to be set.
minate the setting and revert to the standby
mode with the display showing the current
Setting Time and Date
time and date.
10. Input Time in the order of Hour and Minute
using the Dialing Keys. To enter a single digit
Select the Language
number, press [0] followed by that number.
1. The display will show "ENG", "ESP" and
Example: press [0] [1] [3] [0] keys to set for
"FRA" with "ENG" for English language,
1:30 AM.
"ESP" for Spanish and "FRA" for French.
11. Press< or> key for "AM"or "PM".
2. Press < or > buttons until your desired lan-
12. Press DEL button to confirm selection.
guage flashes.
13. Input Date in the order of Month and Day
3. Press DEL Button to confirm selection.
using the dialing keys. To enter a single digit
4. The display will show " [1]———" above "EN-
number, press [0] followed by that number.
TER AREA CODE" and the leftmost digit fol-
Example: press [0] [3] [3] [0] keys to set for
lowing [1] will flash to prompt for your local
March 3 0.
Area Code to be set.
14. Date digit stops flashing indicating the set up
Enter Your Area Code
has been completed.
5. Input your area code using the dialing keys
or press < or > to select, press DEL Button
Note: On receiving a caller ID call, the Date
to confirm.
and Time of your unit will automatically be
6. Continue to input Area Codes 2 and 3 if nec-
updated to synchronize with the date and
essary.
time registered by the Central Office. On
completion of setting, the unit will revert to
the standby mode displaying the current time
and date and TOTAL: " 0" and NEW : 0.
5
