• Never use the product or any of its parts as a step.
Stepping on the product can stress and break parts,
and may result in dangerous operating conditions
from leaking exhaust gases, fuel leakage, oil
leakage, etc.
• Make sure that you have knowledge about all
controls and adjustments before operation.
• Do not overload the product. Also, do not overload
individual panel receptacles. These outlets are
protected against overload with circuit breakers. If
amperage rating of any circuit breaker is exceeded,
that breaker opens and electrical output to that
receptacle is lost.
• Never start or stop engine with electrical devices
plugged into the receptacles and devices turned on.
Safety devices on the product
WARNING: Read the warning instructions
that follow before you use the product.
• Do not use a product with defective safety devices.
• Do a check of the safety devices regularly. If the
safety devices are defective, speak to your
Husqvarna service agent.
Power switch
Use the power switch to start and stop the engine.
(Fig. 25)
Circuit breakers
The circuit breakers prevents overload in the product.
Information about rated value of the circuit breaker is
shown near the circuit breaker.
(Fig. 26)
Ground terminal
The ground terminal makes sure that the product is
correctly grounded. Before each operation, a ground
wire must be connected to the ground terminal.
Introduction
WARNING: Read and understand the safety
chapter before you assemble the product.
To assemble the accessory kit
(G5500P, G8500P)
1. Learn the parts of the accessory kit. (Fig. 33)
1420 - 002 - 02.03.2020
(Fig. 27)
Safety instructions for maintenance
WARNING: Read and understand the
warning instructions that follow before you
do maintenance on the product.
• For safety reasons, the manufacturer recommends
that the maintenance of this equipment is carried out
by an Authorized Dealer. Inspect the generator
regularly, and contact the nearest Authorized Dealer
for parts needing repair or replacement.
• This product is equipped with a muffler that has a
spark arrester. The spark arrester must be
maintained in effective working order by the owner/
operator.
• The exhaust system must be properly maintained.
Do nothing that might make the exhaust system
unsafe or non-compliant with local codes and/or
standards.
• Before performing maintenance on the product,
disconnect the engine starting battery (if equipped)
to prevent accidental start up. Disconnect the cable
from the battery terminal indicated by a negative,
NEG or (–) first. Reconnect that cable last.
• Any attempt to crank or start the engine before it has
been properly serviced with the recommended oil
may result in engine failure.
• When working on the product, always disconnect the
spark plug cap from spark plug and keep the spark
plug cap away from the spark plug.
• Hot oil may cause burns. Allow engine to cool before
draining oil. Avoid prolonged or repeated skin
exposure to used oil. Thoroughly wash exposed
areas with soap.
• The warranty of the product does not cover items
that have been subjected to operator abuse of
negligence. To receive full value from the warranty,
the operator must maintain the product as instructed
in this operator's manual.

Assembly

2. Assemble the accessory kit. Refer to the illustrations.
a) Wheel assembly: (Fig. 34)
b) Handle assembly: (Fig. 35)
7
