Viking DCWH Specification Sheet

Standard Features & Accessories
All models include
• Adjustable duct cover (for 8 – 9'
ceilings) is standard
• Must also purchase interior or exterior
ventilator kit, sold separately (see
Installation Notes & Accessories for
recommended Viking ventilator
products)
• Heat sensor turns the ventilator on full
power when cooking temperatures
reach uncomfortable levels
• Variable speed controls for custom
venting—separate on/off switch allows
you to leave ventilator at favorite/most-
used setting
• 12-hour timer built into ventilator
controls
• Delay feature allows you to set the
ventilator to shut off on its own from
10 to 30 minutes later
• 24"D. (tests show 24"D. hoods perform
properly over 27"D. ranges)
• Heavy-duty construction; sleek,
contemporary design and styling
Model Options
DCWH Designer
Chimney Wall Hood
FINISH DETAILS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Golden Mist (GM), Lemonade (LE),
Sage (SA), Mint Julep (MJ), Sea Glass (SE),
Iridescent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Red (RR), Apple
Red (AR), Burgundy (BU), Plum (PL),
Chocolate (CH), and Cobalt Blue (CB).
• Accessory Rail Option*—Front of hood.
(Must be ordered factory installed. Rail not
available on ledge & ledgeless models.)
ORDERING INSTRUCTIONS
First specify model number, followed by color code (DCWH3042SS). If ordering optional decorative rail, specify code at end
(DCWH3042SSCR).
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M
Built-In Classic Chimney Wall Hood—
Standard, w/Ledge, & Ledgeless
o Virtually seamless stainless steel
design with no visible screws
• Easy cleanup
o Dishwasher-safe, stainless steel mesh
filters efficiently remove grease and
heated vapors from the air, and are
easily removed for quick cleaning
(frame and mesh are stainless steel)
See Dimensions & Specifications
•
table for number of filters per model
o Design of low-profile filter system
means less interior hood space to be
cleaned
o Canopy interior is completely lined in
stainless steel for increased rigidity,
seamless appearance, and easy cleaning
• 50-watt halogen lights with dimmer
control
• Power switch and dimmer control are
separate, allowing you to leave dimmer
at favorite position
o See Dimensions & Specifications
table for number of lights per model
DCWL Designer
Chimney Wall Hood
w/Ledge
o Stainless Steel/Chrome (CR)—Stainless
steel rail with chrome supports/brackets
and hooks (included).
o Brass Rail Option (BR)—nameplate, rail,
supports/brackets, and hooks
(included). Brass components have a
durable protective coating for
maintenance-free normal use.
• 1 - 8 8 8 - V I K I N G 1
VENTILATION
Model numbers
CLASSIC CHIMNEY WALL HOODS
• DCWH3042—30"W./12"H.
• DCWH3644—36"W./14"H.
• DCWH4244—42"W./14"H.
• DCWH4844—48"W./14"H.
CLASSIC CHIMNEY WALL HOODS WITH
LEDGE
• DCWL3342—33"W./12"H.
• DCWL3944—39"W./14"H.
• DCWL4544—45"W./14"H.
• DCWL5144—51"W./14"H.
CLASSIC CHIMNEY WALL HOODS,
LEDGELESS
• DCWN3042—30"W./12"H.
• DCWN3644—36"W./14"H.
• DCWN4244—42"W./14"H.
DCWN4844—48"W./14"H.
DCWN Designer
Chimney Ledgeless
Wall Hood
R E L E A S E D 1 2 / 1 / 0 7
© 2 0 0 7 V R C — INFORMATION SUBJECT TO CHANGE
