Page 1: Table Of Contents
Contents Parts and Functions Safety Precautions Installation Drawing of Outdoor Unit Tools Necessary Installation Instruction Installation Procedures 8-16 Operation and Performance Others and Test Run 18-21 Malfunction 22-24 No.0010573317 Please read this manual carefully before using Keep this operation manual for future reference... -
Page 2: Parts And Functions
Parts and Functions AU242FHBHA AU242FHBIA AU282FHAIA AU282FHAHA AU342FHAIA Air inlet Air outlet Air inlet Service panel AU482FIAIA AU482FIBIA AU482FIBHA AU522FIAIA AU522FIAKA AU48NFIAIA AU48NFIBIA AU48NFIBJA AU52NFIAKA AU55NFIAIA AU60NFIAKA Air inlet Air outlet Air inlet Service panel Cautions: Please cut off power supply of the outdoor unit when don't use the air conditioner for a long... -
Page 3: Safety Precautions
Safety Precautions Read carefully this "SAFETY PRECAUTIONS" to ensure a proper operation of the system. There are four kinds of precautions and suggestions as follows: Warning:An improper handing could lead to grave result like a death, serious injury, etc. Caution:An improper handing could lead to injury or malfunction; a very serious problem could occur depending on situation. - Page 4 Safety Precautions WARNING Neither stand on the air conditioner nor place Do not wash the air conditioner with water. something on it. It could cause electric shocks. There are risks of falling or injury by collapsed object. Execute proper grounding. Ground wires should never connect to a gas pipe, city water pipe, lightning conductor rod or ground wire of the telephone.
- Page 5 Safety Precautions The following instructions should be followed when installing your new refrigerant air conditioner. This air conditioner uses environmentally friendly refrigerant (R407C). 1.R407C refrigerant requires a higher system pressure and is more likely to be affected by moisture, oxides and grease. If polyol ester is used, special care should be taken to avoid contamination from moisture, dust, refrigerant as well as refrigeration oil in the cooling system.
-
Page 6: Installation Drawing Of Outdoor Unit
Installation Drawing of Outdoor Unit Maximal length and drop height permissible of refrigerant piping,please look page 10. Following is an example: Model: Outdoor unit AU482~522 type 18 Ceiling concealed type Piping Gas pipe Liquid pipe Outdoor unit Position MP2A 09 Ceiling concealed type 15.88mm 9.52mm Drop height... -
Page 7: Tools Necessary
Tools Necessary Unit fixing Fix the installation bracket in the selected area according to the dimension as shown in the Fig. Then fix the outdoor unit to the installation bracket. More than 60cm >10cm >10cm >15cm >60cm Installation dimension of outdoor unit (mm) Installation Tools 1. -
Page 8: Installation Instruction
Installation Instruction Please read these "Safety Precautions" first then accurately execute the installation work. Though the precautionary points indicated herein are divided under two headings, "WARNING " and "CAUTION ", those points which are related to the strong possibility of an installation done in error resulting in death or serious injury are listed in the "WARNING"... -
Page 9: Installation Procedures
Installation Procedures Selection of the installation place Installation place Avoid install the air Install the air conditioner firmly on the foundation conditioner near the place that can fully support the weight of the unit. where possibility of inflammable gas leakage exists. - Page 10 Installation Procedures Connecting piping Piping operating precautions 1. When Using braze welding to connect the half union, inflate nitrogen to avoid pipe oxidation. 2. Use new clean piping as refrigerant piping. Be careful not to let water or foreign matters enter the pipe when operating. 3.
- Page 11 Installation Procedures Connecting piping AU242~342 type: Maximal length and drop height permissible of refrigerant piping Piping part Permissible value +a+b+c Total length of piping (actual length) Longest piping L Actual length Piping length of indoor unit which is furthest to the first branch piping L Up outdoor Drop height between indoor and...
- Page 12 Installation Procedures Connecting piping 4) Turn on the Nitrogen bottle valve, ensuring that air outlet pressure at the pressure reducing valve increases to 0.5Mpa(5kg/cm g), and then turn on the valve which connects the gas side Pipes to and the instrument distributor. Preesure 0.5MPa Air offtake Air intake...
- Page 13 Installation Procedures Connecting piping Test if pressure descends. No descend Passing Pressure descends Check leaking point When the temperature has a 1* difference, a variety of 0.01Mpa(0.1Kg/cm g) will occur. Modification is necessary when testing. Leakage point check In condition of pressure descend when doing test step 1-3, check leakage at each joint by listening, touching and using soap water to find out the leakage point.
- Page 14 Installation Procedures Connecting piping Refrigerant charge After air purge, replace the vacuum pump with refrigerant pump to charge refrigerant. Calculation of refrigerant charge amount Refrigerant precharged at factory does not include the amount necessary for field using. The amount necessary for charging piping is according to the calculation result. Additional charge amount is according to the piping diameter and length in job site to calculate.
- Page 15 Short Power supply Power wire (connecting to unit) (connecting to unit) circuit protector Type Spec. --------- --------- H05RN-F H05RN-F Shielding wire AU242FHBHA AU282FHAHA 1PH, 220-230V~,50Hz 2x(0.5 AU242FHBIA AU282FHAIA 3 x 6mm 3x(1 1.5mm AU342FHAIA AU482FIAIA AU482FIBIA AU482FIBHA 1PH, 220-230V~,50Hz 3 x 16mm 3x(1 1.5mm...
- Page 16 Installation Procedures Electrical wiring Method of outdoor unit wiring Power wire (connecting from outdoor unit) Remove service panel of outdoor unit and loosen wire clamp A. Then let fire wire, zero wire and ground wire pass through clamp A and connect to terminal row correspondingly.
- Page 17 Installation Procedures Electrical wiring Notice: When connecting power wire to terminal row, please notice following precaution. 1.Please do not connect power wires with different dimension to the same connecting terminal. loose contact may cause heat generation. 2.Please do not connect with different dimension to the same grounding terminal. loose contact may influence protection.
-
Page 18: Operation And Performance
Operation and Performance 3 minutes delay function Restart soon after stop, the compressor will start to operate after about 3 minutes to protect units. Cooling and heating operation of H-MRV system Indoor units of H-MRV could be controlled separately, but could not cool and heat simultaneously. If cool and heat at the same time, the indoor unit being set latter will be in waiting status and the one being set previously will operate properly. -
Page 19: Others And Test Run
Others and Test Run 1. Marks for connecting units When install multi-air condition system, in order to make clear of the connecting relation between outdoor unit and each indoor unit, make a table on cover of electric box to indicate names of each indoor unit connected. (As follow) Model of indoor unit Room For example 2nd Floor Unit 1 Indoor A... - Page 20 Others and Test Run SW01 SW02 Display of numeral pipe with seven segments Sensor TD Air Discharge value ( )(decimal number): Sensor TA Environment timP. value ( )(decimal number): Sensor TS Air suction value ( ) (decimal number): Sensor TE Defrost value ( )(decimal number): Sensor TC middle part of Condenser value ( )(decimal number):...
- Page 21 Others and Test Run 2. Function explanation of switch SW03 of control panel of outdoor unit. Function explanation SW03 SW03 In general, i.e. indoor units determine the operating mode of outdoor unit. Cooling only type Heating only type In general, same as above 3.
- Page 22 Others and Test Run The room where refrigerant leakage takes place. Outdoor unit (Refrigerants will all leak out.) Indoor unit NOTE : (for adding R407C refrigerant) Containers for R407C refrigerant must be marked with R407C and a brown Stripe. R407C and R22 refrigerants cannot share the same instrument distributor and filling pipes. 2.
-
Page 23: Malfunction
Malfunction The nixie light of the outdoor unit control panel displays malfunction code directly when malfunction occurs. (This malfunction table only applies to the follow models referred in this manual.) AU242FHBHA AU282FHAHA AU482~522FIAIA AU482FIBHA AU48NFIAIA Malfunction code and malfunction confirming... - Page 24 Malfunction The nixie light of the outdoor unit control panel displays malfunction code directly when malfunction occurs. (This malfunction table only applies to the follow models referred in this manual.) AU242FHBIA AU282FHAIA AU342FHAIA AU482FIBIA AU522FIAKA Malfunction code and malfunction confirming Malfunction code Malfunction position Circuit Te of defrosting temperature sensor abnormal...
- Page 25 Malfunction AU48NFIBIA AU55NFIAIA AU52NFIAKA AU60NFIAKA AU48NFIBJA Malfunction confirming and malfunction code When the remote wire controller display E1,check controller board(LED1)of the indoor unit or the contoller board(LED) of the outdoor unit. LED display on Malfunction description code If send to Remarks the regulating indoor unit...
- Page 28 HAIER GROUP Qingdao Haier Air Conditioner Electric Co., Ltd. Address: Haier Garden ,Qianwangang Road , Economic Development Zone, Qingdao ,Shandong 266500, P.R.China Web Site: http://www.haier.com...
