Service Manual
COLOR Television
CHASSIS :
Model:
CM21S7 ***
CM-21S7 ***
CM21S8 ***
CM-21S8 ***
Specification
TV Standard
Sound system
Power consumption
Speaker
Teletext system
Aerial Input
Channel coverage
Tuning system
Visual screen size
Channel indication
Program selection
Auxiliary Terminal
Remote control
Safety standard
Caution
: In this Manual, some parts can be changed for improving. their
performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List)in
Service Information Center.
S/M No. : TCP204SFEF0
CP-204S
PAL-SECAM B/G, D/K (NTSC : AV Only)
Mono
74W
5W 8 Ohm x 2
1 Page teletext
75 Ohm unbalanced
off-air, S-cable and hyperband channels
Ferquency synthesiser tuning system
51cm
On screen display
100 Programmes
RCA jack : TV output and AV input
R-204S(AAA)
CB
Alril 2011
Advertisement
Related Manuals for Daewoo CM21S7 Series
Summary of Contents for Daewoo CM21S7 Series
- Page 1 S/M No. : TCP204SFEF0 Service Manual COLOR Television CHASSIS : CP-204S Model: CM21S7 *** CM-21S7 *** CM21S8 *** CM-21S8 *** Specification TV Standard PAL-SECAM B/G, D/K (NTSC : AV Only) Sound system Mono Power consumption Speaker 5W 8 Ohm x 2 Teletext system 1 Page teletext Aerial Input...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1.SAFETY INSTRUCTION 2.BLOCK DIAGRAM 3.SERVICE ALIGNMENT INSTRUCTIONS 4.SCHEMATIC DIAGRAM 5.PRINTED CIRCUIT BOARD(PCB) 6.EXPLODED VIEW 7.SERVICE PARTS LIST... -
Page 3: Safety Instruction
1. SAFETY INSTRUCTION WARNING : Only competent service personnel may carry out work involving the testing or repair of this equipment X-RAY RADIATION PRECAUTION 1. Excessive high voltage can produce potentially hazardous X-RAY RADIATION. To avoid such hazards, the high voltage must not exceed the specified limit. -
Page 4: Block Diagram
2. BLOCK DIAGRAM... -
Page 5: Service Alignment Instructions
3. SERVICE ALIGNMENT INSTRUCTIONS * Service Remocon Type : R-74S02 or R-30SVC6 3.1 Microcontroller Configuration: Service mode 3.1.1 Tuning System Option Tuning option can be selected among the 4 options: TF->TK->TU->TA. Selection is made possible using factory R/C key H.BOW Down(-) button. Select to TK for PAL/SECAM B/G, D/K reception. - Page 6 ALIGNMENT INSTRUCTIONS 3.2.5 Horizontal Picture Centering - Adjust H-CENTER to have the picture in the center of the screen. 3.2.6 WBF, WBR (Wide Blanking Front and Rear) adjustment - Receive the RETMA PATTERN. - Use the "COR-T UP/DN" keys for the "WBF" adjust and use the "COR-B UP/DN" keys for the "WBR" adjustment.
- Page 11 -10-...
-
Page 12: Service Parts List
40SS210066 TRANSMITTER REMOCON CP-204S HR13-VE3AA ZZ110 PTACPWE573 ACCESSORY AS CM21S7BMFC 00030 40SS210001 BATTERY CP-204S R03(AAAM) 1.5V 10000 48586801E2 MANUAL INSTRUCTION “CM-801S,DTA-21S7MZF,DAEWOO” M821 4858213803 BAG INSTRUCTION L.D.P.E TO.05X250X400(+20 ZZ120 PTBCSHE469 COVER BACK AS DTA-21S7MTF M211 4852179501 COVER BACK HIPS BK M781... - Page 13 ELECTRICAL PARTS LIST PART CODE PART NAME DESCRIPTION REMARK ZZ290 PTMPMSE569 PCB MAIN MANUAL AS CM21S8BMFB M231 4852332511 PANEL CTRL ABS GY M231A 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR M491 4854963301 BUTTON CH M686 4856812001 TIE CABLE NYLON66 DA100 P801A 40SS210037 CORD POWER...
- Page 14 ELECTRICAL PARTS LIST PART CODE PART NAME DESCRIPTION REMARK C415 CSS2E220MT C ELECTRO 250V 22uF RSS C802 CFH2G151ML C ELECTRO 400V 150uF FHS C801 CLC2N104KN C LINE ACROSS AC275V 0.1uF UL/VDE/S/N/D C545 CXM2A102KT C MYLAR 100V 1000pF K CXM2A104KT C MYLAR 100V 0.1uF K C540,C355,C414, C602,C605...
- Page 15 ELECTRICAL PARTS LIST PART CODE PART NAME DESCRIPTION REMARK DA02,DA05 DZDZ-5.6BT DIODE ZENER DZ-5.6B D901 DZDZ-7.5BT DIODE ZENER DZ-7.5B D820 DZDZ-18B-T DIODE ZENER DZ-18B D120 DZUZ-33B-T DIODE ZENER UZ-33B T402 T9XX0040J- T9XX0040J-R LF801 5CL31LF303 FILTER-LINE LF-303 SF101 5CF812917N FILTER-SAW Q2917N 5NJ41FC21D FUSE CLIP FC-21D...
- Page 16 ELECTRICAL PARTS LIST PART CODE PART NAME DESCRIPTION REMARK R572 RDD1501JNT R CARBON FILM 1/6W 1.5K J R351 RDD1501FNT R CARBON FILM 1/6W 1.5K F (1%) R602 RDD1R00JNT R CARBON FILM 1/6W 1 J RDD1000JNT R CARBON FILM 1/6W 100 J R106,R107,R512,R513, R533,R535,R537,R538, R539,R540R541,R549,...
- Page 17 ELECTRICAL PARTS LIST PART CODE PART NAME DESCRIPTION REMARK R805,R603 RDD5600JNT R CARBON FILM 1/6W 560 J R610 RDD5601JNT R CARBON FILM 1/6W 5.6K J R547 RDD5602JNT R CARBON FILM 1/6W 56K J R546 RDD6800JNT R CARBON FILM 1/6W 680 J R725 RDD7500JNT R CARBON FILM...
- Page 18 ELECTRICAL PARTS LIST PART CODE PART NAME DESCRIPTION REMARK P401 4CJ21YF804 WAFER YFW-800-04 P802 4CJ21YF502 WAFER YFW-500-02 (TJC1-2A-7.5mm(M) P801 4CJ21YF802 WAFER YFW-800-02 (TJC1-2A P601 4CJ22YMW04 WAFER YMW250-04 (TJC3-4A) P702 4CJ22YMW02 WAFER YMW250-02 (TJC3-2A) 4NWJP075-T WIRE COPPER AWG22 1/0.5 TIN COATING J001,J003,J008, J009,J015,J016, J019,J024,J036,...
- Page 19 DAEWOO ELECTRONICS CORP. 686, AHYEON-DONG, MAPO-GU, SEOUL, KOREA. C.P.O. BOX 8003 SEOUL KOREA PRINTED DATE : April 2011...
