Vermont Castings Encore 2550CE Homeowner's Installation And Operating Manual

Vermont Castings Encore 2550CE Homeowner's Installation And Operating Manual

Woodburning stove
Hide thumbs
Table of Contents

Advertisement

Quick Links

SAFETY NOTICE: IF THIS APPLIANCE IS NOT PROPERLY INSTALLED, OPERATED AND MAIN-
TAINED, A HOUSE FIRE MAY RESULT.
TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. FAILURE TO
FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN
DEATH. CONTACT LOCAL BUILDING OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION
INSPECTION REQUIREMENTS IN YOUR AREA.
Do Not Discard This Manual: Retain for Future Use
0956
Encore Cover
2/01
Encore
Woodburning Stove
Model 2550CE
Homeowner's
Installation and

Operating Manual

For use in Europe
30003842 2/08 Rev. 1

Advertisement

Table of Contents
loading

Related Manuals for Vermont Castings Encore 2550CE

Summary of Contents for Vermont Castings Encore 2550CE

  • Page 1: Operating Manual

    DEATH. CONTACT LOCAL BUILDING OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN YOUR AREA. Do Not Discard This Manual: Retain for Future Use Encore Woodburning Stove Model 2550CE Homeowner’s Installation and Operating Manual For use in Europe 30003842 2/08 Rev. 1...

  • Page 2: Table Of Contents

    July 1, 1990. Under specific test conditions this heater has been shown to deliver heat up to 10.1 kW (34,500 BTU/hr). The Encore Model #2550CE has been tested to cur- rent standards. The test standards are UL-1482 and ANUL-737 for the United States, and EN13240:2001 + A2:2004 for Europe.

  • Page 3: Specifications

    Encore Model 2550CE Nominal heat out put ...10.1 kW (34,500 BTU/hr) Minimum flue draught ...12 Pa (0.048” WG) Mean flue gas temp ... 339° C (642° F) Efficiency (Space heating) ...75% Area heated ... Up to 175 sq. m (1900 sq. ft.) Fuel size/type ...

  • Page 4: Installation

    Encore Woodburning Stove SAFETY NOTICE: IF YOUR ENCORE IS NOT PROP- ERLY INSTALLED, A HOUSE FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRIC- TIONS AND INSTALLATION INSPECTION REQUIRE- MENTS IN YOUR AREA.
  • Page 5 What Kind of Chimney to Use You must connect the Encore to a code-approved masonry chimney with a flue liner, to a relined masonry chimney that meets local codes, or to a prefabricated metal chimney. (Fig. 3) The chimney and chimney con- nector must be in good condition and kept clean.
  • Page 6 Encore Woodburning Stove Flue Pipes with a spigot and socket joint should be fitted with the socket facing upwards, to contain con- densates and moisture within the flue. Joints should be made gas tight using proprietary jointing accessories, or, where appropriate, by packing joint with noncombus- tible rope and fire cement.
  • Page 7 Chimney Elbow Slip Pipe Standard Connector Oval to Round Adapter Flue Collar Fig. 5 Chimney connection in a freestanding masonry instal- lation. ST492 Defiant Securing the Single-wall Connector to a freestanding installation Masonry Chimney 11/00 Both freestanding masonry chimneys and fireplace masonry chimneys may be used for your installation.
  • Page 8 Encore Woodburning Stove • The fireplace damper must be sealed to prevent room air from escaping up the flue. However, it must be possible to re-open the damper to inspect or clean the chimney. Chimney Connector Shields Mantel * Check These Clear- ances Seal this off...
  • Page 9 Hearths This appliance must be installed on to hearth that meets the requirements of Part J of the Building Regu- lations 2000 (Combustion Appliances and Fuel Storage Systems). This can be achieved by ensuring that the hearth is constructed and sized in accordance with the guidelines included in section 2 of approved document ‘J’.
  • Page 10 Encore Woodburning Stove ance requirements must be strictly observed. In addition, furnishings and other combustible materials must be kept away from the stove as well. In general, a distance of 1219 mm (48”) must be maintained between the stove and moveable combustible items such as dry- ing clothes, furniture, newspapers, firewood, etc.
  • Page 11 at least 3 x D at least 1.5 x D at least 1.5 Elevation Without Shield Fig. 13 Connecting fluepipe clearances. 30003842 Encore Woodburning Stove at least 3 x D Fluepipe Plan Without Shield Elevation With Shield ����� �������� ���������� �����...

  • Page 12: Assembly

    Encore Woodburning Stove Set Up Your Stove Cast iron stoves are heavy, and it will take two to four people to move your Encore into position. Wipe the protective coating of oil from the griddle with a clean dry rag or a paper towel.

  • Page 13: Operation

    Fig. 17 Attach thermostat handle. ST635 Encore The Encore Controls Install thermostat handle Two controls regulate the performance of the Encore: a 2/01 primary air control supplies oxygen for the fire, and a damper directs air flow within the stove to activate and deactivate the catalytic combustor.

  • Page 14: Damper Control

    Encore Woodburning Stove The damper is closed when the handle points forward. Smoke from the fire is directed through the catalytic combustion system where it can be further burned for greater efficiency, before passing up the chimney. When closing the damper, be sure to pull firmly enough to snap it into the locked position.
  • Page 15 Store wood under cover to keep it dry. The longer it is stored, the better heating and fireviewing performance you will enjoy. Even for short-term storage, however, keep wood a safe distance from the heater and keep it out of the areas around the heater used for refueling and ash removal.
  • Page 16 Encore Woodburning Stove High-Efficiency Wood Burning with Catalytic Combustion An Encore leaves the factory with the combustor in- stalled. In the United States, it is against the law to operate this wood heater in a manner inconsistent with operating instructions in this manual, or if the catalytic combustor is deactivated or removed.
  • Page 17 Never use gasoline-type lantern fuel, kerosene, char- coal lighter fluid, or similar liquids to start or “freshen up” a fire. Keep all such liquids well away from the Encore while it is in use. 3. Light the newspaper and close the door. Gradually build up the fire by adding a few 76-127mm (3-5”) di- ameter splits.
  • Page 18 Encore Woodburning Stove fresh fuel (smaller pieces first), close the door and damper, and reset the primary air thermostat for the desired heat output. CAUTION: The Encore will be hot while in opera- tion. Keep children, clothing and furniture away. Contact may cause skin burns.

  • Page 19: Draft Management

    Draft Management A stove is part of a system, which includes the chimney, the operator, the fuel, and the home. The other parts of the system will affect how well the stove works. When there is a good match between all the parts, the system works well.
  • Page 20 Encore Woodburning Stove Creosote Creosote is a by-product of slow wood-burning. It’s an organic tar that can condense in the flue if it’s dense in the smoke, and slow-moving, and cools off to less than 143° C (290° F). Condensed creosote is volatile, and can generate chimney fires if it gets hot enough.

  • Page 21: Maintenance

    Below you will find important information on general care, inspection and maintenance of your Vermont Castings stove. Should it become necessary, use only replacement parts recommended by your authorized dealer. Keep Your Stove Looking New and Working Its Best Let the fire in the stove go out and allow the stove to cool completely before beginning any maintenance procedure.
  • Page 22 Encore Woodburning Stove 3. Replace the doors on the stove. Remove the griddle so you can reach in through the opening to posi- tion the manifold. Move the door manifold as high as possible without actually touching the upper air manifold, and as far toward the center of the stove as possible without hitting the door manifold on the other door.
  • Page 23 Pawl Small Locking Nut Large Lock- ing Nut Set Screw Handle Stub Fig. 33 Turn the door latch striker screw in or out to tighten or loosen the door latch. ST531 Door Pawl The Catalytic Element 11/00 Inspection and Cleaning This wood heater contains a catalytic combustor, which needs periodic inspection and replacement for proper operation.
  • Page 24 Encore Woodburning Stove Refractory Access Cover Left Wedge Fig. 35 Release the lower fireback by tapping out two wedges. ST644 Encore release Fireback lower fireback 3/01 Fig. 36 Remove the lower fireback through the front door opening. 6. Check the combustor’s honeycomb-like element ST645 for a buildup of fly ash.
  • Page 25 If you need to change a gasket, first obtain an appropri- ate replacement from your Vermont Castings’ Autho- rized Dealer. Wait until the fire is out and the stove has cooled. Be sure to follow the standard safety procedure for working with dusty materials: Wear safety goggles and a dust mask.
  • Page 26 Encore Woodburning Stove If you do experience a chimney fire, act promptly • Close the damper and thermostat lever. • Get everyone out of the house. • Call the Fire Department. You should inspect the system every two weeks during the heating season as part of a regular maintenance schedule.

  • Page 27: Appendix: Catalytic Combustor

    Appendix: Catalytic Combustor In any chemical reaction, including the combustion process, there are certain conditions which must be met before the reaction can take place. For example, a reaction may require a certain temperature, or a certain concentration of the reactants (the combustion gases and oxygen), or a certain amount of time.

  • Page 28: Replacement Parts

    CFM Corporation reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. Encore Woodburning Stove Model 2550CE Item Description 1. Secondary Air Cover Plate 2. Secondary Air Probe Assy 3.
  • Page 29 Encore Woodburning Stove Model 2550CE (continued) Item Description 15. Right Griddle Quad 16. Griddle 17. Griddle Handle Assy 18. Top 21. Wedge 22. Upper Fireback 23. Damper 24. Damper Tabs (3) 25. Damper Rod 27. Combustion Throat Hood 28. Lower Fireback 30.
  • Page 30 Encore Woodburning Stove Encore Woodburning Stove Model 2550CE (continued) Shell Enamel Parts - Encore Enamel Color Classic 1308618 Biscuit 30003007 Bordeaux 2328618 Chestnut Brown 30003019 Ebony 30003031 Forest Green 2318618 Midnight Blue 2378618 Sand 1328618 Suede Brown 30002526 Vermont Classic Green...

  • Page 31: Warranty

    Warranty Limited 3 Year Warranty CFM Corporation warrants that this woodburning stove will be free of defects in material and workmanship for a period of three years from the date you receive it, except that the catalyst, thermostat assembly, handles, glass door panels, cement, and gasketing shall be warranted as described below.
  • Page 32 CFM Corporation 2695 Meadowvale Blvd. • Mississauga, Ontario, Canada L5N 8A3 800-668-5323 • www.cfmcorp.com...
