Model 1300/1400
WARM AIR FURNACE
CAUTION:
READ ALL INSTRUCTIONS CARE-
FULLY BEFORE STARTING THE
INSTALLATION OR OPERATING
THE FURNACE
UNITED STATES STOVE COMPANY
S S
C
U
O
OWNERS MANUAL
SOLID FUEL
*FOR PARALLEL INSTALLATION WITH
EXISTING FORCED AIR-GAS OR OIL
FIRED FURNACE (U.S. ONLY)
*FOR INSTALLATION AS A CENTRAL FURNACE
*CERTIFIED UNDER ANSI/UL 391 & CAN/CSA-B366.1-M91
227 Industrial Park Road
P.O.Box 151
South Pittsburg, TN 37380
(423) 837-2100
S T
IMPROPER INSTALLATION MAY VOID
YOUR WARRANTY
DO NOT USE THIS FURNACE
IN A MOBILE HOME OR TRAILER
851486 02/01
Advertisement
Table of Contents
Related Manuals for United States Stove HOTBLAST 1300
Summary of Contents for United States Stove HOTBLAST 1300
- Page 1 *CERTIFIED UNDER ANSI/UL 391 & CAN/CSA-B366.1-M91 CAUTION: READ ALL INSTRUCTIONS CARE- FULLY BEFORE STARTING THE INSTALLATION OR OPERATING THE FURNACE UNITED STATES STOVE COMPANY 227 Industrial Park Road South Pittsburg, TN 37380 OWNERS MANUAL IMPROPER INSTALLATION MAY VOID YOUR WARRANTY...
-
Page 2: Tools And Materials Needed
CONGRATULATIONS! You've purchased one of America's Finest Wood and Coal Burning Furnaces. By heating with wood and coal you're helping CONSERVE AMERICA'S ENERGY! Wood is our Renewable Energy Resource. preserve our wood supply. Plant at least one tree each year. Future generations will thank you. -
Page 3: Caution Labels
Caution Your Furnace has the following labels. Read and Obey all labels. DANGER: RISK OF FIRE OR EXPLOSION. DO NOT burn garbage, gasoline, drain oil, or other flammable liquids. WARNING: FIRE HAZARD. DO NOT operate with fire draft exceeding .06 inches w.c. DO NOT operate with fuel loading or ash removal doors open. -
Page 4: Rules For Safe Installation And Operation
Rules for safe installation and operation Read these rules and the instructions carefully. Failure to follow them will cause a hazard that could result in death, serious bodily injury, and/or property damage. 1. Check your local codes. The installation must comply with their rulings. 2. - Page 5 HOW THE FURNACE FUNCTIONS Your HOTBLAST Furnace is designed to be a supplemental or central heating source for your home. This Solid Fuel Furnace may be installed in conjunction with a properly operating central furnace that is listed or cer- tified in accordance with nationally recog- nized safety standards and equipped with the required controls and other safety features...
- Page 6 DIMENSIONS OF FURNACE 41" Figure 1A Figure 1A 1300 1300 24-7/8" 21-1/32" 1-3/4" 33-7/8" 40-11/16" 9" 49-1/8" Figure 1B Figure 1B 1400 1400/1500 32-1/8" 24-1/16" 1-3/4" 33-7/8" 40-11/16" 9"...
-
Page 7: Locating The Furnace
Locating the Furnace 1. The furnace should be located in the same room as the central system and as close as possible, but not closer than 9". There should be no wall between the furnace and the warm air outlet duct that is connected directly to the warm air outlet plenum of the central furnace. -
Page 8: Chimney Connection
Chimney Connection MASONRY CHIMNEY Before using an existing masonry chimney, clean the chimney and inspect the flue liner to be sure it is safe to use. Make repairs before attaching the furnace. See page 4, item 5. Look at Fig. 4. The connector pipe and fittings you will need to connect directly to a masonry chimney are shown. -
Page 9: Rules For Connector Pipe Installation
Rules for Connector Pipe Installation 1. The crimped end of the chimney connector fits inside the furnace flue collar. Install additional chim- ney connectors and elbow with the CRIMPED END TOWARD THE FURNACE. condensation in the flue to run back into the furnace. Use 6"... - Page 10 CONNECTION OF CHIMNEY CONNECTOR TO A MASONRY CHIMNEY THROUGH A COMBUSTIBLE WALL Figure 8 shows how to connect the chimney connector of a heater to a masonry chimney through a combustible wall. There are five allowable ways that a chimney connector can be connected to a masonry chimney by passing through a combustible wall.
- Page 11 PART A, FIGURE 8 (FIGURE 8 CONTINUED ON NEXT PAGE) MINIMUM 12 IN. TO COMBUSTIBLES 1. Use a minimum 3-1/2" thick brick masonry wall framed into the combustible wall. A fireclay liner (ASTM C315 or equivalent) having a 5/8" minimum wall thickness must be used and it must be at least 12" away from any material that could catch fire.
- Page 12 PART B FIGURE 8 - (FIGURE 8 CONTINUED) PART C FIGURE 8 TWO VENTILATED AIR CHANNELS EACH 1 INCH. CONSTRUCTED OF SHEET STEEL. PART D FIGURE 8 PART E - (Figure 8) In addition to the methods shown by A, B, C, and D of Figure 8, a listed factory-built wall pass-through system may be purchased and installed according to the instructions packaged with it to provide a safe method of passing chimney connector through a combustible wall for a connection to a masonry chimney.
-
Page 13: Assembly Of Furnace
Assembly of Furnace Your furnace requires the following items to be assembled or installed by the service person: Feed Door Pull Handle Feed Door Locking Handle Blower(s) and Blower Controls Electrical Connections Remove all parts from inside the furnace and inspect for damage, including the firebrick as some breakage could occur during shipment. - Page 14 LOAD LOAD BREAK OFF LIMIT LINE LINE JUMPER FOR LOW VOLTAGE Honeywell LIMIT SWITCH WIRE NUTS GROUND VAC, ELECTRICAL JUNCTION BOX BLOWER MOTOR IMPORTANT: POWER SUPPLY WIRING MUST NOT BE LESS THAN 90 CENTIGRADE. LOAD LOAD LIMIT BREAK OFF LINE LINE JUMPER FOR LOW VOLTAGE...
-
Page 15: Installation
Installation Please see all methods of Installation in Appendix at the rear of this booklet. This is a furnace, not a free standing stove. You must direct heated air from 8" outlets away from the furnace, or it will not function properly. 1. -
Page 16: Power Failure Instructions
PLENUM 6" MIN. Figure 14 18" MIN. CEILING TO GAS/OIL/ELECTRIC TRANSFORMER AND COMBUSTION FAN OF SOLID FUEL UNIT POWER SUPPLY GAS/OIL/ELECTRIC POWER SUPPLY JUNCTION BOX FURNACE BLOWER MOTOR Power Failure Instructions: Operation after loss of power-- 1. Remove filter if provided 2. -
Page 17: Operating Instructions
Operating Instructions FUEL, Model 1300 Egg size (1-3/16" or larger) bituminous coal for residential furnaces, or any of the specially packed fireplace coals can be used. Coal with a low ash content (2% to 6%) is recommended. FUEL, Model 1400 Hardwood, 18"... -
Page 18: Service Hints
Service Hints Do not expect a furnace to draw. It is the chimney that creates the draft. Smoke spillage into the house or excessive buildup of water or creosote in the chimney are warnings that the chimney is not functioning properly. Correct the problem before using furnace. -
Page 20: Parts List
(SEE DIAGRAM, PAGE 19) PART # DESCRIPTION 22684 CABINET LEFT SIDE 22682 CABINET BACK PANEL 22762 FORCED DRAFT RING 88032 FLUE COLLAR GASKET 40246 FLUE COLLAR 22761 FLUE COLLAR RING 83227 BOLT (1/4-20 X 1) 83250 KEP NUT (1/4-20) 22683 CABINET TOP PANEL 22685 CABINET RIGHT SIDE... - Page 22 (SEE DIAGRAM, PAGE 21) PART # DESCRIPTION 23461 CABINET LEFT SIDE 23459 CABINET BACK PANEL 22762 FORCED DRAFT RING 88032 FLUE COLLAR GASKET 40246 FLUE COLLAR 22761 FLUE COLLAR RING 83227 BOLT (1/4-20 X 1) 83250 KEP NUT (1/4-20) 23457 CABINET TOP PANEL 23461 CABINET RIGHT SIDE...
-
Page 23: Add-On Installation
(U.S. ONLY) Fig. 17-1 Add-On Installation (U.S. ONLY) Fig. 17... -
Page 24: Filter Box
APPENDIX INSTALLATION A COLD AIR RETURN FILTER BOX (U.S. ONLY) EXISTING FURNACE SOLID FUEL FURNACE TO EXISTING DUCT WORK WARM AIR... - Page 25 INSTALLATION B PLENUM COLLECTOR BOX COLD AIR RETURN FILTER BOX INSTALLATION C PLENUM ELBOW COLD AIR RETURN PLENUM TOP (OPTIONAL) FILTER BOX (U.S. ONLY) TO EXISTING DUCT WORK WARM AIR EXISTING FURNACE SOLID FUEL FURNACE (U.S. ONLY) TO EXISTING DUCT WORK WARM AIR EXISTING FURNACE...
- Page 26 DUCT WORK 2" MINIMUM CLEARANCE ANTI-BACKDRAFT FLAPPER SOLID FUEL FURNACE DUCT WORK 2" MINIMUM CLEARANCE COLD AIR RETURN SOLID FUEL FURNACE INSTALLATION D (U.S. ONLY) 11 PCS (OPTIONAL PLENUM COLD AIR RETURN FURNACE PLENUM INSTALLATION E (U.S. ONLY) BAFFLE FURNACE PLENUM EXISTING FURNACE FAN CONTROL LOCATION) EXISTING FURNACE...
- Page 27 DUCT WORK 2" MINIMUM CLEARANCE SOLID FUEL FURNACE DUCT WORK 2" MINIMUM CLEARANCE CENTRAL FURNACE INSTALLATION SOLID FUEL FURNACE INSTALLATION F COLD AIR RETURN INSTALLATION G FURNACE PLENUM EXISTING FURNACE COLD AIR RETURN TO FILTER BOX...
-
Page 28: Front View
SOLID FUEL FURNACE INSTALLATION H EXISTING OIL, ELECTRIC OR GAS FURNACE SOLID FUEL FURNACE (TOP VIEW) 2" MINIMUM CLEARANCE (FRONT VIEW) EXISTING OIL, ELECTRIC OR GAS FURNACE... - Page 29 Trouble Shooting Tips for Warm Air Furnace LIST OF PROBLEMS 1. Smoking when feed door is open. 2. Furnace does not heat. 3. Blower Does not run. 4. No air from registers- fan running. 5. Air from Registers is not hot 6.
- Page 30 NOTES...
- Page 31 NOTES...
-
Page 32: How To Order Repair Parts
FOLLOWING INFORMATION AS SHOWN IN THIS LIST: 1. The PART NUMBER 2. The PART DESCRIPTION 3. The MODEL NUMBER: 1300 4. The SERIAL NUMBER: UNITED STATES STOVE COMPANY 227 Industrial Park Road P.O. Box 151 South Pittsburg, TN 37380 (423) 837-2100 www.USSTOVE.com...
