TOILET SEAT
K-4761, K-4762
INSTALLATION GUIDE
Tabs
Hinge Slots
Seat
Hinge Cover
Bolt
Nut
Hinge Plate
Bolt
Mounting Bracket
Nut
Install the Toilet Seat
Remove the existing toilet seat and mounting hardware.
If necessary, clean the toilet surface.
Position the mounting bracket with flat side up and align the holes to the
toilet seat mounting holes.
Insert the bolts through the mounting bracket and the toilet seat mounting
holes.
Thread a nut onto each bolt.
Using a Philips screwdriver and an adjustable wrench, tighten the nuts.
Do not overtighten.
Position the toilet seat over the bowl and slide the toilet seat hinge plate onto
the mounting bracket. Press firmly into place.
Insert the hinge cover tabs into the hinge slots.
Press the hinge cover down until it snaps into place over the mounting
bracket.
Verify the seat is securely fastened. Make any adjustments as needed.
Kohler Co.
1
1066739-2-A

Advertisement

Table of Contents
loading

Related Manuals for Kohler K-4761

Summary of Contents for Kohler K-4761

  • Page 1 TOILET SEAT K-4761, K-4762 INSTALLATION GUIDE Tabs Hinge Slots Seat Hinge Cover Bolt Hinge Plate Bolt Mounting Bracket Install the Toilet Seat Remove the existing toilet seat and mounting hardware. If necessary, clean the toilet surface. Position the mounting bracket with flat side up and align the holes to the toilet seat mounting holes.

  • Page 2: Care And Cleaning

    Operating the Toilet Seat Your Kohler toilet seat is designed to close slowly when the seat is dropped. The toilet seat also has an easy-to-clean, quick-release hinge that allows the toilet seat to be quickly removed for complete cleaning. Using a fingertip, lift the hinge cover. Once the hinge cover is lifted, pull the toilet seat forward leaving the mounting hardware in place.
  • Page 3 ® defects in material and workmanship for one year from date of installation. Kohler Co. will, at its election, repair, replace or make appropriate adjustment where Kohler Co. inspection discloses any such defects occurring in normal usage within one year after installation. Kohler Co. is not responsible for removal or installation costs.
  • Page 4 It is recommended that at the time of purchase, you verify that all accessories and components are complete in this package. This Kohler product is warranted to be free of defects in material and workmanship for one (1) year from the date of purchase as shown on the invoice or receipt.

  • Page 5: Guide D'installation

    GUIDE D’INSTALLATION SIÈGE DU W.C. K-4761, K-4762 Languettes Rainures de charnière Couvercle Siège de charnière Boulon Écrou Plaque de charnière Boulon Support de montage Écrou Installer le siège du W.C. Retirer le siège du W.C. existant et les fixations. Si nécessaire, nettoyer la surface du W.C.

  • Page 6: Entretien Et Nettoyage

    Opérer le siège du W.C. Votre siège de W.C. Kohler est conçu pour fermer lentement lorsque le siège est relâché. Le siège du W.C. est aussi menu d’une charnière amovible rapide facile à nettoyer qui permet de retirer rapidement le siège du W.C. pour un nettoyage complet.
  • Page 7 à partir de la date d’installation. Kohler Co. jugera à sa discrétion, de la réparation, du remplacement ou du réglage approprié et ceci après toute inspection faite par Kohler Co. de tous défauts uniquement dûs à...

  • Page 8: Guía De Instalación

    GUÍA DE INSTALACIÓN ASIENTO DE INODORO K-4761, K-4762, Lengüetas Ranuras de la bisagra Asiento Cubre bisagra Perno Tuerca Placa de bisagra Perno Soporte de montaje Tuerca Instale el asiento del inodoro Desmonte el asiento del inodoro existente y los herrajes.

  • Page 9: Cuidado Y Limpieza

    Funcionamiento del asiento del inodoro Su asiento de inodoro Kohler está diseñado para cerrarse lentamente cuando se deja caer. El asiento del inodoro también tiene una bisagra de desenganche rápido, fácil de limpiar, que permite desmontar rápidamente el asiento para poder limpiarlo bien.
  • Page 10 Kohler Co. demuestre que dichos defectos ocurrieron durante el uso normal en el transcurso de un año desde la fecha de la instalación. Kohler Co. no se hace responsable por los gastos de desinstalación o instalación.
  • Page 11 Al adquirir el producto, se recomienda verificar que todos los accesorios y componentes contenidos en la caja estén completos. Kohler Co. garantiza que el material y la mano de obra de este producto está libre de defectos, por un (1) año, a partir de la fecha de compra que aparece en la factura o recibo.
  • Page 12 USA: 1-800-4-KOHLER Canada: 1-800-964-5590 México: 001-877-680-1310 kohler.com ©2007 Kohler Co. 1066739-2-A Kohler Co. 1066739-2-A...
