CAUTION!

for your protection. Although we make every effort to make the assembly process as problem free and

safe as possible, it is characteristic of fabricated steel parts that the edges and corners might be sharp and

could cause cuts if handled incorrectly.

NOTE!

Most stainless steel parts are supplied with a protective plastic coating that must be removed

prior to using the appliance.

NOTE!

For use with or without optional trim kit. If using without the optional trim kit the facing/finishing

material cannot extend past the front surface of the appliance.

N325-0036

N080-0307

N200-0105

OPTIONAL GSS48 COVER

During unpacking and assembly we recommended you wear work gloves and safety glasses

N570-0073

N510-0013

MOUNTING HOLES FOR UNITS WITH

OPTIONAL TRIM KIT (LT48SS).

MOUNTING HOLES FOR UNITS WITHOUT

OPTIONAL TRIM KIT (LT48SS).

N415-0294 JUL 04/13

Page 1 OPTIONAL GSS48 COVER CAUTION! During unpacking and assembly we recommended you wear work gloves and safety glasses for your protection. Although we make every effort to make the assembly process as problem free and safe as possible, it is characteristic of fabricated steel parts that the edges and corners might be sharp and could cause cuts if handled incorrectly.
Page 2 NOTE! The extension bracket kit (GSS48BRT) is sold separately. N325-0036 N570-0073 N510-0013 N080-0308 N200-0105 NOTE! For use with facing/finishing materials which extend up to 3” (76mm) past the front of the appliance with no optional trim kit installed.
Page 3 INSTALLATION DU HOUSSE OPTIONNEL GSS48 ATTENTION! Lors du déballage et de l’assemblage, nous vous conseillons de porter des gants de travail et des lunettes de sécurité pour votre protection. Malgré tous nos efforts pour assurer que l’assemblage soit aussi sécuritaire et sans problème que possible, il se peut que les bords et les coins des pièces usinées en acier soient coupants et qu’ils causent des coupures si les pièces ne sont pas manipulées...
Page 4 NOTE! Le support d’extension (GSS48BRT) est vendu séparément. N325-0036 N570-0073 N510-0013 N080-0308 N200-0105 NOTE! Pour usage avec des matériaux de façade/finition qui se prolongent jusqu’à 3” (76 mm) au-delà de la face avant de l’appareil, sans la moulure optionnelle d’installée.
