Aiwa XR-HG5MD Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

SERVICE MANUAL
MD / CD STEREO SYSTEM
SYSTEM
XR–HG5MD
• This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
XR-HG5MD (K, EZ), (S/M Code No. 09-002-423-9T2).
• If requiring information about the CD mechanism, see Service Manual of
AZG-1 ZD8RMDM, (S/M Code No. 09-001-335-3NA).
• If requiring information about the MD mechanism, see Service Manual of
AZG-7 DM, (S/M Code No. 09-001-338-4N2).
XR-HG5MD
BASIC TAPE MECHANISM : 2ZM-3MK2 PR4NM
BASIC CD MECHANISM : AZG-1 ZD8RMDM
BASIC MD MECHANISM : AZG-7 DM
CD
CASSEIVER
CX–NHG5MD
SX–WNHG5
S/M Code No. 09-004-423-9R2
REMOTE
SPEAKER
CONTROLLER
RC–ZAS16
K, EZ

Advertisement

Table of Contents
loading

Related Manuals for Aiwa XR-HG5MD

Summary of Contents for Aiwa XR-HG5MD

  • Page 1 SX–WNHG5 RC–ZAS16 • This Service Manual is the "Revision Publishing" and replaces "Simple Manual" XR-HG5MD (K, EZ), (S/M Code No. 09-002-423-9T2). • If requiring information about the CD mechanism, see Service Manual of AZG-1 ZD8RMDM, (S/M Code No. 09-001-335-3NA). • If requiring information about the MD mechanism, see Service Manual of AZG-7 DM, (S/M Code No.

  • Page 2: Specifications

    SPECIFICATIONS <FM tuner section> <Compact disc player section> Tuning range 87.5 MHz to 108 MHz Laser Semiconductor laser (λ =780 nm) Usable sensitivity (IHF) 16.8 dBf D-A converter 1 bit dual Antenna terminals 75 ohms (unbalanced) Signal-to-noise ratio 85 dB (1 kHz, 0 dB) Harmonic distortion 0.05 % (1 kHz, 0 dB) <MW tuner section>...

  • Page 3: Protection Of Eyes From Laser Beam During Servicing

    PROTECTION OF EYES FROM LASER BEAM DURING SERVICING This set employs laser. Therefore, be sure to follow carefully CAUTION the instructions below when servicing. Use of controls or adjustments or performance of proce- dures other than those specified herin may result in WARNING!! hazardous radiation exposure.

  • Page 4: Note On Before Starting Repair

    NOTE ON BEFORE STARTING REPAIR 1. Forced discharge of electrolytic capacitor of power supply block When repair is going to be attempted in the set that uses relay circuit in the power supply block, electric potential is kept charged across the electrolytic capacitors (C101, 102) even though AC power cord is removed.
  • Page 5 In such a case, check also if the POWER AMPLIFIER circuit or power supply circuit has any abnormalities or not. 2-2. Regarding reset There are cases that the machine does not work correctly because the MICROCOMPUTER is not reset even though the AC power cord is re-inserted, or the software reset (pressing the STOP key + POWER key) is performed.
  • Page 6 CAUTIONS WHEN ASSEMBLY 1. Assembling the CAM, LOAD Move the LEVER ASSY, CAM in the direction of the arrow as far as it can go. Rotate the CAM, LOAD so that its positioning hole is moved as close as possible to the shaft of the LEVER, SW H. Attach the CAM, LOAD so that it engages with the teeth of the GEAR, IDLER2.
  • Page 7 DISASSEMBLY INSTRUCTIONS Disassembly Procedure Remove the four screws (BVT2+3-10 W/O SLOT) of A. Remove the four screws (VTT+3-4) of B. Remove AZG-4 in the direction of the arrow. Set the mechanism in the PLAY state. Remove the HLDR, SHIELD TOP in the direction of the arrow.

  • Page 8: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION MAIN C.B 87-012-369-080 C-CAP,S 0.047-50F 8A-DB8-616-010 C-IC,LC876580W-5N90 87-012-369-080 C-CAP,S 0.047-50F 87-A21-482-010 IC,RPM6938-H 87-012-368-080 C-CAP,S 0.1-50 F 87-017-888-080 IC,NJM4558MD 87-012-368-080 C-CAP,S 0.1-50 F 87-A21-021-040 C-IC,BU2099FV 87-012-368-080 C-CAP,S 0.1-50 F 87-070-289-040...
  • Page 9 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C213 87-010-405-080 CAP, ELECT 10-50V C502 87-010-401-080 CAP, ELECT 1-50V C214 87-010-405-080 CAP, ELECT 10-50V C503 87-010-545-080 CAP,E 0.22-50 M 11L SME C215 87-010-322-080 C-CAP,S 100P-50 CH C504 87-010-545-080 CAP,E 0.22-50 M 11L SME C216...
  • Page 10 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C776 87-010-197-080 CAP, CHIP 0.01 DM J602 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN C777 87-010-400-080 CAP, ELECT 0.47-50V J802 87-A60-403-010 TERMINAL,ANT PAL 2P HSP-312V05 C778 87-010-401-080 CAP, ELECT 1-50V JW811 87-008-372-080 FILTER, EMI BL OIRNI...
  • Page 11 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C184 87-010-175-080 CAP 560P S311 87-A91-024-180 SW,TACT KSHG611BT C185 87-010-322-080 C-CAP,S 100P-50 CH S321 87-A91-024-180 SW,TACT KSHG611BT C186 87-010-175-080 CAP 560P S322 87-A91-024-180 SW,TACT KSHG611BT C187 87-010-322-080 C-CAP,S 100P-50 CH S323 87-A91-024-180 SW,TACT KSHG611BT...

  • Page 12: Chip Resistor Part Code

    REF. NO. PART NO. KANRI DESCRIPTION HEAD-2 C.B 85-ZM3-602-010 PWB,FLEX A CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor Dimensions (mm) Symbol Wattage Type Tolerance Resistor Code Form 1/16W 1005 0.35 1/16W 1608 0.45 1/10W...

  • Page 13: Wiring - 1 (Main)

    WIRING – 1 (MAIN) – 13 –...

  • Page 14: Schematic Diagram - 1 (Main 1 / 2 : Amp Section)

    SCHEMATIC DIAGRAM – 1 (MAIN 1 / 2 : AMP SECTION) – 14 –...

  • Page 15: Schematic Diagram - 2 (Main 2 / 2 : Tuner Section)

    SCHEMATIC DIAGRAM – 2 (MAIN 2 / 2 : TUNER SECTION) – 15 –...

  • Page 16: Wiring - 2 (Front)

    WIRING – 2 (FRONT) <1 / 2> – 16 –...
  • Page 17 WIRING – 2 (FRONT) <2 / 2> – 17 –...

  • Page 18: Schematic Diagram - 3 (Front)

    SCHEMATIC DIAGRAM – 3 (FRONT) – 18 –...
  • Page 19 WIRING – 3 (PT) – 19 –...

  • Page 20: Schematic Diagram - 4 (Pt)

    SCHEMATIC DIAGRAM – 4 (PT) – 20 –...

  • Page 21: Wiring - 4 (Deck)

    WIRING – 4 (DECK) – 21 –...
  • Page 22 IC DESCRIPTION IC, LC876580W-5N90 Description Pin No. Pin Name I-DISH CD turnable photo sensor input. I-DRF/I-STEREO CD DRF input/Stereo detect input. O-2PB Selection of Deck 1/2. O-BIAS Deck bias output. O-RMT(STB) REC mute output/(STB output:HIGH-PWB used). O-DATA DATA output for MAIN C.B. O-CLK CLOCK output for MAIN C.B.
  • Page 23 Pin No. Pin Name Description LW/P23 LW diode input/FL segment output (P23). SW/P22 SW diode input (Not used)/FL segment output (P22). FM1/P21 FM1 (OIRT) diode input (Not used)/FL segment output (P21). RDS/P20 RDS diode input/FL segment output (P20). AM-9K/10K/P19 AM 10K diode input (Not used)/FL segment output (P19). Q-SUPR/P18 Q-SUPR diode input (Not used)/FL segment output (P18).

  • Page 24: Ic Block Diagram

    IC BLOCK DIAGRAM IC, LC72131D IC, M61500FP – 24 –...
  • Page 25 IC, BU2092F IC, BA3835F – 25 –...
  • Page 26 IC, LA1837NL IC, BU2099FV – 26 –...
  • Page 27 IC, BU1920FS – 27 –...
  • Page 28 FL (HNA-13MM14T) GRID ASSIGNMENT & ANODE CONNECTION GRID ASSIGNMENT – 28 –...
  • Page 29 ANODE CONNECTION – 29 –...
  • Page 30 ADJUSTMENT <TUNER / DECK / FRONT> A MAIN C.B TC942 L771 L942 L772 L941 IC771 TP2 (CLK) L981 SFR451 SFR452 TP3 (DC) TP4 (DC) (3/3) (1/3) FFE801 TP9 (RCH) (VT) TP8 (LCH) B FRONT C.B FL101 TP12 (GND) IC101 TP11 (CLK) CN101 L151 DECK–1 P HEAD,...
  • Page 31 < TUNER SECTION > 1. Clock Frequency Check 7. FM VT Check Settings : • Test point : TP2 (CLK) Settings : • Test point : TP1 (VT) Method : Set to MW 1602kHz and check that the test point is Method : Set to FM 108.0MHz and check that the test 2052kHz ±...
  • Page 32 < DECK SECTION > 16. REC/PB Frequency Response Adjustment (DECK 2) 12. Tape Speed Adjustment (DECK 2) Settings : • Test tape : TTA–602 Settings : • Test tape : TTA–100 • Test point : TP8(Lch), TP9(Rch) • Test point : TP8(Lch), TP9(Rch) •...

  • Page 33: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW 1 / 1 AZG-1 HT-SINK,S P.C.B HT-SINK HT-SINK SUB HT-SINK TRS P.C.B HT-SINK PLAT EARTH MECHA HT-SINK FIN AZG-7 P.C.B 2ZM-3MK2 CHAS,MAIN – 33 –...

  • Page 34: Mechanical Part List

    MECHANICAL PART LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 8A-DB8-031-110 KEY,ASSY JOG 87-CE3-023-010 BADGE,AIWA 30N SILV 8A-DB8-028-010 KNOB,RTRY ASSY JOG 8A-DB8-005-010 PANEL,TRAY 81-532-080-010 LABEL, CASS. COMPT 88-NF5-208-010 HLDR,PWB-M N 8A-DB8-050-110 PANEL,ASSY MD 88-912-151-110 FF-CABLE, 12P 1.25...

  • Page 35: Tape Mechanism Exploded View

    TAPE MECHANISM EXPLODED VIEW 1 / 1 PH(DECK 1) RPH(DECK 2) DECK C.B CUSH-G,DIA3.7-8-3.2 CUSH-G,DIA3.7-8-3.2 CAPSTAN N 2.2-41.7 CAPSTAN N 2.2-41.5 HEAD 1 C.B(DECK 1) BELT D2 HEAD 2 C.B(DECK 2) (DECK 1) (DECK 1) (DECK 2) (DECK 2) 2ZM3MK2 PR4N (BOTTOM SIDE) SH,1.63-3.2-0.5 SLT 2ZM3MK2 PR4N,YPR4N...
  • Page 36 TAPE MECHANISM PART LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 82-ZM3-301-610 CHAS ASSY,M2 32 82-ZM3-305-210 GEAR,CAM M2 2 82-ZM1-258-210 SPR-T,PINCH L 33 82-ZM1-227-310 LVR,TRIG 3 82-ZM1-341-210 LVR ASSY,PINCH L2 34 82-ZM3-306-110 LVR,FR M2 4 82-ZM1-333-210 PLATE,LINK2...

  • Page 37: Spring Application Position

    SPRING APPLICATION POSITION 82-ZM1-257-019 82-ZM1-218-019 SPR-T,CAS SPR-E,HB 82-ZM1-285-310 82-ZM1-244-410 SPR-C,BT L SPR-C,BT 82-ZM1-219-119 SPR-T,LINK 82-ZM1-259-110 SPR-T,PINCH R 82-ZM1-258-110 SPR-T,PINCH L 82-ZM1-269-219 82-ZM1-214-010 82-ZM1-213-019 SPR-T,BRG SPR-T,HEAD SPR-T,DIR 82-ZM1-322-019 SPR-T,FR 60 82-ZM1-265-119 SPR-E.TRIG 82-ZM1-255-319 SPR-E,LER DIR – 37 –...
  • Page 38 SPEAKER DISASSEMBLY INSTRUCTIONS Type.1 Type.4 Insert a flat-bladed screwdriver into the position indicated by the TOOLS arrows and remove the panel. Remove the screws of each speaker 1 Plastic head hammer unit and then remove the speaker units. 2 (() flat head screwdriver 3 Cut chisel How to Remove the PANEL, FR Type.2...

  • Page 39: Accessories / Package List

    SPEAKER PARTS LIST SX-WNHG5 (YSL) REF. NO. PART NO. KANRI DESCRIPTION 1 8A-DS8-001-010 PANEL,FR 2 8A-DS8-004-010 PANEL,DUCT 3 8A-DS8-009-010 PROTECTOR 4 88-NS5-610-010 CORD,SPKR 5 88-NS5-611-010 CORD,SPKR B/L 6 8Z-NSY-003-010 CORD,BUSH 7 88-NS3-029-010 CORD,BUSH L 8 8Z-NS7-602-010 SPKR,W 160 9 8Z-NSY-604-010 SPKR,M 100 10 8Z-NSY-608-010 SPKR,CERAMIC ASSY...
  • Page 40 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9420208 0251431 Printed in Singapore...
  • Page 41 Service Technical Information MODEL NO. − XR HG5MD SUBJECT µ− − − − Notes on replacing REF.No. :G 078 E0 DATE :25. SEP. 2000 <CONTENTS> The CD mechanisms mounted on the models above are broadly divided into two different types. µ−...
