SERVICE MANUAL
COMPACT DISC STEREO
SYSTEM
STEREO
SYSTEM
RECEIVER
MX-NH2000 DX-NH2000
XR-H2000
• This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
XR-H2000 (EZ,K), (S/M Code No. 09-005-427-6T2).
• If requiring information about the CD mechanism, see Service Manual of
AZG-1 ZD3RNDM, (S/M Code No. 09-001-335-3N8).
All manuals and user guides at all-guides.com
CD
CASSETTE
PLAYER
DECK
FX-NH2000 GE-NH2000
S/M Code No. 09-006-427-6R2
XR-H2000
BASIC TAPE MECHANISM : 2ZM-3MK2 PR4NM
BASIC CD MECHANISM : AZG-1 ZD3RNDM
GRAPHIC
EQUALISER SPEAKERS
SX-NDPH2100
EZ,K
REMOTE
CONTROL
RC-ZAS04
