- Page 1 DVD MICRO HI-FI SYSTEM AMD-805...
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS .....................02 FRONT PANEL ......................REAR PANEL ......................CONNECTIONS ......................REMOTE CONTROL ....................REMOTE FUNCTIONS ....................HOW TO SEARCH ...................... SYSTEM SETUP ......................SYSTEM SETUP FOR DVD MODE ................PLAY FROM USB ..................... COMMON OPERATION ..................... TROUBLESHOOTING ....................SPECIFICATIONS ......................18... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS Basic Safety Requirements 1. Unplug the unit during lightning storms or when you do not intend to use it for a long period 2. To remove the plug from the electrical outlet, do not pull on the supply cable. Grasp the plug firmly and pull to remove. - Page 4 11. If it is very cold, please place the unit in a warm room and turn the power on for about an hour. 12. Always ensure that the product is unplugged from the electrical outlet before moving or cleaning. sourcing powder or solvents such as alcohol as they may damage the surface of the unit. Deformed s a disc is rotated at a high speed, it is dangerous to play a broken or deformed disc.
-
Page 5: Front Panel
FRONT PANEL VOLUME 8. USB 1. POWER 9. MODE(Switch between DVD/USB/ 2. REMOTE CONTROL SENSOR FM/AUX/BT) 3. LED DISPLAY 10. EQ(POP /CLASS /FLAT/ROCK/JAZZ) 4. PLAY/PAUSE / SCAN 11. STOP 5. PREV/CH- 12. NEXT/CH+ 6. REV/TUN- 13. FWD/TUN+ 7. VOL+/VOL- 14. AUX IN... -
Page 6: Rear Panel
REAR PANEL FM ANT Cr/Pr Video Cb/Pb 1. Headphone Output 4. Video Output 2. FM ANT 5. L/R Output 3. R/L(Output to right and 6. Component (YPbPr ) output left speakers) -
Page 7: Connections
CONNECTIONS Connecting to a TV Set FM ANT Cr/Pr Video Cb/Pb R Speaker L Speaker... -
Page 8: Remote Control
REMOTE CONTROL POWER EQUALISER (POP/CLASS/ FLAT/ROCK/JAZZ) PLAYBACK CONTROL (PBC) NUMBER BUTTONS PROGRAM CLEAR RETURN GOTO DVD/USB (Switch between DVD and USB) SETUP LEFT DVD/USB ENTER RIGHT DOWN TITLE MENU STOP/STOP SCAN PLAY/PAUSE/SCAN SCAN STOP PREV/CH- REV/FM- VOL+ VOL- NEXT/CH+ FWD/FM+ MODE MODE (Switch between DVD/ USB/FM/AUX/BT) -
Page 9: Remote Functions
REMOTE FUNCTIONS OPERATION DISC INSTRUCTION Press POWER button to turn on the unit/ POWER FORMATS switch to standby. Press EQ button to switch between POP /CLASS / FORMATS FLAT/ROCK/JAZZ display the starter logo. With certain disc types, such as DVD, the player can resume playback from the point where it was STOP RESUME... - Page 10 TITLE Press this key to play the selected menu. MENU Press this key to play the selected menu. DIRECTION & Press this key to choose the selected column ENTER you want, and then press “ENTER” to confirm. Press this key to watch the same scene from ANGLE （...
-
Page 11: How To Search
HOW TO SEARCH DISC OPERATIONS TV SCREEN and search the menu. Press twice to cancel. TITLE :XX/X X CHAPTER :XX/XX to select an item. Then enter the number key • TITLE :02/X X CHAPTER :XX/XX •To play Chapter 5 of Title 1, press GOTO TITLE :01/X X CHAPTER :05/XX on the remote control, enter 1, then press 5 •Press “GOTO"... -
Page 12: System Setup
SYSTEM SETUP 1. MAIN MENU Press the "SETUP" key on the remote control to enter the Setup menu. Then press press "ENTER" to enter. To exit the Setup menu, press the "SETUP" key. 2. LANGUAGE SETUP SUB-MENU CHOICE REMARK Select the language for the OSD Setup menu. AUDIO Select spoken language. - Page 13 4.VIDEO SETUP 5.AUDIO SETUP DOWNMIX LT/RT 5.1CH mixed into stereo STEREO Stereo output 6.DOLBY AUDIO SETUP...
-
Page 14: System Setup For Dvd Mode
SYSTEM SETUP FOR DVD MODE Setup: 1. Turn on the TV and sh i to “VIDEO INPUT” . 2. Turn on other units such as an audio or VCR if they are connected. Turning the Unit On: POWER if it has already been inserted in the player. Insert a disc onto the disc tray and close the cover, the screen will display what type of disc is being played. -
Page 15: Play From Usb
PLAY FROM USB 1) Only insert a USB when there is no disc in the tray. 2) Press or “ DVD/USB ” on the remote control: DVD and USB will appear on the TV screen.Please use “ ↑” and “↓” s to select USB. -
Page 16: Common Operation
Please note: Before copy, ensure that the available space on the USB is enough for the size of the file(s) to be copied. COMMON OPERATION Bluetooth To connect an external device to this unit via Bluetooth: MODE button ‘Aiwa AMD-805’. Once... - Page 17 player using a 3.5mm auxiliary cable. The unit will start playing the selected music on the external player. Using the remote control, play, pause or stop the music being played. Please note that in Line Input search and store radio channels. When the search is complete, the unit will play the first stored channel.
-
Page 18: Troubleshooting
TROUBLESHOOTING PROBLEM SOLUTION If you place the disc on the tray and the player displays “NO "No Disc" DISC” once loaded: displayed on 1) Check whether the disc is placed correctly (label side up). screen. 2) Check the format of the disc. 3) Check whether the disc is dirty or damaged. -
Page 19: Specifications
SPECIFICATIONS SYSTEM Power supply AC 100-240V~50/60Hz Channel separation 40dB AMPLIFIER Output power......................50W FL/FR......................25W/4Ω Frequency response ..............20Hz~20KHz+/-3dB S/N......................... >80dB...
