- Page 1 SETUP INSTRUCTIONS 2016 RC 125 RC 200 Art. no. 3213460en...
- Page 3 KTM accepts no liability for delivery options, devi- ations from illustrations and descriptions, misprints, and other errors.
-
Page 4: Means Of Representation
MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips. - Page 5 SETUP Unpacking and setting up the vehicle – Remove the straps and box. S00827-01 – Remove the adhesive tape in the upper area of the motorcycle. S00828-01 – Roll down the film at the sides. Info To avoid damaging the motorcycle during the setup, leave the protective film on the vehicle until you have finished.
- Page 6 Install the battery. ( p. 8) – Refuel. ( p. 9) – Prepare the vehicle according to the specifications in the KTM Dealer.net for han- dover to the customer. – Set kilometers or miles. ( p. 10) – Set the clock. (...
- Page 7 WORK Removing the front rider's seat – Insert the ignition key in seat lock and turn it clockwise. – Raise the rear of the front rider's seat, pull it toward the rear, and remove it upward. – Remove the ignition key from the seat lock. L02118-10 Mounting the front rider's seat –...
- Page 8 WORK – Check that the passenger seat is correctly mounted. Finishing work – Mount the front rider's seat. ( p. 5) Removing the battery cover Preparatory work – Remove the front rider's seat. ( p. 5) Main work – Pull loop toward the rear.
-
Page 9: Recharging The Battery
WORK Main work – Pull back negative terminal cover – Disconnect negative cable from the battery. L02156-10 – Pull back positive terminal cover – Disconnect positive cable from the battery. – Detach rubber band – Pull the battery up and out of the battery holder. - Page 10 WORK Main work – Connect the battery charger to the battery. Set the battery charger. Alternative 1 Battery charger XCharge-professional EU (00029095050) Alternative 2 Battery charger XCharge-professional US (00029095051) Alternative 3 Battery charger XCharge-professional GB (00029095052) 311910-10 Alternative 4 Battery charger XCharge-professional CH (00029095053) Info Follow the instructions of the charger and the manual.
- Page 11 WORK 3.10 Opening the filler cap Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled. – Do not refuel the vehicle in the vicinity of open flames or lit cigarettes. –...
- Page 12 WORK Warning Danger of poisoning Fuel is poisonous and a health hazard. – Avoid skin, eye and clothing contact with fuel. – Immediately consult a doctor if you swallow fuel. – Do not inhale fuel vapors. – In case of skin contact, rinse the affected area with plenty of water. –...
- Page 13 WORK – Press the MODE button briefly and repeatedly until ODO appears on the display. – Press the MODE button for 5 - 10 seconds. The display changes from km/h to mph or from mph to km/h. 401303-01...
-
Page 14: Technical Data
TECHNICAL DATA Chassis tightening torques – Exhaust clamp 19 Nm (14 lbf ft) – Screw, chain guard EJOT PT ® K60x30 4 Nm (3 lbf ft) – Remaining nuts, chassis 3 Nm (2.2 lbf ft) – Remaining screws, chassis 4 Nm (3 lbf ft) –... - Page 15 TECHNICAL DATA – Screw, front mask structure on head- 6 Nm (4.4 lbf ft) light bracket – Screw, front seat fixing 6 Nm (4.4 lbf ft) – Screw, front spoiler 7 Nm (5.2 lbf ft) – Screw, front spoiler retaining bracket, 6 Nm (4.4 lbf ft) rear –...
- Page 16 TECHNICAL DATA – Fitting, shock absorber, bottom M10x1.25 50 Nm (36.9 lbf ft) Nut, rear sprocket screw M10x1.25 27 Nm (19.9 lbf ft) Loctite ® 243™ – Screw, front footrest bracket / engine M10x1.25 47 Nm (34.7 lbf ft) bearer Screw, side stand bracket M10x1.25 33 Nm (24.3 lbf ft)
- Page 17 SUBSTANCES Gasohol 95 E20 (RON 95) Standard/classification – Gasohol 95 E20 (RON 95) Guideline – Only use super unleaded fuel that matches or is equivalent to the specifications. – Super unleaded fuel with an ethanol content of 19 to 20% is permissible. Info Do not use fuel made of methanol (e.
