Tripp Lite APS/PV Owner's Manual

1111 W. 35th Street
Chicago, IL 60609 USA
Customer Support: (773) 869-1234
www.tripplite.com
The APS/PV Remote allows you to monitor and control at a distance many of the
functions of a Tripp Lite PowerVerter Plus or PowerVerter APS model featuring a
RJ11 Remote Port.
Installation
Label
For Use with a PowerVerter APS: Affix the label marked "APS Remote" to the
front of the Remote so that the holes in the label align with the Remote's LEDs
and switch.
For Use with a PowerVerter Plus: Affix the label marked "PV Remote" to the
front of the Remote so that the holes in the label align with the Remote's LEDs
and switch.
Cable: Insert one end of the 50' Remote Cable into the Remote Port on the front of
your PowerVerter. Insert the other end into the RJ11 port on the bottom of the
Remote.
Mounting: Using two to four screws appropriate to your mounting surface*, attach
the Remote securely so that the LEDs can be clearly seen.
* Screws must be provided by the user.
Operation
PV Remote
1
1. BATTERY LOW/MED/HIGH LEDs (Both Remotes)
These three lights show the approximate charge of your connected batteries.
LEDs Illuminated
Green
Green & yellow
Yellow
Yellow & red
Red
All three lights off
Flashing red
All three lights flash slowly
All three lights flash quickly
Copyright © 2000 Tripp Lite. All rights reserved. PowerVerter
2 3
Owner's Manual
APS/PV Remote
for PowerVerter APS and
PowerVerter Plus Models
ESPAÑOL: p. 3
APS Remote
1
Approximate Charge
96% - Full
81% - 95%
61% - 80%
41% - 60%
21% - 40%
1% - 20%
0% (Inverter shutdown)
Excessive discharge
Overcharge or charger fault
® is a registered trademark of Tripp Lite
4 5 6 7
1
