Summary of Contents for Hyundai HSEC40V-4A
- Page 2 Fig. 1 Fig. 2...
- Page 3 Fig. 3 Fig. 4 Fig. 5...
- Page 4 Fig. 6 Fig. 7...
- Page 5 Safety WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The appliance is only to be used with the power supply unit provided with the appliance. IMPORTANT READ CAREFULLY BEFORE USE.
- Page 6 Safety g) If the machine should start making any unusual noise or vibration, immediately shut off the power source and allow the machine to stop. Remove the battery pack from the machine and take the following steps before restarting and operating the machine: i) inspect for damage;...
-
Page 7: Safety Warnings For Battery Pack
Safety Safety Warnings for battery pack a) Do not dismantle, open or shred cells or battery pack. b) Do not short-circuit a battery pack. Do not store battery packs haphazardly in a box or drawer where they may short-circuit each other or be short-circuited by conductive materials. - Page 8 Safety Ensure that the connection between the battery charger and battery is correctly positioned and is not obstructed by foreign bodies. Keep battery charger’s slots are free of foreign objects and protect against dirt and humidity. Store in a dry and frost-free place. When charging batteries, ensure that the battery charger is in a well -ventilated area and away from inflammable materials.
-
Page 9: Assembly And Operation
Assembly and operation ASSEMBLING THE BLOWER TUBE DESCRIPTION See Figure 2. 1. Trigger ■ Slide blower tube over the blower housing outlet until 2. Turbo button the tube latch locks into place through the opening in the 3. Lock button blower tube. -
Page 10: Operation
Operation WARNING STARTING /STOPPING THE BLOWER See Figure 4 and Figure 5 Do not at any time let brake fluids, gasoline, petroleum based ■ To start the blower, Press the lock button products, penetrating oils, etc. come in contact with plastic parts. - Page 11 Symbol SYMBOL Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. Safety alert Please read the instructions carefully before starting the machine.
-
Page 12: Product Specifications
PRODUCT SPECIFICATIONS Cordless Blower Motor 36 V (40V max) Air Velocity 216 km/h A-weighted sound pressure level 87.0 dB(A) A-weighted sound power level 100 dB(A) Uncertainty KPA =3.0 dB(A) Vibration emission value <2.5 m/s² Uncertainty K = 1.5 m/s² Air Volume 13 m /min Weight... - Page 13 Brushcutter Lpa: 76,7 dB(A) sound power level Lawn trimmer Lwa: 93,7 dB(A) Brushcutter Lwa: 90,9 dB(A) Guarantee sound power level Lwa: 96 dB(A) Hyundai battery model (HBAT40V4-A) is same with the factory model (TPBT3640). Philippe MARIE / PDG Cugnaux, 24-04-2018...
