otherwise your ADSL2+ ROUTER may be damaged.
RESET(reset default): First press the reset button of ROUTER, then turn on the
ROUTER's power for at least three seconds. It will resume the default
manufacturer's setup.
LAN: Connect with your computer's NIC.
USB: Connect with your computer's USB interface
LINE(WAN): Connect to the MODEM Port of Splitter or Connecting the telephone
line.
2.4 Hardware installation procedures（figure2-1）
The procedure to install the Router can be described in general terms in the
following steps:
First Step: Connecting the MODEM port of Splitter with the LINE port of the TD-8811
ADSL2+ ROUTER by telephone line. While you need to use a telephone, please attach
telephone line into the phone of Splitter.
Second Step: Connect category 5 cable with RJ45 jacks to ADSL2+ ROUTER's LAN
port and your computer's NIC. Or connect USB cable to ADSL2+ ROUTER's USB port
and your computer's USB interface
Third Step: Plug one end of the AC Power Adapter into the Power jack on the Ethernet
ADSL2+ ROUTER and the other end to a standard electrical outlet.
Last Step: Check the line connection to see if everything is ready. Power up finally.
TD-8811 External ADSL2+ Router User Guide
Figure2-1
