3M PELTOR WS LiteCom Pro III Series Manual page 8

GB
Your headset comes pre-programmed with a specific
configuration. Please contact your certified two-way radio
dealer or 3M Technical Service for any questions regarding
the headset configuration, including:
• Radio frequencies/channels
• Voice guide language
• Menu configuration
• Power management settings
• Two-way radio transmission settings
4.2 Charging/Replacing the batteries
WARNING: For intrinsically safe models, only use the
3M PELTOR Battery ACK082, 3M
™ ™
Cable AL2AH, and 3M PELTOR
™
(or equivalent SELV 5V power supply).
For non intrinsically safe, use only 3M
charged with cable 3M PELTOR
TM
3M PELTOR FR08.
TM TM
WARNING: The battery may not be charged if the ambient
temperature exceeds 45 C or 113
°
Never change or charge the ACK082 battery in a
potentially explosive atmosphere.
The battery can be charged in a powered off Headset, or
separately.
Insert the rechargeable battery in the battery compartment.
Push down the latch.
The headset will automatically power off 2 hours (default
value) after the last button press or VOX activation.
4.3 Power On/Off
Press and hold the On/Off/Mode button for two seconds until
a voice message is heard to power the headset on or off.
4.4 Adjusting the volume level
Use the [+] and [–] buttons to adjust the volume. By default,
the [+] and [–] buttons will control the volume of the active
sound source, which could be any one of the following:
Two-way radio, Bluetooth communication, or Surround
®
sound. When receiving a two-way radio signal, the [+] and [–]
PELTOR™ Charging
™
Power Supply FR08
™
PELTOR ACK081
TM TM
AL2AI connected to a
TM
F.
°
buttons will control the two-way radio volume. If connected
to a Bluetooth device, [+] and [–] buttons will control the
®
Bluetooth audio playback. Otherwise, the [+] and [–] buttons
®
will control surround volume level. The respective volume
levels can also be adjusted in the Menu.
4.5 Menu
To enter the menu, make a short press on the On/Off/Mode
button. Use the on/off/mode button to navigate through the
menu and the [+] and [–] buttons to adjust the respective
setting.
These are the options available in the menu:
• Channel
Lists all the programmed channels in the headset, up to 70.
• Radio volume
Adjusts the volume level of the incoming radio sound.
(OFF, 1 – 5)
• Surround volume
The surround, or level-dependent, feature uses external
microphones to sense the surrounding environmental noise
level. At noise levels above 82 dB, the level-dependent
technology will limit environmental sound reproduction within
the headset to a maximum of 82 dB. (OFF, 1 – 5)
• Bluetooth radio volume
®
Adjusts the volume level of a Bluetooth
munication radio, 1 – 5.
• Bluetooth pairing
®
Press plus button to set the headset in pairing mode. Press
down button to exit pairing mode.
• Battery status
Battery status is measured and the result is played to the
user. Press plus button to repeat the information.
• Language
Adjusts the ghost voice language between all installed
languages.
• Sub channel/ Color code (if activated)
Sets the subchannel of an analog channel according to lists
(F) and (G) if it is enabled, 0 – 121. Sets the color code of an
digital channel, 0 – 15.
• Output power (if activated)
The Power feature controls the power level of the radio trans-
mitter. There are three output power levels; low, medium, and
high. The low setting will reduce the communication range
but will increase the battery life.
• Reset
Press plus button for 2 seconds to reset the headset to its
default state.
SMART TIP: When browsing long lists such as channel and
sub channel, press and hold either the [+] or [–] button to skip
ten items at the time.
SMART TIP: The headset will automatically exit the menu
after 10 seconds. Or, simultaneously press and hold the [+]
and [–] buttons for two seconds. A beep will confirm the menu
has been exited.
connected com-
®
